go-e Gemini flex Installation guide

go-e Charger
Gemini ex
11/22 kW
Installation
and operating guide
V 1.0

22
Content

33
Symbols
page 4
Sustainable charging
page 4
Before installation and commissioning/download
page 6
Safety regulations/notes
page 6
Product overview
page 10
Scope of delivery
page 11
Technical data
page 12
Installation
page 15
Commissioning/charging
page 18
LED status display/troubleshooting
page 20
Reset card/RFID chip
page 24
App
page 26
Warranty and exclusion
page 31
CE Declaration of Conformity
page 32
Contact and support
page 33
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

44
Thank you for your purchase decision
Warning of a hazardous situa-
tion that may result in damage
to health, fatal injuries or da-
mage to property if the safety
regulations are not followed.
The activity may only be car-
ried out by a qualied electri-
cian.
Hint for a more ecological or
economical use of the product.
Note regarding the adaptation
of the product or product func-
tions to individual needs.
1. Important symbols
2. Sustainable charging
With the go-e Charger Gemini ex
you have chosen an extremely com-
pact and versatile charging station
for EVs. Smart and intelligent solu-
tions that make charging electric ve-
hicles even more convenient are al-
ready integrated in the go-e Charger
Gemini ex.
The charging unit was developed
with the objective of extreme exi-
bility and, in addition to the advan-
tages of a conventional wallbox, of-
fers you the possibility of charging
anywhere where there is alternating
and three-phase current, provided
that you have the appropriate so-
cket adapter.
The go-e Charger was developed
and tested by electric car drivers for
electric car drivers. To ensure that it
remains up-to-date in the future, we
are constantly developing the rm-
ware and adapting the app to the
state of the art. So let us surprise
you with future functions.

55
Drivers of electric vehicles are
very consciously opting for this
type of mobility. Electric drives
are quiet and do not emit any
environmentally harmful gases. But
electric vehicles also need energy, which
has to be generated. If we use the availa-
ble energy carefully, we will not need to
expand fossil fuel power plants or nucle-
ar power plants for electric mobility.
An important contribution we can all
make is to use surplus energy. So if pos-
sible, do not charge your car when you
come home after work, as this is the
time when the electricity grid is at its
peak anyway. In order to save energy
and thus also to charge in an environ-
mentally conscious way, you should, if
possible, postpone your charging with
the go-e Charger „Scheduler“ function to
the midday or the early morning hours,
as there is a surplus of electricity in the
grids at this time.
An even more interesting option could
be an electricity supply contract with
our partner aWATTar (currently only
available in Germany and Austria), whe-
re you can benet from the highly uc-
tuating electricity prices at the electricity
price exchange by purchasing electri-
city when it is cheapest. The technolo-
gy for this is already built into each of
our charging boxes. For more informa-
tion, please visit our page at aWATTar:
www.awattar.com/services/goe
We wish you lots of fun with your go-e
Charger and enough electricity at all
times.
Your go-e team
Sustainable charging

66
Observe all safety regulations and inst-
ructions in this manual!
Read the manual and the data sheet ca-
refully and keep them for future referen-
ce. The documents are intended to help
you:
Note before installation and commissioning
Download the data sheet:
www.go-e.com
Instructions and downloads
•To use the product safely and properly
•Increase the durability and reliability
•To avoid damage to the device or pro
perty
•To prevent a threat to life and limb
Depending on the country, the require-
ments of the authorities and electricity
grid operators have to be observed,
such as a registration or approval requi-
rement for charging stations, or the limi-
tation of single-phase charging.
Registration information
Please contact your electricity grid ope-
rator to nd out whether the go-e Char-
ger is subject to registration or approval
and whether other restrictions must be
observed.
4. Safety regulations/notes
3. Before installation and commissioning
The go-e Charger may only be used for
charging battery electric vehicles (BEV)
and plug-in hybrids (PHEV) with the ad-
apters and cables intended for this pur-
pose.
Disregarding the safety regulations can
have serious consequences. go-e GmbH
declines any liability for damage caused
by disregarding the operating instruc-
tions, safety regulations or warnings on
the unit.
General safety regulations

77
4. Safety regulations/notes
Any information regarding electrical in-
stallation is intended exclusively for a
qualied electrician whose training all-
ows all electrical work to be carried out
in accordance with the applicable natio-
nal regulations.
Before carrying out electrical connec-
tion work, you need to de-energise the
circuit.
Installation must be carried out in accor-
dance with local, regional and national
regulations.
Observe the permissible ambient condi-
tions from the data sheet.
A location without direct sunlight is re-
commended.
The Charger is only suitable for charging
gassing vehicle traction batteries in well-
ventilated rooms.
The unit must not be operated indoors
if there is an increased danger from am-
monia gases.
The Charger should not be operated in
the immediate vicinity of ammable or
explosive substances, running water or
heat-emitting equipment.
Electrical protective measures, installation, operation
High voltage - danger to life! Never use
the go-e Charger if the housing is dama-
ged or open.
In case of unusual heat development, do
not touch the go-e Charger, the charging
cable or adapter and stop the charging
process as soon as possible. If the plastic
is discoloured or deformed, contact cus-
tomer support.
Never cover the go-e Charger during
charging. Heat build-up can lead to re.
Persons wearing electronic implants
should keep at least 60 cm away from
the go-e Charger due to electromagnetic
elds.
Due to legal regulations the Gemini ex
Charger must not be used in the follo-
wing countries: Norway.
The go-e Charger Gemini ex has
the communication interfaces WiFi
802.11b/g/n 2.4GHz and RFID. WiFi is
operated on a frequency of 2.4Ghz,
channels 1-13 with the frequency band
2412-2472Mhz. The maximum transmis-
sion power of the WiFi is 20dBm. RFID
is operated on a frequency of 13.56MHz
with a maximum radiated power of
60dBμA/m at 10m.

88
Connection, plug,
adapter
The go-e Charger Gemini ex 11 kW may
only be operated at the following con-
nections:
CEE red 16 A, 3-phase, 400 V or with
original go-e Charger adapter for Gemi-
ni ex 11 kW at:
•CEE red 32 A, 3-phase, 400 V (limi-
ted by Charger to 16 A, 3-phase)
•CEE blue 16 A, 1-phase, 230 V
•domestic plugs 16 A, 1-phase, 230 V
The go-e Charger Gemini ex 22 kW may
only be operated at the following con-
nections:
CEE red 32 A, 3-phase, 400 V or with
original go-e Charger adapter for Ge-
mini ex 22 kW at:
•CEE red 16 A, 3-phase, 400 V
•CEE blue 16 A, 1-phase, 230 V
•domestic plugs 16 A, 1-phase, 230 V
Always use original go-e adapters. With
the go-e Charger Gemini ex 22 kW,
automatic reduction of the charging cur-
rent to 16 A by plugging in the adapter is
only possible in conjunction with original
go-e adapters.
Observe the maximum permissible char-
ging current of the connection at which
you are charging. If this is unknown,
charge with the lowest charging current.
Fire hazard! We recommend a maximum
charging current of 10 A for use with do-
mestic plugs, as very few domestic so-
ckets/electrical installations are suitable
for continuous operation with 16 A! Na-
tional regulations may prescribe lower
The go-e Charger has to be used hanging
vertically or must be mounted vertically
in the wall bracket on a at wall.
Make sure that the power connection
leading to the go-e Charger is properly
installed and undamaged.
The go-e Charger is equipped with a bu-
ilt-in RCD protection module with direct
current detection (20 mA AC and 6 mA
DC). Therefore, only a type A RCD must
be installed on the building side, unless
local regulations deviate from this. In-
dependently of this, a miniature circuit
breaker must be installed upstream of
each charger.
The go-e Charger may only be operated
at fully functional protective devices.
Connection cables must be suciently
dimensioned.
An electric shock can be fatal. Do not
reach into sockets and plug systems by
hand or with technical aids.
The go-e Charger has a safety function
called „ground check“, which prevents
charging in TT/TN power grids (com-
mon in most European countries) if the
power connection is not grounded. This
function is activated by default. It may
only be deactivated via the go-e Charger
app if you are sure that the power grid
does not have an earth connection (IT
grid, e.g. in many regions of Norway) so
that charging can also take place here.
The go-e Charger visualises a deactiva-
ted „ ground check“ by 4 red LEDs (3, 6,
9, 12 o‘clock).

99
Opening, conversions,
repair, maintenance
Registration/approval
obligation, legal information
Any modication or repair of the hard-
ware or software of a go-e Charger may
only be carried out by specialist person-
nel of go-e GmbH.
Before dismantling an allegedly defecti-
ve product, always contact go-e‘s tech-
nical customer support and wait for its
decision on the further procedure for
handling the service case.
Removing and damaging warning noti-
ces attached to the go-e Charger or ope-
ning the device will result in the loss of
any liability by go-e GmbH. The warranty
also expires in the event of any modica-
tion or opening of a go-e product.
The go-e Charger is maintenance-free.
Disposal
According to directive 2012/19/EU (WEEE
directive), electrical devices must not be
disposed of in household waste after the
end of use. Take the product in accor-
dance with national legal requirements
to a collection point specially set up for
waste electrical equipment. Also dispose
of the product packaging properly so
that it can be recycled.
Depending on the country, the require-
ments of the authorities and electricity
grid operators must be observed, such
as the obligation to register or obtain
approval for ev charging stations or the
limitation of single-phase charging. Con-
tact your grid operator/electricity provi-
der to nd out whether the go-e Charger
requires registration or approval (e.g. in
Germany) and whether other limitations
must be observed.
The copyright for these operating inst-
ructions is owned by go-e GmbH.
All texts and illustrations correspond to
the technical status at the time of writing.
go-e GmbH reserves the right to make
unannounced changes. The content of
the operating instructions does not jus-
tify any claims against the manufacturer.
Pictures are for illustration purposes and
may dier from the actual product.
charging currents. Therefore check the
country settings in the goe-e app before
using an adapter with domestic plug. If
a domestic socket overheats, reduce the
charging current.
Take care of a mechanical relief of the
domestic plug by supporting the weight
of the go-e Charger and the connected
charging cable!
Do not use go-e Charger if any cable
attached to or plugged into the unit is
damaged.
Never use wet or dirty plugs in connec-
tion with the go-e Charger.
Never pull plugs out of the connector by
the cable!
The device may be cleaned with a damp
cloth. Do not use cleaning agents or sol-
vents. Do not clean the device with a
high-pressure cleaner or under running
water.

1010
16/32 A CEE red plug
(Gemini flex 11/22 kW)
Connection to red CEE socket or original go-e adapter
RFID chip
Release of charging processes (can be activated via app)
Reset card
Required for using the app and for resetting the charger to
factory settings
Housing
Impact-resistant and UV-resistant high-performance plastic
RFID reader
Release of charging processes with RFID chips or cards
(can be activated via app)
Button
Change of charging strength (5 levels - adjustable via app)
LED ring
Display of charging strength (1 LED = 1 ampere) and char-
ging status
Rating plate
With serial number of the charger
Sealed screws
Opening leads to loss of guaranty/warranty
Type 2 socket
Connection for type 2 plug of the charging cable
(with weather protection)
Back
a
a
b
b
c
c
d
d
e
ef
f
g
g
h
h
i
j
i
j
5. Product overview

1111
Adapter cable for Gemini flex 11 kW:
• to CEE 32 A red
• to CEE 16 A blue (camping plug)
• to 16 A multiple domestic plugs
Adapter cable for Gemini flex 22 kW:
• to CEE 16 A red
• to CEE 16 A blue (camping plug)
• to 16 A multiple domestic plugs
11 or 22 kW charging box
with 16 A or 32 A CEE red plug
Wall bracket
•Type 2 cable (up to 22 kW) 2.5 m | 5 m | 7.5 m
• Type 2 cable holder
• Type 2 to Type 1 cable 7.4 kW 5 m
• RFID chips, pack of 10
• go-e Charger wall bracket
Optional accessories
6. Scope of delivery
Mounting material
5x Dowel 8 x 40 mm
4x Screws for wall bracket 4.5 x 50 mm
1x Screw for U-piece 4 x 50 mm
1x U-piece (optional anti-theft device)
4x 1x5x 1x
RFID chip
Reset card

1212
Product specications
Gemini ex 11 kW Gemini ex 22 kW
Dimensions Approx. 15.5 x 26 x 11 cm
Weight 1.63 kg 1.82 kg
Connection cable 30 cm + plug, 5 x 2.5 mm²
(type H07BQ-F)
30 cm + plug, 5 x 6 mm²
(type H07BQ-F)
Connection Single-phase or three-phase
Rated voltage 230 V / 240 V (single-phase) / 400 V / 415 V (three-phase)
Norminal frequency 50 Hz
Power grid types TT / TN / IT
Standby power 3.1 W (LEDs dark) to 5.2 W (LEDs bright)
RFID 13.56 MHz
WiFi 802.11b/g/n 2.4 GHz / frequency band 2412-2472 Mhz
Permissible ambient conditions
Gemini ex 11 kW Gemini ex 22 kW
Installation site Indoors and outdoors,
without direct sunlight
Operating temperature -25 °C to +40 °C
Storage temperature -40 °C to +85 °C
Average temperature in hours Maximum 35 °C
Altitude Maximum 2,000 m above sea level
Relative humidity Not more than 95 % (non-condensing)
Impact resistance IK08
Charging capacity
Gemini ex 11 kW Gemini ex 22 kW
Maximum charging power 11 kW
(16 A, 3-phase)
22 kW
(32 A, 3-phase)
Ampere and status display Readable via LED ring and app
By button and app
Adjusting charging power
Via charging current in steps of 1
ampere between
6 A and 16 A
Via charging current in steps of 1
ampere between
6 A and 32 A
7. Technical data

1313
Safety functions
Gemini ex 11 kW Gemini ex 22 kW
RCD protection module with DC
current detection 20 mA AC, 6 mA DC
Protection class I
Pollution degree II
Anti-theft device Charging cable locking device
RFID access control One learned RFID chip included
Input voltage Phase and voltage testing
Switching functions Testing of the switching functions
Ground check For TT, TN grids
(deactivatable ground check for IT grid - Norway mode)
Current sensor 3-phase
IP55 Protected against dirt and water,
suitable for permanent outdoor operation
go-e network operator API For authorised access by the electricity grid operator to the go-e Charger
for grid-serving power control
Modbus TCP e.g. for grid-serving power control by the electricity grid operator
Charging capacity
Gemini ex 11 kW Gemini ex 22 kW Remark
Single-phase
charging car¹
1.4 kW
to 3.7 kW
1.4 kW
to 7.4 kW
Country-specic limitations
need to be observed
Two-phase
charging car¹
2.8 kW
to 7.4 kW
2.8 kW
to 14.8 kWC
Two-phase connection of the charger is
not possible
Three-phase
charging car¹
4.2 kW
to 11 kW
4.2 kW
to 22 kW
go-e Charger switches through the pow-
er that is available at the connection
¹Charging power depending on the number of phases of the car‘s onboard charger
Connection to vehicle
Gemini ex 11 kW Gemini ex 22 kW
Type 2 socket (acc. to EN 62196-2) with mechanical locking device
(own type 2 cable required, available as accessory)
Vehicles with type 1 can be charged with adapter cable type 2 to type 1
(available as accessories)
7. Technical data

1414
Connection to infrastructure
Gemini ex 11 kW Gemini ex 22 kW
CEE red 16 A (3-phase) CEE red 32 A (3-phase)
With original go-e adapters (not included in the scope of delivery, available as accessories):
to CEE red 32 A
(three-phase - limitation by charging station to 16 A)
to CEE red 16 A
(three-phase)
to CEE blue 16 A (single-phase) to CEE blue 16 A (single-phase)
to multiple domestic plugs 16 A
(domestic socket - single-phase)
to multiple domestic plugs 16 A
(domestic socket - single-phase)
go-e Charger app and connectivity
Gemini 11 ex kW Gemini ex 22 kW
Local (WiFi hotspot) or worlwide* (WiFI) controlling and monitoring
Adjustment/check of the charge (voltage, current, power, energy)
Adjusting the current level in 1 ampere steps
Start/stop function and Scheduler
Management of RFID chips/cards (up to 10 users per charger) / Access control (RFID/App)
OCPP 1.6*
Electricity meter (total kWh and total amount per RFID chip)
kWh limit mode / ECO mode* / Planned charge mode*
Push notications*
Cable unlock functions
Flexible energy tarifs with intelligent charging management*/**
Static load balancing*
Photovoltaic connection via open API interface (programming required)*
LED adjustment
Management of the charging levels via button on the charging station
Updateable for later functions (Smart home, etc.)*
Automatic unlocking of the charging cable in the event of a power failure
1-/3-phase switching via app - even during the charging process
Synchronisation of charging processes with the cloud and display of the past charging processes*
Documented public API interfaces: HTTP , MQTT, Modbus TCP
*WiFi connection of the charger required
**Separate electricity supply contract with partner aWATTar required, currently only available in Austria and Germany
7. Technical data

1515
8. Installation
1. Mount the go-e Charger approx. 1.00 to 1.45
meters above the ground, depending on your
personal feeling of well-being. When determin-
ing the optimum installation position, ensure
that there is a proper distance to the three-pha-
se socket so that the CEE plug of the charging
station can be plugged in easily. The go-e Char-
ger has to be mounted exactly below the CEE
socket so that little pressure is exerted on the
supply line.
Place the wall bracket in the desired mounting
position. Use a spirit level to align it straight.
Mark the four drill holes with a pencil by using
the wall bracket as a template.
Required tools
4X
1 M - 1.45 M
b
b
i
i
j
j
k
k
l
l
m
m
bPencil Spirit level Measuring tape Drilling machine
Screwdriver Hammer
Dowel 8 x 40 mm Screws for wall bracket 4.5 x 50 mm
Screw for U-piece 4 x 50 mm
U-piece (optional anti-theft device) Wall bracket
Enclosed mounting material
e
5x4x1x
a
a
c
c
d
d
e
e
f
f

1616
8. Installation
4. Hook the go-e Charger into the wall bracket.
Optional: If required, attach the supplied U-pie-
ce directly above the charger, making it impossi-
ble to remove the device from the wall bracket.
In addition, a padlock (not included in the scope
of delivery) can be attached.
2. Drill holes at the four marked positions.
4x
3. Attach the wall bracket with four screws and do-
wels each. Drive the dowels into the wall with a
hammer.
Make sure that the surface is not warped. The
device may not be attached if the wall bracket is
distorted. Compensate possible unevenness of
the wall with spacers (not included in the scope
of delivery).
4X

1717
8. Installation
5. The go-e Charger is equipped with an integra-
ted RCD protection module with direct current
detection (20 mA AC, 6 mA DC).
Only a type A RCD is required on the building
side, unless local regulations deviate from this.
In addition, a miniature circuit breaker must be
installed upstream.
Miniature circuit breakers with characteristic B
or C for 16 or 32 amperes are permissible:
•3- or 4-pole for three-phase connection
•2-pole for single-phase connection
6. When installing multiple units, activate static
load balancing via the go-e Charger app (WiFi
required).

1818
9. Commissioning/charging
3.
2.
Ready to charge
The go-e Charger is ready for operation. The
number of blue LEDs corresponds to the set
charging current.
Five predened charging levels can be selected
via the button.
1 LED = 1 A
Gemini ex 11 kW = 6 A - 16 A
Gemini ex 22 kW = 6 A - 32 A
1.
Start of the charger
The go-e Charger performs a self-test during
initial start-up or after a restart, during which
the LEDs light up in rainbow colours.
Plugging in the charger
Connect the go-e Charger Gemini ex directly to
a red CEE socket or to a suitable socket using an
original go-e adap ter.
Gemini ex 11 kW = 16 A
Gemini ex 22 kW = 32 A

1919
Starting the charging process
Connect the go-e Charger and the vehicle by
using a type 2 charging cable (or if the car has
a type one socket by using a type 2 to type 1
adapter cable). Make sure that the type 2 plug is
inserted as far as possible into the type 2 socket
of the charger.
The Charger is ready for charging and is waiting
for the car to release it. The LEDs light up yellow
in the number of the preset charging current.
9. Commissioning/charging
Charging
After the car has enabled charging, the LEDs rot-
ate clockwise around the type 2 socket during
the charging process.
The number of „tails“ corresponds to the num-
ber of connected phases or the number of pha-
ses set in the app:
•1 rotating tail = 1-phase charging (230 V)
•3 rotating tails = 3-phase charging (400 V)
The speed of rotation and length of the tails in-
dicate the amount of charging current.
You can adjust the charging levels individually in
the go-e Charger app („Current levels“). It does
not matter whether the go-e Charger is connec-
ted single-phase or three-phase.
4.
5.

2020
6. Stop charging
The charging process is completed when the
LEDs light up green.
If you want to stop charging prematurely, use
the „cable release“ function of your vehicle or
the large round button of the go-e Charger app
(tab „Charging“).
The cable remains locked in the type 2 socket in
the standard setting after the charging process
has ended (adjustable via the app) until it is re-
moved from the vehicle (theft protection).
If the power supply is interrupted, the char-
ging cable remains locked in the charging box
for reasons of theft protection. To unlock it, it
is necessary to re-energise the charging station.
The cable can also be unlocked automatically
after a power failure, provided the function has
been activated in advance via the „Cable unlock“
setting in the app. However, it is then no longer
theft-protected in the event of a power failure.
The go-e Charger displays the charging status
via dierent colours and positions of the LEDs.
In addition, it executes a whole series of safe-
ty queries to check the used power source for
possible errors. For this reason, the go-e Char-
ger may display an error and refuse to charge,
especially with unknown power sources.
The device visualises the cause of the error by
certain colours and positions of the LEDs. You
can also nd the error message within the „Sta-
tus“ information of the app. (The following co-
lour codes correspond to the factory setting).
9. Commissioning/charging
10. LED status display/troubleshootingoting
