alfen Twin 4XL Instruction Manual

Twin 4XL
–
Installation / User Manual

8
EXTERIOR VIEW (ART. NO. 934452-502 / -505 / -550)
1
2
3
5
4
5
5
7
8
9

9
INTERIOR VIEW (ART. NO. 934452-502 / -505 / -550)
3
4
5
2a
1
1
3
2a
a
1385 mm
335 mm

10
EXTERIOR VIEW (ART. NO. 934452570) 1
2
3
5a
4
7
8
9
6
5a
6
REMARK
- The socket type E and socket shutter type 2 on the right side of the charging station cannot be used simultaneously.
- Switching between the sockets is not possible during the charging process.
- When both sockets are occupied at the beginning of a charging process, the socket shutter type 2 for EV charging will
always take priority over the socket type E.
6
5a

11
INTERIOR VIEW (ART. NO. 934452570)
3
5
2b
1
3
1
335 mm
1385 mm
4
2b

12 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH

ENGLISH
13
Step-by-step Twin 4XL
installation and commissioning
–
Thank you for purchasing this Alfen charging station
for electric vehicles!
We advise you to carefully read the contents of this manual, to ensure a safe and
proper installation and enable you to fully use all the advanced features of this
product. Please store this manual for future use.
Although this manual was compiled with the utmost care, we always continue to
further improve its contents and instructions. To download the most recent version
of this manual, please visit: https://knowledge.alfen.com/

14 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
DECLARATION OF CONFORMITY
Manufacturer:
Alfen ICU B.V.
Herugweg 28
1332 AP Almere
The Netherlands
declares that the Alfen Twin 4XL type charging stations to
which this declaration applies, complies with the provisions of
the following European directives:
1) Machinery directive 2014/35/EC
2) Low voltage directive 2014/35/EU
3) EMC directive 2014/30/EU
4) And the following harmonized standards:
IEC 61851-1 ed. 3 (2017) - Electric vehicle conductive
charging system -
General requirements, implemented at national level under:
•NL: NEN-EN-IEC 61851-1
•BE: NBN EN 61851-1
•UK: BS-EN 61851-1
All named products are labelled with the CE mark.
Almere, 28 April 2021
Dipl.-Ing. M. Roeleveld
TABLE OF CONTENTS
1. Safety and Usage Instructions 9
1.1 Purpose and intended audience 9
1.2 General safety 9
2. Product 10
2.1 The charging station 10
2.2 Status indications on the interface 11
2.3 Using the charging station 12
2.4 Technical specications Alfen Twin 4XL 13
2.4.1 Model overview 13
2.4.2 Specications for type E socket 13
2.4.3 Input / power supply 14
2.4.4 Output 14
2.4.5 Protection / integrated components 14
2.4.6 Charging and access 15
2.4.7 Operating conditions 15
2.4.8 Casing 16
2.5 Optional factory settings 16
2.6 Accessories 17
2.7 Scope of delivery 17
3. Assembly and connecting 18
3.1 Installing and connecting 18
3.2 Mounting and installation requirements 18
3.3 Mechanical installation 18
3.3.1 Preparing the charging station 19
3.3.2 Installing the charging station 19
3.4 Electrical installation 20
4. Commissioning the charging station 21
4.1 Safety instructions prior to usage 21
4.2 Commissioning 21
5. Connectivity 22
5.1 Backoce management systems 22
5.2 Establishing a connection 22
5.2.1 Wireless connection 22
5.2.2 UTP (Ethernet) connection 22
5.3 Registering your ICU EZ account 23
5.4 Registering your charging station within
your own backoce management system 23

15
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
1.1 Purpose and intended audience
The Alfen Twin 4XL charging station is exclusively intended
for charging electric vehicles, both in situations with a
separate grid connection (for instance at home with a
meter box), and in public situations (connected directly
to the grid with the Grid Connection Box). Follow these
instructions carefully to ensure proper usage of the
charging station.
The installation, commissioning and maintenance may
only be performed by a qualied technician (Alfen certied
partner).
This qualied technician must meet the following
requirements:
• Expertise of the relevant generic and specic rules
regarding safety and incident prevention;
• Awareness of the relevant regulations regarding
electricity;
• The ability to identify risks and avoid potential hazards;
• Awareness of these installation and operation
instructions.
This manual applies to the product Alfen Twin 4XL,
equipped with rmware version 3.2.2. (or higher).
1.2 General safety
DANGER!
The safety instructions are intended to ensure proper
practical usage. If you do not comply with these safety
regulations and instructions, you may expose yourself to
the risk of electric shock, re and/or severe injuries.
Using this product is expressly prohibited in the following
situations:
• In the vicinity of explosive or highly ammable
substances.
• If the product is located in or close to water.
• If the product or individual components are damaged.
• Usage by children or individuals not properly able to
assess the risks associated with using this product.
In the following cases, Alfen ICU B.V. shall not be liable
in any possible way for any kind of damages while all
warranties on the product and its accessories become void:
• Non-compliance with these installation and operation
instructions;
• Usage in ambient temperatures below -25 °C or above
40 °C;
• Improper use;
• Improper handling;
• Installation and/or usage by unqualied sta;
• Independently applied expansions or modications of
the product;
• Usage of replacement parts not manufactured or
approved by Alfen.
More extensive safety information is available in the
relevant sections of this document.
1. SAFETY AND USAGE INSTRUCTIONS

16 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.1 The charging station
The overview on page 2/3 and 4/5 shows the standard
product variants.
Legenda exterior view, page 2 and 4
1 Charging station identication number
2LED/RFID-interface
3RFID reader
4Quick start usage instructions
5Type 2 socket
5a Type 2 socket shutter
6Type E socket
7Door lever
8Cylinder for grid operator
9Cylinder for end customer
Legenda interior view, page 3 and 5)
1Fuses
2a Type A residual current device (RCD)
2b Type B residual current device (RCD)
3Power meter
4 Identication label
5Main switch
10
11
12
Figure 1 Controllerboard
10 UTP (Ethernet) Connection
11 P1 (Smart meter) Connection
12 SIM card holder (refer to g. 8 on page 22 for detailed
location)
13 Main switch 4-pole (refer to g. 2 for detailed
location)
14 Identication number of the charging station (refer to
description under paragraph ‘Identication label’)
14
13
Figure 2: main switch (13), identication label (14)
ACE0059312 24-11-2020NG920-52502
RATING:
400V.50Hz.64A.3F+N+PE -25 °C.. +40 °C
Class I
934452502TYPE:
Made in the Netherlands by
Warning: before providing access to electrical components,
all power supplies must be disconnected
IP54
IK10
Hefbrugweg 28
1332 AP Almere
Nederland
www.Alfen.com
1
4
5
2
Figure 3: Example of an identication label
Identication label
The identication label (see g. 3) species information
such as the model, production date and serial number. This
label is located on the inside of the charging station door.
Please have your serial number available when contacting
Alfen to enable quick support.
1Model name of the charging station consisting of the
platform name and the last ve digits of the article
number: (NG920)-(52570, 52502, 52505 or 52550)
2Serial number, unique number issued by Alfen for this
specic charging station
3Production date of the charging station
4Technical specications of the charging station, such as
the number of phases, maximum charging current and
voltage
5Article number of the charging station
2. PRODUCT
3

17
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.2 Status indications on the interface
The Alfen Twin 4XL uses an interface equipped with LEDs
to provide status indications of the charging station, and
inform the user about starting and stopping the charging
process.
1
2
3
5
6
8
4
1
5
6
7
2
3
Figure 4: Display of the Alfen Twin 4XL during a charging session
(charge point on the left in use)
Status and information interface;
The charging station informs the user about the actual
status of the charging station and provides the user
with feedback about completed actions. The following
information is available:
1Socket side indication
2Charge card accepted, cable connected
3Communicating with vehicle, or charging completed
4RFID-reader
5Charging session active
6Error
7User steps to start the charging process
8User steps to stop the charging process
Charge card
accepted, cable
connected
Communicating
with vehicle, or
charging completed
ErrorActive charging
transaction
2. PRODUCT

18 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
RFID – Charging station with user authorization
Start
Stop
1
1
2
2
3 4
3 4
2.3 Using the charging station
Plug & Charge – General authorization without charge card
Start 1
1
2
2
3
3
Stop
2. PRODUCT
REMARK
- The type E socket and type 2 shutter socket on the right side of the charging station cannot be used simultaneously.
- Switching between the sockets is not possible during the charging process.
- When both sockets are occupied at the beginning of a charging process, the type 2 shutter socket for EV charging will
always take priority over the type E socket.

19
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.4 Technical specications Alfen Twin 4XL
2.4.1 Model overview
Variants
Model name Art. no. OCPP chargePointModel
2 x type 2 socket shutter,
3-phase, max. input current 35A per phase,
type B RCD
934452570 NG920-52570
2 x type 2 socket, 3-phase, max. input current 64A
per phase, type A RCD, 6mA DC detection
934452502 NG920-52502
2 x type 2 socket, 3-phase, max. input current 64A
per phase, type A RCD, 6mA DC detection
934452505 NG920-52505
2 x type 2 socket shutter,
3-phase, max. input current 64A per phase,
type B RCD
934452550 NG920-52550
Packing unit (PU) 1 piece
2. PRODUCT
Number of outlets 1 type E socket available (right side)
Socket type Type E socket, conform IEC 60884-1, CEE7/5, NF C 61-314
Charging mode Mode 2
Nominal output voltage (+/- 10%) 230VAC, 1-phase
Nominal current Max. 16A
Nominal power Max. 3.6 kW, 1-phase
2.4.2 Specications for type E socket

20 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.4.3 Input / power supply
NOTICE!
Your installation must comply with the standards and regulations of the location (country) where it is located. The tables
below are advisory and based on proper practical functioning of the charging stations; provided that all prerequisites are met.
Printing errors expressly reserved.
2.4.5 Protection / integrated components
Sockets in accordance with IEC62196-2
Output voltage 400 V (3x230 V)
Max. charging current 64 A per phase
Energy meter MID-certied
Power switching relay Integrated, simultaneous activation
Residual current
protection
Optional: Residual Current Device (RCD): 100mA S (Selective), type B, 4P
Rating: 22kW charging: 80A
Overcurrent protection
Integrated in rmware, shutdown at:
105% after 1,200 seconds;
112% after 100 seconds;
120% after 5 seconds;
150% after 2 seconds
Short-circuit
protection
per outlet: fuses 3x 40A gG
Input: minimum advised
cable diameters
(based on assumed max.
50 m cable length)
11 kW charging, 16 A selected per phase: 5 x 4 mm2
22 kW charging, 32 A selected per phase: 5 x 6 mm2
Nominal input voltage • VL1-N: 230V (+/-10%)
• VL2-N: 230V (+/-10%)
• VL3-N: 230V (+/-10%)
• VL1-L2: 400V (+/-10%)
• VL1-L3: 400V (+/-10%)
• VL2-L3: 400V (+/-10%)
• VPE-N: ≈ 0V
Nominal frequency 50 Hz
Grounding TN system: PE cable
TT system: separately installed grounding electrode < 100 Ohm spreading resistance
IT system: connected to a shared reference (common earth) with other metal parts
Connection terminals Strain relief, clamping range for cable thicknesses (11 mm - 29 mm)
Cable grommets base plate range 13 mm - 34 mm
Range cable clamps: max. 16 mm2per wire
Main switch 4 pole, 80 A, 400 V
Cable clamps on main switch, range:
- 16 mm2 per wire: solid (VD) wire
- Max. 6 mm2 per wire: strandes (VDS) wire with ferrules
2.4.4 Output

21
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
The charging station is equipped with a 6mA detection
circuit per socket. The charging current is interrupted if a DC
leakage current of 6mA or more is detected. After 5
minutes, the charging current will be switched back on. If
the 6mA DC leakage current is detected again, the station
will interrupt the charging current again.
This protocol is repeated up to 3 times while the charging
transaction remains active, after which the transaction will
be permanently terminated. If the charging cable is
reconnected, the charging station will restart this cycle.
2.4.6 Charging and access
Controllers NG920
Vehicle
communication
Mode 3 in accordance with IEC 61851-1 ed. 3 (2017)
Status indication User interface equipped with LEDs
Card reader RFID (NFC) ISO/IEC 14443A/B, Mifare 13,56 MHz, DESFire
Internet / networking
possibilities
GPRS (2G),
LTE CAT M1 (4G)
Ethernet/ LAN
Communication
protocol
OCPP 1.5 (JSON)
OCPP 1.6 (JSON) 2nd edition, certied
OCPP 2.0 (JSON)
Back-end connection ICU Connect (optional) or other backoce management system (upon request)
Communication with
Smart Meter
DSMR 4.0 and higher via P1 port (RJ11) (934452502)
2.4.7 Operating conditions
Operating temperature -25°C to 40°C
Relative humidity 5 % to 95 %
Protection class I
Protection level
(casing)
IP54
IK protection IK10
Stand-by consumption Approx. 9 - 12W
NOTICE!
The mentioned operating temperature assumes the ambient temperature of a product delivered in the standard casing
color RAL7043. Direct exposure to sunlight may have an adverse eect on the temperature range.
The temperatures mentioned in the table apply to the
ambient temperature for the product, assuming the
standard casing color: RAL7043. Other (darker) colors may
have an adverse eect on the operating temperature of
the product. If the product is exposed to lower or higher
temperatures, continuous operation cannot be guaranteed.
In case of higher temperatures, the charging station will
automatically decrease the charging capacity to stabilize
the internal temperature. This prevents transactions from
being paused unexpectedly.
If the product is exposed to direct sunlight, it may occur
that the automatic temperature management is congured
below the maximum ambient temperature.
2. PRODUCT

22 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.4.8 Casing
Type Charging column
Mounting options Directly on solid underground or on optional metal or concrete base
Material (casing) Cold-rolled stainless steel 304
Color (casing) RAL 7043 (Trac Grey B)
Locking Lockable lever with space for two cylinder locks (not included)
Standard master key included for door operating
Dimensions (H x W x D)
Casing
Packaging
1,385 x 335 x 220 mm
1,400 x 350 x 300 mm
Weight
Casing
Packaging
Approx. 40 kg
Approx. 2.5 kg
2.5 Optional factory settings
Factory settings Options
Authorisation Plug & Charge
RFID *
Maximum available charging current
per socket
20 A
32 A *
Smart charging options O
Standard load balancing *
User availability if temporarily
oine
Accept all RFID cards
Only cards registered in the database
Not available
Behaviour if plug is disconnected on
vehicle side
Terminate transaction and release plug
Pause charging session until plug is reconnected
Backoce management system Stand alone
ICU Connect *
Various backoce management systems available upon request *
Communication via * Autodetect
GPRS
UTP/LAN
The settings marked with an asterisk *) may incur additional costs. The default settings are always mentioned rst,.
2. PRODUCT

23
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
2.7 Scope of delivery
The package of the charging station contains:
• Alfen Twin 4XL
• Installation manual
• Assembly accessories
• RFID charge cards (depending on the selected options)
Figure 5: Bottom assembly overview
1 1x Cable clamp k24u
2 1x Wiska cable gland M12x1.5
3 1x Connection nut 12 M12x1.5
4 1x Gasket cable entry
5 3x Grommet for ethernet cable
6 1x Grommet for ground cable
7 2x Grommet for Smart Charging Network
8 1x Bottom gasket plate
2. PRODUCT
1
2
3
4
7
5
8
6
Concrete base Art. 833829300-ICU
Dimensions (H x W x D) 570 x 350 x 220 mm
Weight 42 kg
Metal base Art. no. 803828601-ICU
Dimensions (H x W x D)) 598 x 204 x 300
Weight 7.8 kg
Packaging (H x W x D) 50 x 295 x 620
Additional RFID card Art. no. 203120010-ICU
2.6 Accessories

24 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
3.1 Installing and connecting
Carefully read these instructions prior to installing the
charging station. Alfen ICU B.V. is not liable for any
consequential damage caused by usage of this manual.
DANGER!
The electric system must be entirely disconnected from
every power source prior to performing installation or
maintenance work!
REMARK
The installation must be carried out by a qualied profes-
sional who has read this manual and works in compliance
with the IEC 60364 standard. Neglecting this may lead
to injuries or hazardous situations while working with
electricity.
REMARK
A charging station must always be installed in a dedicated
power circuit.
DANGER!
The charging station contains electric components that
may still contain electrical charge after being disconnec-
ted. Wait at least 10 seconds after disconnection before
commencing work.
DANGER!
Hazard of fatal injury if installed incorrectly! Non-compli-
ance with the installation and environmental requirements
may lead to hazardous situations while working with
electricity.
3.2 Mounting and installation requirements
Refer to the table in paragraph 2.4.2 for the safety
options and required cable thicknesses to create a proper
connection.
REMARK
Wear personal protective equipment at all times when wor-
king. Make sure to follow the national and local standards
and and regulations.
Ensure that the following requirements for installing the
Alfen Twin 4XL are met
•The cable trajectory from the main distributor to the
Alfen Twin 4XL must be protected against overcurrent
with:
- gG type fuses (or dierent pursuant to local standards
and regulations) or a type B or C MCB
•The cable trajectory and the charging station are part of
a TT/TN-S system; the charging station must be earthed
via the main distributor or earth electrode.
•Earthing the charging station is the responsibility of the
owner.
•For each location It must be determined whether the
earthing can be provided by the grid operator.
•The cable trajectory must be installed in compliance
with the usual locally applying professional standards.
REMARK
The conditions at the specic location may inuence the
installation requirements.
REMARK
The system and cables must be installed based on the
maximum charging current on the input(s) of the charging
station. This must assume a continuous load (max. simul-
taneity).
The cable diameters mentioned in this manual are indica-
tive. The technician remains responsible for determining
the correct cable diameter and compliance with the applica-
ble standards and regulations.
When selecting an installation location, make sure the
following requirements are met::
• Never install in a potentially explosive atmosphere;
• Never install in areas prone to ooding without imple-
menting compensating measures;
• Always fully comply with local technical requirements
and safety regulations;
• The installation site must have a levelled and solid
underground;
• Maximum atmospheric humidity of 95%;
• Ambient temperature of -25 °C to 40 °C;
• Temperature dierence within 24 hours <35 °C;
• Ensure that the charging station is located in such a way
that users can use their charging cable (approx. 5 me-
ters length) without tension being applied on the cable;
• Prevent road users from being able to drive over the cable;
• Prevents pedestrians from being able to trip over the
cable.
3.3 Mechanical installation
Use the following tools and materials to install the
Charging station:
• Spirit level
• Spade or excevator
• Utility knife
• Screwdriver for a terminal block
• Wire stripper
• Ratchet set/open-end wrenches
3. ASSEMBLY AND CONNECTING

25
Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
3.3.1 Preparing the charging station
1. Verify the content of the packaging based on the
required parts
a. On the door: The charging station is equipped with
a lock with a lever suitable for two locks (type euro
prole half-cylinder 17mm).
- Left lock is for: Owner of the charging station
- Right lock is for: Grid operator
b Remove the protection from the lock.
c The charging station may have one, two or no
cylinder lock(s);
d. Open the lock with the included key(s) or the
included master key if no cylinders were placed;
e. Lever can be pulled outward;
f. Rotate the lever counterclockwise to open the door
3.3.2 Installing the charging station
2. Foundation for mounting on the ground (with concrete
or metal base):
a. Excavate a hole of 50x50 cm with a 55cm depth
below the surface level and level the hole
horizontally.
b. Insert the concrete or metal base and level it.
c. Place the cable glands and cable grommets supplied
on the gasket plate, then place it into the bottom of
the charging station.
d. Apply an earth electrode or grounding pin
depending on the locally applicable standards and
regulations.
3. Inserting the mains cable and earth cable:
a. Guide the mains cable through the pipe sleeve,
concrete base and grommet in the gasket plate.
Refer to the specications for appropriate cable
diameters.
b. The excess length from the upper side of the
base must be at least 25cm. Due to the installation
of the strain relief, it is advised not to cut the cable
before the charging station is mounted on the base.
If the charging station is not equipped with a Grid
Connection Box (934452502), the system must be
directly connected to the main switch. This requires
a greater excess length of the supply cable. Measure
this distance before proceeding.
c. Guide the earth cable, originating at the earth
3. ASSEMBLY AND CONNECTING
4a
4b
3c
Figure 6: Concrete base and installation steps (3c, 4a, 4b)

26 Twin 4XL manual |Version 2.9 |July 2021
ENGLISH
electrode, through the base and the cable gland in
the gasket plate.
4. Mounting the charging station on the base
a. Insert the 4 threaded rods M10x10 mm into the
openings on the base.
b. Apply the gasket over the threaded rods and the
gasket plate.
c. Tilt the charging station, which has been readied
on its back, over the base, onto the base over the
threaded rods and over the supply cable and earth
cable.
d. Cut the cable grommet to t, so that it rmly grips
the supply cable and guide the supply cable through
the base plate, which is tted into the charging
station. Pull the supply cable to the exterior of
the charging station to install the strain relief (see
gure 5).
e. Guide the supply cable, after having installed the
strain relief, back into the charging station / concrete
base, so that the prescribed 25 cm cable length
remains in the charging station.
f. Attach the charging station with the supplied 4 M10
nuts including washers and v-rings.
g. Mount the charging unit with 4 x stud bolts
M10x10 mm onto the base.
Figure 7: Example of a strain relief
3.4 Electrical installation
WARNING
Read and comply with all safety instructions in this manual!
DANGER!
The electric system must be completely disconnected from
every power source prior to carrying our installation and
maintenance work. Always wait 10 seconds after discon-
necting from an energy source before proceeding.
3. ASSEMBLY AND CONNECTING
1. Remove the shield of the supply cable with a utility
knife and remove the sheath of the separate wires
with a wire stripper;
WARNING
Always connect an earth connector rst
2. The charging station must be properly earthed.
Connect the earth electrode rst. An earth busbar is
installed at the right bottom of the charging station to
which the earth electrode can be connected;
3. The grid operator’s earth sheath / earth wire may only
be regarded as an earting solution after having obtain-
ed written permission of the grid operator to do so;
4. Ensure that the earth spreading resistance is below
100 Ohm;
5. Ensure that the main switch is in the OFF (0)-position.
6. Remove the fuses;
7. Connect the phase wires to:
i. The MCBs or fuse holders in the grid connection box
of the charging station (if a grid connection box is
included in the delivery). PE on separate rail;
ii. The main switch of the charging
station (if a grid connection box is not delivered).
PE on separate rail;
8. A clamping bracket is required (see gure 5) for strain
relief;
9. Put the main switch and the residual current device
into the ON (1) position;
10. If a transparent cover cap was delivered for the internal
components, install it with the accompanying plastic
bolts;
11. Close the door and the lock and make sure it is properly
locked.
