BIKFUN AMA005795 User manual

Caution : Please read the manual before your first ride!
E-BIKE
USER‘S MANUAL

Safety Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
General Information . . . . . . . . . . . . . . . . . . . . . . . . . 3
Bike Useage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation And Adjustment . . . . . . . . . . . . . . . . 8
Meter Operation. . . . . . . . . . . . . . . . . . . . . . . . . 12
Battery And Charging: Further Information . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
TABLE OF
CONTENTS

1
Thank you for choosing our products.
To ensure your safety and health, we encourage you to read this manual thoroughly before
you assemble the bike and take the first ride.Safe and effective use can only be assured if the
equipment is assembled, maintained, and used properly. More importantly, this will offer
you a general understanding and get the most out of your bike.Please check your electric
bike before every ride, especially when traveling long distances.
This manual is intended as a general guide to your new e-bike. For technical support,
including repair information, please consult your dealer.
Safety Instruction
Things to know before use
Do not use the product before carefully reading the instructions from this manual and
understanding the performance of the item;
Don't lend this product to people who can't operate it, so as not to cause harm; if you
lend the bike, please let the user follow instructions, it could help to decrease the risk
of accident;
The E-bike cannot be used as off-road vehicles or used for extreme bicycle sports; when
riding the bicycle, please wear a safety helmet and protective gear. It is forbidden to
ride with one hand;
Please abide by the traffic rules and prohibit riding on motorized lanes and roads with
multiple pedestrians;
Carry people or objects in accordance with the requirements of laws and regulations,
and do not park in the building's lobby, evacuation stairs, walkways, and safe entrances
and exits;
It is recommended to charge and park in an outdoor dedicated parking hall, while
avoiding rain; when charging, keep away from combustibles, and the charging time
should not be too long;
For safety reasons, please do not change the default speed setting of the electric
bicycle and do not exceed speed limit in accordance with the traffic rule. Riding on
non-motorized lanes, downhills and paved roads not exceeding 15km/h;
When adjusting the handlebar or saddle, please be careful not to exceed the safety line
markings on the handlebar and saddle;
Please check the tire pressure before riding, the recommended tire pressure is 35-45PSI;
Please check the power circuit, lighting circuit, etc. before riding;
●
●
●
●
●
●
●
●
●
●

2
Safety Instruction
Before riding, please check whether the front and rear brakes work normally, check the
fastening status of the handlebars and front and rear wheels, and check whether the
reflector is damaged or contaminated;
When using the motor, please be careful not to hit vigorously and keep the rotating
shaft lubricated;
Try to avoid traveling in severe weather such as heavy rain;
Riding in rain or snow, the braking distance will be extended, pay attention to slow
down;
It is not allowed to exceed the maximum load of the vehicle body when riding (the
maximum load is 130 (KG);
It is suitable for people between 16 and 45 years old, and it is strictly forbidden to drive
electric bicycles on the road by people under 16 years old.
●
●
●
●
●
●

3
General Information
1. About BIKFUN Electric Bike
2. What’s In the Box (Parts List)
BIKFUN electric bike is a leading icon of e-bikes. For years, BIKFUN has been not only
dedicating to innovation, cutting-edge technology and premium materials, but also
providing cost effective e-bikes, to satisfy riders' various needs of transportation and even
desire of exploring sports & outdoors life. Just ride freely with BIKFUN !
Description Quantity
BIKFUN Electric Bike
User Manual
Key
1
1
2
Saddle Tube
Pedal
Throttle
Saddle
Tools Bag
Charging Adapter
Front & Rear Fender
Kickstand 1
2
1
1
1
1
1
1
1
Battery

4
General Information
3. Bike Components
1
2
3
4
6
81011 79 5
12 1413 15 16 17 18 19 20 2221
2
1
3
4
5
6
7
8
9
10
Tyre Rear Disc Brake Callipers
Front Fork Rear Derailleur
Rim Flywheel
Head Light/Front Light Chain
Stem Battery
Folder Carry Handle
Saddle Post/ Seat Tube
Pedal
Crank
Saddle
Front Disc Brake CalipersSeat Post Clamp/ Seat Clamp
Wheel Reflector
Disc
Rear Seat
Rear Reflector Lamp
12
11
13
14
15
16
17
19
18
20
21
22

5
General Information
4. Tool List
MODEL:AMA005795
5. Standover Height
For the sake of safety and comfortable riding, when the rider stands on the ground there
should be clearance of 78cm/31in from ground to the crotch of the rider. Also, at least
3-8cm/1-3in between the crotch and the top tube of the bike.
Standover height does not apply to bicycles with step-through frames. Instead, the limiting
dimension is determined by saddle height range. You should adjust your saddle position
without exceeding the limit line on the saddle tube.
Note

6
Bike Usage
Before Riding
During riding
After riding
Before riding the bike on the open road, try all the settings on the electric bike, and get
used to various results in a safe and controllable environment.
Please check the power circuit, lighting circuit, and test the brake system before cycling.
Always check the tire pressure before starting to ride, and make sure that the tire is inflated
to a pressure within the specified range.
In order to ensure the safety of riding, please check regularly for loose parts or screws.
The places that need to be checked include but not limited to the seat tube, wheels,
handlebars and pedals.
If necessary, please confirm whether the battery capacity can meet you riding demand.
If the pressure is too low, the wheel may be damaged, or the inner tube may be
squeezed, causing the tire to leak air.
If the pressure exceeds the recommended maximum value, the tire may blow
out of the rim, which may damage the bicycle and cause injury to the cyclist and
nearby people.
Please wear helmets and riding gear that meet the requirements in accordance with
regulations.
Avoid traveling in severe weather such as heavy rain.
Carry people or objects in accordance with the requirements of laws and regulations,
and the load of the entire bike should not exceed 130kg.
Obey the traffic rules.
After heavy use, do not touch the hot surface, such as the disc brake rotor or the side
edge of the brake rim.
When folding the kickstand, always make sure that the stand is secure and the base is
firm to prevent the bicycle from falling.
If the bicycle is splashed with moisture, please wipe it dry and clean in time.
●
●
●
●
●
●
●
●
●
●
●
●
1.
2.

7
Bike Usage
Shifting Recommendations
Brake Adjustment
In order to increase the range, we recommend shifting according to the speed.
For starting and low-speed riding, it is best to use a low-speed gear.
At higher speeds, a higher gear should be selected.
If the brake is not sensitive, loosen the
anchor bolt of the brake cable to shorten
the brake distance of the brake cable and
then tighten the bolt. Or, lengthen the
distance of the brake cable when the brake
is too sensitive.
If the rotor always rubs against the
brake pad or the gap is too large, loose
the two centering adjustment screws,
but do not remove them. Slowly rotate
the wheel and check the space between
the rotor and the brake pad; adjust the
position of the brake pad and the rotor.
Centering the rotor and the pads to
avoid friction. After the adjustment is
complete, tighten the screws.
Ensure that the brake cables are properly inserted into the brake levers before aligning a
mechanical disc brake. If the disc rotor is bent or damaged, replace the rotor first.
2.
1.
Leave the same clearance on
both sides of the disc rotor
Brake pad
Disc rotor
Adjust caliper to
center the rotor
Centering
adjustment screws

8
Installation And Adjustment
1. Install the handlebar
2. Assemble the saddle tube
1.1 Install the handlebar into the folding stem and unfold the folded stem and fasten
the buckle.
Adjust the height of the stem(Note: please be careful not to exceed the limit line.),
and then fasten the clamp.
Install the saddle tube into post receiver. Set right its position and adjust height to
fit your ridding habit. (Note: please be careful not to exceed the limit line) and then
tighten the seat with the clamp.
Open the package of the bike, take out the electric bike and all the accessories inside and
use the tool to cut off the packing rope.
2.1
1.2

9
Installation And Adjustment
3. Assemble the front fender and headlight
3.1
3.2
Loosen the screw on the corresponding position of the front wheel, as shown in
the figure below. Put the fender in this position.
Connect the front light, and after that, re-fix the loosened screw and tighten
it.Connect the front light and tighten screw.

10
4.1
Installation And Adjustment
4. Install the front wheel
4.2
Loosen the nut and safety washer in both sides of the hub and install the front wheel
to the hub on each side (Note: Make sure that the front wheel is in line with the rear
wheel). Then tighten the nut on each side.
Remove the protective washer from the hub of wheel (this accessory is to prevent
the brake from damage during delivery).
4.3
Using the tool to loosen the fixing rod of the front fork and remove it (this accessory
is to prevent the front fork from being deformed during delivery).

11
Installation And Adjustment
5. Install the pedals
6. Install the Battery
5.1
5.2 Ensure that the thread of each pedal is fully
inserted into the crank arm. Tighten the pedals
completely with a wrench. (Counterclockwise
screw the pedal marked "L" on the left side
crank. Clockwise screw the pedal marked "R" on
the right side crank.)
There are a right pedal marked "R" and a left
pedal marked "L". When installing, make sure
to identify the R/L letter on the pedal bolt.
So far, congratulations! You have completed the assembly of the entire bike.
Push the battery into the rack until it is tightly connected to the controller socket on the
rock behind the seat spot, then insert the key to lock the battery. (The battery is locked
and needs to be turned on when in use.. Please turn on the battery switch before you
turn on the meter.)

12
1. Meter Instruction
2. Meter Operation
3. Operation Cautions
Meter Operation
Avoid the risk of collision.
Don’t modify system parameters to avoid parameters disorder.
Contact the seller when error code appears.
Please refer to the separate meter manual.
●
●
●
TRI P
OD O
TIME
MA X
AVG
W
PAS
Mile Km
MOD
MPH
Km/h

13
Battery And Charging: Further Information
Please follow the instructions for use, otherwise the consequences are at his own risk.
Please use the original special charger. It is strictly prohibited to use other chargers.
Pay attention to the battery type and applicable voltage that the charger can charge, and
it is strictly forbidden to mix them. The charging time shall not exceed 12 hours, and the
charging current shall not exceed 2A.
When charging, it should be placed in a ventilated environment, and it is strictly
forbidden to charge in a confined space or in a hot environment.
WHEN CHARGING THE BATTERY
●
●
●
●
Battery: Further information
Charging: Safe operation guide
Keep the battery out of reach of children.
Charging at 0°C~40°C/ 32°F~104°F, and discharging at -5°C~40°C/ 23°F~104°F. Please do
not store the battery in temperatures above 35°C/ 95°F or below -5°C/ 23°F.
Keep the battery dry, do not put the battery in acidic or alkaline liquid, keep away from
rain, fire and high temperature environment.
It is strictly forbidden to connect the positive and negative poles of the battery reversely,
and it is strictly forbidden to damage, disassemble or short-circuit the battery.
Used batteries are hazardous chemicals, and the used batteries should not be
disassembled without authorization, and recycled by relevant professional departments.
It is forbidden to modify the battery, electronic control system and the frame structure of
the bike, etc. Otherwise, it may cause safety hazards and void the warranty service. If you
continue to do so, all will be at your own peril.
●
●
●
●
●
●
Charging port
❶
❷
❸
❹
Insert the charger probe into the charger port
on the e-bike battery. As shown in the figure.
Insert the pronged end of the battery cord
into the battery charger.
Insert the AC plug into an AC outlet.
The red indicator light turns on and will
remain red until it is fully charged. The
indicator light turns green once the battery is
fully charged.

14
Reminder
Battery and charging: Further Information
Battery must be recycled or disposed of in an environmentally sound manner.
Do not dispose of the battery in a fire. The battery may explode or leak.
Do not dispose of a battery in your regular household trash.
●
●
●
Battery Disposal
Charge a new battery 4-6 hours before you use it in your product for the first time.
If the battery is dropped or damaged due to a bicycle accident, there may be a danger of
electrolyte leakage. Please stop using it immediately.
It is better not to wait until the power is completely exhausted before charging, which
can more effectively extend the battery life. Besides, Overheating or undercharging the
battery may shorten battery life.
How far can a fully charged battery go? It depends on the load weight, road conditions
and battery capacity. But under the same conditions, the average speed can last longer
riding distances. Using pedal assist mode allows you to go further.
The charger should not be carried with the ebike as much as possible. If it is really
necessary to carry it, it should be placed in the toolbox after the shock absorption
treatment is done. It is not allowed to disassemble or replace the components in the
charger by yourself.
When not in use for a long time, keep the battery in a cool and dry place, and charge
the battery for two hours a month.
●
●
It is recommended to charge the battery in the fireproof battery charging
over when charging. And the battery should be stored in the fireproof battery
charging cover when not in use.

15
Maintenance
●
●
●
●
●
●
●
●
●
●
●
The front and rear wheels of the vehicle should be located in the center of the front
fork or frame.
After riding, please store the bike in a place without sunlight and rain.
Water showering is forbidden, and the surface of the car body can be wiped with a
semi-dry cloth.
Do not touch the charging hole on the bicycle, or touch it with metal, otherwise, it may
cause an accident due to an instantaneous short circuit of the current.
Check all cables and cable housings for fraying, breaks, rust, or corrosion and replace
if necessary.
Check the motor and brake frequently, and do not fill the brake area with oil.
Additionally, check the brake pads for any damage as they will be worn over time and
eventually need replacement.
Regularly check the various screws of the car and the places that need to be fastened,
and regularly reinforce to prevent injury and unnecessary wear and tear on your e-bike..
Recommended torque (unit: kgf.cm): the horizontal screw 60-80, the stem screw 175-
200, the seat cushion screw 175-250, the wheel screw 320-450.
Regularly check the tension of the chain, which can be adjusted by the chain regulator.
Always check the tire for scratches, cracks, or excessive wear. The inner tube and
the valve should be perpendicular to the wheel hub and not crooked. Accidentally
punctured, damaged or excessively worn inner and outer tires need to be replaced
immediately, please seek professional technicians to repair or replace your tires.
It is forbidden to modify key structural parts such as the frame, front fork, standpipe, and
electrical function parts. If damaged, use the original parts to replace it. Otherwise, the
guarantee service will not be provided. Any loss or damage caused by the modification
shall be solely responsible.

16
Warranty
One-Year Limited Hardware Warranty
Support Services
Your electric bike includes a One Year Limited Hardware Warranty. BIKFUN provides
warranty service for the electric bikes. If there is a hardware defect and a valid claim is
received during the warranty period, we will resend new parts within the scope permitted
by law.
The Warranty covers product defects in materials and workmanship under normal use.
This Warranty is limited to original purchasers and is not assignable or transferable.
The Warranty starts on the date of your purchase and lasts for one year (the "Warranty
Period") and the Warranty Period is not extended if the product is repaired or replaced.
The Warranty does not cover any damage due to: improper use; failure to follow the
product instructions or to perform any preventive maintenance; unauthorized repair;
external causes such as accidents, abuse, or other actions or events beyond our reasonable
control.
We provide lifetime customer support services. For any questions about the product,
please contact customer service from where you brought the equipment. We will be happy
to answer your questions.
You can also email us your inquiries at [email protected].

17
Attachment
Technical parameters
Performance index Project Parameter
Wheel Size
Vehicle Size
20*4.0 Inches
Frame Material Aluminium Alloy
Maximum Load 286 lbs
Vehicle Weight 65 lbs
Maximum Speed 20 mph (32km/h)
Maximum Gradient 25 Degrees
Rear Derailleur 7-Speed
Mileage Range 18~30 miles (29-48km)
Working Temperature 23°F-104°F (-5℃~40℃)
Rated Voltage 48V
Battery Capacity 12.5Ah
Service Life 1000 Times
Motor Power
Display
500W
LCD Display
Motor Type
Brake
Brushless Gear Motor
Mechanical disc brake
Maximum Torque
Suspension
Light
64N.M
Suspension front fork
Front light and rear Light
Input Voltage 100-240V
Input Current 1.8A
Output Voltage DC 54.6V
Output Current 2A
1560*580*1150mm
Basic Parameters
Performance
Parameters
Battery Parameters
Motor Parameters
Other Parameters
Charger Parameters

18
Attachment
Remarks:
The amount of battery remaining, load of the bike(weight of rider and cargo), tire
pressure, road environment, chain and wheel axle lubrication, etc. will affect the
maximum speed;
Riding habits, temperature, load, tire pressure, road environment and other factors will
affect the riding range.
●
●
