GLARE WHEEL GWEB-C1PRO User manual

Folding E-Scooter GWEB-C1PRO
Instruction Manual
ORIGINAL INSTRUCTION MANUAL
Item / IT number: 142309 Edition: 9/2020 Revision: Version 01

Table of contents
2
Technical specifications 2
Introduction 3
Key 3
Intended Use 4
Package contents 4
Important safety instructions 5
Preparation 8
Display functions 10
Using the battery 12
First use 15
Maintenance and care 17
Warranty 22
Information on disposal 25
Declaration / certificate of conformity 25
Notes 26
Technical specifications
Material
Aluminium
Maximum range
approx. 20 km*
Maximum speed
approx. 23 km/h*
Dead weight
17.4 kg
Maximum load
120 kg
Display
LCD
Wheel size
12" pneumatic tyres at the front and rear
Brakes
Disk brake at the front and rear
Product size
1270 x 480 x 970 mm
Product size folded
1270 x 330 x 660 mm
Charger
220-240 V / 50-60 Hz
Charging time
approx. 5 hours
Motor
300 Watt
Battery
36 V / 7.5 Ah lithium battery
Airborne noise emissions
58 dB
Vibration intensity
0.09-0.13 mm/s
Gradeability
5°
*Guide values, with a user weighing approx. 75 kg and with a fully charged battery on smooth,
even road surfaces and under optimal temperature conditions (see pages 12, 13 and 14)

Introduction
3
WARNING!
ATTENTION!
NOTE!
Thank you for purchasing the GWEB-C1PRO Folding E-Scooter!
Please read the instruction manual carefully before using the
Folding E-Scooter and ensure that it is used properly and in
accordance with the instructions.
Retain the instruction manual for future reference. Only give
the Folding E-Scooter to third parties in conjunction with the
instruction manual.
The manufacturer reserves the right to make changes to the
product.
The instruction manual and illustrations within it may differ
depending on the model.
We hope you enjoy using the GWEB-C1PRO Folding E-Scooter!
Explanation of symbols
Contains important information to avoid injuries.
Contains important information to prevent damage to the pro-
duct.
When reading the manual, it points out important
information and instructions.

4
E-Kl appsc oote r EKS GW EB -C1PR O (ST VO)
7,5 A h
DE
ORIGINALBEDIENUNGSANLEITUNG
Artikel/ ITNummer:142309Ausgabe:12/2019 Revision: Version01
Intended use
The GWEB-C1PRO Folding E-Scooter is a vehicle (fun vehicle)
designed for transporting one person.
The Folding E-Scooter is exclusively for private use
and is not suitable for commercial use.
Only use the Folding E-Scooter as described in this instruction
manual. Any other use is considered improper and may result in
material damage or even injury to people.
The manufacturer or distributor accepts no liability for damage
caused by unintended or improper use.
Package contents
Saddle and seat post*
Charger Allen key
Luggage rack with rear light*
Folding E-Scooter GWEB-C1PRO
User manual
*The saddle and luggage rack must be assembled before first use (page 8)

5
Important safety information
WARNING!
• Please strictly comply with the safety regulations stated
in the manual. The producer or distributor cannot be held
liable for any injury to persons, material damage, accidents
or legal disputes resulting from the violation of the safety
regulations. The liability is always limited to the purchase
value of the E-Scooter.
• Please check your Folding E-Scooter before every journey
(see the section on "Maintenance and Care" on page17).
• Do not use the Folding E-Scooter if there is visible damage
or a damaged power cord or plug.
• Modifying the Folding E-Scooter is prohibited.
• Repairs may only be carried out by qualified personnel aut-
horised by Glare Technology USA Inc. Liability and
warranty claims are excluded if repairs are carried out
independently or in the event of improper connections or
incorrect operation.
• Always wear a safety helmet, appropriate clothing, protective
gear and flat-heeled shoes.
• Hold the handlebar with both hands while riding.
• Practise riding the Folding E-Scooter on open and level terrain
initially.
• The Folding E-Scooter is not suitable for children under 12 years
of age.
• Please carefully read all the instructions in this instruction
manual. This should help to minimise potential risks. Please
note that even if you follow the instructions completely, there
will still be some remaining risk when using the Folding E-
Scooter. Always adjust your speed to the current situation to
minimise the risk of accidents and injuries.

6
WARNING!
Important safety information
• The Folding E-Scooter has been designed to transport one
person with a maximum weight of 120 kg.
• The Folding E-Scooter is suitable for use on flat, dry surfa-
ces. Do not ride through water, in rainy conditions, at night or
when visibility conditions are poor.
• The Folding E-Scooter is not suitable for stunts –
DO NOT ATTEMP to jump or perform any dangerous mano-
euvres.
• Do not leave the Folding E-Scooter outdoors. Please store it
in a dry, dark location.
• Make sure that all bolts are tight before each ride.
• Be careful not to touch any moving parts during the ride, in
order to avoid injuries.
• The Folding E-Scooter is a vehicle (leisure vehicle) designed
for transporting one person.
• According to the Road Traffic Act, every road user must
behave in such a way that no other road user is endangered,
harmed, harassed or hindered. In order to be allowed to
operate your Folding E-Scooter on public roads, it must
comply with the legal guidelines. Basically, the Folding E-
Scooter must be equipped with two independently operating
brakes, a bell, a brightly lit headlamp that illuminates the
lane ahead with white or light-yellow, steady light, and must
have a red taillight and reflector strips.
• Before starting to use your Folding E-Scooter, check the
current legal provisions for your region by contacting the
relevant authorities.

Important safety information
WARNING!
7
• The Folding E-Scooter is equipped with a lithium ion battery.
Please note that in some countries there are separate regu-
lations for transporting lithium ion batteries.
• The best operating temperature for the battery is between
10° C and 30° C. Above and below this temperature the
power output will deteriorate, resulting in a reduced range.

8
Preparation
Take the Folding E-Scooter out of its box, pull the locking lever
on the steering column forward and fold the handlebar up. Then
push the lever back again.
Open the quick release in the middle of the handlebar and turn
the handlebar to a position that's comfortable for you.
Open the quick release on the seat post mount on the frame
and insert the seat post. Adjust the seat height to a comfortable
position and then close the quick release.

9
ATTENTION!
Preparation
Remove the 4 mounting screws for the luggage rack above the
rear mudguard. Adjust the luggage rack and fix it in place with
the screws you just removed.
Check the pressure of the tyres.
Make sure that the front light, rear light and bell are working.
Check the battery capacity on the display before setting off.
• Regularly check the tyre pressure and fill the tyres with air
as needed.
• The recommended tyre pressure is 2.8 bar per tyre.

10
Display functions
Button functions
The display has three buttons:
M:
• Press and hold to turn the display on or off.
• Press briefly to choose between the following display opti-
ons:
1. ODO shows the total distance covered
2. TRIP shows the distance travelled since the scooter
was last turned on
3. Battery voltage in Volts
4. PWM shows the pulse width modulation
5. Error code (display in the event of an error)
+:
• Press briefly to increase the speed level.
• Press and hold to turn the front light on or off.
-:
• Press briefly to decrease the speed level.

11
Display
Description
Speed
Charge level indicator
Battery voltage in volts
Total distance
Distance since being
turned
on
PWM
Speed level*:
ECO: 13 km/h
MID: 18 km/h
HIGH: 23 km/h
WARNING!
Display functions
*Guide values, with a user weighing approx. 75 kg and with a fully charged battery on
smooth, even road surfaces and under optimal temperature conditions (see pages 12, 13
and 14)
• Before starting your journey, make sure that the front and
rear lights work!
• The light must be switched on in the dark or in poor visibility!

12
Using the battery
Charging port
Charging the battery:
1. The charging port is located at the rear end of the running
board as shown.
2. Open the protective cap over the charging port
3. Make sure the charging port and charger are dry.
4. Make sure that the Folding E-Scooter is turned off.
5. Connect the charging cable to the charging port.
6. Connect the charging device's mains plug to a suitable wall
socket (220 - 240 V / 50 - 60 Hz).
7. The charging light on the charger will light red when charging.
8. The battery is charged once the charging light changes from
red to green. You should stop charging at this point.
9. Disconnect the charger from the mains and the Folding E-
Scooter.

13
WARNING!
Using the battery
• Never remove the battery from the Folding E-Scooter.
• Charge the battery every 2 months for at least 1 hour, even
if the Folding E-Scooter has not been in use, otherwise it will
lose capacity.
• Regular charging protects the battery from total discharge.
• Never heat the battery or throw it into an open fire.
• Never dispose of battery cells in the household waste.
• Never get moisture on the battery contacts.
• The optimal operating temperature for the battery is between
10° C and 30° C. Above and below this temperature, the
power output will deteriorate, resulting in a reduced range
and power output.
• The Folding E-Scooter may only be charged with the sup-
plied charger. Ensure the correct voltage supply (220 - 240
V / 50 - 60 Hz).
• The Folding E-Scooter must not be charged if the charging
cable is damaged. Please contact customer service.
• A battery's service life and performance depends on its age,
care and how often it has beenused.
• For optimum battery life, charge and store the E-Scooter in
a dry and clean environment, preferably at a temperature
between 7 and 15° C.
• The Folding E-Scooter takes approx. 5 hours to charge. If the
charger is permanently connected to the battery and power
supply, this will have a negative effect on the battery life.
• The Folding E-Scooter and the charger must not be covered
during charging.

Using the battery
14
WARNING!
• Depending on the charge state, lithium batteries have a
freezing point of approx. -20° C to -25° C. If a battery cell
freezes, it will be irretrievably destroyed and the whole battery
will need to be replaced. A lithium battery loses capacity at low
temperatures just like conventional batteries.
• Compared to other battery models, Lithium Ion batteries have
a very low self-discharge and a very low memory effect, but
they must be periodically charged.
• Please note that a over-discharged battery is irreparably de-
stroyed and must to be replaced for a fee. The battery should
never be completely discharged during operation.

15
First use
Before you begin:
Wear a safety helmet and protectors
for your own safety.
• Wear comfortable leisure or sports clothing and flat shoes
while riding.
• Before riding for the first time, make sure you have plenty
of space and ensure that there are no obstacles in the way.
• Fold the handlebar up and check the tyre pressure (see
section on "Preparation" on page 8).
• Please check your Folding E-Scooter before every journey
(see the section on "Maintenance and Care" on page 17).
• Switch on the Folding E-Scooter (see section on "Display
functions" on page 10).
• Turn on the rear light.
On/off button on the rear light
• Fold in the kickstand before riding, otherwise there may be a
risk of accidents and injuries.
Kickstand

16
First use
First steps
• Use the throttle twist grip to accelerate.
• You can use the front and rear brakes to brake.
• You can choose between three speed levels (see section on
"Display functions" on page 10).
Throttle twistgrip
Rear wheel brake
Front wheel brake
Always turn the
• Folding E-Scooter and the rear light off after riding.
• Charge the Folding E-Scooter.
• To fold in, pull the locking lever on the handlebar.
• Please note the information on storage (see section on
"Using the battery" on pages 12, 13 and 14)

17
Maintenance and care
NOTE!
WARNING!
• Before each ride, please make sure that all screws or self-lo-
cking fasteners and quick release clamps are tightened and
that the the handlebar's locking lever is well engaged.
• Make sure the tyre pressure is correct (see page 9)!
• Only use a soft, damp cloth for cleaning the Folding E-Scoo-
ter. Dirt that cannot be removed this way can be removed
with plastic polish. Follow the manufacturer's instructions in
this respect.
• Never use alcohol, cleaner's naphtha, acetone or other
corrosive and volatile chemical solvents that are corrosive
to surfaces. These substances can damage the bike's ap-
pearance and its exterior or interior structure.
• Never clean the Folding E-Scooter with a strong jet of water
or high-pressure cleaner.
• Make sure the Folding E-Scooter is switched off and the
charging socket cover is closed before cleaning, otherwise
you may be exposed to the risk of electric shock or damage
the Folding E-Scooter.

18
Maintenance and care
NOTE!
• Store your Folding E-Scooter in a dry and cool place.
• A well-maintained battery can still provide good performance
even after many kilometres. Charge the battery after each
ride and avoid operating the battery on "empty". Please note
that the performance of the battery decreases continuously
at low temperatures (see section on "Using the battery" on
pages 12, 13 and 14).
• Do not store the scooter outdoors. Exposing the Folding E-
Scooter to sunlight or to hot or cold environments will
accelerate ageing of the plastic surfaces, in particular, and
reduce the battery life.
• Do not forget to turn off the Folding E-Scooter after each
ride and to charge the battery. The cells will be irreparably
damaged if the battery is over-discharged. Damage resulting
from incorrect use is not covered by the warranty. Removing
or opening the battery is not permitted.

19
Maintenance and care
NOTE!
Adjusting the brake callipers:
• Check regularly to see whether the brake callipers of the two
disc brakes are properly adjusted.
• You will need theAllen key and a rubber band to adjust the
brake callipers:
1. Slightly loosen the two brake calliper mounting bolts until
you can move the brake calliper.
2. Then fix the brake lever with the rubber band to centre
the brake calliper.
3. Tighten both brake calliper mounting bolts again. After
removing the rubber band, check whether the wheel can
be moved easily.
Brake calliper mounting bolts
• The adjustment procedure is the same for both the front and
rear brakes.

20
Maintenance and care
NOTE!
Tautening/loosening the brake cables:
1. To tauten or loosen a brake cable, you first need to loosen
the lock nut on the brake lever in question.
2. Then turn the adjusting nut to tauten the brake cable (distan-
ce between the brake shoes and brake disc is reduced), or
in the opposite direction to loosen it (distance between the
brake shoes and brake disc increases).
3. After you have tautened the brake cable, tighten the lock nut
again to fix the adjusting nut in place.
• The setting is correct if the brake shoes are a max.
1 mm distance from the brake disc.
