Billion BiPAC 3010N User manual

Wireless speed up to 300Mbps and
3X the coverage of standard 802.11g
Using the BiPAC 3010N Wireless USB Adapter is a simple way to add wireless connectivity to your desktop or
notebook computer. The BiPAC 3010N deploys the very latest technology, draft 802.11n, which enables
expanded wireless coverage of up to 3 times the range of standard 802.11g products and faster speeds of up
to 300Mbps data rate. By combining the BiPAC 3010N with Billion’s 802.11n ADSL router products, faster
wireless speed and wider range can be assured.
The BiPAC 3010N features industrial-strength WEP, WPA1/2 and WPA1/2-PSK encryption, so your wireless
connectivity is protected with strong security. It also supports most Windows and Mac platforms. Once you're
connected, you can go online, access your email, and share files and other resources on the network. At
home, you can surf the Internet and chat with your friends whenever you want. You can also use it for a
wireless connection in a number of public hotspots, Internet cafes, airport lounges, and other places with
publicly accessible wireless networks.
Just plug it into your computer's USB port and enjoy wireless network access for true mobility. It is also
compliant with both the 802.11g and 802.11b standards and 300Mbps RX PHY rate, 150Mbps TX PHY rate.
Draft 802.11n Wireless USB Adapter
BiPAC 3010N
• Compliant with draft 802.11n,
802.11g, and 802.11b network
devices
• Supports WEP, WPA ,WPA2, 802.1x
and 802.11i for WLAN security
• USB 2.0 Interface
• Universal Plug and Play (UPnP)
• Supports the most popular Windows
and Mac operation systems
Standards
• IEEE 802.11g/b/n draft 2.0
Interface
• USB rev. 2.0 A-Type
Frequency Band
• 2.400GHz ~ 2.4835GH
Modulations
• IEEE 802.11g:
OFDM (64-QAM, 16-QAM, QPSK, BPSK)
• IEEE 802.11b:
DSSS (CCK/DQPSK/DBPSK)
• IEEE802.11n:
OFDM (64-QAM,16-QAM,QPSK, BPSK)
Data Rates
• IEEE 802.11g: 54, 48, 36, 18, 12, 9 & 6Mbps;
Auto-fallback
• IEEE 802.11b: 11, 5.5, 2 and 1 Mbps;
Auto-fallback
• Legacy, Mixed and Green Field Modes,
Support 20/40MHz Bandwidth MCS0-7
(150Mbps PHY Rate Support)
Security
• 64/128bit WEP, WPA, WPA2, 802.1x and 802.11i
• Cisco CCX Compliant
Transmitting Power
• 802.11b: up to 16.5 ±1 dBm
• 802.11g: up to 13.5 ±1 dBm
• 802.11n: up to 13.5 ±1 dBm
Antenna
• Integrated diversity antenna
Number of Operational
channels
• U.S. 1-11
• Japan 1-13, 14
• Elsewhere Worldwide 1-13
Supported Operating
Systems
• Windows 2000/XP/Vista
• Mac 10.3/10.4
Receiver Sensitivity
• 54Mbps OFDM, 10% PER, -70dBm
• 11Mbps CCK, 8% PER, -85dBm
• 1Mbps BPSK, 8% PER, -91dBm
• 11n MCS15 & MCS7 20MHZ,
10% PER,-64dBm
• 11n MCS15 & MCS7 40MHZ,
10% PER, -61dBm
Dimensions
• 88(L) x 27(W) x11.5(H) mm
Weight
• 19.9g
Temperature Range
• Operation: 0°C ~ 40°C
• Storage: -20°C ~ 80°C
Humidity
• Operating: Max. 95%
(Non Condensing)
• Storage: Max. 95%
(Non-Condensing)
Certifications
• FCC,CE
Features & Specifications
All the specifications are subject to change without prior notice. V.040208
