Billion BiPAC 7800NXL
Setup Guide

Modem reference & light status sheet
On the front of your modem you will notice a number of lights. The below table
explains what each of these lights mean:
LABEL
ACTION
DESCRIPTION
[1] Internet
Solid Green
Device has connected to the Internet
Blinking Green
Data flow
Solid Red
Authentication failed
[2] DSL
Solid Green
DSL signal established
Blinking Green
Trying to achieve DSL signal
Off
No DSL signal
[3] Wireless
Solid Green
Wireless connection enabled
Blinking Green
Data flow
Solid Red
Wireless connection disabled
[3] WPS
Solid Green
WPS enabled
Blinking Green
Data flow
Off
WPS disabled
[4] Ethernet WAN
Solid Green
WAN connection established
Off
No WAN connection
[5] Ethernet (1-4)
Blinking Green
Connected via Ethernet
Solid Green
Data Flow
Off
No Ethernet Connection
[6] Power
Solid Green
Power is on
Off
Power is off

1. Getting started
Requirements
1. Any operating system is compatible, however depending on the version this
may affect your internet experience
2. Internet Explorer 6.0 or higher / Firefox 2.0 or higher
3. Ethernet network adapter
4. Wireless enabled computer (if you are using the wireless feature)
Connecting the Billion BiPAC 7800NXL to your computer
1. Connect a network cable to the yellow port (numbered ‘4’) located at the
back of the modem
Figure: Billion BiPAC 7800NXL
The other end of your network cable will connect to the UNI-D port on your
NBN ONT
Figure: NBN ONT

2. Connect a second network cable to one of the remaining three yellow ports
located at the back of the modem. The other end will connect directly to your
computer.
3. Finally, connect the power cable to your modem and plug the power adapter
in to your power point. Press the power button to the "ON" state
The diagram on the previous page (Figure: Billion BiPAC 7800NXL) shows
how the modem connects physically to your phone line, computer, and power
point.
4. Now that the modem is connected to your computer, the ONT, and is
powered on, you will need to ensure that the lights on the modem indicate the
following:
Power On
EWAN On
Ethernet (1-4) On or Blinking
A network icon will appear in your task bar, and you are now ready to setup
your Internet connection
Note: If you have already connected via Wi-Fi you will see the below icon
instead.

2. Configuring your modem
Logging in to your modem
1. Open your web browser (typically Internet Explorer/Chrome/Firefox/Safari)
and in the address bar enter the details:
http://192.168.1.254
2. You will be asked for a Username and Password. Enter the following login
details:
Username admin
Password admin

Configuring your NBN modem to access the Internet
1. Once you have logged into your modem, the Billion home page will appear as
shown below. Click on the Quick Start tab on the left hand side to begin the
setup
2. Ensure the following settings have been set, then click on Continue
Main Port Ethernet
3. Enter the Username and Password provided to you, then click on Continue

4. Please wait while the device is being configured
5. Once the settings have been successfully configured, you will now receive a
message to configure your wireless connection
6. To configure the wireless connection, ensure the following settings are
entered:
Wireless check box is ticked to Enable
SSID is named (this will be any name you wish to give to your Wireless
Network. By default this is set to wlan-ap)
WPA2 Pre Shared Key: This will ensure that in order to connect to your
wireless network a password will be required. Please enter a password
between 8 - 63 characters; this can contain letters and numbers
7. You will now receive a message that process is finished. On the bottom of the
page you will see an option to Restart the modem, please click on restart

8. Click on Restart with Current Settings selected to restart the modem
9. Please wait while the modem is restarting. This can take a few minutes so please
be patient. The following page will appear while the modem is updating your
details
10. Once connected the Internet, the modem light will turn on and flash to
indicate there is Internet traffic. Try browsing to a website such as
www.google.com to test your connection

3. Connecting the Billion 7800NXL to your
devices using wireless
In the previous section you have configured the wireless connection for your modem.
Please use your Wi-Fi Network Name (SSID) and Pre Shared Key (Password) to
connect to any wireless compatible devices you have.
How to connect to your Windows computer
1. In Windows, click on the Network icon located at the bottom right hand corner
of your screen as shown below. This will provide you with a list of available
wireless networks in your range
2. Look for the default Wi-Fi Network Name (SSID) in your wireless networks list.
The default Wi-Fi Network Name (SSID) is wlan-ap. If, in the previous section
you have chosen your own SSID, this name will be shown in the list instead.
Once you have selected the right connection, click Connect to continue. You
may want to also tick the box to connect automatically, so that you will
automatically connect to this Wi-Fi access point when you are within range
3. Enter the Security Key or Pre Shared Key and click OK, Connect, or Next to
connect

4. Once connected it will indicate that you are now connected to wlan-ap or your
chosen Wi-Fi Network Name (SSID)
5. Repeat steps 1-3 to add other wireless devices such as laptops, tablets, and
smart phones
