Billy Goat CR550HCV Installation instructions

Part No. 350245 Form No. F021805A
Page 1 of 12
Thank You for SelectingThank You for Selecting
Thank You for SelectingThank You for Selecting
Thank You for Selecting
Operator Owner's Manual
The Powerful CR
POWER RAKE
Specifications
FLAIL BLADES
P/N 35 251.
A complete replacement
set. 52 of our high quality
flail lades for your CR.
Includes 8 new lock clips
for replacement installa-
tion.
CR550HC, CR550HCV
FLAIL SHAFTS
P/N 35 185.
A full set of four shafts for
replacement. Includes 8
new lock clips for replace-
ment installation.
Note: We recommend
replacing the shafts when
you replace flails.
REPLACEMENT PARTS
DR VE BELT
P/N 350207.
Original Equipment drive
belt for your CR.
SLICING REEL
P/N 35 252.
A complete verti-slicing
reel for your CR. 20" wide
reel for use in grasses
that require vertical
cutting, and for assisting
in lawn overseeding
projects.
ACCESSOR ES
SLICING BLADES
P/N 35 187.
A full set of twenty lades
for replacement. Includes
40 new capscrews, and
lock nuts for replacement
installation.
R
21
3
SPACER BUMPERS
P/N 350258.
A complete replacement
set. 44 of 1/2" spacer
umpers and 4 of 1/4"
spacer umpers
CR550HC CR550HCV
ENGINE: H.P. 5.0 (3.73 kW) 5.0 (3.73 kW)
ENGINE: TYPE HONDA OHC HONDA OHC
ENGINE: FUEL CAP. 2.1 qt. (2.0 L) 2.1 qt. (2.0 L)
ENGINE: OIL CAP. 0.63 qt. (0.6 L) 0.63 qt. (0.6 L)
WEIGHT: UNIT 125# (56.8 kg) 125# (56.8 kg)
WEIGHT: SHIPPING 150# (68.2 kg) 150# (68.2 kg)
MAX. ENGINE OPERATING SLOPE 20° 20°

Part No. 350245 Form No. F021604A
Page 2 of 12
N THE NTEREST OF SAFETY
TH S SYMBOL MEANS WARN NG OR CAUT ON. DEATH, PERSONAL NJURY AND/OR PROPERTY
DAMAGE MAY OCCUR UNLESS NSTRUCT ONS ARE FOLLOWED CAREFULLY.
BEFORE START NG ENG NE, READ AND UNDERSTAND THE “ENT RE OPERATOR'S MANUAL &
ENG NE MANUAL.”
WARNING: DO NOT
1. DO NOT run engine in an enclosed area.
Exhaust gases contain car on monoxide, an
odorless and deadly poison.
2. DO NOT place hands or feet near moving
or rotating parts.
3. DO NOT store, spill or use gasoline near
an open flame, or devices such as a stove,
furnace, or water heater which use a pilot
light or devices which can create a spark.
4. DO NOT refuel indoors where area is not
well ventilated. Outdoor refueling is recom-
mended.
5. DO NOT fill fuel tank while engine is
running. Allow engine to cool for 2 minutes
efore refueling. Store fuel in approved
safety containers.
6. DO NOT remove fuel tank cap while
engine is running.
7. DO NOT operate engine when smell of
gasoline is present or other explosive
conditions exist.
8. DO NOT operate engine if gasoline is
spilled. Move machine away from the spill
and avoid creating any ignition until the
gasoline has evaporated.
9. DO NOT transport unit with fuel in tank.
10. DO NOT smoke when filling fuel tank.
11. DO NOT choke car uretor to stop
engine. Whenever possi le, gradually
reduce engine speed efore stopping.
12. DO NOT run engine at excessive
speeds. This may result in injury & /or
damage to unit.
13. DO NOT tamper with governor springs,
governor links or other parts which may
change the governed engine speed.
14. DO NOT tamper with the engine speed
selected y the engine manufacturer.
15. DO NOT check for spark with spark plug
or spark plug wire removed. Use an
approved tester.
16. DO NOT crank engine with spark plug
removed. If engine is flooded, place throttle
in “FAST” position and crank until engine
starts.
17. DO NOT strike flywheel with a hard
o ject or metal tool as this may cause
flywheel to shatter in operation. Use proper
tools to service engine.
18. DO NOT operate engine without a
muffler. Inspect periodically and replace, if
necessary. If engine is equipped with
muffler deflector, inspect periodically and
replace, if necessary, with correct deflector.
19. DO NOT operate engine with an
accumulation of grass, leaves, dirt or other
com usti le material in the muffler area.
20. DO NOT use this engine on any forest
covered, rush covered, or grass covered
unimproved land unless a spark arrester is
installed on the muffler. The arrester must
e maintained in effective working order y
the operator. In the State of California the
a ove is required y law (Section 4442 of
the California Pu lic Resources Code).
Other states may have similar laws. Federal
laws apply on federal lands.
21. DO NOT touch hot muffler, cylinder, or
fins ecause contact may cause urns.
22. DO NOT run engine without air cleaner
or air cleaner cover.
23. DO NOT operate during excessive
vi ration!
24. DO NOT leave machine unattended
while in operation.
25. DO NOT park machine on a steep grade
or slope.
WARNING: DO
1. ALWAYS DO remove the wire from the
spark plug when servicing the engine or
equipment TO PREVENT ACCIDENTAL
STARTING.
2. DO keep cylinder fins and governor
parts free of grass and other de ris
which can affect engine speed.
3. DO pull starter cord slowly until resis-
tance is felt. Then pull cord rapidly to avoid
kick ack and prevent hand or arm injury.
4. DO examine muffler periodically to e
sure it is functioning effectively. A worn or
leaking muffler should e repaired or
replaced as necessary.
5. DO use fresh gasoline. Stale fuel can
gum car uretor and cause leakage.
6. DO check fuel lines and fittings frequently
for cracks or leaks. Replace if necessary
7. Follow engine manufacturer operating
and maintenance instructions.
8. Inspect machine and work area efore
starting unit.
VIBRATION
VIBRATION LEVELS 3.2 g max.
Vi ration levels at the operators handles were
measured in the vertical, lateral, and longitudinal
directions using cali rated vi ration test equipment.
Tests were performed on 09/08/97 under the
conditions listed:
WIND DIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRIC PRESSURE:
SOUND
Sound tests conducted were in accordance with 2000/14/EEC
and were performed on 2/9/2002 under the conditions listed:
GENERAL CONDITION:
29.72" Hg (754mm Hg)
82.2 %
North West
10 MPH (16.1 kmh)
43° F (6.1° C)
Sunny
5
6
8
7
○○○○○○
SAFETY INSTRUCTIONS
GENERAL SAFETY
ASSEMBLY
CONTROLS
LABELS
OPERATION
MAINTENANCE
PARTS DRAWING & LIST...
TROUBLESHOOTING
WARRANTY PROCEDURE
○○○
○○○○○○○
○○○○○○○○○
○○○○○○○○
○○○○○
○○
7
12
12
5 - 6
4
4
3
3
2
TABLE OF CONTENTS
8 - 11
WARNING: The Engine Exhaust from this product contains chemicals known
to the State of California to cause cancer, irth defects or other reproductive harm.
○○○○○○○○
WIND SPEED:
NOTE: Sound power level listed is the highest value for any model in this manual. Please
refer to serial plate on the unit for the sound power level for your model.
99 dB WIND DIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRIC PRESSURE:
GENERAL CONDITION:
29.91" Hg (760mm Hg)
31 %
East
10 MPH (16.1 kmh)
85° F (29.4° C)
Sunny
WIND SPEED:
Sound level of 81 dBA at operator position

Part No. 350245 Form No. F021805A
Page 3 of 12
PUT OIL IN ENGINE BEFORE STARTING
Read all safety and operating instructions
before assembling or starting this unit.
Engine
Manual Per
Model
These items should be included in your carton. If any
of these parts are missing, contact your dealer.
ASSEMBLY
PACKING CHECKLIST
GENERAL SAFETY
For your safety and the safety of others, these directions should be followed:
Use of Ear Protection is recommended while
operating this machine.
Use of Eye and Breathing protection is recommended
when using this machine, especially in dry and dusty
conditions.
·DO NOT place hands or feet underneath unit, near de ris
outlet or near any moving parts.
·DO NOT start engine without height adjust lever in up
position and clutch ail disengaged.
·DO NOT start or operate machine with guards removed.
·DO NOT perform any service on the unit without removing
the spark plug wire.
·DO NOT operate a machine that exhi its excessive vi ration.
·DO NOT operate this machine on slopes greater than19°.
·DO NOT use this unit on any surface other than grass lawns.
·DO NOT allow children to operate this equipment.
-DO read all maintenance and operating instructions efore egining
work.
-DO read all engine manufacturers operating and maintenance
instructions.
-DO inspect lawn efore egining work. Remove all rocks, wire,
string, or other o jects that can present a hazard during work prior to
starting.
-DO identify and mark all fixed o jects to e avoided during work,
such as sprinkler heads, water valves, uried ca les, or clothes line
anchors, etc.
9
1
11
Do not operate this machine without first reading
owner's manual and engine manufacturer's manual.
Per Model
1. ASSEMBLE left rear wheel to axle using 3/4" wrench.
2. UNFOLD the upper handle (item 26) and slide handle lock loops
(item 28) into place to secure the upper handle to the lower.
3. CHECK engine oil level and fill to proper level with engine manufactur
ers recommended grade of oil. Move height adjust lever to down
position, to level engine during checking. See engine manufacturers
instruction manual.
4. CONNECT spark plug wire.
Literature
Assembly
35 243
Wearing gloves is recommended while
operating this machine.
Chec Owner's
Manual
35 245
Literature CR
Accessories
35 246
Chec
Chec EU Declaration
of Conformity &
EU Distributor
List 35 139
Chec
Warranty
Card 4 972
28
28
26 Chec
Honda GC 5. OHC

Part No. 350245 Form No. F021604A
Page 4 of 12
These labels should be included on your Power Rake. If any of
these labels are damaged, replace them before putting this
equipment into operation. Item and part numbers are given to help
in ordering replacement labels.
Label Danger
Keep Hands
and Feet
Away
Item 51 Part
No.400424
Label Do Not Fill While
Engine Is Hot
Item 50 Part No.400268
EXPLOSIVE FUEL
STOP ENGINE AND ALLOWTO
COOL BEFORE REFUELING.
400268
WARNING
14 15
INSTRUCTION LABELS ENGINE LABELS
DANGER
810736
Label Danger Flying Material
Item 48 Part No.810736
13 CONTROLS
READ OWNERS MANUAL
BEFORE OPERATING
BEFORE STARTING, MAKE SURE:
USE PERSONAL
PROTECTION EQUIPMENT
HEIGHT ADJUST LEVER IS IN DOWN POSITION.
ALL GUARDS ARE ATTACHED.
USE ONLY AQUALIFIED MECHANICTO SERVICETHIS MACHINE.
INSPECT MACHINE BEFORE EACH USE AND REPLACE ANY
WORN AND DAMAGED PARTS.
CHECK ENGINE OIL DAILY .
PROPERLY SECURE EQUIPMENT BEFORETRANSPORTING.
DISCONNECT SPARK PLUG WIRE BEFORE SERVICING UNIT.
FOR PREVENTATIVE MAINTENANCE
INSPECT AND CLEAN ENGINE AIR FILTER
DAILY. REPLACE AS NEEDED.
GREASE REEL BEARINGS AND LUBRICATE DEPTH
CONTROL LEVER EVERY ENGINE OIL CHANGE.
ALWAYS:
ROTATE KNOB TO ADJUST BLADE DEPTH
BLADES UP
TRANSPORT POSITION BLADES DOWN
OPERATING POSITION
PROTECT BYSTANDERS
FLYING DEBRIS
BLADES UP BLADES DOWN
350224
LOOSEN JAM NUT
BEFORE ADJUSTING
BLADE DEPTH THEN
TIGHTEN BACK TO
LOCK IN PLACE
Label Instructions Height Adjust
Item 35 Part No. 350224
WARNING
900327
Label Danger Guard
Item 52 Part No.900327
'
'
'
..
Honda
PULLTO ENGAGE CLUTCH
RELEASETO DISENGAGE CLUTCH
830503
Label Clutch Item 49
Part No.830503
HONDA ENGINE THROTTLE CONTROL
THROTTLE LEVER
FUEL VALVE CHOKE LEVER
'
'
'

Part No. 350245 Form No. F021805A
Page 5 of 12
ENGINE: See engine manufacturer’s instructions
for type and amount of oil and gasoline used.
Engine must e level when checking and filling oil and
gasoline.
ENGINE SPEED: Controlled y throttle lever on the engine.
Under normal conditions, operate at full throttle to accom-
plish your task.
FUEL VALVE: Move fuel valve to "ON" position (Honda
only).
CHOKE: Operated with lever on the engine.
THROTTLE: Move throttle control on engine to fast position.
Pull starting rope to start engine.
IF YOUR UNIT FAILS TO START:
See Trou leshooting on page 12.
INTENDED USE: This machine is designed for removing
thatch from your lawn, renovation of existing lawns, and to
assist in overseeding operations. The machine should not
e used for any other purpose than that stated a ove.
Inspect machine work area and machine before operat-
ing. Make sure that all operators of this equipment are
trained in general machine use and safety.
Do not operate if excessive vi ration occurs. If excessive
vi ration occurs, shut engine off immediately and check for
damaged or worn reel, loose pulley olts or set screws, loose
engine or lodged foreign o jects. (See trou le shooting
section on page 12).
16 Operation
STARTING ENGINE
RAKING OPERATION
Like all mechanical tools, reasona le care must
e used when operating machine.
MOW: Mow the lawn to it's normal cut height
DRY: Be sure grass is dry. Wet conditions can cause in-
creased damage to healthy grass.
SET DEPTH: With engine off, set the raking depth so that the
lades just touch on a flat surface (i.e. driveway, or sidewalk).
START ENGINE: See a ove.
ENGAGE BLADES: Pull ack on the ail on the operators
handle. NOTE: When engaging the blades in heavy load
conditions (i.e. heavy thatch, or very uneven turf), push down
on the operators handle lifting the front wheels slightly.
Engage the blades. Slowly lower the unit into the turf.
RAKE: Rake a small test area and examine the results.
Thatch should e removed and deposited on top of the healthy
grass. If excessive damage occurs to healty grass, adjust the
lade depth to decrease damage. Continue raking the yard,
working in one direction (i.e. north-south, or east-west).
NOTE: If a large drop in engine RPM occurs, or the unit pulls
you forward and bounces during operation the blade depth is
set too low.
REMOVE THATCH: After raking, a layer of thatch will e
deposited over the top of the lawn. This thatch must e
removed prior to any fertilizing, seeding, or watering of the
lawn. We suggest the use of a lawn vacuum or wheeled
lower for collection and removal of the thatch.
DO NOT- Use this machine on any surface other than a lawn.
DO NOT- Use this machine on slopes in excess of 19°.
DO NOT-
Allow persons unfamiliar with this equipment to operate it.
DO NOT- Allow children to operate this equipment.
The lades can e raised or lowered into the ground y height
adjusment lever on the engine ase. The resulting lade
depth can e adjusted higher or lower.
See ADJUSTING BLADE DEPTH.
BLADE POSITION & DEPTH CONTROL LEVER
Clockwise:
To lower lades
Counter Clockwise:
To raise lades
ADJUSTING BLADE DEPTH
The depth of the lades can e raised or lowered y rotating the
kno on the top of the adjustment lever. The lades are lowered
y rotating the kno clockwise, and raised y rotating the kno
counter-clockwise. The relative depth of the lades can e
gauged y using the depth scale located on the right front corner
of the engine ase.
BLADES UP
TRANSPORT
BLADES DOWN
RUNNING

Part No. 350245 Form No. F021604A
Page 6 of 12
OPERATION continued
16
OVERSEEDING OPERATION continued
MOW: Mow the lawn to it's normal cut height
DRY: Be sure grass is dry. Wet conditions can cause in-
creased damage to healty grass.
SET DEPTH: With engine off, set the raking depth so that the
lades just touch on a flat surface (i.e. driveway, or sidewalk).
START ENGINE: See Page 5.
ENGAGE BLADES: Pull ack on the ail on the operators
handle. NOTE: When engaging the blades in heavy load
conditions (i.e. heavy thatch, or very uneven turf), push down
on the operators handle lifting the front wheels slightly.
Engage the blades. Slowly lower the unit into the turf.
SLICE: Verti-cut a small test area and examine the results.
Some thatch and cut stems should e removed and deposited
on top of the healthy grass. Grass runners should e cut and
ready for removal. If excessive damage occurs to healthy
grass, adjust the lade depth to decrease damage. Continue
raking the yard, working in one direction (i.e. north-south, or
east-west). NOTE: If a large drop in engine RPM occurs, or
the unit pulls you forward and bounces during operation the
blade depth is set too low.
REMOVE THATCH/STEMS: After verti-cutting, a layer of
thatch and cut stems will e deposited over the top of the lawn.
We suggest the use of a lawn vacuum or wheeled lower for
collection and removal of the thatch/stems.
DO NOT- Use this machine on any surface other than a lawn.
DO NOT- Use this machine on slopes in excess of 19°.
DO NOT- Allow persons unfamiliar with this equipment to
operate it.
DO NOT- Allow children to operate this equipment.
RAKING/SLICING TIPS
THATCH: Thatch is a dense layer of dead grass, clippings,
and roots that uilds up over time at the ase of of the lawn
preventing air, water, and fertilizer from reaching the soil.
This can cause shallow root development and make a lawn
more suscepti le to drought and disease. Thatch also
provides an ideal environment for insects to hide and
multiply. Periodic removal of thatch will keep your lawn in
good health.
HEAVY THATCH: Lawns with an excessive amount of thatch
will require multiple treatments for effective removal. Trying
to remove excessive thatch (greater than 3/4"[19 mm] deep)
in one treatment will damage or destroy the living part of the
lawn. It is est to remove heavy thatch in seasonal treat-
ments (i.e. spring, and fall).
CHECK: Before egining, it is est to evaluate the condi-
tion of the lawn y cutting one or more core samples from
area to e treated. A core can e cut using a piece of pvc,
or metal pipe. Hammer the pipe into the ground, remove it,
push the core out of the pipe and inspect it to determine the
depth of thatch in your yard.
SLOPES: Rake slopes across not up and down. This is
much easier and safer for the operator and is etter for the
lawn. Raking across will help to reduce runoff during
watering and allow the sloped ground to hold more seed,
fertilizer, and water. The units maximum operating slope is
35% or 19°.
DEPTH: The wide range of depth adjusment on your unit is
provided to allow for lade wear. Setting the reel deeper will
not produce etter, or quicker results. The flail reel is
intended to e set so it just touches the surface on flat
ground. The slicing reel should e set even with the ground
for verti-slicing work, and set to a maximum 1/2" depth for
overseeding jo s. Setting the reel deeper than this will only
result in premature wear on the unit (i.e. failed elt). If you
desire to work the ground deeper than the a ove guidlines
allow, it should e done gradually in multiple passes.
Hints!
OVERSEEDING OPERATION
MOW: Mow the lawn to it's normal cut height
DRY: Be sure grass is dry. Wet conditions can cause in-
creased damage to healthy grass.
SEED: Spred grass seed according to the seed suppliers
directions (e.g. 10 l s. per 1000 ft2 [4.5 kg. per 93 m2 ])
SET DEPTH: With engine off, set the raking depth so that the
lades reach 1/4"-1/2"(6-12 mm) elow a flat surface (i.e.
driveway, or sidewalk).
START ENGINE: See Page 5.
ENGAGE CLUTCH: Pull ack on the ail on the operators
handle. NOTE: When engaging the clutch in heavy load
conditions (i.e. heavy thatch, or very uneven turf), push down
on the operators handle lifting the front wheels slightly.
Engage the clutch. Slowly lower the unit into the turf.
DO NOT- Use this machine on any surface other than a lawn.
DO NOT- Use this machine on slopes in excess of 19°.
DO NOT- Allow persons unfamiliar with this equipment to
operate it.
DO NOT- Allow children to operate this equipment.
SLICE: Run machine over the area that has een seeded to
incorporate the seed into the soil. If excessive damage
occurs to healthy grass, adjust the lade depth to decrease
damage. Continue raking the yard, working in one direction
(i.e. north-south, or east-west). NOTE: If a large drop in
engine RPM occurs, or the unit pulls you forward and
bounces during operation the blade depth is set too low.
WATER/FERTILIZE: After the seed has een worked into
the soil, water and fertilize according to the seed suppliers
directions.
VERTI-CUTTING OPERATION
This unit is equipped with a folding upper handle for easier storage
and transportation. The handle can e folded y sliding the handle
lock loops(item 28) up. This releases the upper handle, allowing it to
e folded over the unit.
FOLDING HANDLE
This unit requires two people to lift it. With the handle in the folded
position, lift holding the lower handle and elt/shaft guard one on
each side of the machine. Secure the machine in place during
transport.
HANDLING & TRANSPORTING

Part No. 350245 Form No. F021805A
Page 7 of 12
MAINTENANCE
BLADE WEAR AND ROTATING REEL END TO END
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine. (Honda only)
3. Lean unit ack onto lower handles and secure in place.
4. Inspect lades for wear, and immediately replace any ent or
cracked lades. Measure the overall length of the lade. (See fig. 1)
5. If lades measure less than 3.0"(76 mm) in overall length they must
e replaced. NOTE: We recommend replacing all the flails at once.
FLAIL BLADE WEAR
Use only a qualified mechanic for
any adjustments, disassembly or
any kind of repair .
DISCONNECT SPARK PLUG WIRE
BEFORE SERVICING UNIT.
WARNING: TO AVOID PERSONAL INJURY, ALWAYS
TURN MACHINE OFF, MAKE SURE ALL MOVING
PARTS COME TO A COMPLETE STOP.
RECONNECT SPARK PLUG WIRE,
AND ALL GUARDS, BEFORE
STARTING ENGINE.
ENGINE: See engine manufacturer
operator's instructions.
17
Engine (See Engine Manual)
Check engine oil
Inspect and clean engine air filter
Grease reel earings
Inspect elt
Maintenance Operation
Follow these hourly
maintenance intervals.
Maintenance Schedule
Every
25 hrs
Every Use
(Daily)
ROTATING FLAIL REEL END TO END
USE ONLY BILLY GOAT ORIGINAL
EQUIPMENT PARTS FOR
REPLACEMENT AND REPAIR
NOTE: Takes approx. 10 min. and requires 3/8" socket wrench with
extension.
1. Wait for engine to cool and disconnect spark plug.
2 . Remove (6) self tapping screws (item 65) holding the elt guard
(item 21 & 22) in place. Remove the guard.
3. Remove the elt (item 9) y rotating the reel pulley(item 2) and
walking it out of the groove. Discard old elt
4. Install new elt using same procedure to walk the elt into the
groove.
5. With new elt installed pull ail rod ack to engaged position and
measure extension of idler spring. Spring should stretch 1" to 1.25"
(25-32 mm) with ail engaged. Adjust clutch ca le as necessary to
achieve this extension.
6. Re-install the elt guard.
DRIVE BELT REPLACEMENT
Inspect for loose, worn,
or damaged parts
Oil height adjustment linkage
To maximize flail lade life and performance the reel can e rotated end
to end periodically to provide a fresh lead cutting edge. Takes approx. 20
min. and requires two 1/2" socket wrenches with extension ar.
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine. (Honda only)
3. Lean unit ack onto lower handles and secure in place.
4. Remove (6) lock nuts(item 62) holding the elt and shaft guards(item
21 &22) in place. It is necessary to lower the height adjust lever to reach
the locknuts on the guards. Remove the guards.
5. Remove the drive elt(item 9) y "walking" it out of the groove on the
reel pulley(item 2).
6. Remove the (4) lock nuts(item 60) and washers(item 68) holding the
earings(item 23) to the frame of the unit.
7. The reel is now free from the machine. Slide the reel down and out of
the machine.
8. Remove the capscrew(item 71), lockwasher(item 57), reel pulley(item
2), key(item 42), and reel spacer(item 10) from the end of the reel.
9. Rotate the reel end to end, and re-install these items on the opposite
end of the reel.
1 . Re-install the reel in reverse order of removal. Re-install the guards
in reverse order of removal.
Fig. 1
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine. (Honda only)
3. Lean unit ack onto lower handles and secure in place.
4. Inspect lades for wear, and immediately replace any ent or
cracked lades. Measure the overall length of the lade from the center
of the attachment olts to the tip of the worn lade.
5. If lades measure less than 3.0"(76 mm) they must e replaced.
NOTE: We recommend replacing all the lades at once.
SLICING BLADE WEAR

Part No. 350245 Form No. F021604A
CR550HC, CR550HCV
Page 8 of 12
18 PARTS DRAW NG
R

Part No. 350245 Form No. F021805A
Page 9 of 12
item PARTS CR550HC QTY CR550HCV QTY
no. LIST Part No. Part No.
1 Pulley 3.0" O.D. 350101 1 350101 1
2 Pulley 5.5" O.D. X ¾" 350206 1 350206 1
3 Wheel 8" Semi-Pneu White 350236 4 350236 4
4BarStrap 350211 1 350211 1
5RodHeightWa 350220 1 350220 1
6 Reel Flail Assy (see page 10 & 11 for parts list and detailed dwg.) 350241 1 350252 1
7 Pulley Idler 2.75" 350114 1 350114 1
8 Arm Idler WA 350115 1 350115 1
9 Belt 5L X 34" 350207 1 350207 1
10 Spacer Reel Pulley 350118 1 350118 1
11 Bracket Belt Finger 350208 1 350208 1
12 Chassis WA W/ Label 350235 1 350235 1
13 Frame Front WA 350213 1 350213 1
14 GRIP 1" x 13" 400570 2 400570 2
15 Label Instr. Hgt. Adj. 350224 1 350224 1
16 Link Height Bar 350223 1 350223 1
17 Knob Height Adj. 850154 1 850154 1
18 STUD 3/4"-10 X 5 1/2" PLTD 810538 1 810538 1
19 LOCKNUT ASSY 800227 1 800227 1
20 WASHER 3\4" NYLON 800109 1 800109 1
21 Guard Belt Top Wa 350248 1 350248 1
22 Guard Belt Bottom Wa 350249 1 350249 1
23 Bearing ¾" Cast Flange 350209 2 350209 2
24 Handle Lower LH WA 350134 1 350134 1
25 Handle Lower RH WA 350135 1 350135 1
26 Handle Upper PR500 350136 1 350136 1
27 Bail Clutch WA 350137 1 350137 1
28 Loop Folding Handle 350138 2 350138 2
29 Deflector Rubber 350210 1 350210 1
30 Guard Shaft CR 350250 1 350250 1
31 PIN LIFT FRONT 3/8" X 21 3/16" Long 350212 1 350212 1
32 PIN COTTER 1/8" X 1" Z/P 8197031 1 8197031 1
33 SCREWCAP 5/16-24x3/4" GR5 8042026 2 8042026 2
34 SCREWCAP 5/16 - 18 x 1 1/2 8041030 7 8041030 7
35 WASHER 1/4" FLAT Z/P 8171002 8 8171002 8
36 SCREWCAP 1/4"-20X2 1/2" 8041012 1 8041012 1
37 BELT FINGER WIRE 350301 1 350301 1
38 Cable Clutch Reel PR500 350181 1 350181 1
39 Spring Extension 350300 1 350300 1
40 Bolt Shoulder 1/2" X 1" 500114 1 500114 1
41 ENGINE HONDA 5.0 HP GC 430272 1 430272 1
42 KEY 3/16" X 1" 9201078 2 9201078 2
43 NUT 1/2 - 13 JAM 8162005 4 8162005 4
44 WASHER 1/2 SAE 8172011 8 8172011 8
45 SCREWCAP 1/2-13 x 3" Z/P 8041102 4 8041102 4
46 SCREWCAP 5/16"-18X1 1/4" HCS ZP 8041029 4 8041029 4
47 NUT LOCK 5/16-18 8160002 9 8160002 9
48 LABEL DANGER THROWN OBJECT 810736 1 810736 1
49 LABEL CLUTCH VQ 830503 1 830503 1
50 LABEL HOT ENGINE 400268 1 400268 1
51 LABEL WARNING 400424 2 400424 2
52 LABEL DANGER GUARD 900327 1 900327 1
53 PLUG CAP 1" RD 890132 2 890132 2
54 BOLT CARRAIGE 3/8-16 x 1 3/4 8024061 4 8024061 4
55 BOLT CARRAIGE 5/16-18 x 1 3/4 8024043 2 8024043 2
56 SCREWCAP 1/4-20x1" 8041006 4 8041006 4
57 LOCK WASHER TWISTED TOOTH 400502 1 430298 2
58 SCREWCAP REEL ASSEMBLY 8041050 1 400164 1
59 NUT LOCK 1/4-20 8160001 5 8160001 5
60 NUT LOCK 3/8-16 8160003 4 8160003 4
61 NUT LOCK 3/8-16 THIN 8161042 1 8161042 1
62 NUT LOCK 1/4-20 8160001 13 8160001 13
63 WASHER 5/16 FLAT CUT 8171003 8 8171003 8
64 SCREWCAP 3/8-16x1 1/4" 8041051 4 8041051 4
65 SCREWCAP SHEET METAL DRILL POINT 1/4X3/4 430208 6 430208 6
66 NUT JAM 1/4-20 8143001 1 8143001 1
67 SCREW MACH. #10-24X2" 8059143 1 8059143 1
68 BRACE DEFLECTOR 350234 4 350234 4
69 Knob Height Adj. 430128 1 430128 1
70 WASHER 5/16 SAE 8172009 1 8172009 1
71 SPACER CRANK CR HONDA 350338 1 350338 1
72 SCREWCAP 5/16-24 x 1 1/4" GR. 8 400389 1 400389 1
73 WASHER FENDER 5/16 8172020 1 8172020 1

Part No. 350245 Form No. F021604A
Page 10 of 12
FLAIL REEL ASSY 35 241
FLAIL SHAFT KIT 35 185 FLAIL BLADE KIT 35 251
item PARTS CR500 QTY
no. LIST Part No.
73 SHAFT FLAIL BLADE 350141 4
78 CLIP LOCK 1/2" 350146 8
item PARTS CR500 QTY
no. LIST Part No.
74 BLADE FLAIL 350205 52
78 CLIP LOCK 1/2" 350146 8
item PARTS CR500 QTY
no. LIST Part No.
73 SHAFT FLAIL BLADE 350141 4
74 BLADE FLAIL 350205 52
75 SPACER BUMPER 5/8" x 1/4" 350143 4
76 SPACER BUMPER 5/8" x 1/2" 350144 44
77 SHAFT WA FLAIL REEL 350145 1
78 CLIP LOCK 1/2" 350146 8
79 WASHER 1/2 SAE 8172011 8

Part No. 350245 Form No. F021805A
Page 11 of 12
SLICING REEL ASSY 35 252
SLICING BLADE KIT 35 187
item PARTS PR500 QTY
no. LIST Part No.
81 BLADESLICING REEL 350147 20
85 SCREWCAP1/4-20 x 3/4, GR. 5 350151 40
86 NUT LOCK 1/4-20 8142004 40
SPACER BUMPER KIT 35 258
item PARTS PR500 QTY
no. LIST Part No.
75 SPACERBUMPER 5/8" x 1/4" 350143 4
76 SPACERBUMPER 5/8" x 1/2" 350144 44
item PARTS PR500 QTY
no. LIST Part No.
57 LOCK WASHER 5/16 TWISTEDTOOTH 430298 1
58 SCREWCAP5/16 - 24 X 1" GR. 5 400164 1
80 SHAFT SLICING WA 350142 1
81 BLADESLICING REEL 350147 20
82 PLATEBLADEMTG. 350253 20
83 SPACERBLADEMTG. 350254 10
84 SPACER BLADEASSY 350150 9
85 SCREWCAP1/4-20 x 3/4, GR. 5 350151 40
86 NUT LOCK 1/4-20 8142004 40
87 COLLARSPACER 350152 1
88 WASHER 0.937 x 1.750 x 0.119 350153 1
89 WASHER LOCK 7/8 INT. TOOTH 350154 1
90 NUT JAM7/8-14 350155 1

Part No. 350245 Form No. F021604A
Page 12 of 12
TROUBLESHOOTING Before Requesting Service Review These Suggestions
Engine stalls or la ors when raking. Raise lades so that they just touch the ground on a
level surface.
Solution
Possible Cause
Problem
Blades set too deep into ground
2
Engine Service and Warranty
Contact your nearest engine manufacturer's
authorized servicing dealer. (See page 7)
22.1 22
B LLY GOAT NDUSTR ES NC.
1803 S.W. JEFFERSON / LEE'S SUMMIT, MO 64082-2312 / USA
PHONE: [phone] FAX: [phone] www. illygoat.com
WARRANTY PROCEDURE
Purchased
from
Purchase
Date
21 Serial Plate Record your machine model, serial number and
date-of-purchase and where purchased
R
min-1
1803 S. Jefferson
Lee's Summit,
MO 64062 / USA
Tel [phone]
Fax [phone]
Model Serial No.
Unit(Weight) Engine Power
lbs. kg kW rpm
A normal vi ration.
Engine will not start.
Engine is locked, will not
pull over.
De ris locked against reel, or drive pulleys. Engine
pro lem.
Check stop switches, throttle, choke position and
gasoline. Connect spark plug wire. Clean or replace
air cleaner. Contact a qualified service person.
Stop work immediately. Replace any damaged or
missing lades. Tighten all loose olts and nuts.
Damaged or missing lades. Loose handle olts.
Loose engine olts
Stop switch off (Honda only). Throttle in off position.
Engine not in full choke position. Out of gasoline. Bad
or old gasoline. Spark Plug wire disconnected. Dirty air
cleaner. Engine oil level too low (Honda only).
Pull spark plug wire and remove de ris. Contact an
engine servicing dealer for engine pro lems.
MODEL NO.
GENERAL ENGINE SPECIFICATIONS
HORSEPOWER
ENGINE
HONDA 5. GC16 AQHA
GOVERNED RPM
36
ENGINE
When servicing engine refer to specific manufacturers engine
owner's manual. All engine warranty is covered y the specific
engine manufacturer. If your engine requires warranty or other
repair work contact your local servicing engine dealer. When
contacting a dealer for service it is a good idea to have your engine
model num er availa le for reference(See ta le page a ove). If
you can not locate a servicing dealer in your area you can contact
the manufacturers national service organization.
To reach:
American Honda: 800-426-7701
Never store engine indoors or in enclosed poorly ventilated
areas with fuel in tank, where fuel fumes may reach an open flame,
spark or pilot light, as on a furnace, water heater, clothes dryer or
other gas appliance.
If engine is to be unused for 3 days or more, prepare as follows:
Remove all gasoline from car uretor and fuel tank to prevent
gum deposits from forming on these parts and causing possi le
malfunction of engine. Drain fuel outdoors, into an approved
container, away from open flame. Be sure engine is cool. Do not
smoke. Run engine until fuel tank is empty and engine runs out of
gasoline.
NOTE: Fuel sta ilizer (such as Sta-Bil) is an accepta le alternative in minimizing
the formation of fuel gum deposits during storage. Add sta ilizer to gasoline in
fuel tank or storage container. Always follow mix ratio found on sta ilizer
container. Run engine at least 10 min. after adding sta ilizer to allow it to reach
the car uretor.
UNIT STORAGE
R
99 dB
Should a Billy Goat Machine fail due to a defect in material and/or
workmanship, the owner should make a warranty claim as follows:
-The Machine must be taken to the dealer from whom it was purchased
or to an authorized Servicing Billy Goat Dealer.
-The owner must present the remaining half of the Warranty
Registration Card, or, if this is not available, the invoice or receipt.
-The Warranty Claim will be completed by the authorized Billy Goat
Dealer and submitted to their respective Billy Goat Distributor for their
territory. Attention: Service Manager. Any parts replaced under
warranty must be tagged and retained for 90 days.
-The distributor service manager will sign off on the claim and submit
it to Billy Goat for consideration.
-The Technical Service Department at Billy Goat will study the claim
and may request parts to be returned for examination. Billy Goat will
notify their conclusions to the distributor service manager from whom
the claim was received.
-The decision by the Quality / Service department at Billy Goat to
approve or reject a Warranty claim is final and binding.
Note: To process a Warranty Claim, it is necessary to quote the Model & Serial
Number which are printed on the Billy Goat Serial Plate (See owner’s manual).
