CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
2
ABOUT THIS MANUAL
THANK YOU for purchasing a BILLY GOAT®CR Power Rake. Your new machine has been carefully designed and
manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance
instructions that will help to maintain your machine in top running order. Read this manual carefully before assembling,
operating, or servicing your equipment.
CONTENTS
SPECIFICATIONS/SOUND AND VIBRATION 3
INTENDED USE & INSTRUCTION LABELS 4
PACKING CHECKLIST & ASSEMBLY 5
OPERATION 6-7
MAINTENANCE 8-9
TROUBLESHOOTING AND WARRANTY PROCEDURE 9
PART ILLUSTRATION & PARTS LIST 10-13

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
3
SPECIFICATIONS
CR550H CR550HC CR550HCEU
Engine: HP
5.4 (4.0kW)
5.0 (3.73 kW)
5.0 (3.73 kW)
Engine: Model
X160TQX2
GC160AQHA
GC160AQHL
Engine: Type
HONDA OHC
HONDA OHC
HONDA OHC
Engine: Fuel Capacity
3.8 qt (3.6L)
2.1 qt (2.0 L)
2.1 qt (2.0 L)
Engine: Oil Capacity
0.63 qt (0.6L)
0.63 qt. (0.6 L)
0.63 qt. (0.6 L)
Total Unit Weight:
125# (56.8 kg)
125# (56.8 kg)
125# (56.8 kg)
Max. operating slope
20o
20o
20o
In accordance with 2000/14/EEC standards
99 dB(a)
99 dB(a)
99 dB(a)
Sound at operator’s ear
81 dB(a)
81 dB(a)
81 dB(a)
Vibration at operator position
1.01g (9.94 m/s2)
1.01g (9.94 m/s2)
1.01g (9.94 m/s2)
SOUND
SOUND LEVEL 81 dB(a) at Operator Position
Sound tests were conducted in accordance with 2000/14/EEC, and were performed on 2-9-2002 under the conditions listed
below.
Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for
the sound power level for your model.
VIBRATION DATA
VIBRATION LEVEL 1.01g (9.94m/s2)
Vibration levels at the operator’s handles were measured in the vertical, lateral and longitudinal directions using calibrated
vibration test equipment. Tests were performed on 5-25-2006 under the conditions listed below.
General Conditions: Sunny
Temperature: 43oF (6.1oC)
Wind Speed: 10 mph (16.1 kmh)
Wind Direction: North West
Humidity: 82.2%
Barometric Pressure: 29.72Hg (754 mm Hg)
General Conditions: Sunny
Temperature: 72.32oF (22.4oC)
Wind Speed: 3.8 mph (6.12kph)
Wind Direction: East
Humidity: 62.2%
Barometric Pressure: 29.9Hg (101.3kpa)
99

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
4
INTENDED USE
INTENDED USE
This machine is designed for removing thatch from your lawn, renovation of existing lawns, and to assist in overseeding
operations. The machine should not be used for any other purpose than that stated above.
DO NOT operate if excessive vibration occurs. If excessive vibration occurs, shut engine off immediately and check for
damaged or worn reel, loose pulley bolts or set screws, loose engine or lodged foreign objects. (See troubleshooting section on
page 9).
INSTRUCTION LABELS
The labels shown below were installed on your BILLY GOAT®CR Power Rake. If any labels are damaged or missing, replace
them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for
convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and
Item numbers shown.
LABEL DANGER KEEP HANDS LABEL CLUTCH ITEM #49 DANGER FLYING DEBRIS
AND FEET AWAY P/N 830503 ITEM # 48 P/N 810736
ITEM #51 P/N 400424
LABEL CAUTION GUARD LABEL EXPLOSIVE FUEL LABEL INSTRUCTION HEIGHT ADJ.
ITEM #52 P/N 900327 ITEM # 50 P/N 400268 ITEM #35 P/N 350224
ENGINE LABELS/CONTROLS
Controls CR550H
Fuel Valve Throttle
Choke
HONDA

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
5
PACKING CHECKLIST
NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts List on pages 10-11.
Your Billy Goat Power Rake is shipped from the factory in one carton, completely assembled.
PUT OIL IN ENGINE BEFORE STARTING
ASSEMBLY
READ all safety instructions before assembling unit.
TAKE CAUTION when removing the unit from the box the Handle Assembly is attached and folded over.
NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts list on pages 10-11.
1. UNFOLD the upper handle (item 26) and slide handle lock loops (item 28) into place to secure the upper handle to the
lower.
2. CHECK engine oil level and fill to proper level with engine manufacturers recommended grade of oil. Move height adjust
lever to down position, to level engine during checking. See engine manufacturer’s instruction manual.
3. CONNECT spark plug wire.
Boxing Parts Checklist
Honda GC 5.0
OHC
Literature Assy
P/N-350243
PARTS BAG & LITERATURE ASSY
Warranty card P/N- 400972, Owner’s Manual P/N-350245, Declaration of Conformity P/N-350139, General Safety and
Warnings manual P/N-100295, and Literature CR Accessories 350246.
28
28
26

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
6
OPERATION
STARTING ENGINE
See engine manufacturer’s instructions for type and amount of oil and gasoline used. Engine must be level when checking and
filling oil and gasoline.
FUEL VALVE: Move fuel valve to "ON" position (when provided on engine).
STOP SWITCH: Located on the engine. "slow/stop" position.
CHOKE: Operated with choke lever on side of engine.
THROTTLE: Controlled by throttle lever on the motor.
If your unit fails to start, check the troubleshooting section on page 9 and also see the engine manual.
SLICING OPERATION
NOTE: NEVER PARK THIS UNIT ON A SLOPE OF ANY KIND. Always keep
the reel in the up position when parking the unit.
BLADE POSITION & DEPTH CONTROL LEVER: The blades can be raised or
lowered into the ground by height adjustment lever on the engine base. The
resulting blade depth can be adjusted higher or lower. (See Fig. 1 & 2)
ADJUSTING BLADE DEPTH: The depth of the blades can be raised or lowered by
rotating the knob on the top of the adjustment lever. The blades are lowered by
rotating the knob counter-clockwise, and raised by rotating the knob clockwise. The
relative depth of the blades can be gauged by using the depth scale located on the
right front corner of the engine base. (See Fig. 3)
FOLDING HANDLE: This unit is equipped with a folding upper handle for easier
storage and transportation. The handle can be folded by sliding the handle lock
loops up (item 28). This releases the upper handle, allowing it to be folded over
the unit.
HANDLING & TRANSPORTING:
This unit requires two people to lift it. With
the handle in the folded position, lift holding the lower handle and belt/shaft guard
one on each side of the machine. Secure the machine in place during transport.
Never lift the machine while the engine is running.
RAKING OPERATION
SET DEPTH: With engine off, set the raking depth so that the blades just touch on a flat surface (i.e. driveway, or sidewalk).
ENGAGE BLADES: Pull back on the bail on the operators handle. NOTE: When engaging the blades in heavy load conditions,
i.e. heavy thatch or very uneven turf, push down on the operators handle lifting the front wheels slightly. Engage the blades.
Slowly lower the unit into the turf.
RAKE: Rake a small test area and examine the results. Thatch should be removed and deposited on top of the healthy grass. If
excessive damage occurs to healthy grass, adjust the blade depth to decrease damage. Continue raking the yard, working in
one direction (i.e. north-south, or east-west). NOTE: If a large drop in engine RPM occurs, or the unit pulls you forward and
bounces during operation, the blade depth is set too low.
REMOVE THATCH: After raking, a layer of thatch will be deposited over the top of the lawn. This thatch must be removed prior
to any fertilizing, seeding, or watering of the lawn. We suggest the use of a lawn vacuum or wheeled blower for collection and
removal of the thatch.
Fig. 1
Fig. 2
Fig. 3
STORAGE: Never store engine indoors or in enclosed poorly ventilated areas
with fuel in tank, where fuel fumes may reach an open flame, spark or pilot light, as
on a furnace, water heater, clothes dryer or other gas appliance.
If engine is to be unused for 30 days or more, prepare as follows:
Remove all gasoline from carburetor and fuel tank to prevent gum deposits from forming on these
parts and causing possible malfunction of engine. Drain fuel outdoors, into an approved container,
away from open flame. Be sure engine is cool. Do not smoke. Run engine until fuel tank is empty and
engine runs out of gasoline.

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
7
VERTI-CUTTING OPERATION
SET DEPTH: With engine off, set the raking depth so that the blades just touch on a flat surface (i.e. driveway, or sidewalk).
ENGAGE BLADES: Pull back on the bail on the operator’s handle. NOTE: When engaging the blades in heavy load conditions (i.e.
heavy thatch, or very uneven turf), push down on the operator’s handle lifting the front wheels slightly. Engage the blades. Slowly
lower the unit into the turf.
SLICE: Verti-cut a small test area and examine the results. Some thatch and cut stems should be removed and deposited on top of
the healthy grass. Grass runners should be cut and ready for removal. If excessive damage occurs to healthy grass, adjust the
blade depth to decrease damage. Continue raking the yard, working in one direction (i.e. north-south, or east-west). NOTE: If a large
drop in engine RPM occurs, or the unit pulls you forward and bounces during operation, the blade depth is set too low.
REMOVE THATCH/STEMS: After verti-cutting, a layer of thatch and cut stems will be deposited over the top of the lawn. We
suggest the use of a lawn vacuum or wheeled blower for collection and removal of the thatch/stems.
*****TIPS*****
MOW
Mow the lawn to its normal cut height.
DRY
Be sure grass is dry. Wet conditions can cause increased damage to healthy grass.
INSPECT
Check the lawn before beginning work. Remove all rocks, wire, string, or other objects that can present a hazard during work prior
to starting.
IDENTIFY
Mark all fixed objects to be avoided during work, such as sprinkler heads, water valves, buried cables, or clothes line anchors, etc.
THATCH
Thatch is a dense layer of dead grass, clippings, and roots that builds up over time at the base of the lawn preventing air, water,
and fertilizer from reaching the soil. This can cause shallow root development and make a lawn more susceptible to drought and
disease. Thatch also provides an ideal environment for insects to hide and multiply. Periodic removal of thatch will keep your lawn
in good health.
HEAVY THATCH
Lawns with an excessive amount of thatch will require multiple treatments for effective removal. Trying to remove excessive thatch
(greater than 3/4"[19 mm] deep) in one treatment will damage or destroy the living part of the lawn. It is best to remove heavy
thatch in seasonal treatments (i.e. spring, and fall).
CHECK
Before beginning, it is best to evaluate the condition of the lawn by cutting one or more core samples from the area to be treated.
A core can be cut using a piece of pvc, or metal pipe. Hammer the pipe into the ground, remove it, push the core out of the pipe
and inspect it to determine the depth of thatch in your yard.
SLOPES
Rake slopes across not up and down the slope. This is much easier and safer for the operator and is better for the lawn. Raking
across will help to reduce runoff during watering and allow the sloped ground to hold more seed, fertilizer, and water. The units
maximum operating slope is 35% or 19°.
DEPTH
The wide range of depth adjustment on your unit is provided to allow for blade wear. Setting the reel deeper will not produce
better, or quicker results. The flail reel is intended to be set so it just touches the surface on flat ground. The slicing reel should be
set even with the ground for verti-slicing work, and set to a maximum 1/2" depth for overseeding jobs. Setting the reel deeper than
this will only result in premature wear on the unit (i.e. failed belt). If you desire to work the ground deeper than the above
guidelines allow, it should be done gradually in multiple passes.

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
8
MAINTENANCE
PERIODIC MAINTENANCE
NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts List on pages 10-11.
Periodic maintenance should be performed at the following intervals:
Maintenance Operation
Every Use (daily)
Every 25 Hours
Inspect for loose, worn or damaged parts

Check engine oil

Inspect belt

Engine (See Engine Manual)
Grease reel bearings

Inspect and clean engine air filter

Oil height adjustment linkage

FLAIL BLADE WEAR
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine. (Honda only)
3. Lean unit back onto lower handles and secure in place.
4. Inspect blades for wear, and immediately replace any bent, or cracked
blades. Measure the overall length of the blade. (See Fig. 4)
5. If blades measure less than 3.0"(76 mm) in overall length, they must be
replaced. NOTE: We recommend replacing all the flails at once.
SLICING BLADE WEAR
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine. (Honda only)
3. Lean unit back onto lower handles and secure in place.
4. Inspect blades for wear, and immediately replace any bent or cracked blades. Measure the overall length of
the blade from the center of the attachment bolts to the tip of the worn blade.
5. If blades measure less than 3.0"(76 mm) they must be replaced. NOTE: We recommend replacing all the
blades at once.
ROTATING FLAIL REEL END TO END
To maximize flail blade life and performance, the reel can be rotated end to end periodically to provide a fresh lead cutting edge.
Takes approx. 20 min. and requires two 1/2" socket wrenches with extension bar.
1. Wait for engine to cool and disconnect spark plug.
2. Close fuel valve on engine.
3. Lean unit back onto lower handles and secure in place.
4. Remove six screws (item 65) holding the belt and shaft guards (item 21 & 22) in place. It is necessary to lower the height
adjust lever to reach the locknuts on the guards. Remove the guards.
5. Remove the drive belt (item 9) by "walking" it out of the groove on the reel pulley (item 2).
6. Remove the four lock nuts (item 47) and washers (item 35) holding the bearings (item 23) to the frame of the unit.
7. The reel (item 6) is now free from the machine. Slide the reel down and out of the machine.
8. Remove the capscrew (item 58), lock washer (item 57), reel pulley (item 2), key (item 75), and reel spacer (item 10) from the
end of the reel.
9. Rotate the reel end to end, and re-install these items on the opposite end of the reel.
10. Re-install the reel in reverse order of removal. Re-install the guards in reverse order of removal.
Fig. 4

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
9
TROUBLESHOOTING
DRIVE BELT REPLACEMENT
NOTE: Takes approx. 10 min. and requires 3/8" socket wrench with extension.
1. Wait for engine to cool and disconnect spark plug.
2. Remove six self-tapping screws (item 65) holding the belt guard (item 21 & 22) in place. Remove the guard.
3. Remove the belt (item 9) by rotating the reel pulley (item 2) and walking it out of the groove. Discard old belt
4. Install new belt using same procedure to walk the belt into the groove.
5. With new belt installed, pull bail rod back to engaged position and measure extension of idler spring. Spring should stretch
1" to 1.25" (25-32 mm) with bail engaged. Adjust clutch cable as necessary to achieve this extension.
6. Re-install the belt guard.
Problem Possible Cause Solution
Abnormal vibration
Damaged or missing blades.
Loose handle bolts. Loose engine
bolts.
Stop work immediately. Replace any
damaged or missing blades. Tighten
all loose nuts and bolts.
Engine stalls or labors when
raking
Blades set too deep into ground.
Raise blades so that theyjust touch
the ground on a level surface.
Engine will not start Throttle in offposition. Check choke position.
Out of gasoline or bad, old
gasoline.
Check gasoline.
Spark plug wire disconnected. Connect spark plug wire.
Gas valve off. Turn on gas valve.
Dirtyair cleaner.
Clean or replace air cleaner. Contact a
qualified service person.
Engine is locked, will not pull
over
Debris locked against reel, or drive
pulleys. Engine problem.
Pull spark plug wire and remove
debris. Contact an engine servicing
dealer for engine problems.

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
10
CR PARTS DRAWING

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
11
CR PARTS LIST
item PARTS CR550HC QTY CR550HCEU QTY CR550H QTY
no. LIST Part No. Part No. Part No.
1 Pulley 3.0" O.D. 350101 1350101 1350101 1
2 Pulley 5.5" O.D. X¾" 350206 1350206 1350206 1
3 Wheel 8" Semi-Pneu White 350236 4350236 4350236 4
4 Bar Strap 350211 1350211 1350211 1
5 Rod Height Wa 350220 1350220 1350220 1
6 Reel Flail Assy (see page 10 & 11 for parts list and detailed dwg.) 350241-S 1 350241-S 1 350241 1
7 Pulley Idler 2.75" 350114 1350114 1350114 1
8 Arm Idler WA 350115 1350115 1350115 1
9 Belt 5L X34" 350207 1350207 1350207 1
10 Spacer Reel Pulley 350118 1350118 1350118 1
11 Bracket Belt Finger 350208 1350208 1350208 1
12 Chassis WA W/ Label 350235 1350235 1350235 1
13 Frame Front WA 350213 1350213 1350213 1
14 GRIP 1" x 13" 400570 2400570 2400570 2
15 Label Instr. Hgt. Adj. 350224 1350224 1350224 1
16 Link Height Bar 350223 2350223 2350223 2
17 Knob Height Adj. 850154 1850154 1850154 1
18 STUD 3/4"-10 X5 1/2" PLTD 810538 1810538 1810538 1
19 LOCKNUT ASSY 800227 1800227 1800227 1
20 WASHER 3\4" NYLON 800109 1800109 1800109 1
21 Guard Belt Top Wa 350248 1350248 1350248 1
22 Guard Belt Bottom Wa 350249 1350249 1350249 1
23 Bearing ¾" Cast Flange 350209 2350209 2350209 2
24 Handle Lower LH WA 350134 1350134 1350134 1
25 Handle Lower RH WA 350135 1350135 1350135 1
26 Handle Upper PR500 350136 1350136 1350136 1
27 Bail Clutch WA 350137 1350137 1350137 1
28 Loop Folding Handle 350138 2350138 2350138 2
29 Deflector Rubber 350210 1350210 1350210 1
30 Guard Shaft CR 350250 1350250 1350250 1
31 PIN LIFTFRONT 3/8" X21 3/16" Long 350212 1350212 1350212 1
32 PIN COTTER 1/8" X1" Z/P 900471 1900471 1900471 1
33 SCREWCAP 5/16-24x3/4" GR5 8042026 28042026 28042026 2
34 SCREWCAP 5/16 - 18 x 1 1/2 8041030 68041030 68041030 6
35 WASHER 1/4" FLAT Z/P 8171002 13 8171002 13 8171002 13
36 SCREWCAP 1/4"-20X1.5" 8041008 18041008 18041008 1
37 BELT FINGER WIRE 350301 1350301 1350301 1
38 Cable Clutch Reel PR500 350181 1350181 1350181 1
39 Spring Extension 350300 1350300 1350300 1
40 Bolt Shoulder 1/2" X1" 500114 1500114 1500114 1
41 ENGINE HONDA 5.0 HP (CR550HC), HONDA 5.5 (CR550H) 430272 1430272 1600115 1
ENGINE HONDA 5.5 HP (CR550H) 600115 1600115 1
ENGINE HONDA 5HP (CR550HCEU 350426EU 1
42 KEY 3/16" X1" 9201078 19201078 19201078 1
43 NUT1/2 - 13 JAM 8162005 48162005 48162005 4
44 WASHER 1/2 SAE 8172011 88172011 88172011 8
45 SCREWCAP 1/2-13 x 3" Z/P 8041102 48041102 48041102 4
46 SCREWCAP 5/16"-18X1 1/4" HCS ZP 8041029 58041029 58041029 5
47 NUT LOCK 5/16-18 8160002 13 8160002 13 8160002 13
48 LABEL DANGER THROWN OBJECT 810736 1810736 1810736 1
49 LABEL CLUTCH VQ 830503 1830503 1830503 1
51 LABEL WARNING 400424 2400424 2400424 2
52 LABEL DANGER GUARD 900327 1900327 1900327 1
53 PLUG CAP 1" RD 890132 2890132 2890132 2
54 BOLT CARRAIGE 3/8-16 x 1 3/4 8024061 48024061 48024061 4
55 BOLT CARRAIGE 5/16-18 x 1 3/4 8024043 28024043 28024043 2
56 SCREWCAP 1/4-20x1" 8041006 48041006 48041006 4
57 LOCK WASHER TWISTED TOOTH 400502 1400502 1430502 2
58 SCREWCAP 3/8-16x1" REEL ASSEMBLY 8041050 18041050 18041050 1
60 NUT LOCK 3/8-16 8160003 58160003 58160003 5
61 NUT LOCK 3/8-16 THIN 8161042 18161042 18161042 1
62 NUT LOCK 1/4-20 8160001 58160001 58160001 5
63 WASHER 5/16 FLAT CUT 8171003 28171003 28171003 2
64 SCREWCAP 3/8-16x1.5" 8041052 18041052 18041052 1
65 SCREWCAP SHEET METAL DRILL POINT 1/4X3/4 430208 6430208 6430208 6
67 SCREW MACH. #10-24X2" 8059143 18059143 18059143 1
69 Knob Height Adj. 430128 1430128 1430128 1
70 WASHER 5/16 SAE 8172009 18172009 18172009 1
71 SPACER CRANK CR HONDA 350338 1350338 1350338 1
72 SCREWCAP 5/16-24 x 1 1/4" GR. 8 400389 1400389 1400389 1
74 WASHER TWISTED TOOTH 400389 1400389 1400389 1
75 KEY 3/16" X5/8" 9201072 19201072 19201072 1
76 3/8 FLAT CUT WASHER 8171004 58171004 58171004 5
77 LABEL SPARK ARRESTOR 100256 1100256 1100252 1

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
12
FLAIL SHAFT KIT 350185
FLAIL BLADE KIT 350251
FLAIL REEL ASSY 350241-S
item PARTS QTY
no. LIST Part No.
73 SHAFT FLAIL BLADE 350141 4
74 BLADE FLAIL 350205 60
76 SPACER BUMPER 5/8" x 1/2" 350144 54
77 SHAFT WA FLAIL REEL 350145 1
78 CLIP LOCK 1/2" 350146 8
79 WASHER 1/2 SAE 8172011 8
item
PARTS
Part No. QTY
no. LIST
73 SHAFT FLAIL BLADE 350141 4
78 CLIP LOCK 1/2" 350146 8
item
PARTS
Part No. QTY
no. LIST
74 BLADE FLAIL 350205 60
78 CLIP LOCK 1/2" 350146 8

CR POWER RAKE Owner’s Manual
Part No 350245 Form No F030515D
13
SPACER BUMPER KIT 350258
SLICING BLADE KIT 350187
item PARTS QTY
no.
LIST
Part No.
76 SPACER BUMPER 5/8" x 1/2" 350144 54
SLICING REEL ASSY 350252
item PARTS PR500 QTY
no. LIST Part No.
57 LOCK WASHER 5/16 TWISTED TOOTH 430298 1
58 SCREWCAP 5/16 - 24 X 1" GR. 5 400164 1
80 SHAFT SLICING WA 350142 1
81 BLADE SLICING REEL 350147 20
82 PLATE BLADE MTG. 350253 20
83 SPACER BLADE MTG. 350254 10
84 SPACER BLADE ASSY 350150 9
85 SCREWCAP 1/4-20 X 3/4 HCS ZP 8041004 40
86 NUT LOCK 1/4-20 8142004 40
87 COLLAR SPACER 350152 1
88 WASHER 0.937 x 1.750 x 0.119 350153 1
89 WASHER LOCK 7/8 INT. TOOTH 350154 1
90 NUT JAM 7/8-14 350155 1
item
PARTS
PR500 QTY
no.
LIST
Part No.
81 BLADE SLICING REEL 350147 20
85 SCREWCAP 1/4-20 X 3/4 HCS ZP 8041004 40
86 NUT LOCK 1/4-20 8142004 40
