Bilt Trinity TLS-0408 User manual
OWNER’S MANUAL
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
TRINITY 43"x25" STAINLESS STEEL TOOL CHEST - COMBO
Model # TLS-0408
Your TRINITY 43"x25" Stainless Steel Tool Chest –Combo should include the following parts. Please
inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
You will need 10mm wrench (for handles), 14mm wrench (for casters) and Phillips screwdriver for
assembly. Not included.
PARTS LIST
TOP CHEST (1)
A
SIDE HANDLE (4)
C D
CASTER BOLT (16)
M10
E
LINER (12)
F
JK
HANDLE BOLT (24)
M6
LOCKING
CASTER (2)
G
NON-LOCKING
CASTER (2)
KEY (4)
© 2020 TRINITY - 800.985.5506
1
BOTTOM CHEST (1)
B
REAR BRACE (2)
H
BRACE SCREW (8)
I
ASSEMBLY INSTRUCTIONS
Position SIDE HANDLE (C) over pre-installed nuts
on side of TOP CHEST (A). Insert HANDLE BOLTS
(D) through holes on SIDE HANDLE (C). Use a
10mm socket wrench to fully tighten HANDLE
BOLTS (D) to TOP CHEST (A).
Repeat to install all remaining SIDE HANDLES (C).
Be sure to assemble SIDE HANDLES (C) on both
TOP CHEST (A) and BOTTOM CHEST (B) to make it
easier to move your Tool Chest.
AC
D
© 2020 TRINITY - 800.985.5506 2
STEP 1
STEP 2
10mmA (1) C (4) D (24)
Location of parts:
1) 2 KEYS (K) are hooked to key leash mounted
inside TOP LEFT drawer of TOP CHEST (A)
2) 2 KEYS (K) are hooked to key leash mounted
inside TOP drawer of BOTTOM CHEST (B).
3) 2 SIDE HANDLES (C) / 12 HANDLE BOLTS (D)
and 7 LINERS (J) for TOP CHEST (A) are inside
TOP lid.
4) 2 SIDE HANDLES (C) / 12 HANDLE BOLTS (D) /
4 CASTERS (E/F) / 16 CASTER BOLTS (G) / 2
REAR BRACES (H) / 8 BRACE SCREWS (I) and 5
LINERS (J) for BOTTOM CHEST (B) are inside
BOTTOM drawer.
1
2
4
3
B (1)
ASSEMBLY INSTRUCTIONS
© 2020 TRINITY - 800.985.5506
3
STEP 3
E (2) F (2) G (16)
Carefully lay BOTTOM CHEST (B) on its backside.
Two people are needed. Do NOT attempt this alone.
Position LOCKING CASTERS (E) on side of BOTTOM
CHEST (B) of your choice and align holes to pre-
installed nuts on underside of BOTTOM CHEST (B).
Use a 14mm socket wrench to fully tighten CASTER
BOLTS (G) to BOTTOM CHEST (B).
Repeat to install NON-LOCKING CASTERS (F).
Notes:
* Make sure to install both LOCKING CASTERS (E) on
same side of tool chest.
** For ease of use, place LOCKING CASTERS (E) on
side you will regularly push or pull.
*** If you plan to push tool chest against a wall,
place LOCKING CASTERS (E) on front long side for
ease of access.
14mm
B
H (2)
STEP 4
EFG
I (8)
B (1)
With two people, stand BOTTOM CHEST (B) back
up, carefully place TOP CHEST (A) on top of
BOTTOM CHEST (B). Be sure to assemble REAR
BRACES (H) to secure TOP CHEST (A) to BOTTOM
CHEST (B).
Position REAR BRACE (H) over pre-installed nuts
at back edge where two CHESTS (A+B) adjoin.
Insert BRACE SCREWS (I) to holes on REAR
BRACE (H) and tighten securely.
Repeat to install second REAR BRACE (H).
Phillips
A
B
H
I
ASSEMBLY INSTRUCTIONS
STEP 5
J (12)
J
© 2020 TRINITY - 800.985.5506 4
Place LINERS (J) inside top compartment and
inside each drawer.
USAGE INSTRUCTIONS
DRAWER REMOVAL
DRAWER REPLACEMENT
© 2020 TRINITY - 800.985.5506
5
Pull drawer out so that it is almost fully extended. On RIGHT-hand side, push black release lever DOWN.
On LEFT-hand side, pull black release lever UP. While holding levers as instructed, pull drawer forward
until released from slides attached to tool chest (“Tool Chest Slides”).
Note: Slides attached to drawer (“Drawer Slides”) are an integral part of drawer and must be removed
along with drawer itself.
To replace drawer, pull slides out completely. Insert brackets on each side of Drawer Slides into
corresponding slots on Tool Chest Slides, making sure they are properly positioned. Once brackets are
inserted into slots, completely close drawer to set all slides in their proper positions.
Part Number Description Part Number Description
1) XBS-17-003-4325 Top Lid 11) XBK-22-001-4122 Top Liner
2) XST-09-017-
0001
Top Lid Hinge 12) AMA-05-019-2100 21” Drawer handle
3) AMA-05-019-1400 14” Drawer Handle 13) ZSV-12-001-2000 Slide (drawer side)
4) XBS-07-014-1506 15” Small Drawer 14) ZSV-12-015-2000 Slide (tool chest side)
5) ZSV-01-001-0612 Handle Bolt 15) XBS-07-014-2203 22” Small Drawer
6) XSV-05-001-1100 Side Handle 16) CSV-11-001-0XXX Lock
7) XBS-07-014-1509 15” Large Drawer 17) PBK-09-002-0002 Gas Lift
8) XBS-07-014-2206 22” Large Drawer 18) XBK-10-001-0XXX Key
9) XBK-22-001-2015 15” Drawer Liner 19) XBK-02-047-0001 Key leash
10) XBK-22-001-2022 22” Drawer Liner
TRINITY Customer Service provides the following replacement parts:
5
10
2
6
3
8
11
14
15
18
12 7
16
1
4
13
17
SERVICE PARTS LIST –TLS-0408: TOP CHEST
NOTE: Replacement keys may be ordered using the code shown on the face of lock. Top and
Bottom Chests may have different key codes.
9
© 2020 TRINITY - 800.985.5506 6
19
7
SERVICE PARTS LIST –TLS-0408: BOTTOM CHEST
Part Number Description Part Number Description
1) XBK-22-001-2239 Drawer Liner 10) ZSV-12-001-2200 Slide (drawer side)
2) CSV-11-001-0XXX Lock 11) ZSV-12-015-2200 Slide (tool chest side)
3) XBS-07-015-3903 Small Drawer 12) ZSV-01-001-0612 Handle Bolt
4) XBS-07-015-3906 Medium Drawer 13) XSV-05-001-1100 Side Handle
5) AMA-05-019-3800 Drawer Handle 14) ZSV-01-004-0410 Brace Screw
6) XBS-07-015-3909 Large Drawer 15) ZSV-19-003-0275 Rear Brace
7) ZSV-01-001-1020 Caster Bolt 16) XBK-02-047-0001 Key leash
8) ZSV-99-002-5020 Non-locking Caster 17) XBK-10-001-0XXX Key
9) ZSV-99-001-5020 Locking Caster
TRINITY Customer Service provides the following replacement parts:
6
2
7
3
9
8
1
5
11
14
15
12
16
13
17
4
NOTE: Replacement keys may be ordered using the code shown on the face of lock. Top and
Bottom Chests may have different key codes.
© 2020 TRINITY - 800.985.5506
7
10
WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
5. Do NOT overload the product. Below capacity is based on evenly distributed weight.
6. Lock casters when leaving tool chest in stationary position.
7. Lock drawers and lid before moving tool chest.
8. Do NOT open more than one drawer at a time. Tipping can occur.
9. Do NOT step or lean on open drawers. Tipping can occur.
10. Do NOT let children play near tool chest.
11. Load tool chest starting with bottom drawers to prevent tool chest from tipping
12. Make sure all drawers are closed tightly before locking or unlocking.
Weight capacity per drawer w/ 1 pair of slides 45.4 kg / 100 lb
Weight capacity per drawer w/ 2 pairs of slides 90.7 kg / 200 lb
Total weight capacity of tool chest combo 997.9 kg / 2200 lb
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals. Do not use scouring pad for
cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
© 2020 TRINITY - 800.985.5506 8
Thank you for purchasing a TRINITY 43”x25” Stainless Steel Tool Chest - Combo. In order to register
your product and receive streamlined customer service, please fill out the following Product
Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form
online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. Include a
copy of your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TLS-0408 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION
© 2020 TRINITY - 800.985.5506
9
1 YEAR LIMITED WARRANTY
TRINITY 43”x25” Stainless Steel Tool Chest - Combo
Model # TLS-0408
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY 43”x 25” Stainless Steel Tool Chest-Combo (“Product”) that each Product shall be free from defects
in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation
under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product
which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity,
during the warranty period. All replaced parts and Products become the property of Trinity and must be
returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at (800) 985-5506, between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2020 TRINITY - 800.985.5506 10
TRINITY Customer Service
TEL: 800.985.5506
FAX: 310.347.4134
EMAIL: customerservice@trinityii.com
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
CONTACT US
Table of contents
