GAVI Folding Workbench User manual
GAVI FOLDING WORKBENCH INSTALLATION INSTRUCTIONS
Visit gavipop.com/foldingworkbench for installation videos and additional information.
Revised 3/22/16
The GAVI Folding Workbench is shipped in 2 BOXES (1 box containing the tabletop
and 1 box containing the metal parts). Note that the metal brackets are preassembled
in the middle table height position (approximate 36” table height). The table height can
be adjusted after installation. Table height adjustment instructions are on page 3.
Tools required for installation: #2 Square Drive Bit (included),
5/32” Allen Wrench (included), Phillips Head Screwdriver.
Step 1: On the wall where the workbench will be mounted, using a stud nder, nd the center of the stud for mounting
the left bracket. Place a reference mark at the center of the stud 68” from the oor. (See g. A)
Before you begin, decide where you are going to install the tabletop, making
sure you have at least a minimum of 52” of unobstructed wall space.
Disclaimer: The screws provided with the GAVI Folding Workbench are for wood stud installations only. Other applications
may require different screws for proper and safe use. It is the buyer’s responsibility to research, secure and use the right
screws for applications other than wood studs.
LEFT BRACKET INSTALLATION
68”
Step 2: Attach the left bracket through the 1st hole at the top, using the supplied
screw. (Black #8 x 2” long - Part# 21347-19) Do not tighten the screw all of the
way at this time. (See g. B)
Step 3: Use a level so the bracket is vertically straight. Make sure to place the
level against the at part of the bracket and not against any screw heads along
the side.
Step 4: Without moving the level, mark the center of the last hole at the bottom of
the bracket. Attach with a screw and tighten all of the way. Then, go back to the
top screw and nish tightening it all of the way.
Install rst
screw in rst
hole
Bracket Leg
Wall
Floor
Center of Stud
Wood Stud
Install second
screw in
bottom hole
A
B
GAVI FOLDING WORKBENCH INSTALLATION INSTRUCTIONS
Visit gavipop.com/foldingworkbench for installation videos and additional information.
Step 5: Unfold the bracket to attach three (3) more screws.
(See g. C) Tighten screws all of the way to properly secure
the bracket to the wall.
Step 6: Locate the center of the stud for mounting the right
bracket. It should be at least 24” away from the left bracket.
Step 7: Position the level on top of the left bracket extending
past the stud (for the right bracket), and make a reference
mark across the stud. (See g. C)
Step 8: Position the top of the right bracket even with the
reference line. Then repeat steps 2-5 to mount the right
bracket.
Step 9: Re-insert Safety Pins in the 7th hole from the bottom
in each bracket. (See g. D)
Step 10: Position the tabletop on the brackets so it is equally
spaced left and right, and 1¾” from the wall.
Step 11: Using the supplied screws, attach the tabletop to
the brackets. (Silver #10 x 3/4” long Part# 21347-5) 6 screws
total - (See g. E)
With the butcherblock tabletop, it’s recommended to pre-drill
1/8” holes ¾” deep.
The GAVI Folding Workbench is now ready to be used.
2
Tabletop
Safty Pins Safty Pins
Unfolded
Bracket
(3) Screws
for each bracket
Left Bracket
Right Bracket
Safety Pin
Reference
Mark
Level
C
D E
(3) screws
Visit gavipop.com/foldingworkbench for installation videos and additional information.
To store the tabletop in the
stored position, remove
the Safety Pins and slide
the tabletop all the way
up. Then re-insert the
safety pins.
42” Table Height:
1) To adjust the table height to 42”, start from the stored postion with the safety pins in place.
(See g.A1) Using the supplied allen wrench, unscrew and remove the bottom bolt, spacer,
and nut (do the same on the right side). (See g.A2 - exploded view)
2) Swing the tabletop out and reposition the bracket legs to the next higher holes. (See g.A3)
3) Put the bolt, spacer, and nut back in the hole and repeat on the other side.
4) Remove the Stop and reinstall on the 8th hole from the bottom (both left and right).
5) Slide tabletop down and replace Safety Pin in 4th hole from top. (See g.A4)
30” Table Height:
1) To adjust the table height to 30”, start from the stored postion. Remove Safety Pins and slide
tabletop down enough to re-insert the Safety Pins into the 3rd hole from the top. (See g.
B1) With the Safety Pins in place, use the supplied allen wrench, to unscrew and remove the
bottom bolt, spacer, and nut (do the same on the right side). (See g.B2 - exploded view)
2) Reposition the ends of the bracket legs to the bottom holes. (See g.B3)
3) Put the bolt, spacer, and nut back in the hole and repeat on the other side.
4) Remove the Stop and reinstall on the 4th hole from the bottom (both left and right).
5) Slide tabletop down and replace Safety Pin in 5th hole from bottom. (See g.B4)
GAVI FOLDING WORKBENCH INSTALLATION INSTRUCTIONS
3
TABLE HEIGHT ADJUSTMENT INSTRUCTIONS
Safety
Pin
Bolt,
Spacer,
and Nut.
Bracket Leg
Stop
Bracket Diagram
Storing Workbench
g.A2 - exploded view
g.B2 - exploded view
Bolt
Bracket Bracket Leg
Spacer
Nut
Bolt
Bracket Bracket Leg
Spacer
Nut
g.A3
g.B3
g.A4
g.B4
g.A1
g.B1
PARTS LIST
HARDWARE BAG CONTAINS:
Part #5 - 3/4” silver screws
Part #19 - 2” black screws
Part #20 - #2 Square Drive Bit
Part #21 - 5/32” Allen Wrench
Disclaimer: The screws provided with the GAVI Folding Workbench are for wood stud installations only. Other applications
may require different screws for proper and safe use. It is the buyer’s responsibility to research, secure and use the right
screws for applications other than wood studs.
Visit gavipop.com/foldingworkbench for installation videos and additional information. 4
GAVI FOLDING WORKBENCH INSTALLATION INSTRUCTIONS
20 21347-20 #2 SQUARE DRIVE BIT 1
21 21347-21 5/32” ALLEN WRENCH 1
