Supatool STP7726 User manual

Keys x 2
1
OPERATION MANUAL
PARTS LIST
STP7726
IMPORTANT:
THIS OPERATING MANUAL CONTAINS
IMPORTANT SAFETY INFORMATION.
READ CAREFULLY AND UNDERTAND ALL
INFORMATION BEFORE OPERATING TOOL
TROLLEY SAVE THIS MANUAL FOR
FUTURE USE.
40kg+
This product requires a two person lift
- use proper lifting techniques
Bunnings Weight Icons (2676) 30/3/04 10:11 AM Page 3
TOOLS & ASSISTANCE NEEDED
2 People Lift 10mm Spanner
12mm Spanner or
5mm Hex Key
or
Castor Handle
TOOL TROLLEY SPECIFICATIONS
Width Depth Height
Overall 758mm 461mm 957mm
Overall
(w/out Castors) 758mm 461mm 812mm
Small Drawers 583mm 400mm 57mm
Deep Drawers 583mm 400mm 132mm
Castor Size 114x38mm (4.5” x 1.5”) 2 x Locking
Weight 42.6kg
16 x 12mm Bolts
for Castors
7 x EVA Liners
CAUTION: TAKE SAFETY PRECAUTIONS
WHEN USING YOUR TOOLBOX
Non-Locking Castors x 2 Locking Castors x 2
4 x 10mm Bolts
for Handle
Trolley Handle
TOOL TROLLEY
6 DRAWER (660mm/26”)

2
Handle Installing
• Position the trolley side handle behind
the holes on the trolley.
• Attach with (4) bolts and tighten with an
adjustable wrench.
Note: The side handle can be mounted
to either side of the trolley.
Castor Installing (If applicable)
• Be sure the drawers are locked and lay
the trolley on its side.
• Secure castors to the unit using the
12mm bolts provided.
• Tighten with a 12mm spanner or
5mm hex key.
• Repeat this process for the castors on
the opposite of the trolley.
• Return the trolley to its upright position.
Caution: Do not over tighten the bolts.
Caution: Both locking castors must be
fitted to front of trolley.
Removing the Drawers
• Fully extend the empty drawer.
• Push up the right grey release lever while
pushing down the left grey release lever.
• Pull the drawer outward until it is
released from the drawer slide.
Re-Inserting The Drawers
• Extend the drawer slides.
• Insert the brackets on each side of the
drawer into the slots on the slides, being
careful that they are properly positioned.
• Once properly inserted, completely close
the drawer to set the slides in their
proper positions.
• Periodically tighten all hardware
• Periodically lubricate castors
• Lubricate the slides twice a year
• Lubricate the lock with graphite annually
• Use a damp Microfibre cloth to clean all surfaces
Push up the
right release lever
Pull down the
left release lever
1
2
1
1
2
3
ASSEMBLY INSTRUCTIONS
MAINTENANCE
STP7726
TOOL TROLLEY
6 DRAWER (660mm/26”)

REPLACEMENT PARTS
3
1 & 2
8
National Head Office
National Distribution and Showroom
3 Lakeview Dve, Caribbean Business Park
Scoresby Victoria 3179 Australia
E [e-mail]
W kincrome.com.au
Administration
T+61 3 9730 7100 F+ 61 3 9730 7199
ABN 41 007 185 006
Customer Service Centre
T1300 657 528 F1300 556 005
National Head Office
National Distribution and Showroom
3 Lakeview Dve, Caribbean Business Park
Scoresby Victoria 3179 Australia
E [email protected]
W kincrome.com.au
Administration
T+61 3 9730 7100 F+ 61 3 9730 7199
ABN 41 007 185 006
Customer Service Centre
T1300 657 528 F1300 556 005
Australia & Global UK & EU
www.kincrome.com.au www.kincrome.co.uk
[e-mail] [e-mail]
ITEM PART NO. DESCRIPTION QUANTITY
1 STP7779 Key Only (Specify Key Number) X 1 1
2 STP7778 Lock & Key 1
3 STP7736-3 Trolley Handle 1
4STP7726-3 Ball Bearing Slide (Pair) 6
5 STP7736-8 Castor Swivel x 1 2
6STP7736-9 Castor Swivel x 1 (Locking) 2
7 STP7736-10 Castor Bolt Pack 1
8 STP7726-4 EVA Mat Pack 7 Piece 1
TOOL TROLLEY
6 DRAWER (660mm/26”)
STP7726
3
4
5
6 & 7
Made to Supatool Premium global specifications
and quality standards in China
