Binatone ICARUS 1210 User manual

Icarus 1210 System
USER GUIDE
OFFHOOK light
This comes on when Line
is off HOOK
Off when on HOOK
PHONE button
Press to begin or answer a
telephone call.
Press to hang up at the end
of a call.
PLAY / MSG button
VOLUME button
Press during a call to
adjust the volume.
INT ( ) button
Press and Hold over 2
second for Intercom
Call.
CHARGE lights
This comes on when
thehandset batteries are
being charged.
SPEAKERPHONE button
Press to turn the
speakerphone on and off.
MEMORY button
Press to make calls to
numbers stored in memory
R (Recall) button
Direct Message Play
You may need this during a
call if your Icarus 1210 is
connected to a PBX, or if
you use BT Select
Services
PROG / LNR button
When on hook, press to start
programming.
When off hook, press for Last
Number Redial
HANDSET LOCATOR
button
Press this to make the
handset ring, to help you
find it if you’ve forgotten
where you put it.
1 Installation
You need one battery pack (NiMH, 3.6v, 300mAh) for each handset.
To fit the batteries
1 Open the battery
compartment cover.
2 Insert the plug in the
connector, as shown.
Tuck the wires in and lay the
battery pack in the
compartment
3 Fit the battery compartment
cover, sliding it into place
and pressing firmly to make
sure it is secure
Warnings
Dispose of used batteries safely never try to burn them
or put them anywhere they could get burnt or punctured.
When you are not going to use your Icarus 1210 for a few
weeks, take the batteries out so they do not leak
corrosive substances.
Do not leave dead batteries in your handset they might
leak if you do.
2 Making and answering calls
To make a call
To answer a call
To redial the last number
To end a call
Press PHONE or SPEAKER PHONE
Key in the telephone number
When the handset and base unit ring, press PHONE or
SPEAKER PHONE
Press PHONE or SPEAKER PHONE
Press LNR
Press PHONE
or
or
or
or
or
or
1
2
1
1
2
Earpiece Volume
To store a number
To make amemory call
During a phonecall, press VOL to cycle throughthe
different earpiece volumesettings.
On Hook Stage
Press MEM
Offhook indication LEDblinks slowly
Key in the memory location(0 to 9)
Press MEM again
Key in the number (key*,#,0~9, up to20digits) you
wish to store
Press MEM again
Confirmation Tone or ErrorTone
Off Hook Stage
Press MEM
Offhook indication LEDis blinking slowly
Key in the memory location(0 to 9)that you want to
dial
Dials out thestored number. [No confirmationtone.]
An Error Tone is heardif the memory is empty.
3 Memory dialing
1
2
3
4
5
6
7
1
2
3
4
To delete a storednumber
Dial Mode Setting(P/LNR button function and code *2 2)
On hook stage
Press MEM
Offhook indication LEDblinks slowly
Key in the memory location(0 to 9)
Press MEM again
Press MEM again
Confirmation Tone or ErrorTone
Offhook indication LEDis OFF
On hook stage
Press key P/LNR
Offhook indication LEDblinks slowly
Press digits 2 2
Confirmation Tone
Press DTMF mode, or # Pulse mode
Press key P/LNR
Confirmation Tone
1
2
3
4
5
6
7
1
2
3
4
5
6
7
4 Program operation
Press P/LNR key
Key in digits 3 1 1
Melody On
Press to increasethe volume
Press # to decrease thevolume
Press P/LNR keyto confirm setting
Confirmation Tone
Change handset ringer volume
1
2
3
4
5
6
7
Press P/LNR key
Key in digits 3 1 2
Melody On
Press button 0~9to select melody
Press P/LNR key to confirmsetting
Confirmation Tone
Change handset ringer melody
1
2
3
4
5
6
On Hook Stage
Press and Hold /INT key
Youhear the internal call dial tone
Press handset number
Ringback tone canbe heard
Called Handset isringing
Intercom Calll ( /INT button function )
1
2
3
4
5
6
Press the P/LNR button then key in digits 2 1 1
Melody is on
Press the button to increase the volume up to volume
level 5
Press the #button to decrease the volume down to level 1
or to turn the base ringer off (level 0)
Press P/LNR button to confirm
A confirmation can be heard
Base melody volume
1
2
3
4
5
6
Press the P/LNR button then key in digits 2 1 2
Melody is on
Press button 1~5 to select melody
Press P/LNR to confirm
A confirmation tone can be heard
Base melody
1
2
3
4
5
When the battery level is low during a call, you will hear the low battery
tone in the earpiece every minute.
Low battery tone
When the handset goes out of range of the base unit, you will hear the
Out of Range Tone in the earpiece every 12 seconds. You must return in
range of the base soon otherwise the call will be dropped.
Out of range
Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate)
Reset the System
HS on hook stage
Press key P/LNR
Offhook indication LED is blinking slowly
Key in digits 4 2 1 0
Wait until you hear the confirmation tone from HS and BU
Both HS and BU are set in default setting
1
2
3
4
5
6
Call Transfer ( /INT button function)
Off hook stage
Press and hold /INT to transfer acall.
Youwill hear internal dial tone inthe earpiece and the
caller will beon hold.
Press Handset numberfor the call transfer
Hear internal ringback tone
Once Connected withsecond handset
Press PHONE key to transferand hang up
OR - pressand hold INT key to reconnectto the caller
1
2
3
4
5
6
What’s the TONE mean ?
Confirmation Tone : ( =__== ) two short
beeps
Error Tone :(======) One long beep
Low battery Tone :(==) single beep with
long pause (1 mins)
Out of range Tone :(==) single beep
with long pause (12 seconds)
Where is the Handset number?
1
Handset
number
Special error tone
If you tryto operate an empty memo duringonline stage, there
will be aspecial error tone heard.
RED
BLACK
Leave the handset on the
charging cradle for 15 Hours
To Re-register handsets
First de-register allhandsets
Obtain all handsetsfor the operation
Start register handsetfrom handset number 1 with
the following setps:
Press and holdthe Base Page key for4 seconds until it
gives a doublebeep. The base will then bein
registration mode for20 seconds.
Put Handset OnHook Stage
Press key P/LNR
Offhook indication LEDis blinking slowly
Press digits 1 1
Confirmation tone
Press base number(1,2,3,4)
Handset and Basein registration communication
Confirmation Tone or ErrorTone
Repeat 1-12 forhandset number 2~4 If multiple
handset systems insequence.
1
2
3
4
5
6
7
8
9
10
11
12
13
Remove Base power
Press and holdthe Page key.
Reconnect the Basepower.
Wait untilyou hear 4 double beeps.
Release the Pagekey.
After a shorttime you will hear a confirmationtone.
Now, allthe registrations are removed from yourbase
De-register all handsets from a Base
1
2
3
4
5
6
7
WARNING: Your phone have been registered before ship - you doesn't
need to register nor de-register normally

5 Answering machine quick Reference
Button Shortcut function
Record the outgoing message (OGM)
Play the OGM
Record a memo
Delete this message
Turn the answering machine on
Turn the answering machine off
Go back to the previous message
Play back messages and memos
Go forward to the next message
Stop message playback
6 Using the answering machine
Press P(program key)
On-line LED blinks slowly
Press Key 1
Hold handset to ear and wait for confirmation tone.
Record your OGM, speaking clearly into the microphone
When the message is finished, press Key 0to stop the
recording
Confirmation Tone or Error Tone
Returns to standby mode.
To record your own OGM:
1
2
3
4
5
6
7
8
Press P(program key)
On-line LED blinks slowly
Press Key 2
The OGM plays back
Wait for the message to end, or press Key 0 to stop the
playback
Confirmation Tone or Error Tone
Returns to standby mode.
To playback your OGM
1
2
3
4
5
6
7
Press 7 to go back to previous message
Press 9to skip to the next message
Press 8to play the current message AGAIN
Press 4to delete the playing message (NOT all)
Press 0to stop playing and return to standby mode
All operation will have Confirmation Tone or Error Tone
While playing messages
1
2
3
4
5
6
Press Pkey
Offhook indication LED blinks slowly
Press Keys 9 9
Wait for confirmation beep
Key in the number of rings (2~9, or 0 for TollSaver)
Press Pkey to confirm
Confirmation Tone
Returns to standby mode.
Setting the number of rings
Incoming message length
1
2
3
4
5
6
7
8
Memory Full
If the machine's memory is full, the answering machine will answer
after 12 rings and send a beep.
The line will release after about 10 seconds, unless you enter your
security code to enter remote operation.
To clear some memory, delete unwanted messages by pressing 4 as
the messages play.
To switch the answering machine on remotely
Call up your answering machine. (You will need to be phoneing
from a Tone Dialling phone, or have a Tone Dialler Pad.)
The answering machine will answer after 12 rings and send
three beep.
Enter your security code.
The call is cut off immediately, but the answering machine will
be turned on.
The Binatone Icarus 1210 is guaranteed for 12 months from the date
of purchase shown on your sales receipt. The Guarantee does not cover
damage by misuse or negligence, or by excessive voltages for
example, faults on the telephone line, or lightning.
Please keep your sales (till) receipt this is your guarantee. You
should also keep the original packaging material.
In the unlikely event that you need to return your Icarus 1210 to our
Repair Centre while it is under guarantee, there will be a 5 handling
charge.
7 Guarantee and service
Disconnect the base unit from the telephone line and the mains
electricity supply
Pack up all parts of your Icarus 1210, using the original packaging.
Remember to include the mains Adapter
Return the unit to the shop where you bought it, making sure you take
your sales receipt
While the unit is under Guarantee
If the unit is no longer under Guarantee, first follow steps 1and 2as for
repair under Guarantee. Then . . .
Call our Service Department on 0845 345 9677 and ask for a quotation
of the repair charge and details of where to send your Icarus 1210 for
repair
Make sure you include with your Icarus 1210:
your name and address
a cheque or postal order for the value of the repair charge
Return your Icarus 1210 to the address given by the Service Department
1
2
3
After the Guarantee has expired
3
4
5
8 Technical details
Standard Digital Enhanced Cordless Telecommunications
(DECT)
Frequency range 1.88 to 1.9 GHz (bandwidth = 20 Mhz)
Channel bandwidth 1.728Mhz
Operating range up to 300 m outdoors; up to 50 m indoors
Operating time standby: 100 hours approx.
talking: 9 hours approx.
battery charge time: 15 hours
Temperature range Operating 0 to 40
Storage -20 to 60
Electrical power Handset
Base unit input 230 V AC, 50 Hz; output 9V
AC 300mA
Charger pod input 230 V AC, 50 Hz; output
AC 9 V, 300 mA
Port specification The port (connected to the mains power
supply) is a SELV port with respect to EN41003.
The port (connected to the telephone line)
is a TNV port with respect to En41003.
PBX compatibility Timed break recall: 100 ms (short press)
Network connection Thisequipment is intended to be used in the
UK only. Operation on other countries PSTN
termination points cannot be guaranteed.
3 x 2/3 AAA NIMH 300mAh
Battery Pack
'
Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Binatone Help Line:0845 345 9677 (Local Call rate) Ver 4,Mar 06
Press P
Press 5to switch answering machine On
OR
Press 6to switch answer machine Off.
Confirmation Tone or Error Tone
To switch answer machine On or Off.
1
2
3
4
Directly playback Message
Press PLAY/MSG key while handset is in standby mode
The speaker is On
You will hear the message if message or ICM is not empty
Press 0to stop
Confirmation Tone or Error Tone
And go back into standby mode.
1
2
3
4
5
6
Waste electrical products must not be disposed of with
householdwaste. This equipmentshould be taken to your
local recycling centre for safe treatment.
Key in your remote security code
Confirmation Tone
Any recorded messages will start playing back
[9] skip forward to next message
[8] play the current message again
[4] del the message currently being played back
[0] stop playback
after the new message have been played, the keys will be
used as below,
[8] play the current message again
[8] play all recorded message
[9] skip forward to next message
[7] go back to the previous message
[4] del the message currently being played back
[1] record a new OGM
[2] play back the OGM
[0] stop playback or recording
[6] switch the answering machine off
4
5
6
7
Press Pkey
Offhook indication LED blinks slowly
Press Keys 8 8
Wait for confirmation beep
Key in the security code by pressing 0~9 (up to 3 digits)
Press Pkey to confirm
Confirmation Tone
Returns to standby mode.
Setting the remote security code
1
2
3
4
5
6
7
Press Pthen 8 3 6 7
Offhook indication LED is blinking slowly
Wait then hear a Confirmation tone
Both indication LED and charge LED are fast blinking
Wait until both LEDs Off
Return to standby mode
Delete all messages
1
2
3
4
5
6
Call up your answering machine. (You will need to be
phoneing from a Tone Dialling phone, or have a Tone
Dialler Pad.)
While the OGM is playing, press # to stop play the OGM
Confirmation Tone
Remote Operation
1
2
3
Press the PLAY MSG key to start playback immediately
through the loudspeaker.
(Or press Pkey then 8to start play back)
Any messages will be played
Press key 0to stop play back
Confirmation tone
Returns to standby mode
Message playback
1
2
3
4
5
The caller is recording a message after the OGM and 'beep '
To speak to the caller, press PHONE or SPEAKER PHONE
The answering machine will stop the recording but keep the
message up to the intercept.
To intercept a call
1
2
3
or
Press P
Then 3to record your memo.
Confirmation Tone
Press 0to stop recording and go back to standby mode
Confirmation Tone or Error Tone
To record a memo
1
2
3
4
5
The machine hasa total recording time of 4to 6 minutes.
The maximum incomingmessage length is 60 seconds each.
