Binder FDL 115 User manual

Issue 03/2011 Art. No. 7001-0127
Operating Manual
Translation of the Original Operating Manual
APT.line™ FDL 115
Safety / paint drying ovens
for drying of limited quantities of solvents
with microprocessor program controller RD3
Model Art. No.
FDL 115 (E2) 9010-0269, 9110-0269
BINDER GmbH
Address Post office box 102
D-78502 Tuttlingen
Tel. [phone]
Fax [phone]
Internet http://www.binder-world.com
E-mail [email protected]
Service Hotline [phone]
Service Fax [phone]
Service E-Mail [email protected]
Service Hotline USA [phone] or [phone]
Service Hotline Spain [phone]
Service Hotline Asia Pacific [phone] or [phone]
Service Hotline Russia and CIS [phone]

FDL (E2) 03/2011 page 2/68
EG - KONFORMITÄTSERKLÄRUNG
EC - DECLARATION OF CONFORMITY
CE - DECLARATION DE CONFORMITE
Anbieter / Supplier / Fournisseur: BINDER GmbH
Anschrift / Address / Adresse: Im Mittleren Ösch 5, D-78532 Tuttlingen
Bezeichnung der Maschine /
Denomination of the machine /
Dénomination de la machine:
Sicherheits- / Lacktrockenschrank
Safety / paint drying oven
Armoire séchante de sécurité / pour peintures et vernis
Typenbezeichnung / Type / Type: FDL 115
Die oben beschriebene Maschine ist konform mit folgenden EG-Richtlinien (gemäß Veröf-
fentlichung im Amtsblatt der europäischen Kommission):
The machine described above is in conformity with the following EC guidelines (as published in
the Official Journal of the European Union):
La machine décrite ci-dessus est conforme aux directives CE suivantes (selon leur publication
dans le Journal officiel de l’Union européenne):
Maschinenrichtlinie 2006/42/EG
Machinery directive 2006/42/EC
Directive Machines 2006/42/EC
Richtlinie 2006/42/EG des Europäischen Parlaments und des Rates
vom 17. Mai 2006 über Maschinen und zur Änderung der Richtlinie
95/16/EG (Neufassung)
Directive 2006/42/EC of the European Parliament and of the Council
of 17 May 2006 on machinery, and amending Directive 95/16/EC
(recast)
Directive 2006/42/CE du Parlement Européen et du Conseil du 17
mai 2006 relative aux machines et modifiant la directive 95/16/CE
(refonte)
EMV-Richtlinie 2004/108/EG
EMC Directive 2004/108/EC
Directive CEM 2004/108/CE
Richtlinie 2004/108/EG des Europäischen Parlaments und des
Rates vom 15. Dezember 2004 zur Angleichung der Rechtsvor-
schriften der Mitgliedstaaten über die elektromagnetische Ver-
träglichkeit und zur Aufhebung der Richtlinie 89/336/EWG.
Directive 2004/108/EC of the European Parliament and of the Coun-
cil of 15 December 2004 on the approximation of the laws of the
Member States relating to electromagnetic compatibility and repeal-
ing Directive 98/336/EEC.
Directive 2004/108/CE du Parlement Européen et du Conseil du 15
décembre 2004 relative au rapprochement des législations des États
membres concernant la compatibilité électromagnétique et abro-
geant le directive 98/336/CEE.
ATEX-Richtlinie 94/9/EG
ATEX Directive 94/9/EC
Directive ATEX 94/9/CE
Richtlinie 94/9/EG des Europäischen Parlaments und des Rates zur
Angleichung der Rechtsvorschriften der Mitgliedstaaten für Geräte
und Schutzsysteme zur bestimmungsgemäßen Verwendung in ex-
plosionsgefährdeten Bereichen.
Directive 94/9/EC of the European parliament and the council of 23
March 1994 on the approximation of the laws of the Member States
concerning equipment and protective systems intended for use in
potentially explosive atmospheres
Directive 94/9/CE du parlement européen et du conseil du 23 mars
1994 concernant le rapprochement des législations des États mem-
bres pour les appareils et les systèmes de protection destinés à être
utilisés en atmosphères explosibles.
1 / 3

FDL (E2) 03/2011 page 3/68
Die oben beschriebene Maschine entspricht aufgrund ihrer Konzipierung und Bauart sowie in der von uns
in Verkehr gebrachten Ausführung den einschlägigen grundlegenden Sicherheits- und Gesundheitsan-
forderungen der genannten EG-Richtlinien.
The machine described above is conform to the mentioned EC directives in regard to the relevant safety
and health demands due to its conception and its style of construction as well as to the version put onto
market by us.
La machine décrite ci-dessus correspond aux demandes de sécurité et de santé des directives citées de
la Communauté Européenne due à sa conception et construction et dans la réalisation mise sur le
marché par nous.
Die oben beschriebene Maschine trägt entsprechend die Kennzeichnung CE.
The machine described above, corresponding to this, bears the CE-mark.
La machine décrite ci-dessus, en correspondance, porte l’indication CE.
Die oben beschriebene Maschine ist konform mit folgenden harmonisierten Normen:
The machine described above is in conformity with the following harmonized standards:
La machine décrite ci-dessus est conforme aux normes harmonisées suivantes:
Sicherheit / safety / sécurité:
EN 61010-1:2010 Sicherheitsbestimmungen für elektrische Mess-, Steuer-, Regel- und
Laborgeräte – Teil 1: Allgemeine Anforderungen (DIN EN 61010-
1:2002 + Berichtigung 1:2002 + Berichtigung 2:2004)
Safety requirements for electrical equipment for measurement, con-
trol, and laboratory use – Part 1: General requirements (IEC 61010-
1:2010, BS EN 61010-1:2010)
Règles de sécurité pour appareils électriques de mesurage, de régu-
lation et de laboratoire – Partie 1: Prescriptions générales (CEI 61010-
1:2010, NF EN 61010:2011)
EN 61010-2-010:2003 Sicherheitsbestimmungen für elektrische Meß-, Steuer-, Regel- und
Laborgeräte – Teil 2-010: Besondere Anforderungen an Laborgeräte
für das Erhitzen von Stoffen (DIN EN 61010-2-010:2004)
Safety requirements for electrical equipment for measurement, con-
trol, and laboratory use – Part 2-010: Particular requirements for labo-
ratory equipment for the heating of materials (IEC 61010-2-10:2005,
BS EN 61010-2-10:2003)
Règles de sécurité pour appareils électriques de mesurage, de régu-
lation et de laboratoire – Partie 2-010 : Prescriptions particulières pour
appareils de laboratoire utilisés pour l’échauffement des matières
(CEI 61010-2-10:2003, NF EN 61010-2-10:2005)
EN ISO 12100:2010 Sicherheit von Maschinen - Allgemeine Gestaltungsleitsätze - Risi-
kobeurteilung und Risikominderung (DIN EN ISO 12100:2011)
Safety of machinery - General principles for design - Risk assessment
and risk reduction (BS EN ISO 12100:2010)
Sécurité des machines - Principes généraux de conception -
Appréciation du risque et réduction du risque (NF EN ISO
12100:2010)
EN ISO 13732-1:2008 Ergonomie der thermischen Umgebung - Bewertungsverfahren für
menschliche Reaktionen bei Kontakt mit Oberflächen. Teil 1: Heiße
Oberflächen (DIN EN ISO 13732-1:2008)
Ergonomics of the thermal environment - Methods for the assessment
of human responses to contact with surfaces. Part 1: Hot surfaces (BS
EN ISO 13732-1: 2008)
Ergonomie des ambiances thermiques - Méthodes d'évaluation de la
réponse humaine au contact avec des surfaces. Partie 1: Surfaces
chaudes (NF EN ISO 13732-1: 2008)
2 / 3

FDL (E2) 03/2011 page 4/68
Sicherheit / safety / sécurité:
EN 60204-1:2006 + A1:2009 Sicherheit von Maschinen. Elektrische Ausrüstung von Maschinen.
Teil 1: Allgemeine Anforderungen (DIN EN 60204-1:2007 + A1:2009)
Safety of machinery. Electrical equipment of machines. General re-
quirements (IEC 60204-1:2005 mod. + A1:2008, BS EN 60204-1:2006
+ A1:2009)
Sécurité des machines - Équipement électrique des machines - Partie
1 : règles générales (CEI 60204-1:2005 mod. + A1:2008, NF EN
60204-1:2006 + A1:2009)
EN 1539:2009 Trockner und Öfen, in denen brennbare Stoffe freigesetzt werden.
Sicherheitsanforderungen (DIN EN 1539: 2010)
Dryers and ovens, in which flammable substances are released.
Safety requirements (BS EN 1539:2009)
Séchoirs et fours dans lesquels se dégagent des substances inflam-
mables. Prescriptions de sécurité (NF EN 1539 : 2010)
EMV / EMC / CEM:
EN 61326-1:2006
+ Corr. 1:2008 + Corr. 2:2010
Elektrische Mess-, Steuer-, Regel- und Laborgeräte - EMV-
Anforderungen - Teil 1: Allgemeine Anforderungen (DIN EN 61326-
1:2006 + Berichtigung 1:2008 + Berichtigung 2:2011)
Electrical equipment for measurement, control and laboratory use -
EMC requirements - Part 1: General requirements (IEC 61326-1:2005
+ Corr. 1:2008 + Corr. 2:2010, BS EN 61326-1:2006+ A1:2008)
Matériel électrique de mesure, de commande et de laboratoire - Exi-
gences relatives à la CEM - Partie 1: Exigences générales (CEI
61326-1:2005 + AC1:2008, NF EN 61326-1:2006 mod.)
EN 61326-2-2:2006 Elektrische Mess-, Steuer-, Regel- und Laborgeräte – EMV-
Anforderungen. Teil 2-2: Besondere Anforderungen - Prüfanordnung,
Betriebsbedingungen und Leistungsmerkmale für ortsveränderliche
Prüf-, Mess- und Überwachungsgeräte in Niederspannungs-
Stromversorgungsnetzen. (DIN EN 61326-2-2:2006)
Electrical equipment for measurement, control and laboratory use –
EMC requirements. Part 2-2: Particular requirements - Test configura-
tions, operational conditions and performance criteria for portable test,
measuring and monitoring equipment used in low-voltage distribution
systems. (IEC 61326-2-2:2005, BS EN 61326-2-2:2006)
Matériel électrique de mesure, de commande et de laboratoire – Exi-
gences relatives à la CEM. Partie 2-2: Exigences particulières - Con-
figurations d’essai, conditions de fonctionnement et critères d’aptitude
à la fonction des matériels portatifs d’essai, de mesure et de surveil-
lance utilisés dans des systèmes de distribution basse tension. (CEI
61326-2-2:2005 + AC1:2007, NF EN 61326-2-2:2006)
D-78532 Tuttlingen, 30.03.2011
BINDER GmbH
P. M. Binder
Geschäftsführender Gesellschafter
Managing Director
Directeur général
Dr. H. von Both
Leiter F & E und Dokumentationsbevollmächtigter
Director R & D and documentation representative
Chef de service R&D et autorisé de documentation
3 / 3

FDL (E2) 03/2011 page 5/68
Certificate for the GS mark of conformity of the “Deutsche Gesetzliche Unfallversicherung e.V.”
(German Social Accident Insurance (DGUV)

FDL (E2) 03/2011 page 6/68

FDL (E2) 03/2011 page 7/68
Contents
1. SAFETY..................................................................................................................9
1.1 Legal considerations ...........................................................................................................................9
1.2 Structure of the safety instructions......................................................................................................9
1.2.1 Signal word panel......................................................................................................................9
1.2.2 Safety alert symbol..................................................................................................................10
1.2.3 Pictograms...............................................................................................................................10
1.2.4 Word message panel structure ...............................................................................................11
1.3 Localization / position of safety labels on the unit.............................................................................11
1.4 Type plate .........................................................................................................................................12
1.5 General safety instructions on installing and operating the safety / paint drying oven FDL.............13
1.6 Intended use .....................................................................................................................................14
1.7 Operating instructions .......................................................................................................................14
1.8 Measures to prevent accidents.........................................................................................................15
1.9 Important points to consider before commissioning .........................................................................16
1.9.1 Technical ventilation / permissible load...................................................................................16
1.9.2 Loading instructions ................................................................................................................16
1.9.3 Drying nitro-cellulose lacquers ................................................................................................16
1.9.4 Drying mould varnishes...........................................................................................................16
1.9.5 Drying impregnating resins......................................................................................................17
2. UNIT DESCRIPTION............................................................................................17
2.1 Unit overview.....................................................................................................................................18
2.2 Control panel.....................................................................................................................................19
2.3 Solvent curve FDL 115 .....................................................................................................................19
3. COMPLETENESS OF DELIVERY, TRANSPORTATION, STORAGE, AND
INSTALLATION....................................................................................................20
3.1 Unpacking, and checking equipment and completeness of delivery................................................20
3.2 Guidelines for safe lifting and transportation ....................................................................................21
3.3 Storage..............................................................................................................................................21
3.4 Location of installation and ambient conditions ................................................................................21
4. INSTALLATION OF THE EQUIPMENT ...............................................................22
4.1 Operating instructions .......................................................................................................................22
4.2 Electrical connection .........................................................................................................................23
4.3 Connection to a suction plant (optional) ...........................................................................................23
5. START UP............................................................................................................24
5.1 Settings at the RD3 program controller ............................................................................................24
5.2 General indications ...........................................................................................................................25
6. FIXED VALUE ENTRY MODE .............................................................................27
7. WEEK PROGRAM EDITOR.................................................................................28
7.1 Program table template for Week program Editor ............................................................................30
8. PROGRAM EDITOR.............................................................................................31
8.1 Selecting between set-point ramp and set-point step.......................................................................31
8.1.1 Programming with setting “Ramp” (default setting).................................................................31
8.1.2 Programming with setting “step” .............................................................................................33
8.1.3 General notes on programming temperature transitions ........................................................34
8.2 Set-point entry for program operation...............................................................................................34
8.3 Program table template.....................................................................................................................37
8.4 Deleting a program section ...............................................................................................................38

FDL (E2) 03/2011 page 8/68
9. PROGRAM START LEVEL..................................................................................39
10. USER LEVEL .......................................................................................................41
11. BEHAVIOR IN CASE OF FAILURES...................................................................48
11.1 Behavior after power failure ..............................................................................................................48
11.2 Alarm messages ...............................................................................................................................48
12. SAFETY DEVICES...............................................................................................48
12.1 Temperature safety device class 2 (DIN 12880:2007) .....................................................................48
12.2 Exhaust air monitoring ......................................................................................................................50
13. OPTIONS..............................................................................................................50
13.1 Communication software APT-COM™ 3 DataControlSystem (option) ............................................50
13.1 Ethernet interface (option) ................................................................................................................50
13.2 Protocol printer (option) ....................................................................................................................51
13.3 Additional measuring channel for digital object temperature indicator with magnetic sensor or
pincer-type sensor (option) ...............................................................................................................52
14. MAINTENANCE, CLEANING, AND SERVICE ....................................................53
14.1 Maintenance intervals, service..........................................................................................................53
14.2 Replacing the intake filter..................................................................................................................54
14.3 Cleaning and decontaminating the safety / paint drying oven..........................................................54
14.4 Sending the unit back to BINDER GmbH .........................................................................................55
15. DISPOSAL............................................................................................................56
15.1 Disposal of the transport packing .....................................................................................................56
15.2 Decommissioning..............................................................................................................................56
15.3 Disposal of the unit in the Federal Republic of Germany .................................................................56
15.4 Disposal of the unit in the member states of the EC except for the Federal Republic of Germany .57
15.5 Disposal of the unit in non-member states of the EC .......................................................................59
16. TROUBLESHOOTING .........................................................................................59
17. TECHNICAL DESCRIPTION................................................................................61
17.1 Factory calibration and adjustment...................................................................................................61
17.2 Definition of usable volume...............................................................................................................61
17.3 Technical data...................................................................................................................................61
17.4 Equipment and Options ....................................................................................................................63
17.5 Spare parts........................................................................................................................................64
17.6 Dimensions FDL 115 ........................................................................................................................65
18. CONTAMINATION CLEARANCE CERTIFICATE ...............................................66

FDL (E2) 03/2011 page 9/68
Dear customer,
For the correct operation of the safety / paint drying ovens FDL, it is important that you read this operating
manual completely and carefully and observe all instructions as indicated. Failure to read, understand
and follow the instructions may result in personal injury. It can also lead to damage to the unit and/or poor
equipment performance.
1. Safety
This operating manual is part of the components of delivery. Always keep it handy for reference. The
device should only be operated by laboratory personnel especially trained for this purpose and familiar
with all precautionary measures required for working in a laboratory. To avoid injuries and damage ob-
serve the safety instructions of the operating manual.
WARNING
Failure to observe the safety instructions.
Serious injuries and unit damage.
Observe the safety instructions in this operating manual.
Carefully read the complete operating instructions of the safety / paint drying oven FDL.
1.1 Legal considerations
This operating manual is for informational purposes only. It contains information for installing, start-up,
operation and maintenance of the product. Note: the contents and the product described are subject to
change without notice.
Understanding and observing the instructions in this operating manual are prerequisites for hazard-free
use and safety during operation and maintenance. In no event shall BINDER be held liable for any dam-
ages, direct or incidental arising out of or related to the use of this manual.
This operating manual cannot cover all conceivable applications. If you would like additional information,
or if special problems arise that are not sufficiently addressed in this manual, please ask your dealer or
contact us directly by phone at the number located on page one of this manual
Furthermore, we emphasize that the contents of this operating manual are not part of an earlier or exist-
ing agreement, description, or legal relationship, nor do they modify such a relationship. All obligations on
the part of BINDER derive from the respective purchase contract, which also contains the entire and ex-
clusively valid statement of warranty administration. The statements in this manual neither augment nor
restrict the contractual warranty provisions.
1.2 Structure of the safety instructions
In this operating manual, the following safety definitions and symbols indicate dangerous situations in
accordance with ISO 3864-2 and ANSI Z535.6.
1.2.1 Signal word panel
Depending on the probability of serious consequences, potential dangers are identified with a signal
word, the corresponding safety color, and if appropriate, the safety alert symbol.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious (irreversi-
ble) injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious (irre-
versible) injury.

FDL (E2) 03/2011 page 10/68
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in moderate or minor (re-
versible) injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in damage to the product
and/or its functions or of a property in its proximity.
1.2.2 Safety alert symbol
Use of the safety alert symbol indicates a risk of injury.
Observe all measures that are marked with the safety alert symbol in order to avoid death or
injury.
1.2.3 Pictograms
Warning signs
Electrical hazard Hot surface Explosive atmosphere
Tipover hazard
Inhalation hazard
Pollution Hazard
Harmful substances
Biohazard
Mandatory action signs
Mandatory regulation Read operating
instructions
Disconnect the power
plug
Lift with several persons
Environment protection
Prohibition signs
Do NOT touch Do NOT spray with
water
Information to be observed in order to ensure optimum function of the product.

FDL (E2) 03/2011 page 11/68
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅Instruction how to avoid the hazard: prohibition
Instruction how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels on the unit
The following labels are located on the unit:
Pictograms (Warning signs) Service label
Hot surface
Figure 1: Position of labels on the unit
Keep safety labels complete and legible.
Replace safety labels that are no longer legible. Contact BINDER Service for these replacements.

FDL (E2) 03/2011 page 12/68
1.4 Type plate
Figure 2: Position of type plate
Figure 3: Type plate (example of FDL 115 regular unit)
Indications of the type plate Information
BINDER Manufacturer: BINDER GmbH
FDL 115 Model FDL 115
Safety Drying Oven Safety / paint drying oven
Serial No. 00-00000 Serial No. 00-00000
Nominal temperature 300 °C
572°F
Nominal temperature
Enclosure protection IP 33 IP type of protection 33 acc. to EN 60529
Temp. safety device DIN 12880 Temperature safety device acc. to standard DIN 12880
Class 2.0 Temperature safety device, class 2
Art. No. 9010-0269 Art. No. 9010-0269
Project No. --- (Special application acc. to project no.)
Built 0000 Year of construction: 0000
2,90 kW Nominal power 2.90 kW
230 V 1 N PE ~ Nominal voltage 230 V ±10%, single-phase unit
13,0 A Nominal current 13.0 Amp
50/60 Hz Power frequency 50/60 Hz
Usable volume 0,115m³ Usable volume 0.115 m³
Steam space 0,156m³ Total steam space 0.156 m³
Max. solvent at nominal temp. 3,0g Highest permissible solvent quantity at 300 °C / 572°F: 3.0g
Min. exhaust flow rate 24m³/h at +20 °C Minimum exhaust flow rate at +20 °C: 24 m³/h
Max. temp. of heating surfaces +750 °C Maximum temperature of heating surfaces +750 °C / 1382°F
Wiring diagram FDL 115 pages 1-3 Wiring diagram FDL 115 pages 1 to 3
Nominal temperature 300 °C 2,90 kW Usable volume 0,115m³
572°F 230 V 1 N PE ~ Steam space 0,156m³
Enclosure protection
Temp. safety device
IP 33
DIN 12880
13,0 A
50/60 Hz
Max. solvent at nominal temp. 3,0g
Min. exhaust flow rate 24m³/h at +20 °C
Class 2.0
Max. temp. of heating surfaces +750 °C
Art. No. 9010-0269 US PATS 4585923 / 5222612 / 5309981 Wiring diagram FDL 115 pages 1-3
Project No.
Built 0000
5405194 / 5601143 / 5773287 / 6079403
Safety Drying Oven
D 78532 Tuttlingen / Germany
Tel. + 49 (0) 7462/ 2005-0
Internet: www.binder-world.com
FDL 115 Serial No. 00-00000
Made in Germany

FDL (E2) 03/2011 page 13/68
Symbol on the type plate Information
CE conformity marking
Electrical and electronic equipment manufactured / placed on the
market in the EC after 13 August 2005 and to be disposed of in a
separate collection according to directive 2002/96/EC on waste elec-
trical and electronic equipment (WEEE).
The equipment is certified in the GOST R certification system of
GOSTSTANDARD Russia.
GS mark of conformity of the “Deutsche Gesetzliche Unfallversi-
cherung e.V. (DGUV), Fachausschuss Metall- und Oberflächenbe-
handlung, Prüf- und Zertifizierungsstelle im DGUV Test“ (German
Social Accident Insurance (DGUV), Expert Committee: Metal and
Surface Treatment, Testing and Certification Body in DGUV)
1.5 General safety instructions on installing and operating the safety / paint
drying oven FDL
With regard to operating the safety / paint drying oven FDL and to the installation location, please ob-
serve the guideline BGI/GUV-I 850-0 on safe working in laboratories (formerly BGR/GUV-R 120 or ZH
1/119 laboratory guidelines issued by the employers’ liability insurance association) (for Germany).
BINDER GmbH is only responsible for the safety features of the unit provided skilled electricians or quali-
fied personnel authorized by BINDER perform all maintenance and repair, and if components relating to
chamber safety are replaced in the event of failure with original spare parts.
To operate the unit, use only original BINDER accessories or accessories from third-party suppliers au-
thorized by BINDER. The user is responsible for any risk caused by using unauthorized accessories.
CAUTION
Danger of overheating.
Damage to the unit.
∅Do NOT install the unit in unventilated recesses.
Ensure sufficient ventilation for dispersal of the heat.
Do not operate the safety / paint drying oven FDL in hazardous locations.
DANGER
Explosion hazard.
Danger of death.
∅Do NOT operate the unit in potentially explosive areas.
∅KEEP explosive dust or air-solvent mixtures AWAY from the unit.
Familiarize yourself with any potential health risks caused by the charging material, the contained mois-
ture constituent or by reaction products which may arise during the temperature process. Take adequate
measures to exclude such risks prior to putting the safety / paint drying oven into operation.

FDL (E2) 03/2011 page 14/68
DANGER
Electrical hazard.
Danger of death.
∅The unit must NOT become wet during operation or maintenance.
The safety / paint drying ovens were produced in accordance with VDE regulations and were routinely
tested in accordance to VDE 0411-1 (IEC 61010-1).
If a warning signal which indicates an of error condition, no further charging material must be introduced
into the unit.
DANGER
Explosion and ignition hazard.
Danger of death.
∅Do NOT introduce any further charging material as long as there is a warning signal.
During and after the drying process, the inner surfaces have got a temperature close to the set-point.
CAUTION
The inner chamber, the outgoing air pipe, the door window (option), the door gasket,
and the access ports will become hot during operation.
Danger of burning.
∅Do NOT touch the inner surfaces, the outgoing air pipe, the door window, the door gas-
ket, the access ports, or the charging material during operation.
1.6 Intended use
The BINDER safety / paint drying oven FDL 115 is suitable for drying and burn in of lacquers and similar
liquid coating materials which are containing solvents that can form explosive mixtures with air. The
maximally permitted drying temperature and the maximally permitted quantity of solvent are limited, see
chap. 1.9.
Other applications are not approved.
Do NOT use the unit to warm up coating materials in containers, vessels, etc. or for drying textiles
soaked in solvent.
Do NOT use the unit for drying purpose if greater quantities of steam or solvent gas leading to condensa-
tion will be set free.
Following the instructions in this operating manual and conducting regular maintenance work
(chap. 14.1) are part of the intended use.
1.7 Operating instructions
Depending on the application and location of the unit, the operator of the safety / paint drying oven must
provide the relevant information for safe operation of the unit in a set of operating instructions.
These operating instructions must be kept with the unit at all times in a place where they are
clearly visible. They must be comprehensible and written in the language of the employees.

FDL (E2) 03/2011 page 15/68
1.8 Measures to prevent accidents
During drying of fluid paints, flammable solvent/air mixtures can form and ignite.
The manufacturer took the following measures to prevent ignition and explosions:
•Indications on the type plate
See operating manual chap. 1.4
•Operating manual
An operating manual is available for each safety / paint drying oven.
A diagram in the operating manual (chap. 2.3) indicates the maximum permissible solvent quantities
for various operating states.
The operating manual asks the operator of the safety / paint drying oven to set up an instruction on
the permissible loading quantity.
•Maximum temperatures and maximum permissible steam concentration
By means of the diagram “Highest permissible solvent quantity”, which is included in the operating
manual chap. 2.3 and applied on the front of the safety / paint drying oven, the operator must adapt
the drying temperature to the maximum solvent quantity arising.
When using nitro-cellulose lacquers or nitro combination lacquers, the diagram ”Highest permissible
solvent quantity” specifies a limit temperature of max. 130 °C/ 266 °F, which must not be exceeded.
(In this context, all paints containing more than 5 % nitro-cellulose relative to the non-volatile contents
are regarded as nitro-cellulose lacquers and nitro-combination lacquers).
A gas-tight separation between the drying chamber and the heating chamber is not necessary since
there is an effective forced air motion in the entire steam room.
•Throttle valves
No throttle valves are used, i.e., the full air change occurs permanently.
•Protecting the heating surfaces against dripping
The BINDER APT.line™ preheating chamber protects all heating elements against lacquer dripping
and direct contact with lacquer coatings.
•Heat insulation
All heat insulation is sealed against penetration by lacquer vapors from the outside with high tempera-
ture-resistant and ageing-resistant sealant.
The insulation material consists of non-combustible mineral wool (class A1 according to DIN 4102-
1:1998).
•Temperature monitoring
The safety / paint drying oven is equipped with a temperature display, which can be read from outside.
A built-in additional temperature safety device can turn off the heating and is functionally independent
of the main controller. When turning off the unit, the forced convection and the control equipment’s
function are maintained. Visual (red indicator light) and audible (buzzer) signals indicate temperature
exceeding.
•Safety in case the technical ventilation fails
The heating only turns on if the air circulation is already in operation.
If the air circulation fails, the heating immediately turns off. In addition, there are audible (buzzer) and
visual (red indicator light) signals.
•Moving parts participating in the work process
It is impossible to touch the fan from outside the device or from the interior.
•Safety, measurement and control devices
The safety, measuring, and control equipment is easily accessible via the housing top cover.

FDL (E2) 03/2011 page 16/68
•Electrostatic charge
The interior parts are grounded.
•Protection against touchable surfaces
Tested according to EN ISO 13732-1:2006.
•Floors
See operating manual chap. 3.4 for the oven’s installation.
•Ventilation
Ventilation shall be realized by the operator according to GUV-R 500 chap. 2.29 “Verarbeiten von
Beschichtungsstoffen” (Processing of paints) (for Germany).
•Cleaning
See operating manual chap. 14.
•Examinations
The safety / paint drying oven has been inspected by the “Deutsche Gesetzliche Unfallversicherung
e.V. (DGUV), Fachausschuss Nahrungs- und Genussmittel, Prüf- und Zertifizierungsstelle im DGUV
Test“ (German Social Accident Insurance (DGUV), Expert Committee: “Metal and Surface Treatment”,
Testing and Certification Body in DGUV) and bears the GS mark.
1.9 Important points to consider before commissioning
1.9.1 Technical ventilation / permissible load
For safety reasons, the formation of a dangerous, explosive atmosphere must be avoided in all operating
modes (see GUV-R 500 chap. 2.28 “Betreiben von Trocknern für Beschichtungsstoffe” ("Dryers for coat-
ing materials")). Keeping the maximum permissible amount of solvent when loading the unit will meet this
requirement. The permissible quantity can be calculated according to the "principles for the calculation of
ventilation of chamber dryers and continuous dryers" (EN 1539:2009, Appendix B). According to this
standard, the safety / paint drying oven’s technical data (chap. 17.3) must be included in the calculation,
and it is required to set up a set of loading instructions (for Germany).
1.9.2 Loading instructions
The loading instructions should specify the amount of material, which can be loaded into the drying oven
for treatment without any risk of creating a dangerous, explosive atmosphere. GUV-R 500 chap. 2.28
“Betreiben von Trocknern für Beschichtungsstoffe” ("Dryers for coating materials") explicitly states that
the operator must set up a set of loading instructions (for Germany).
1.9.3 Drying nitro-cellulose lacquers
When using the safety / paint drying oven FDL to dry material, which is coated with nitro-cellulose lac-
quers, the temperature safety device must be set to max. 130 °C / 266 °F, so that the surface tempera-
ture of the goods to be dried is ensured not to exceed 130 °C / 266 °F. Deviations are only permissible if
a report from a testing agency, which is recognized by the employer's liability insurance association, has
declared safe a higher surface temperature.
1.9.4 Drying mould varnishes
When using the safety / paint drying oven FDL to dry mould varnishes, the operator is allowed to increase
the highest permissible amount of solvent specified for surface drying (chap. 2.3) by up to 10 times (see
GUV-R 500 chap. 2.28 “Betreiben von Trocknern für Beschichtungsstoffe” ("Dryers for coating materials")
or EN 1539:2009, Appendix A.1.1.2).

FDL (E2) 03/2011 page 17/68
1.9.5 Drying impregnating resins
When using the safety / paint drying oven FDL to dry impregnating resins, the operator is allowed to in-
crease the highest permissible amount of solvent specified for surface drying (chap. 2.3) by up to 20
times (see GUV-R 500 chap. 2.28 „Betreiben von Trocknern für Beschichtungsstoffe“ ("Dryers for coating
materials") no. 3.7.4 or EN 1539:2009, Appendix A.1.1.2).
2. Unit description
The safety / paint drying oven FDL 115 was built according to EN 1539:2009 (“Dryers and ovens, in
which flammable substances are released. Safety requirements”).
The fan in the rear of the safety / paint drying oven delivers a constant amount of fresh air through the
working area irrespective of the drying temperature. A large-area filter removes dust from the incoming
air (permeability up to approx. 1 micrometer).
A flow monitor in the upper part of the device (pressure differential switch) monitors the stream of exhaust
air. In the event of failure, the monitoring system turns the heater off immediately and registers this status
with a visual and an audible signal. The heating of the device is released with a time delay of 4 minutes
after you turn on the device by its main power switch.
The indicator light (3) in the operating panel only lights up as long as the air-flow monitor has not yet en-
abled the heating process. The drying temperature is also monitored constantly by the temperature limiter
(2). If the temperature would exceed the maximum permissible temperature, the heating is turned off
immediately and this state is indicated visually by indicator light (2a) and acoustically. In the event of fail-
ure, the safety / paint drying oven cannot be restarted until the RESET key (2b) or (4) has been reset
BINDER safety / paint drying ovens with forced convection FDL are equipped with the electronic program
controller RD3 with digital display. This permits programming of temperature cycles.
The APT.line™ preheating chamber system ensures high level of spatial and time-based temperature
precision, thanks to the direct and distributed air circulation into the interior. The air turbine supports ex-
act attainment and maintenance of the required temperature accuracy.
All functions of the multifunctional program control can be set simply and conveniently via the easy to
understand function keypad of the RD3 temperature program controller. This controller is equipped with
touch function keys and a digital display and permits exact temperature setting and programming tem-
perature cycles. The FDL provides almost unlimited possibilities of adapting to individual customer re-
quirements based upon extensive programming options and on the week program timer and real time
clock of the controller.
All unit functions are easy and comfortable to use thanks to their clear arrangement. Major features are
easy cleaning of all unit parts and avoidance of undesired contamination.
The inner chamber, the pre-heating chamber and the interior side of the doors are all made of stainless
steel (material no. 1.4301 (V2A) in Germany, US equivalent 304). When operating the chamber at tem-
peratures above 150 °C, the impact of the oxygen in the air may cause discoloration of the metallic sur-
faces (yellowish-brown or blue) by natural oxidation processes. These colorations are harmless and will
in no way impair the function or quality of the unit. The housing is RAL 7035 powder-coated. All corners
and edges are also completely coated.
The safety / paint drying oven FDL comes equipped with a serial interface RS 422 for computer commu-
nication, e.g. via the communication software APT-COM™ 3 DataControlSystem (option, chap. 13.1). For
further options, see chap. 17.4.
The units can be operated at an ambient temperature of 18 °C / 64.4 °F up to 40 °C / 104 °F in a tem-
perature control range by 5 °C above ambient temperature up to +300 °C / 572 °F.

FDL (E2) 03/2011 page 18/68
2.1 Unit overview
Figure 4: Front view FDL 115 with optional window
(A) Control panel
(B) Microprocessor program controller RD3
(C) Temperature safety device class 2 according to DIN 12880:2007
(D) Main power switch ON/OFF
(E) Solvent curve
(F) Door handle
(G) Unit door
(H) Window (optional)
RES
AI
(E) (B) (C) (D)
(F)
(A)
(G)
(H)

FDL (E2) 03/2011 page 19/68
2.2 Control panel
(6) (5) (4) (3) (2) (2b) (2a) (1)
Figure 5: Control panel of standard unit
(1) Main power switch ON/OFF
(2) Temperature safety device class 2
(2a) Red pilot lamp for temperature safety device class 2
(2b) RESET key for temperature safety device
(3) Red indicator light, loss of technical ventilation
(4) RESET key for the heating cut-out due to failure of technical ventilation
(5) Temperature program controller RD3
(6) Solvent curve: Highest permissible amount of solvent Gtotal [g] as a function of the drying tempera-
ture
2.3 Solvent curve FDL 115
0,00
5,00
10,00
15,00
20,00
25,00
30,00
35,00
50 60
70 80 90
100
110 120 130
140
150 160 170
180 190 200 210
220 230 240 250 260 270 280
290 300
Temperature [°C]
Gtotal [g]
Figure 6: Solvent curve FDL 115
The diagram shows the highest permissible solvent quantity Gtotal [g] in the steam room in correspon-
dence to the drying temperature. This is based on the calculation acc. to EN 1539:2009 considering the
unit specific data, an assumed molecular weight of the solvent of 100g/Mol, and a lower explosion limit of
40g/m3at 20 °C / 68 °F and at 760 Torr (1013 hPa) (assumptions for unknown solvents acc. to EN
1539:2009).
RESET AIR

FDL (E2) 03/2011 page 20/68
In case of too high drying temperature and /or too high quantity of solvent in the steam room it could be
possible that the concentration of the solvent steam will lead to an explosion. The permitted maximum of
solvent brought into the drying oven and the maximal temperature must not be exceeded.
DANGER
Excessive drying temperature and/or excessive solvent quantity.
Danger of explosion.
Danger of death.
∅Do NOT exceed the maximum solvent quantity.
∅Do NOT exceed the maximum drying temperature for the solvent quantity.
Adjust the temperature safety device according to the selected set-point (chap. 12.1).
3. Completeness of delivery, transportation, storage, and installa-
tion
3.1 Unpacking, and checking equipment and completeness of delivery
After unpacking, please check the unit and its optional accessories, if any, based on the delivery receipt
for completeness and for transportation damage. Inform the carrier immediately if transportation damage
has occurred.
The final tests of the manufacturer may have caused traces of the shelves on the inner surfaces. This
has no impact on the function and performance of the unit.
Please remove any transportation protection devices and adhesives in/on the unit and on the doors and
remove the operating manuals and accessory equipment.
CAUTION
Sliding or tilting of the unit.
Damage to the unit.
∅Do NOT lift or transport the unit using the door or the handle.
Lift the unit from the pallet at the four lower corners with the aid of four people.
If you need to return the unit, please use the original packing and observe the guidelines for safe lifting
and transportation (chap. 3.2).
For disposal of the transport packing, see chap. 15.1.
Note on second-hand units (Ex-Demo-Units):
Second-hand units are units that were used for a short time for tests or exhibitions. They are thoroughly
tested before resale. BINDER ensures that the chamber is technically sound and will work flawlessly.
Second-hand units are marked with a sticker on the unit door. Please remove the sticker before commis-
sioning the unit.
