Binder M Series User manual

Issue 04/2019 Art. Nr. 7001-0056
Operating Manual
M (E2)
Drying and heating ovens with forced convection
and advanced program functions
Model Model version Art. No.
M 53 M053-230V 9010-0201, 9110-0201
M 115 M115-230V 9010-0202, 9110-0202
M 240 M240-230V 9010-0203, 9110-0203
M 400 M400-230V 9010-0204, 9110-0204
M 720 M720-230V 9010-0205, 9110-0205
BINDER GmbH
Address: Post office box 102, 78502 Tuttlingen, Germany Phone: [phone]
Fax: [phone] Internet: http://www.binder-world.com
E-mail: [e-mail] Service Hotline: [phone]
Service Fax: [phone] Service E-Mail: [e-mail]
Service Hotline USA: [phone] or [phone] x3
Service Hotline Asia Pacific: [phone] or [phone]
Service Hotline Russia and CIS: [phone]

M (E2) 04/2019 page 2/71
Contents
1. SAFETY..................................................................................................................4
1.1 Legal considerations...........................................................................................................................4
1.2 Structure of the safety instructions......................................................................................................4
1.2.1 Signal word panel.....................................................................................................................4
1.2.2 Safety alert symbol...................................................................................................................5
1.2.3 Pictograms................................................................................................................................5
1.2.4 Word message panel structure.................................................................................................6
1.3 Localization / position of safety labels on the chamber......................................................................6
1.4 Type plate ...........................................................................................................................................7
1.5 General safety instructions on installing and operating the chambers...............................................8
1.6 Intended use .......................................................................................................................................9
2. CHAMBER DESCRIPTION..................................................................................10
2.1 Chamber overview............................................................................................................................11
2.2 Control panel.....................................................................................................................................12
3. COMPLETENESS OF DELIVERY, TRANSPORTATION, STORAGE, AND
INSTALLATION....................................................................................................12
3.1 Unpacking, and checking equipment and completeness of delivery................................................12
3.2 Guidelines for safe lifting and transportation ....................................................................................13
3.3 Storage..............................................................................................................................................13
3.4 Location of installation and ambient conditions................................................................................14
4. INSTALLATION AND CONNECTIONS................................................................15
4.1 Electrical connection.........................................................................................................................15
4.2 Connection to a suction plant (optional) ...........................................................................................15
5. START UP............................................................................................................16
5.1 Function overview of the MB1 display program controller................................................................16
5.2 Operating modes...............................................................................................................................16
5.3 Performance after power failures......................................................................................................17
5.4 Turning on the chamber....................................................................................................................17
6. CONTROLLER MB1 SETTINGS..........................................................................18
6.1 Selection of the menu language .......................................................................................................18
6.2 Overview of program controller MB1 displays..................................................................................19
6.3 Menu settings in the “User-settings” menu.......................................................................................20
6.4 Menu settings in the “User Level” menu...........................................................................................21
7. GRAPHIC REPRESENTATION OF THE HISTORICAL MEASUREMENT
(CHART RECORDER FUNCTION).....................................................................22
7.1 Setting the storage rate.....................................................................................................................24
8. MANUAL MODE...................................................................................................25
8.1 Entering the set point values.............................................................................................................25
8.2 Performance after power failure in Manual Mode.............................................................................26
9. PROGRAM OPERATION.....................................................................................26
9.1 Menu-based program entry...............................................................................................................27
9.2 Selecting between set-point ramp and set-point step.......................................................................29
9.3 Program entry as set-point ramp or as set-point step ......................................................................29
9.4 Information on programming different temperature transitions.........................................................32
9.5 Repetition of a section or several sections within a program ...........................................................33
9.6 Performance after power failure in Program Mode...........................................................................33

M (E2) 04/2019 page 3/71
9.7 Starting a previously entered program..............................................................................................34
9.8 Deleting a program............................................................................................................................34
9.9 Temperature profile template............................................................................................................35
9.10 Program table template.....................................................................................................................36
10. TEMPERATURE SAFETY DEVICES...................................................................37
10.1 Temperature safety device class 2 (DIN 12880)..............................................................................37
10.2 Temperature safety device class 3.1 (DIN 12880) (available via BINDER INDIVIDUAL customized
solutions)...........................................................................................................................................38
11. OPTIONS..............................................................................................................39
11.1 APT-COM™ 4 Multi Management Software (option)........................................................................39
11.2 Ethernet interface..............................................................................................................................39
11.3 HEPA fresh air filter (option).............................................................................................................39
11.4 Data logger kit (option)......................................................................................................................40
11.5 Additional flexible Pt100-temperature sensor (option)......................................................................40
11.6 Analog output for temperature (option).............................................................................................40
11.7 Additional measuring channel for digital object temperature indicator with flexible temperature
sensor Pt 100 (option).......................................................................................................................41
11.8 Mostly gas-tight version (option for M 53 and M 115) ......................................................................41
11.9 Inert gas connection with mostly gas-tight version (option for M 53 and M 115).............................42
11.10 Keyboard locking (option).................................................................................................................44
12. MAINTENANCE, CLEANING, AND SERVICE ....................................................44
12.1 Maintenance intervals, service..........................................................................................................44
12.2 Cleaning and decontamination .........................................................................................................45
12.2.1 Cleaning..................................................................................................................................45
12.2.2 Decontamination.....................................................................................................................47
12.3 Sending the chamber back to BINDER GmbH.................................................................................48
13. DISPOSAL............................................................................................................48
13.1 Disposal of the transport packing .....................................................................................................48
13.2 Decommissioning..............................................................................................................................49
13.3 Disposal of the chamber in the Federal Republic of Germany.........................................................49
13.4 Disposal of the chamber in the member states of the EU except for the Federal Republic of
Germany ...........................................................................................................................................50
13.5 Disposal of the chamber in non-member states of the EU...............................................................51
14. TROUBLESHOOTING .........................................................................................52
15. TECHNICAL DESCRIPTION................................................................................53
15.1 Factory calibration and adjustment...................................................................................................53
15.2 Definition of usable volume...............................................................................................................53
15.3 Over current protection.....................................................................................................................54
15.4 Technical data...................................................................................................................................54
15.5 Equipment and options (extract).......................................................................................................56
15.6 Accessories and spare parts (extract) ..............................................................................................57
15.7 Dimensions M 53 ..............................................................................................................................58
15.8 Dimensions M 115 ............................................................................................................................59
15.9 Dimensions M 240 ............................................................................................................................60
15.10 Dimensions M 400 ............................................................................................................................61
15.11 Dimensions M 720 ............................................................................................................................62
16. EU DECLARATION OF CONFORMITY...............................................................63
17. PRODUCT REGISTRATION................................................................................65
18. CONTAMINATION CLEARANCE CERTIFICATE ...............................................66
18.1 For chambers located outside the USA and Canada.......................................................................66
18.2 For chambers located in the USA and Canada................................................................................69

M (E2) 04/2019 page 4/71
Dear customer,
For the correct operation of the chambers, it is important that you read this operating manual completely
and carefully and observe all instructions as indicated. Failure to read, understand and follow the instruc-
tions may result in personal injury. It can also lead to damage to the chamber and/or poor equipment
performance.
1. Safety
This operating manual is part of the components of delivery. Always keep it handy for reference. The
device should only be operated by laboratory personnel especially trained for this purpose and familiar
with all precautionary measures required for working in a laboratory. Observe the national regulations on
minimum age of laboratory personnel. To avoid injuries and damage observe the safety instructions of
the operating manual.
WARNING
Failure to observe the safety instructions.
may result in serious injuries and chamber damage.
Observe the safety instructions in this operating manual.
Carefully read the complete operating instructions of the chambers.
1.1 Legal considerations
This operating manual is for informational purposes only. It contains information for installing, start-up,
operation and maintenance of the product. Note: the contents and the product described are subject to
change without notice.
Understanding and observing the instructions in this operating manual are prerequisites for hazard-free
use and safety during operation and maintenance. In no event shall BINDER be held liable for any dam-
ages, direct or incidental arising out of or related to the use of this manual.
This operating manual cannot cover all conceivable applications. If you would like additional information,
or if special problems arise that are not sufficiently addressed in this manual, please ask your dealer or
contact us directly by phone at the number located on page one of this manual
Furthermore, we emphasize that the contents of this operating manual are not part of an earlier or exist-
ing agreement, description, or legal relationship, nor do they modify such a relationship. All obligations on
the part of BINDER derive from the respective purchase contract, which also contains the entire and ex-
clusively valid statement of warranty administration. The statements in this manual neither augment nor
restrict the contractual warranty provisions.
1.2 Structure of the safety instructions
In this operating manual, the following safety definitions and symbols indicate dangerous situations fol-
lowing the harmonization of ISO 3864-2 and ANSI Z535.6.
1.2.1 Signal word panel
Depending on the probability of serious consequences, potential dangers are identified with a signal
word, the corresponding safety color, and if appropriate, the safety alert symbol.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious
(irreversible) injury.

M (E2) 04/2019 page 5/71
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious
(irreversible) injury
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in moderate or minor
(reversible) injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in damage to the product
and/or its functions or of a property in its proximity.
1.2.2 Safety alert symbol
Use of the safety alert symbol indicates a risk of injury.
Observe all measures that are marked with the safety alert symbol in order to avoid death or
injury.
1.2.3 Pictograms
Warning signs
Electrical hazard
Hot surface
Explosive atmosphere
Stability hazard
Lifting hazard
Suffocation hazard
Pollution Hazard
Risk of corrosion and /
or chemical burns
Biohazard
Harmful substances
Mandatory action signs
Mandatory regulation Read operating
instructions
Disconnect the power
plug
Lift with several persons
Lift with mechanical
assistance
Environment protection
Wear protective gloves
Wear safety goggles

M (E2) 04/2019 page 6/71
Prohibition signs
Do NOT touch Do NOT spray with
water
Information to be observed in order to ensure optimum function of the product.
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
Instruction how to avoid the hazard: prohibition
Instruction how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels on the chamber
The following labels are located on the chamber:
Pictograms (Warning signs)
Service label
Hot surface
•Outer chamber door
•On the chamber rear next to the ex-
haust duct
6
8
ENTE
R
ENT
ENT
ENT
ER
ENT
ER
ENT
Figure 1: Position of labels on the chamber front
Keep safety labels complete and legible.
Replace safety labels that are no longer legible. Contact BINDER service for these replacements.

M (E2) 04/2019 page 7/71
1.4 Type plate
The type plate sticks to the left side of the chamber, bottom right-hand.
Figure 2: Type plate (example of M 115 regular chamber)
Indications of the type plate (example)
Information
BINDER
Manufacturer BINDER GmbH
M 115
Model designation
Drying and heating oven
Chamber name
Serial No.
000000000000
Serial no. of the chamber
Built
2017
Year of construction
Nominal temperature
300 °C
572 °F
Nominal temperature
IP protection
20
IP type of protection acc. to EN 60529
Temp. safety device
DIN 12880
Temperature safety device acc. to standard DIN 12880
Class
2.0
Class of temperature safety device
Art. No.
9010-0202
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
1,60 kW
Nominal power
230 V 1 N ~
Nominal voltage
±
10%, phase indication
7,0 A
Nominal current
50/60 Hz
Power frequency
Symbol on the type plate (example)
Information
CE conformity marking
Electrical and electronic equipment manufactured / placed
on the market in the EU after 13 August 2005 and to be
disposed of in a separate collection according to directive
2012/19/EU on waste electrical and electronic equipment
(WEEE).
The chamber is certified according to Customs Union
Technical Regulation (CU TR) for the Eurasian Economic
Union (Russia, Belarus, Armenia, Kazakhstan Kyrgyzstan).
Nominal temp.
300 °C
1,60 kW / 7,0 A
572 °F
230 V / 50 Hz
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
2.0
Art. No.
9010-0202
Project No.
Built
2017
Drying and heating oven
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
M 115
E2
Serial No. 00000000000000
Made in Germany

M (E2) 04/2019 page 8/71
1.5 General safety instructions on installing and operating the chambers
With regard to operating the chambers and to the installation location, please observe the DGUV guide-
lines 213-850 on safe working in laboratories (formerly BGI/GUV-I 850-0, BGR/GUV-R 120 or ZH 1/119,
issued by the employers’ liability insurance association) (for Germany).
BINDER GmbH is only responsible for the safety features of the chamber provided skilled electricians or
qualified personnel authorized by BINDER perform all maintenance and repair, and if components relat-
ing to chamber safety are replaced in the event of failure with original spare parts.
To operate the chamber, use only original BINDER accessories or accessories from third-party suppliers
authorized by BINDER. The user is responsible for any risk caused by using unauthorized accessories.
CAUTION
Danger of overheating.
Damage to the chamber.
Do NOT install the chamber in unventilated recesses.
Ensure sufficient ventilation for dispersal of the heat.
Do not operate the chambers in hazardous locations.
DANGER
Explosion hazard.
Danger of death.
Do NOT operate the chamber in potentially explosive areas.
KEEP explosive dust or air-solvent mixtures AWAY from the chamber.
The chambers do not dispose of any measures of explosion protection.
DANGER
Explosion hazard.
Danger of death.
Do NOT introduce any substance into the chamber which is combustible
or explosive at
working temperature.
NO explosive dust or air-solvent mixture in the inner chamber.
Any solvent contained in the charging material must not be explosive or inflammable. I.e., irrespective of
the solvent concentration in the steam room, NO explosive mixture with air must form. The temperature
inside the chamber must lie below the flash point or below the sublimation point of the charging material.
Familiarize yourself with the physical and chemical properties of the charging material, as well as the
contained moisture constituent and its behavior with the addition of heat energy.
Familiarize yourself with any potential health risks caused by the charging material, the contained mois-
ture constituent or by reaction products that may arise during the temperature process. Take adequate
measures to exclude such risks prior to putting the chamber into operation.

M (E2) 04/2019 page 9/71
DANGER
Electrical hazard.
Danger of death.
The chamber must NOT become wet during operation or maintenance.
The chambers were produced in accordance with VDE regulations and were routinely tested in accord-
ance to VDE 0411-1 (IEC 61010-1).
During and shortly after operation, the temperature of the inner surfaces almost equals the set-point.
CAUTION
The inner chamber, the door gasket, and the exhaust duct will become hot during
operation.
Danger of burning.
Do NOT touch the inner surfaces, the door gasket, the exhaust duct or the charging
material during operation.
1.6 Intended use
Drying and heating ovens with forced convection and advanced program functions M are suitable for
drying and heat treatment of solid or pulverized charging material, as well as bulk material, using the
supply of heat. They can be used for drying purposes but are specially designed for solving all the prob-
lems which occur during material and ageing tests.
The chambers are suitable for harmless materials. A mixture of any component of the charging material
with air must NOT be explosive. The operating temperature must lie below the flash point or below the
sublimation point of the charging material. Any component of the charging material must NOT be able to
release toxic gases.
Other applications are not approved.
The chambers are not classified as medical devices as defined by the Medical Device Directive
93/42/EEC.
Do NOT use the chambers for drying processes when large quantities of vapor would form and result in
condensation.
Due to the special demands of the Medical Device Directive (MDD), these chamber are not
qualified for sterilization of medical devices as defined by the directive 93/42/EWG.
Following the instructions in this operating manual and conducting regular maintenance work
(chap. 12) are part of the intended use.
The charging material shall not contain any corrosive ingredients that may damage the ma-
chine components made of stainless steel, aluminum, and copper. Such ingredients include
in particular acids and halides. Any corrosive damage caused by such ingredients is exclud-
ed from liability by BINDER GmbH.

M (E2) 04/2019 page 10/71
The chambers do not dispose of any measures of explosion protection.
DANGER
Explosion or implosion hazard.
Danger of poisoning.
Danger of death.
∅Do NOT introduce any substance combustible or explosive at working temperature in
to
the chamber, in particular no energy sources such as batteries or lithium-ion batteries
∅NO explosive dust or air-solvent mixture in the inner chamber.
∅Do NOT introduce any substance which could lead to release of toxic gases.
In case of foreseeable use of the chamber there is no risk for the user through the integration of the
chamber into systems or by special environmental or operating conditions in the sense of EN 61010-
1:2010. For this, the intended use of the chamber and all its connections must be observed.
2. Chamber description
The drying and heating ovens with forced convection and advanced program functions APT.line™ M are
specially developed precision warming chamber with high capacity. They are equipped with a multifunc-
tional microprocessor display controller with a digital display accurate to one-tenth of a degree. With their
comprehensive program control functions, they allow the high precision performance of temperature cy-
cles with fast heating-up phases.
The APT.line™ preheating chamber system guarantees high level of spatial and time-based temperature
precision, thanks to the direct and distributed air circulation into the interior. The fan supports exact at-
tainment and maintenance of the desired temperature accuracy.
The high-quality housing insulation ensures both a low noise mode of operation and a consistently low
housing temperature. The inner chamber, the pre-heating chamber and the interior side of the doors are
all made of stainless V2A (German material no. 1.4301, US equivalent AISI 304). When operating the
chamber at temperatures above 150 °C / 302 °F, the impact of the oxygen in the air may cause discolora-
tion of the metallic surfaces (yellowish-brown or blue) by natural oxidation processes. These colorations
are harmless and will in no way impair the function or quality of the chamber. The housing is RAL 7035
powder-coated. All corners and edges are also completely coated.
All chamber functions are easy and comfortable to use thanks to their clear arrangement. Major features
are easy cleaning of all chamber parts and avoidance of undesired contamination.
The chambers are equipped with a serial interface RS 422 for computer communication, e.g. with the
APT-COM™ 4 Multi Management Software (option, chap. 11.1) For further options, see chap. 15.4.
The M 720 model is equipped with four castors. Both front castors can be easily locked via the attached
brakes.
At an ambient temperature of +18 °C up to +40 °C / 64.4 °F to 104 °F, you can operate the chamber in a
temperature range from 5 °C / 9 °F above ambient temperature up to 300 °C / 572 °F.
