Bio Fireplace Group BIO-10-363 Operator's manual

USER MANUAL AND
SAFETY INSTRUCTIONS
Wall-mounted bioethanol replace

User manual and safety instructions for
wall-mounted bioethanol replace
Important!
Be sure to keep this user guide as long as the product is in your possession. If the product is
re-sold, this user guide must be included.
The bioethanol replace should only be used by adults, 18 years of age or older, who are
competent and who have read and understood this user manual with safety instructions and
guidelines.
• The bioethanol replace may only be used for decorative purposes, but at the same time
also provides heat, but can not be used as the primary heating source.
• Examine local legislation before use.
• The bioethanol replace is intended for indoor use only.
• Never change the construction of the bioethanol replace.
• Inside the bioethanol burner, there is ceramic cotton. This cotton should not be removed.
It is part of the replaces’ safety features and it absorbs liquid, so that any bioethanol lled
into the burner can not be spilled.
• It is forbidden for children, people under the inuence of alcohol, drugs or medication
and people with reduced physical or mental abilities to use and operate the bioethanol
replace.
• Outer surfaces and materials near the replace becomes hot during operation. Adequate
attention is required, as there may be a risk of burns.
• Be careful with ammable clothing or hair.
• Never leave the replace unattended, and keep children and pets at a safe distance.
• Keep a safe distance of at least 50 cm (from the left, right and front of burner) to other
objects and ammable materials.
• Never move a bioethanol burner or replace while in use.
• Only use bioethanol intended for bio replaces. A bioethanol with between 95-97.5%
alcohol is recommended.
• Bioethanol is a hazardous material with hazard level UN1987, level 3.
• Bioethanol is extremely ammable and must be handled with care.
• Be sure to check national and (or) regional regulations, on how to safely store fuel.
• Bioethanol should be stored in a safe and cool location, away from re and out of reach of
children.
• Keep a re extinguisher or re blanket in close reach during use.
ENGLISH

It is recommended to have a
re blanket
It is recommended to have a
re extinguisher
Read the instructions before
installation and use
Only use bioethanol
according to the instructions
Intended for decoration and
home use only
Should only be used in a
ventilated room
Installation of the wall-mounted replace
The replace should be mounted to the wall, using the included mounting brackets and the
replace should only be installed onto non-ammable wall surfaces. Mounting the replace onto
a wall with a wooden surface is not recommended.
For installing the replace, mark out the holes for the mounting brackets according to the
drawing. It is recommended to use a spirit level to make sure the replace is installed in level.
A minimum distance of 60 cm between the oor and the replace is recommended, and a
minimum of 100 cm above the replace to ammable materials.
Drill holes in the wall and fasten the bracket using the supplied plugs and screws. Make sure that
the brackets are well tted to the wall and that it can carry the weight of the replace.
Hang the replace onto the brackets and place the bioethanol burner inside the replace.
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m

How to use
Maintenance
Before you start to use the replace, make sure that it is assembled correctly and mounted
securely to the wall.
NEVER rell a burning or hot burner. Before relling the burner, turn off the replace and
wait a minimum of 30 minutes to allow the replace to cool down. Failing to do so can
result in very dangerous situations and severe personal damage.
1. Fill bioethanol into the burner. Make sure to not overll the burner and spill bioethanol. We
recommend using a funnel when relling the burner.
2. If the bioethanol burner is overlled, the excess bioethanol should be removed before
ignition. The same goes for bioethanol spilt next to the burner.
3. Spilt bioethanol can be removed with an absorbent cloth before ignition.
4. Once the lling is complete, empty bioethanol bottles should be closed and moved away
from the bioethanol replace before igniting.
5. WARNING! Never add bioethanol to a hot burner. Therefore, allow the burner to cool
down for a minimum of 30 minutes after use before relling.
6. Ignite the burner using a long lighter. It is recommended to use a long lighter to avoid
contact with the ames.
7. Extinguish the ames using the included extinguishing tool. Place it on top of the burner
and close off the supply of oxygen to the ames.
It is recommended to not leave any unburned bioethanol in the burner. It will evaporate over
time and be a waste of money. Try to only pour the amount of fuel into the replace that you
expect to use.
The replace itself can be cleaned using a damp cloth and some all-purpose cleaning products.
If the bioethanol burner is used frequently, discolouration may occur on top of the burner. This
is normal and does not change the function of the replace. Do not use abrasive products to
clean the insert. Instead, clean the surface with a damp cloth. Glass can be cleaned with normal
glass-cleaner.

Brugsvejledning og sikkerhedsinsturktioner
til væghængt biopejs
Vigtigt!
Sørg for at opbevare denne brugervejledning, så længe at produktet er i din besiddelse. Hvis
produktet videresælges, skal denne brugervejledning medfølge.
Bioethanolpejsen bør kun bruges af voksne, 18 år eller ældre, som er kompetente og som har
læst og forstået denne brugervejledning med sikkerhedsinstruktioner og retningslinjer.
• Bioethanolpejsen må kun bruges til dkeorative formål, men giver samtidig også varme, men
kan ikke bruges som primær varmekilde.
• Undersøg lokal lovgivning før brug.
• Bioethanolpejsen er kun beregenet til indendørs brug.
• Ændre aldrig konstruktionen af bioethanolpejsen.
• Inde i bioethanol brandkarret er der keramisk vat. Dette vat bør ikke fjernes. Det er en del
af pejsens sikkerhedsfunktioner og det absorbere væske, sådan at påfyldt bioethanol ikke
kan spildes ud af brandkarret igen.
• Det er forbudt for børn, personer påvirket af alkohol, stoffer eller medicin og personer med
nedsatte fysisk eller psykiske evner at bruge og betjene bioethanolpejsen.
• Ydre overader og materialer i nærheden af pejsen bliver varme under drift. Vær
opmærksom på dette for at undgå at blive forbrændt.
• Vær forsigtig med brændbart tøj eller hår.
• Efterlad aldrig pejsen uden opsyn, og hold børn og kæledyr på sikker afstand.
• Hold en sikker afstand på mindst 50 cm (fra venstre, højre og front) af brandkarret til andre
genstande og brændbare materialer.
• Flyt aldrig brandkarret eller biopejsen, mens den er i brug.
• Brug kun bioethanol beregnet til biopejse. En bioethanol mellem 95-97,5% alkohol anbe-
fales.
• Bioethanol er et farligt materiale med farenivuea UN1987, niveau 3.
• Bioethanol er ekstremt brandfarligt og skal håndteres med forsigtighed.
• Sørg for at tjekke nationale og (eller) regionale regler om, hvordan man sikkert opbevarer
brændstof.
• Bioethanol skal opbevares på et sikkert og køligt sted, væk fra ild og utilgængeligt for
børn.
• Hav en pulverslukker og/eller brandtæppe i nærheden under brug.
DANSK

Det anbefales at have et
brændtæppe
Det anbefales at have en
brændslukker
Læs vejledningen inden
installation og brug
Anvend kun bioethanol i
henhold til brugervejledningen
Kun beregnet til dekoration
og brug i hjemmet
Må kun anvendes i et
ventileret rum
Installation af den væghængte biopejs
Pejsen skal monteres på væggen ved hjælp af de medfølgende monteringsbeslag, og pejsen
bør kun monteres på ikke-brændbare vægoverfalder. Det anbefales ikke at montere pejsen på
en væg med træoverade.
Til montering af pejsen markeres hullerne til monteringsbeslaget i henhold til tegningen
herunder. Det anbefales at bruge et vaterpas for at sikre, at pejsen er installeret i vatter. Der
anbefales at have en minimumsafstand på 60 cm under pejsen til gulvet, samt 100 cm over
pejsen til brandbare materialer.
Bor huller i væggen og fastgør beslaget med de medfølgende rawlplugs og skruer. Sørg for, at
beslagene er monteret godt og at væggen kan være vægten af pejsen.
Hæng pejsen på beslagene og placer bioethanolbrænderen inde i pejsen.
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m

Fremgangsmåde
Vedligehold
Inden du begynder at bruge pejsen, skal du sikre dig, at den er monteres korrekt og sikkert på
væggen.
FYLD ALDRIG en tændt eller varm biopejs med bioethanol. Før du genopfylder brand-
karret, skal du slukke for pejsen og vente i mindst 30 minutter for at lade pejsen køle af.
Undladelse af at gøre dette kan resultere i ekstremt farlige situationer og alvorlig person-
skade.
1. Fyld bioethanol i brandkarret. Sørg for ikke at overfylde brænderen og derved spilde bioet-
hanol. Vi anbefaler at bruge en tragt ved genopfyldning af brandkarret.
2. Hvis brandkarret overfyldes, skal alt overskydende bioethanol fjernes inden antænding. Det
samme gælder for evt. bioethanol spildt ved siden af brandkarret.
3. Spildt bioethanol kan fjernes med en absorberende klud.
4. Når påfyldningen er færdig, skal tomme bioethanolasker lukkes og yttes væk fra pejsen
før den tændes.
5. ADVARSEL! Tilføj aldrig bioethanol til et varmt brandkar. Lad derfor brandkarret køle
af i minimum 30 minutter efter brug, før den genopfyldes.
6. Tænd brandkarret med en lighter. Det anbefales at bruge en lang lighter for at undgå
kontakt med ammerne.
7. Sluk ammerne med det medfølgende slukningsværktøj. Placer den oven på brandkarret
og luk dermed for ilttilførslen til ammerne.
Det anbefales ikke at efterlade uforbrændt bioethanol i brandkarret. Det vil med tiden fordampe
af sig selv, og derved være spild af penge. Førsøg derfor kun at hælde den mængde bioethanol
i brandkarret, som du forventer at skulle bruge.
Selve biopejsen kan rengøres med en fugtig klud og almindelig universal rengøringsmiddel.
Hvis bioethanolbrænderen bruges hyppigt, kan der forekomme misfarvning oven på brand-
karret. Dette er normalt og ændre ikke brandkarrets funktionalitet. Undgå at bruge slibende
rengøringsmidler til at rengøre pejsen og brandkar. Rengør i stedet overaden med en fugtig
klud. Glas kan rengøres med glasrens.

Bedienungsanleitung und Sicherheitshinweise
für Bioethanol Wandkamine
Wichtig!
Bewahren Sie diese Bedienungsanleitung unbedingt auf, solange sich das Produkt in Ihrem
Besitz bendet. Wenn das Produkt weiterverkauft wird, muss diese Bedienungsanleitung
beigefügt werden.
Der Bioethanol Kamin darf nur von sachkundigen Erwachsenen ab 18 Jahren verwendet werden,
die diese Bedienungsanleitung mit Sicherheitshinweisen und Richtlinien gelesen und verstanden
haben.
• Der Bioethanol Kamin darf nur zu dekorativen Zwecken verwendet werden. Er liefert aber
gleichzeitig auch Wärme, kann aber nicht als primäre Wärmequelle genutzt werden.
• Informieren Sie sich vor der Verwendung über die örtliche Gesetzgebung.
• Der Bioethanol Kamin ist nur für den Gebrauch in Innenräumen bestimmt.
• Verändern Sie niemals die Konstruktion des Bioethanol Kamins.
• Im Inneren des Bioethanol Brenners bendet sich Keramikwatte. Diese Kermaikwatte sollte
nicht entfernt werden. Es gehört zu den Sicherheitsmerkmalen des Brenners und absorbiert
Flüssigkeit, sodass eventuell vorhandenes Bioethanol gefüllt wird in den Brenner kann nicht
verschüttet werden.
• Es ist für Kinder, Personen unter dem Einuss von Alkohol, Drogen oder Medikamenten
und Menschen mit eingeschränkten körperlichen oder geistigen Fähigkeiten verboten, den
Bioethanol Kamin zu verwenden und zu betreiben.
• Äußere Oberächen und Materialien in der Nähe des Kamins werden während des Betriebs
heiß. Eine angemessene Aufmerksamkeit ist erforderlich, da Verbrennungsgefahr bestehen
kann.
• Seien Sie vorsichtig mit brennbarer Kleidung oder Haaren.
• Lassen Sie den Kamin niemals unbeaufsichtigt und halten Sie Kinder und Haustiere in
sicherem Abstand.
• Halten Sie einen Sicherheitsabstand von mindestens 50 cm (links, rechts und vor dem
Brenner) zu anderen Gegenständen und brennbaren Materialien ein.
• Bewegen Sie niemals einen Bioethanol Brenner oder Kamin, während er in Betrieb ist.
• Verwenden Sie nur für Bioethanol Kamine bestimmtes Bioethanol. Empfohlen wird ein
Bioethanol mit einem Alkoholgehalt zwischen 95-97,5 %.
• Bioethanol ist ein Gefahrstoff der Gefahrenstufe UN1987, Stufe 3.
• Bioethanol ist hochentzündlich und muss mit Vorsicht behandelt werden.
• Beachten Sie unbedingt die nationalen und (oder) regionalen Vorschriften zur sicheren
Lagerung von Kraftstoff.
• Bioethanol sollte an einem sicheren und kühlen Ort, fern von Feuer und außerhalb der
Reichweite von Kindern gelagert werden.
• Halten Sie während des Gebrauchs einen Feuerlöscher oder eine Löschdecke in Reichweite.
DEUTSCH

Es wird empfohlen, eine
Löschdecke zu haben
Es wird empfohlen, einen
Feuerlöscher dabei zu haben
Lesen Sie die Anweisun-
gen vor der Installation und
Verwendung
Verwenden Sie Bioethanol nur
gemäß den Anweisungen
Nur für Dekoration und den
Heimgebrauch bestimmt
Sollte nur in einem belüfteten
Raum verwendet werden
Installation von dem Ethanol Wandkamin
Der Kamin muss mit den mitgelieferten Montagehalterungen an der Wand montiert werden
und der Kamin sollte nur auf nicht brennbaren Wandpfosten montiert werden. Es wird nicht
empfohlen, den Kamin an einer Wand mit Holzoberäche zu montieren.
Markieren Sie bei der Installation des Kamins die Löcher für die Montagehalterung gemäß der
folgenden Zeichnung. Es wird empfohlen, eine Wasserwaage zu verwenden, um sicherzustellen,
dass der Kamin im Wasser installiert wird. Es wird empfohlen, unter dem Kamin einen Mindest-
abstand von 60 cm zum Boden und 100 cm über dem Kamin zu brennbaren Materialien einzu-
halten.
Bohren Sie Löcher in die Wand und befestigen Sie die Halterung mit den mitgelieferten Dübeln
und Schrauben. Stellen Sie sicher, dass die Halterungen gut befestigt sind und dass die Wand
das Gewicht des Kamins tragen kann.
Hängen Sie den Kamin an die Halterungen und platzieren Sie den Bioethanol Brenner in den
Kamin.
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m
Installation of SUNSET GARDEN bio-fireplace
SUNSET GARDEN bio-fireplace is a free-standing device designed for
installation on a flat and non-flammable surface. The device should be
installed as specified below. Stick the rubber or felt washers (4 pcs.) included
in the delivery to the base of the bio-fireplace. Position the bio-fireplace on
an even surface and install the windows (4 pcs.).
To properly mount the windows, insert them gently all the way into the
dedicated longitudinal holes. As an additional precaution, this should always
be performed using protective gloves. Also, insert the bio-ethanol tank in the
appliance. Never insert a filled fuel tank, as you can accidentally spill the fuel
onto the bio-fireplace parts or around it.
Once the device is installed, make sure that everything has been carried out according to the manual.
Installation of suspended 1200x400, 900x400 and 650x400 bio-fireplaces
The bio-fireplace should be mounted to the wall only by an installer with appropriate
permissions. The bio-fireplace should be installed only on a wall made of non-
combustible materials. Before installation, check the specifications described in the
"Important Safety Instructions" section to determine if the room to be assembled is
suitable for use.
For assembly, mark the position of the mounting holes in the target place on the wall.
It is recommended to use a spirit level in order to obtain a vertical and level of assembly
strips. It is recommended to keep a minimum distance of 60 cm between the floor and
the device.
Drill holes and fasten the slats with fastening elements to the wall using the supplied
assembly materials (the supplied fasteners are suitable for stone, brick and concrete
walls). It is necessary to hang the bio-fireplace on the mounting rails and make sure that
the fixing of the rails and the device are properly fixed.
Before or after installing the device, make sure that the place where the device is
installed will withstand its weight. The bioethanol container should be placed in the
device. Never place a filled container for biofuel, because you can inadvertently pour fuel
on parts of the device or its surroundings. In the case of adjustable containers, the
bioethanol container cover should be placed on the container in such a way that when
the flame height is closed or controlled, the lid can move freely backwards and forwards.
Installation of suspended 650x400BOX, 900x400BOX and 1200x400BOX bio-fireplaces
The bio-fireplace should be installed on the wall only by an installer with an appropriate licence. The bio-fireplace may be installed only on a wall made of
non-flammable materials. Before installation, check the specifications contained in “Important safety guidelines” to determine whether the room of
installation is suitable to use the appliance. BOX bio-fireplaces are designed for placement and installation on a flat surface by the wall or for suspension on
the wall. We recommend a minimum distance of 60 cm between the floor and the device. The device should be mounted on the wall as specified below.
On the casing rear, there are two irregular holes used for wall mounting. Mark two attachment points on the wall, spaced 865mm. In the attachment points,
drill holes with a diameter of 8 mm. Insert the expansion anchors supplied with the bio-fireplace into the pre-drilled holes. Screw the two upper bolts into
the expansion anchors so that the distance between the wall and bolt head is is approx.
3mm. The insert them into the circular mounting hole. Then vigorously move the entire
bio-fireplace rightwards and then downwards, which will block it in a safe position.
Also, insert the bio-ethanol tank in the appliance. Never insert a filled fuel tank, as you can
accidentally spill the fuel onto the bio-fireplace parts or around it. For adjustable tanks,
place the bio-ethanol tank’s cover on the tank in such a way that during closing or
controlling the flame the cover can be freely moved frontward or backward.
Before or after the installation, make sure that the place of installation can withstand the
device weight.
Installation of 650 insert
The 650 insert is a bio-fireplace device intended for installation
in a furniture board with increased resistance to high temperature (e.g. MDF
laminated board, non-inflammable), fireproof plasterboard, metal and stone
constructions, as well as other non-combustible materials. The device should be
mounted in a horizontal position (acceptable deviation
horizontally is +/- 5 degrees). The construction must guarantee the stability of the
device.
The assembly should be carried out according to the steps described below. Insert
handles included in the set into the body of the 650 insert. Depending on the material
from which the device casing is made, the supplied screws with self-locking nuts or
screws with a plug should be used for this. The holes for fixing the glass holder also
serve as a fastening function for the entire bio-fireplace insert in the building. Then
attach the glass
in the handles, pressing them with the adjustment screws being an integral part of
the handle. The final stage of assembly is the insertion of a container for bioethanol
in the hole at the top of the device.
BIO-FIREPLACE PARAMETERS
NAME HOME BOARD STAINLESS SMART SUNSET GARDEN
Weight [kg] 3 4.1 1.25 1.3 12
Burner capacity [l]
0.7 0.7 0.5 0.2 1
Burning time [h] 2–5h/l 2–5h/l 2–5h/l 8h/l 1–3h/l
Minimum distance to flammable materials: 0.5 m
Parameters and dimensions of suspended bio-fireplaces: 1200x400, 900x400, 650x400, BOX 1200x400, BOX 900x400 and BOX 650x400
NAME 650x400 900x400 1200x400 650x400 BOX 900x400 BOX 1200x400 BOX
A [mm] 650 900 1200 650 900 1200
B [mm] 400 400 400 400 400 400
C [mm] 510 760 1060 490 740 1040
D [mm] 526 776 1076 650 900 1200
E [mm] 90 90 90 0 0 0
F [mm] 120 120 120 120 120 120
G [mm] 276 276 276 400 400 400
Weight [kg] 4.3 6.5 8.5 6.5 9 15
Burner capacity [l]
0.35 0.75 3 x 0.35 0.35 0.75 3 x 0.35
Burning time [h] 1 1.2 1 1 1.2 1
Minimum distance to flammable materials: 0.5 m

Vorgehensweise
Wartung
Bevor Sie den Kamin in Betrieb nehmen, vergewissern Sie sich, dass er korrekt und sicher an der
Wand montiert ist.
FÜLLEN SIE NIEMALS einen brennenden oder heißen Ethanol Kamin mit Bioethanol. Bevor
Sie den Brenner wieder befüllen, schalten Sie den Kamin aus und warten Sie mindestens
30 Minuten, damit der Kamin abkühlen kann. Nichtbeachtung kann zu äußerst gefährlichen
Situationen und schweren Verletzungen führen.
1. Füllen Sie den Brenner mit Bioethanol. Achten Sie darauf, den Brenner nicht zu überfüllen
und dadurch Bioethanol zu verschütten. Wir empfehlen, beim Nachfüllen des Brenners
einen Trichter zu verwenden.
2. Wenn der Brenner überfüllt ist, muss vor der Zündung alles überschüssige Bioethanol
entfernt werden. Gleiches gilt für neben dem Brenner verschüttetes Bioethanol.
3. Verschüttetes Bioethanol kann mit einem saugfähigen Tuch entfernt werden.
4. Leere Bioethanolaschen müssen nach dem Befüllen verschlossen und vor dem Anzünden
vom Kamin entfernt werden.
5. WARNUNG! Gießen Sie niemals Bioethanol in einen heißen Brenner. Lassen Sie den
Brenner daher nach Gebrauch mindestens 30 Minuten abkühlen, bevor Sie ihn wieder
befüllen.
6. Zünden Sie den Brenner mit einem Feuerzeug an. Es wird empfohlen, ein langes Feuerzeug
zu verwenden, um den Kontakt mit den Flammen zu vermeiden.
7. Löschen Sie die Flammen mit dem mitgelieferten Löschwerkzeug, indem Sie die Platte
schieben und die Sauerstoffzufuhr zu den Flammen unterbrechen.
Es wird nicht empfohlen, unverbranntes Bioethanol im Brenner zu belassen. Wenn Sie die
nachhaltigste und billigste Verbrennung wünschen, müssen Sie nur die Menge Bioethanol in
die Brennkammer gießen, die Sie voraussichtlich verwenden werden. Denn Bioethanol kann
verdunsten und wird somit verschwendet.
Der Bioethanol Kamin kann mit einem feuchten Tuch und Allzweck-Reiniger gereinigt werden.
Bei häuger Verwendung des Bioethanol Brenners kann es zu Verfärbungen auf der Oberseite
des Brenners kommen. Dies ist normal und ändert nichts an der Funktionalität des Brenners.
Vermeiden Sie die Verwendung von Scheuermitteln, um den Kamin und Brenner zu reinigen.
Reinigen Sie die Oberäche stattdessen mit einem feuchten Tuch. Glas kann mit Glasreiniger
gereinigt werden.

www.bioreplacegroup.com
