Firegear FPB-16RBSMT-N User manual

Outdoor Match Throw (MT) Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
INSTALLATION PRECAUTION:
This re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
Natural Gas Description Propane
FPB-16RBSMT-N 16” Round Stainless pan & Spur Kit FPB-16RBSMT-P
FPB-19RBSMT-N 19” Round Stainless Pan & Spur Kit FPB-19RBSMT-P
FPB-25RBSMT-N 25” Round Stainless Pan & Spur Kit FPB-25RBSMT-P
FPB-29RBSMT-N 29” Round Stainless Pan & Spur Kit FPB-29RBSMT-P
FPB-33RBSMT-N 33” Round Stainless Pan & Spur Kit FPB-33RBSMT-P
FPB-20SBSMT-N 20” Square Stainless Pan & Spur Kit FPB-20SBSMT-P
FPB-26SBSMT-N 26” Square Stainless Pan & Spur Kit FPB-26SBSMT-P
FPB-32SBSMT-N 32” Square Stainless Pan & Spur Kit FPB-32SBSMT-P
FPB-38SBSMT-N 38” Square Stainless Pan & Spur Kit FPB-38SBSMT-P
MODELS
MH# 60069

REV. 1-9-19 Page 2
MT Burning Spur Fire Pits
Fuels used in gas red appliances, and the products of combustion such as fuels, contain
chemicals known to cause cancer, birth defects and/or other reproductive harm.
This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed area can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open ame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or re department.
DANGER WARNING
Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or other appliances.
Any LP cylinder not connected for use
shall not be stored in the vicinity of this
or other appliances.
WARNING
Do not leave unattended during use.
Do not use for cooking.
Follow all gas leak procedures in this
manual prior to operation.
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
WARNING
If the information in these instructions is not followed exactly, a re or explosion
may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other ammable vapors and liquids in the vicinity
of this or other appliances.

REV. 1-9-19 Page 3
MT Burning Spur Fire Pits
Specications 4
Gas Pipe Sizing Chart 5
Preparation for Non-Combustible Structure 6
Hard Piping to Fire Pit 6
Cross Ventilation Requirements 6
High Elevation 6
Installation into an Approved Enclosure 7
Requirements 7
Installing Orice & Key Valve 7
Typical Installation Drawings 8
Operation 9
Lighting Instructions 9
Expanded View Drawing 10
Replacement Parts 11
Replacement Parts List 12
Fire Pit Maintenance/ Trouble Shooting 13
Optional Accessories 14
TABLE OF CONTENTS
All media (i.e. lava rock, lava stones, lava boulders and re glass) has the potential of thermal
spalling. This is a process that may occur when media is wet and moisture gets trapped inside of
the material due to rapid temperature differences. When this happens the media has the potential
to crack or “pop” outside the replace.
WE HIGHLY RECOMMEND COVERING ALL FIRE FEATURES WHEN NOT IN USE
The use of a cover can lessen the impact of thermal spalling; however, heavy rains, high
humidity and the presence of moisture may still cause the media to pop.
ALWAYS USE CAUTION WHEN USING THE FIRE FEATURE
Extra caution should be taken when lighting a replace when heavy rains, high humidity and
moisture are present. Light the replace; leave the area allowing any moisture in the media to
dissipate. We strongly recommend that during this drying out time that you monitor the re feature
from a distance. This drying out period should be no less than 30 minutes. Continue monitoring
the ame from distance to ensure that all popping has ceased before fully enjoying the re.
CALIFORNIA PROPOSITION 65
WARNING
This product is designed to operate with one of the following fuel sources: Liquid Propane or Natural Gas. The fuel
used to operate this product, and the products of combustion of such fuel, can expose you to chemicals including
Benzene which is known to the State of California to cause cancer, birth defects and other reproductive harm and
Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm.
(For more information go to: www.p65Warnings.ca.gov.)

REV. 1-9-19 Page 4
MT Burning Spur Fire Pits
SPECIFICATIONS
Table 1. Fire Pit Dimensions
A
B
C
⅞”TYP. (usable flat lip)
*
*D
Ground Level (Earth)
Fig 1. Fire Pit Dimensions; refer to Table 1.
(Dimensions applicable to round or square pans)
Model:
MT Natural Gas (NG)
NG Factory
Orice
NG
Btu’s
Model:
MT Propane (LP)
LP Factory
Orice
LP
Btu’s
FPB-16RBSMT-N #35 45,500 FPB-16RBSMT-P #47 45,000
FPB-19RBSMT-N #29 65,000 FPB-19RBSMT-P #41 65,000
FPB-25RBSMT-N #29 65,000 FPB-25RBSMT-P #41 65,000
FPB-29RBSMT-N #29 65,000 FPB-29RBSMT-P #41 65,000
FPB-33RBSMT-N #29 65,000 FPB-33RBSMT-P #41 65,000
FPB-20SBSMT-N #29 65,000 FPB-20SBSMT-P #41 65,000
FPB-26SBSMT-N #29 65,000 FPB-26SBSMT-P #41 65,000
FPB-32SBSMT-N #29 65,000 FPB-32SBSMT-P #41 65,000
FPB-38SBSMT-N #29 65,000 FPB-38SBSMT-P #41 65,000
Table 2. Btu Specications
Pressure NG LP
Min. Inlet 5.0” WC 10.5” WC
Max. Inlet 10.5” WC 13.0” WC
Normal Inlet 7.0” WC 11.0” WC
Table 3. Gas Pressures
Model:
Natural Gas (NG)
Model:
Propane Gas (LP) A
Pan
Depth
B
Min./Max.
Install Opening
C
Inside
Pan
D
Ground
Level
E
Side
Wall
F
Combustible
Ceiling
G
Combustible
Floor
FPB-16RBSMT-N FPB-16RBSMT-P 2 ½” 16 ¼”- 17 ½”15 ⅞”8” 14” 57” 15.½”
FPB-19RBSMT-N FPB-19RBSMT-P 2 ¾”19¼” - 21” 19” 8” 16” 54” 18”
FPB-25RBSMT-N FPB-25RBSMT-P 2 ¾” 25 ¼”- 27” 25” 8” 19” 69” 18”
FPB-29RBSMT-N FPB-29RBSMT-P 2 ¾” 30 ¼” - 31 ¼”29” 8” 19” 69” 18”
FPB-33RBSMT-N FPB-33RBSMT-P 2 ¾” 34 ¼” - 35” 33” 8” 19” 69” 18”
FPB-20SBSMT-N FPB-20SBSMT-P 2 ¾” 20 ¼” - 21” 20” 8” 16” 54” 18”
FPB-26SBSMT-N FPB-26SBSMT-P 2 ¾” 26 ¼” - 27” 26” 8” 19” 69” 18”
FPB-32SBSMT-N FPB-32SBSMT-P 2 ¾” 32 ¼”- 33” 32” 8” 19” 69” 18”
FPB-38SBSMT-N FPB-38SBSMT-P 2 ¾” 38 ¼”- 39” 38” 8” 19” 69” 18”
Disclaimer: Btu listings are based on 7.0”WC for Natural Gas and 11.0”WC
for Liquid Propane (LP) to the gas valve. Flex line size and proper gas pipe
sizing will also affect Btu’s. As a result your Btu’s may vary slightly from
Table 2 specications.
Fig 2. Clearance to Combustibles (Not
to be used in an enclosed space)
F
E
G

REV. 1-9-19 Page 5
MT Burning Spur Fire Pits
GAS PIPE SIZING CHART
REFERENCE
GAS PIPE SIZING
Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4”
10 275 567 1071 2205 3307 6221 10140 17990 35710
20 189 393 732 1496 2299 4331 7046 12510 25520
30 152 315 590 1212 1858 3465 5695 10110 20620
40 129 267 504 1039 1559 2992 4778 8481 17300
50 114 237 448 913 1417 2646 4343 7708 15730
60 103 217 409 834 1275 2394 3908 6936 14150
70 89 185 346 724 1086 2047 3329 5908 12050
80 78 162 307 630 976 1811 2991 5309 10830
90 69 146 275 567 866 1606 2654 4711 9613
100 63 132 252 511 787 1496 2412 4281 8736
125 54 112 209 439 665 1282 2083 3618 7382
150 48 100 185 390 590 1138 1808 3210 6549
175 43 90 168 353 534 1030 1637 2905 5927
200 40 83 155 325 491 947 1505 2671 5450
300 37 77 144 303 458 887 1404 2492 5084
NATURAL GAS : PIPE SIZING CHART
• Natural Gas (NG) flow is given in
thousands of BTU/hr. = 1cubic
foot of NG gas - 1000 BTU
• Nominal pressure at the burner
for Natural Gas is 3.5” of water
column. (Typical machine supply
5”-7”)
• Pipe length must include
additional length for all fittings.
Add approximately 5 feet of pipe
per fitting.
• Natural Gas Example: A machine
with a burner that requires
440,000 BTU would need a 1 -1/4”
pipe for a 20” long run.
LIQUID PROPANE : PIPE SIZING CHART
NOTE: The sizing charts above list the specific pipe sizes required for the amount of BTU’s for a new gas line installations. If you
are using an existing gas line you must take into consideration the existing gas line capacities to ensure you will have proper
pressure. This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel
Gas Code - current edition) for more details.
Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4”
10 108 230 387 793 1237 2259 3640 6434 -
20 75 160 280 569 877 1610 2613 5236 9521
30 61 129 224 471 719 1335 2165 4107 7859
40 52 110 196 401 635 1143 1867 3258 6795
50 46 98 177 364 560 1041 1680 2936 6142
60 42 89 159 336 513 957 1559 2684 5647
70 38 82 149 317 476 896 1447 2492 5250
80 36 76 140 239 443 840 1353 2315 4900
90 33 71 133 275 420 793 1288 2203 4667
100 32 68 126 266 411 775 1246 2128 4518
125 28 60 117 243 369 700 1143 1904 4065
150 25 54 105 215 327 625 1008 1689 3645
175 23 50 93 196 303 583 993 1554 3370
200 22 47 84 182 280 541 877 1437 3160
300 17 37 70 145 224 439 686 1139 2539
• Liquid Propane (LP) Gas flow is
given in thousands of BTU/hr. =
1cubic foot of LP gas - 2500 BTU.
• This chart refers to low pressure LP,
after regulation, Standard nominal
pressure at the burner for Liquid
Propane Gas is 11” of water column.
• Pipe length must include additional
length for all fittings. Add
approximately 5 feet of pipe per
fitting.
• LP Example: A machine with a
burner that requires 440,000 BTU
would need a 1” pipefor a 20’ long
run.
Table 4 Gas pipe sizing.

REV. 1-9-19 Page 6
MT Burning Spur Fire Pits
WARNING: Proper clearances from combustible materials must be maintained from all sides, top and bottom of this
appliance. Use the specications listed on page 4 for proper clearance to combustibles.
PREPARING A NON-COMBUSTIBLE STRUCTURE
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Fire pits are subjected to many outdoor elements such as rain,
snow, wind, heat or cold. A minimum of 18 square inches of
cross ventilation (2 sides) is required to keep the
components in good working order. Use Fig 3 as guide to
assist to incorporate proper ventilation.
Fig 3. Cross Ventilation Example
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0-4500 feet in
Canada and the U.S. If elevation exceeds 4500 feet it may be
necessary to decrease the input rating by changing the
existing burner orice to a smaller size. Input should be
reduced 4% for each 1000 feet beyond the 4500 feet above
sea level. Check with your local gas utility for assistance in
determining the proper orice in your location. In some cases
the heating value may already be reduced and downsizing the
orice may not be necessary. Refer to NFPA54 Table E.1.1(d)
for high altitude orice sizing.
(2) 6”x12”
Fire Pit
Examples of Cross Ventilation
3 - 2”x3” Slots Per Side or
2- 1” x 9” Slots Per Side or
2- Firegear 6 x12 vents
Cross Flow Ventilation
(Min. 18 Sq. In. Per Side)
Fire Pit
Enclosure
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
The appliance and its manual shutoff valve must be disconnected from the gas supply piping system during any
pressure testing of the system at test pressure testing of the system at test pressures in excess of ½” psig (3.5kPa).
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½” psig (3.5kPa)
The re pit can be installed on a at, stable surface, away from any combustible materials. Install re pit on any level,
outdoor non-combustible, at stable surface or a combustible oor according to the clearances specied in this manual.
NOTE: Do not place re pit directly on grass, dirt, or rocks as this may prevent proper ventilation (Fig. 3). Ensure proper
water drainage is also incorporated into the re pit enclosure.
HARD PIPING TO FIRE PIT WITHOUT GAS PROXIMITY
NOTE: Refer to the NFPA54 (National Fuel Gas Code) for proper pipe sizing. In the absence of NFPA54 booklet, you
can use gas pipe sizing chart on page 5.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply pipe sealant to the ttings before making any connection.
2. BE CAREFUL! Ensure all gas connections are snug, but do not over tighten!
3. Consult a plumber for proper installation to ensure you are providing adequate gas supply for your application.
4. The primary gas shut-off (not supplied) will require a ½” male ared tting to enable connection of the stainless steel
ex gas line supplied with the re pit.
5. Do not place an LP tank inside any re pit enclosure. Locate all propane (LP) tanks outside the enclosure.
6. To prevent performance problems in Propane (LP) re pits, do not use a Propane tank less than 100lbs. capacity.

REV. 1-9-19 Page 7
MT Burning Spur Fire Pits
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
INSTALLING KEY VALVE
The key valve contents: 1- key valve, 1-
key and 1- ange. (See Fig. 5). The valve
requires a 1¼” round clearance hole in the
non-combustible enclosure wall. See the
instructions supplied with the key valve for
more specic details. Note: Be sure to leak
test all tting before operation. Fig. 6 shows
an example of a typical installation.
Primary Gas
Supply
ON
OFF
Fig. 5 Key valve components.
REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath
should be non-combustible or a at level combustible surface according to the clearances specied in this manual.
2. Refer to the NFPA54 (National Fuel Gas Code) for proper pipe sizing. See Table 4 on page 5.
3. Determine the size of the round or square re pit you are preparing to install (Refer to page 4).
4. You must provide a round or square cut-out opening to place the re pit into the non-combustible enclosure.
Do not exceed the maximum opening from Table 1, dimension B.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance.
7. CAUTION: A minimum of 18 square inches of cross ventilation (per side) is required to keep the inside of the
enclosure dry. We recommend installation of a VENT-KIT-6x12SS. See accessory page 14.
8. These products are designed for outdoor use only. Not approved for any indoor use.
9. This re pit is designed to have lava rock completely covering the spur burner, so that the burner is not visible.
Do not cover more than 1” above the top of the covered burner. When purchasing Lava Rock use minimum of 1” to
2” diameter as a base to ll the burner pan. DO NOT COVER THE IGNITION HOOD WITH ANY ROCK OR MEDIA.
10. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak tested
before installation of the re pit. Soapy water leak detection is required before regular use of the re pit.
11. Do not use material that will absorb moisture over time and will not release this moisture quickly. Moisture can boil
in this material and can rapidly break apart and cause damage or personal injury.
12. Never leave any other combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
INSTALLING BURNER ORIFICE (OAS)
GAS FLOW
Burner Pan
OAS#
U3-8D-S
Lock Nut
Locate the burner nipple underneath the
burner pan. Ensure the nipple from on
the spur burner has gas rated Teon tape
wrapped around the threads. Thread the
OAS (orice air shutter) on to the nipple
of the burning spur clockwise manner.
Secure into position. See Fig. 4.
Fig. 4 Installing OAS assembly to spur burner.

REV. 1-9-19 Page 8
MT Burning Spur Fire Pits
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Primary Gas
Supply
K
e
y
V
a
l
v
e
S
i
d
e
V
i
e
w
D
e
t
a
i
l
Fig. 6 Typical installation.
Key valve and exible gas line are supplied; E-Stop shut-off is not provided, but available in
accessories page. Flex lines with ared ttings do not require Teon tape or pipe
compound. Ensure not to “kink” the ex lines to allow better gas ow of gas.
Note: The illustration above is only a guide for the gas connection. Local codes may
require different methods to connect the gas supply.
Note: A 1¼” x 2” black iron or galvanized
coupler/nipple (not supplied) can be used
as a spacer between the manual valve
and the valve ange to add additional
support to hold the manual key valve in
place.
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Black Iron
Nipple
Key Valve
Gas Supply
Fire Pit Pan
Non-Combustible
Fire Pit Enclousure
E-Stop
Spur Burner
Steel Studs
Steel Studs
Steel Studs
Steel Studs
Key
PUSH TO STOP
TURN TO START
OFF
0.5
HOURS
1
1.5
2
2.5

REV. 1-9-19 Page 9
MT Burning Spur Fire Pits
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the re pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
Key
Fig. 7 Inserting Key into Valve
ON
OFF
Fig. 6. Key Valve Face
Butane Lighter
Fig. 8 Lighting re pit with lighter
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE
ATTEMPTING TO LIGHT FIRE PIT
CAUTION: ENSURE YOU HAVE LEAK TESTED THE FIRE PIT BEFORE OPERATING
TURNING ON FIRE PIT
1. Insert key into shut-off valve and secure into square end (see Figs 6 & 7).
2. Light a long match or butane lighter and hold it near the burner.
3. Turn the key slowly counter-clockwise in gas valve (until it stops) to allow gas to ow
and simultaneously apply the long burning match or Butane lighter as close to the end
burner as possible to light the re pit.
4. Gas should ignite within 10 seconds or less. If re pit does not light within 10 seconds
turn key clockwise to turn OFF the gas supply. Ensure there is not too much media on
top of the burner that might inhibit gas ow and try again in 5-minutes.
TURNING OFF FIRE PIT
1. Insert key into shut-off valve and secure into square end.
2. Turn key clockwise until it stops.
3. After cooling off install cover.

REV. 1-9-19 Page 10
MT Burning Spur Fire Pits
” Washer
Brass Nut
OASNG#
U3-8D-S
(Fitting)
Spur Burner
CVR-BVL2CP
(Chrome Cover Plate)
BVL2S
(Key Valve)
U1-8D-S
U1-8D-S
(Fitting)
Fire Pit Pan
Inlet Gas Supply
Expanded View of Match Throw (MT) Fire Pits
T200-9898-46
(Flex Connector)
Note: Use joint compound or
gasses on all male NPT
Ensure all connections are
tight and check for gas leaks
before and after assembly is
complete.
(Not Supplied)
