Owner’s Manual
Model : 1265
BIOCARE NO TOUCH THERMOMETER :
Thank you for purchasing the BioCare NoTouch Forehead Thermome-
ter. Please read this instruction manual rst so you can use this
thermometer safely and correctly. Please keep this instruction manual
for future reference.This innovative medical device uses advanced
infrared (IR) technology to measure temperature instantly and
accurately on the forehead or object.
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE USE
The following basic safety precautions should always be taken.
1. Close supervision is necessary when the thermometer is used by, on,
or near children , handicapped persons or invalids.
2. Use the thermometer only for the intended use described in this
manual.
3. Do not use the thermometer if it is not working properly, or if it has
suered any damage.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
BEFORE YOU BEGIN
Cautions and Warnings
• As with any thermometer, proper technique is crucial to obtaining
accurate temperaturereadings. Please read this manual thoroughly
and carefully before using.
• Always operate the thermometer in an operating temperature range
16°C to 40°C (60.8°F to 104°F ) , and relative humidity less than 95%.
• Always store the thermometer in a cool and dry place -20°C to 50°C
(-4°F to 122°F) and relative humidity less than 95%.
• Avoid direct sunlight.
• Avoid dropping the thermometer, if it happens and you think the
thermometer may be damaged ,please contact customer services
immediately.
• Do not touch the lens.
• Do not disassemble the thermometer.
• Basic safety precautions should always be observed, especially when
the thermometer is used on or near children and disabled persons.
• This thermometer is not intended to substitute for a consultation with
your physician.
• This thermometer and the subject must remain in a stable environ
ment for at least 30 minutes before measuring the temperature.
• When the measured temperature falls within the fever temperature
range of ≥37.5°C (99.5°F) and <43°C (109.4°F), as indicated by the red
LED on display, please consult with your physician immediately.
Restrictions of Use
This thermometer is clinically proven to produce accurate temperature
measurements. However,please be advised that the accuracy cannot be
ensured when the thermometer is not clean.Check that the probe is
clean before taking ameasurement.
Intended Use
BioCare No Touch Thermometer is intended for the intermittent
measurement and monitoring of human body temperature from
forehead measurement at home. A control measurement using a
conventional thermometer is recommended in the following cases:
1. If the reading is surprisingly low,
2. For new-born infants up to 100 days old,
3. For children under three years of age who have a weakened immune
system or who react unusually in the presence or absence of fever.
How does it work
The thermometer measures the infrared heat generated by the surface
of the skin over the vessel and its surrounding tissue. The thermometer
then converts it into a temperature value .
NOTE : The thermometer does not emit any infrared signal.
Highlighted Features
● Non-contact measurement that does not require probe cover, there
by saving cost of replacement.
●Automatically power o if left idle for 30 seconds.
●Memory function allows you to recall previous results up to 20
previous results.
●Easy to read LCD with white backlight in a dark environment.
●Color visible indication of alarm (red) and measurement in progress
(blue).
●Button-free power on and auto-sense measurement within 3 cm.
Package Content
Meter Overview
Display
Display Mode
Two modes can be selected.
1. Body Mode
This mode is used to measure the forehead
temperature. It also provides clock.
2. Object Mode
This mode is used to measure the object
temperature. It also provides clock.
Setting the Thermometer
You will need to set time for rst-time use or after
replacing the batteries.
1. Entering the setting mode
Start with the meter o, press Set Button for
3 seconds to enter the setting mode.
2. Set the date and time
Press Mode Button to select the correct year.
Press Set Button to conrm and move on the
next step.
Press Mode Button to select the correct
month/day/hour/minute.
Setting is all completed. Press Set Button to
exit the setting mode.
Select the Temperature Unit
This meter provides two measurement units used for indicating the
body/object temperature, oC or oF, for your preferred selection.
1. Press Start button to turn on the
thermometer rst.
2. Press C/F button to select.
PERFOEM THE TEST
Using the Device
As a Boby Measurement Thermometer
1. Press Start button to trun on the
thermometer rst.
2. Press the button to select Body mode.
The temperature unit ashes.
3. Move the probe close to the forehead.
Make sure the probe is at and close to the
forehead, not at an angle. Perform a forehead
measurement with a distance within 3cm.
The meter will take measurement automatically
when the blue blinks.
4. Read the result.
The measurement result will be done in 3
seconds.
The reading is shown together with green LED
and three short beeps.
NOTE :
• As the forehead measurement temperature is likely to be aected
by sweat, oil and the surroundings, the reading shall be taken as a
reference only.
• If the probe is placed at an angle close to the forehead measure
ment, the reading will be aected by surrounding temperature.
Babies’ skin reacts very quickly to the ambient temperature.
Therefore, do not take their temperature with the thermometer
during or after breastfeeding, because the skin temperature may
then be lower than the internal body temperature.
• If the reading is <32°C (89.6°F), the display will show together with
red LED and three short beeps.
• If the reading is ≥37.5°C (99.5°F) and < 43°C (109.4°F), the display
will show together with red LED and ten short beeps.
• The thermometer will automatically turn o if left idle for 30
seconds.
As an Object Measurement Thermometer
1. Press Start button to turn on the
thermometer rst.
2. Press the Mode button to select
Object mode. The temperature unit ashes.
3. Move the probe close to the object.
Make sure the probe is at and close to the
object, not at an angle. Perform an object
measurement with a distance within 3 cm.
The meter will take measurement automatically
with the blue LED blinks.
Owner’s Manual Owner’s Manual Owner’s Manual Owner’s Manual Owner’s Manual
Thermometer User’s Manual Soft Pouch
(Optional)
1.5V AAA
batteries
Auto-sense Probe
1
Start, Set (C/F) Button
5
3-color LED
2
Battery Cover
6
Display Screen
3
Memory Button
4
1
2
3
6
4
5
Object temperature indicator
1
Body temperature indicator
2
Memory mode
3
8
1 2 3
7 6
4
5
4
Temperature unit
5
Low battery indicator
6
Time
7
Date
8
Temperature reading
Non-Contact Infrared
Thermometer

Owner’s ManualOwner’s Manual Owner’s Manual Owner’s Manual Owner’s Manual Owner’s Manual
4. Read the result.
The measurement result will be done in
3 seconds.
The reading is shown together with green
LED and three short beeps.
●The body of the thermometer is not water-resistant.
Never put the thermometer under a running tap or submerge it into
water. Use a soft and dry cloth to clean it. Do not use abrasive
leaners.
●Store the thermometer in a cool and dry location. Free from dust and
away from direct sunlight.
Remove the battery
The thermometer comes with two 1.5 V AAA alkaline batteries. The
meter will display “ ” to alert you when the meter power is getting
low, please follow the steps below to replace new batteries
immediately.
1. Remove the battery cover as the arrow
direction accordingly.
2. Remove the old batteries and replace
with two 1.5V AAA size alkaline batteries.
Positive ( + ) and Negative ( - ) are displayed
on the back of battery cover.
3. Close the battery cover.
NOTE :
1. Although the thermometer works when " " appears,we still
recommend that you change the batteries to obtain an accurate
result.
2. Remove the batteries if stored for a long period of time.
3. The batteries should be kept away out of child’s reach. If they are
swallowed, promptly see a doctor for help.
METER MEMORY
Recalling the Memory
Your thermometer stores 20 most recent
readings
1. Be sure the thermometer is OFF before
recalling this memory.
2. Press Memory Button to enter the
memory mode.
Each time you press the Memory Button, a
result will be displayed
in the order of dates (latest result
shown rst), together with ” ”
and number ( from 1 to 20 ).
LED in green or red will appear according
to the memory reading.
When the memory is full, the oldest result is
deleted as the new one added. When the
last record displayed in the Display, press
Memory Button again to return the rst
record.
3. Exit the memory.
Press Set Button to exit the memory or
keep the meter in idle for 10 seconds to
switch o automatically.
MAINTENANCE
Care & Cleaning
● The probe is not waterproof. Please wipe with a clean and dry
cotton swab to clean the probe on the inside.
SYSTEM TROUBLESHOOTING
Measurement Result
Troubleshooting
The table below shows problems you may encounter. All error
messages below would be shown together with backlight. Please
follow "what to do" to resolve problems. If the problem still exists,
please call your local dealer for help.
SPECIFICATIONS
Model No.: 1265
Dimension & Weight : 151.5 x 55 x 41 mm, 74g (includebatteries)
Power Source : 2 x 1.5 V AAA alkaline batteries
Displayed temperature range :
Forehead : 32°C to 43°C (89.6°F to 109.4°F)
Object : 0°C to 100°C (32°F to 212°F)
Display resolution: 0.1 °F/0.1°C
Accuracy :
FOR BODY MODE:
±0.2°C (±0.36°F) from 36.0°C (96.8°F) to 39.0°C (102.2°F)
±0.3°C (±0.54°F) from 32.0°C (89.6°F) to 35.9°C
(96.6°F) and from 39.1°C (102.4°F) to 43.0°C ( 109.4°F)
FOR OBJECT MODE : ± 1°C (±2°F) from 0°C (32°F) to 100°C (212°F)
Temperature unit : °C or °F
Operating temperature range : 16°C to 40°C (60.8°F to 104°F)
Operating humidity : 95% RH or less
Storage temperature range : -25°C to 55°C (-13°F to 131°F)
Storage humidity : 95% RH or less
Memory capacity : 20 measurements
Expected service life : 3 years
DISPOSAL
Adhere to the applicable regulations when disposing of the device.This product must not be disposed of
together with domestic waste.All users are obliged to hand in all electrical or electronic devices, regardless
of whether or not they contain toxic substances, at a municipal or commercial collection point so that they
can be disposed of in an environmentally acceptable manner.
Please remove the batteries before disposing of the device/unit. Do not dispose of old batteries with your
household waste, but at a battery collection station at a recycling site or in a shop.
REFERENCE STANDARDS
Device Standard :
Device Corresponds to the requirements of the
standard for infrared thermometers
ASTM E1965-98
EN 12470-5
EN 60601-1-2 : 2007/AC:2010
Electromagnetic Compatibility : Device fullls the stipulations of the standard EN 60601-1-2
The stipulations of EU-Directive 93/42/EEC for Medical Devices Class Ila have been fullled.
SYMBOL INFORMATION
DETAILED INFORMATION
About Normal Body Temperature & Fever
The temperature in the forehead and temple area diers from the
internal temperature, which is taken orally or rectally. Vasoconstriction,
an eect which constricts the blood vessels and cools the skin, can
occur during the early stages of a fever. In this case, the temperature
measured by the Biocare ForeheadThermometer may be unusually low.
If the measurement therefore does not match the patient’s own
perception or is unusually low, repeat the measurement every 15
minutes. As a reference, you can also measure the internal body
temperature using a conventional oral or rectal thermometer.
Body temperature can vary from one individual/person to next. It also
varies by location on the body and time of day. Below shows the
statistical normal ranges from dierent sites. Please keep in mind that
temperatures measured from dierent sites, even at the same time,
should not be directly compared. Fever indicates that the body
temperature is higher than normal. This symptom may be caused by
infection, overdressing or immunization. Some people may not
experience fever even when they are ill.These include, but are not
limited to, infants younger than 3 months old, persons with compro-
mised immune systems, persons taking antibiotics, steroids or
antipyretics (aspirin, ibuprofen, acetaminophen), or persons with
certain chronic illnesses. Please consult your physician when you feel ill
even if you do not have fever.
Table*
1
Body Site Normal Temperature Range
*
1
. Body Temperature at WebMD; website: http://rstaid.web
d.com/body-temperature retrieved at 2010 Jan 7.
0.6°C (1°F) or more above or below
37°C (98.6°F)
0.3°C to 0.6°C (0.5°F to 1°F) higher
than oral temperature
0.3°C to 0.6°C (0.5°F to 1°F) lower
than oral temperature
Oral
Rectal/ear
Axillary(armpit)
Measured temperature falls outside
the displayed temperature range of
32°C to 43°C (89.6°F to 109.4°F), is
shown on the display with red LED.
●Hi-temperature ≥43°C (109.4°F)
●Lo-temperature < 32°C (89.6°F)
Measured temperature falls in
normal reading, within the range
of 32°C to 37.5°C (89.6°F to 99.5°F),
is shown on the display with green
LED.
Measured temperature falls in
fever reading, ≥37.5°C (99.5°F) and
< 43°C (109.4°F), is shown on the
display with red LED.
Appear when
environmental
temperature is
below system
operation range.
Put the thermometer
under operating
temperature range of
16°C to 40°C(60.8°F
to 104°F)
MESSAGE WHAT IT MEANS
MESSAGE WHAT IT MEANS WHAT TO DO
Appear when
environmental
temperature is
above system
operation range.
Battery is low
and " " appears
on display.
Put the thermometer
under operating
temperature range of
16°C to 40°C(60.8°F
to 104°F)
Please replace
batteries as
soon as possible.
If the thermometer
is broken or
aected by EMF.
Please contact
the customer
service line.
MESSAGE
SYMBOL REFERENT
WHAT IT MEANS WHAT TO DO
Read instructions before use
Manufacturer
Serial number
CE mark
Authorized representative in the European Community
Caution, consult accompanying documents
Type BF Equipment
Collection for electrical and electronic equipment
Shanghai International Trading Corp.
GmbH(Hamburg)
Eiffestrasse 80, 20537 Hamburg, Germany
TEL:+49‐40‐2513175
FAX:+49‐40‐255726
Biocare Asia Co., LTD
No.260,Mayun Road, New District Suzhou,
Jiangsu,215129,P.R.C
TEL:+86‐512‐68091772
FAX:+86‐512‐68097761
www.bca-medical.com
EN 60601-1-4 :1996
EN 60601-1-6 : 2010

外觀尺寸 : 150x480mm
成形尺寸 : 150x80 mm
才質 : 模造紙80p/正反面印刷
表面 : 一般
成形 : 對折再N字折;正面朝上
印刷色 : 單黑
