BionWell Marais Premium User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
Marais Premium
MASSAGE CHAIR
20 AUTO PROGRAM

01
Thank you for purchasing this product. Before you use it, please read the Operation
Instructions in detail for the correct usage of this product, especially the important
safety warnings. Keep the Operation Instructions properly for future reference.
Note: Our company reserves the right to change and explain the design of the
product. If there is some difference between the product function in market
circulation and the description in the manual, it is a normal update of the product,
and our company will not inform you otherwise. The specific product function and
color shall prevail in kind.
TABLE OF CONTENTS
02-03
04-05
06
07
08-09
10-36
10
10
29
31
32
32
32
34
36
37
37
38
Safety and Maintenance
Safety Warning
Name of Components
Function
Introduction to the Remote Controller
Method of Usage
I.Turn on the power supply of this product
II.Massage Function Control Operation
III.Introduction to Armrest Shortcut Keys
IV.Voice Control Instruction
V.Turn off the Power and Stop Massage
VI.Operation Instructions for Bluetooth Speaker Play
VII.Installation Instructions for Armrests
VIII.nstallation Instructions for Legrest
IX.Instructions for Removal and Use of Head Cushion and Backrest
X.Floor Protection
XI.Instruction for Movement
Product Specification

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
No downward pressure
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
Warning
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.

06 07
1.Head cushion
2.3D digital audio
(left built-in voice-
activated microphone)
3. Anion generator
4.Upper arm airbag
component
5.Arm airbag component
6.Armrest shortcut key
7.Hip airbag component
8.Seat cushion
9.Legrest
10.Footrest
11.Backrest
12.Back air bag
13.Remote controller
14.Remote controller bag
15.Armrest
16.Side cover
17.Backrest cover
18.LED atmosphere lamp
19.Drive box cover
20.Lockable wheel
21.Power cord and plug
22.Power input
23.Power switch
·This product is designed with a set of 3D intelligent massage chair manipulators that
can move up and down, extend from front to back and operate in mute mode.
·It is designed with automatic detection and micro-adjustment functions of the shoulder
position, as well as automatic detection function of the human body curve and shiatsu
massage points. Therefore, according to the detected human body curve and shiatsu
massage points, it can automatically adjust the manipulators to extend from front to
back, making the massage more user-friendly and scientific.
·With Twenty special automatic massage functions:fast massage, comfortable massage,
relaxing massage, stretching massage, full body massage, neck & shoulder massage,
back & waist massage, and full airbag massage, stress relieving, energy, good-night
sleep, joint care, shaping, spine massage, office regimen, sport recovery, brain refresh,
spine care, legs care, rejuvenation.
·There are three intelligent memory functions: Custom Storage I, Custom Storage II,
and Custom Storage III.
·Manually select the massage function for the upper body; there are five options of
massage positions (i.e. full range, local, fixed point, upper back, and lower back), as
well as six massage techniques (i.e. shoulder lifting, kneading, tapping, shiatsu,
simultaneous kneading and tapping, and 3D. For each massage technique, five speed
levels can be switched; during massage in the state of tapping and shiatsu, the
massage balls of manipulators have five width levels for switching.
·The airbag massage function is available: airbag massage function for the arms (8
built-in air bags), and airbag massage function for the upper arms (4 built-in air bags);
and there are three levels of air pressure intensity for adjustment.
·Airbag massage function for the lower part; airbag massage function for the waist (4
built-in air bags); airbag massage function for the legs (26 built-in air bags, including
the leg side); airbag massage function for the feet (22 built-in air bags); and there are
three levels of air pressure intensity for adjustment.
·This product is equipped with the heat treatment function for the back and legs:
carbon fiber is used as far infrared heat source.
·The slide rail technology for the backrest ensures zero space between the backrest and
wall, so as to save the space to the greatest extent.
·The backrest guide adopts the curve guide technology, so it completely fits the curve of
human back. The full body can enjoy full massage from the head to the thighs.
·This product is equipped with the intelligent voice control and recognition function (i.e.
built-in voice-activated microphone for the left speaker).
·The music player system is available. 3D digital audio systems are built into the left and
right upper arms. The Bluetooth function of the smart device can be used to play music
wirelessly.
·This product is equipped with the waist massage function: use the air pressure on the
waist to swing around for the waist massage, so as to relieve the tension of the waist
muscles caused by prolonged sitting.
·The right armrest is provided with the feet stretching key, linkage lying key, heat
treatment key, anion key, voice button, AUTO key, zero gravity key, ON/OFF (pause)
key, 3D massage intensity and other shortcut keys.
·The massage chair is equipped with the independent up/down adjustment function of
the legrest, the linkage up/down adjustment function of the backrest, and the zero-
gravity automatic lying angle adjustment function.
·The foot roller massage function is available for the feet bottoms. Two sets of rollers roll
to massage the roots of the toes; rolling and scraping massage is available for the foot
arch.
·The footrest can perform automatic detection of the footrest length. When the legrest is
raised or lowered to a suitable angle, the footrest will automatically detect the length of
the feet and identify the most comfortable massage area.
·The left and right armrests are equipped with LED atmosphere lamps.
·The right armrest is equipped with an anion generator.
·Such functions as shutdown, automatic sitting up, and automatic manipulator resetting
are available
·The product has a remote controller with TFT color screen.
POWER I NPUT
1
2
4
5
10
11
8
17
22
13
23
9
19
21
15
16
18
6
7
20
12
3
14
Names of Components Function

0908
13
14
15
16
18
19
20
21
17
1
2
4
5
6
7
8
9
10
11
12
3
114
2
3
4
5
6
15
16
7
8
17
9
10
11
12
18
21
13
19
20
Introduction to the Remote Controller
Remote Controller Interface Remote Controller Buttons
ZERO
2
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Note: The controllerremote controller displays the colors, massage functions
and massage function icon layout order. Please refer to the physical display!
1. TFT color LCD
2. Massage function status bar
3. Anion generator display
4. Time display
5. Zero gravity display
6. Back stretching display
7. Air pressure display for the arms
8. Air pressure display for the legs
and feet
9. Foot roller display
10. Speed adjustment
11. Adjustment
12. Shoulder position adjustment
13. Bluetooth display
14. Massage mode display
15. Massage position display
16. Heat treatment display for the legs
and back
17. Width adjustment
18. Massage intensity adjustment
19. Air pressure adjustment for the arms
20. Air pressure adjustment for the lower
body
21. Information bar
12. Lying button: Linkage lying of the
massage chair
13. Zero-gravity key: press it to adjust the
massage chair to the angle for zero
gravity.
14. Pause button: Pause the current
function.
15. Manual button: Enter the manual
mode selection interface.
16. Back button: Return to the function
information interface.
17. Right button: Right navigation key
18. Legrest up button: Adjust the
legrest upward.
19. Legrest down button: Adjust the
legrest downward.
20. Footrest retraction button: Retract the
footrest.
21. Footrest extension button: Extend the
footrest.
1. Power button: Turn on or off the massage
chair.
2. Adjustment button: Enter the adjustment
function selection interface.
3. AUTO button: Enter the automatic mode
selection interface.
4. Menu button: Enter main menu interface.
5. UP button: UP navigation key
6. OK: confirmation key
7. Left button: Left navigation key
8. Backrest up button: Adjust the backrest
upward.
9. Backrest Down button: Adjust the backrest
downward.
10. Down button: Down navigation key
11. Sitting button: Linkage UP of the massage
chair
Introduction to the Remote Controller

1110
·After selecting any automatic mode, the positions of the backrest and the legrest will
be adjusted to the preset angles.
·After the angle is adjusted, the massage chair will automatically perform the shoulder
position and body shape detection (Note: the fast massage function can only detect
the shoulder position, and other modes are for full body shape and shoulder position
detection). Wait for completion of such detection. By pressing "OK," you can skip
such detection. The default value will be adopted automatically to start massage.
·After detecting the shoulder position, the buzzer will beep. If there is any difference
from the actual shoulder position, adjust it to the appropriate position by pressing
the "UP" or "DOWN" key. The shoulder position has 11 adjustable levels. If there is
no shoulder position adjustment within 10 seconds, the massage function will start
automatically. Alternatively, press "OK" directly to start massage immediately. If no
shoulder position can be detected, massage will be started according to the
shoulder height by default.
·Press the power switch to start massage. Enter the start-up screen. The backrest
will maintain the default position, and the legrest will be slightly raised. Just wait for
the automatic mode to start massage. If "AUTO" mode is not selected within 5
minutes, the massage chair will automatically shut down.
Method of Usage Method of Usage
POWER INPUT POWER INPUT
I. Turn on the Power Supply of this Product
Plugging-in diagram Product connection
diagram
Power switch diagram
of the product
II. Massage Function Control Operation
1.Standby
·After the massage chair is powered on or turned off or when it is in standby mode, it
cannot enter any mode of operation, except the settings.
2.Start massage (power switch)
"Up&Down" to select,"OK" to confirm.
Auto Function
Fast
Comfort
Relax
Stretch
Full body
Just a moment！
Press 'OK' for default setting.
Body Sensing
Just a moment......
Attention! Ensure that there are no
objects around the massage chair.
Angle adjustment
02
"Up & Down" to select,"OK"to confirm.
Shoulder Adjust
06
·Low shoulder position
·Suitable shoulder position
·High shoulder position
Button Description
Move the massage balls upward to a suitable shoulder position.
Move the massage balls downward to a suitable shoulder position.
OK

·While the massage function is running, press the "Pause" button to temporarily
stop all the massage functions; press the "Pause" button again to continue the
massage function before pause. If the pause time exceeds 20 minutes, all the
massage functions will be automatically turned off.
·Press the "Menu" button to enter the main menu massage function selection
interface, including: automatic function, manual mode, adjustment, customize,
settings, and equipment information function interface.
·Press the "UP/DOWN" button for menu selection. Then press "OK" to enter the
menu selected. Press the "Back" button to return to the selected function operation
status information interface.
1312
·Press the "Menu" button to enter the main menu interface, and select the automatic
function icon: fast massage, comfortable massage, relaxing massage, stretching
massage, full body massage, neck & shoulder massage, back & waist massage, and full
airbag massage, stress relieving, energy, good-night sleep, joint care, shaping, spine
massage, office regimen, sport recovery, brain refresh, spine care, legs care,
rejuvenation.
·Press the "UP/DOWN" button to choose the massage function. Press "OK" to
confirm that you have entered the massage function menu selected. Press the
"Back" button to return to the selected function operation status information
interface.
·If you need to adjust the shoulder position after the massage program is started,
you can direct select the shoulder position button in the operating status information
interface to enter the shoulder position adjustment interface.
02
"Up & Down" to select,"OK"to confirm.
Shoulder Adjust
ZER O
2
Speed Width
Intensity
Arms air
Lower air
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Adjustment
Shoulder
3.Pause button
ZER O
2
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast
ZER O
2
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Time Out
4.Menu
Method of Usage Method of Usage
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
5.Automatic function (AUTO key: You can also press the "AUTO" key directly
to enter the automatic function interface.)
"Up&Down" to select,"OK" to confirm.
Auto Function
Fast
Comfort
Relax
Stretch
Full body
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
Note: The automatic function already selected will be displayed in the massage
function status bar. You can directly press the "Back" button to view the operating
status.

1514
Method of Usage Method of Usage
Function
Fast
massage Experience all the massage effects quickly.
The most comfortable massage experience.
Gentle and comfortable deep massage to relieve your body
fatigue and relax the body.
Stretch your legs and waist through the leg rest and the backrest to
effectively remove fatigue,relieve joint pain and restore vitality.
Deep massage to rejuvenate your body.
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and reduce fatigue
on the neck and shoulder.
Focus on the back and waist massage to relieve the pain on the
back and waist.
Focus on the full-body airbag massage to achieve full relaxation
and deep massage of the body and fully relieve the fatigue and
pain from your body.
Comfortable
massage
Relaxing
massage
Stretching
massage
Full body
massage
Neck&
shoulder
massage
Back&waist
massage
Full airbag
massage
Description
Restore the full body from fatigue and pain; achieve relaxation,
improve micro-circulation, and quickly relieve fatigue for the back
and limbs.
Stress
Relieving
Energy
Good-night
Sleep
Joint Care
After a night of rest, the body can have a rest; the whole body
muscles are massaged to quickly wake up the body functions and
start a new day of vitality.
Through the massage for the twelve major acupoints for healthcare,
it helps the body to adjust balance, quickly improve your sleep and
your sleep quality.
Care for the health of all your limbs and joints by pushing, pulling,
stretching, and other massage modes.
Legs Care
Office
Regimen
Sport
Recovery
Brain
Refresh
Spine Care
For sitting in the office for a long period of time, this function can
increase physical exercise by massage and improve the body
functions.
Make you quickly recover from physical fatigue after exercise.
Relieve the neck and shoulder pain; promote the blood supply to the
brain by massaging the YUZHEN and DAZHU points.
Care for the health of spine and perform improvements for the lack
of exercise.
Quickly relieve the pain of the lower extremities and the muscle
fatigue.
Improve the quality of nap and work efficiency.
Rejuvenation
Spine
Massage
Improve humpback and chest down; massage for each vertebra;
care for the spine health; and improve the protrusion of
intervertebral disc.
Shaping Relieve the neck and shoulder pain; promote the blood supply to
the brain by massaging the yuzhen and dazhu points.
·Press the "Menu" button to enter the main menu interface, and select the manual
mode icon: including massage technique, massage part, airbag massage, and
other massage functions.
·Press the "Left" or "Right" button to switch among the submenus. Then press the
"UP" or "DOWN" button to select the massage function. Press the "Back" button to
return to the operating status information interface.
6. Manual mode (Manual button: You can also press the "Manual" button
directly to enter the manual mode interface.)
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode

1716
Method of Usage Method of Usage
·Manual (massage technique): six different massage techniques, including
kneading, tapping, simultaneous kneading and tapping, shiatsu, 3D, and shoulder
lifting. In the massage state of tapping and shiatsu, the massage ball width of each
manipulator is adjustable. The massage speed is adjustable in other massage
modes except the stop mode.
·Press the "UP/DOWN" button to select the massage technique icon. Then press
"OK" to confirm that the massage technique will be applied.
Wise
Stop
Knead
Flap
Knead&Flap
Manual mode
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Massage Area
Spot
Partial
Full back
Upper back
Manual mode
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Air
Manual mode
Upper body air pressure
Lower body air pressure
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
01).Manual mode (manual button - massage techniques)
Wise
Stop
Knead
Flap
Knead&Flap
Manual mode
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Manual mode
Note: Selecting the
stop icon will stop all
the massage
technique functions of
the method; selecting
a massage technique
icon will enable the
individual massage
technique.
Function Description
Kneading
5 speed levels adjustable
5 width levels adjustable
Simultaneous
kneading and tapping
3D
Shoulder lifting
Shiatsu
Speed,width
Tapping
Speed
Speed
Speed,width
Speed
Speed,width
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Massage Area
Spot
Partial
Full back
Upper back
Manual mode
·Manual mode (massage part): including such massage functions as fixed point,
local, full back, upper back, and lower back.
·Press the "UP/DOWN" button to select the area function icon. Then press "OK" to
confirm the area selected.
02).Manual mode (manual button - massage part)
Manual mode
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Manual mode
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Manual mode
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Manual mode
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Manual mode
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Fixed point state Local state
Full back state Upper back state Lower back state
Function Description
Fixed point
Local
Upper back
Lower back
Full back
Massage at fixed point
Local round-trip massage in a
small area
Round trip massage on the upper back
Round trip massage on the lower back
Round trip massage on the full back
When choosing the fixed point and
local massage technique, you can
adjust the massage area by
pressing the "UP/DOWN" button.

1918
Method of Usage Method of Usage
·Manual mode (airbag massage): including airbag massage functions for the upper
body and the lower body.
·Press the "UP/DOWN" button to choose different airbag massage functions. Press
"OK" to confirm your choice.
·Manual mode (other massage functions): including such massage functions as
heat treatment, foot roller, anion generator, and Bluetooth.
·Press the "UP/DOWN" button to choose the massage function. Press "OK" to
enable or disable such massage function.
03).Manual mode (manual button - airbag massage)
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Air
Manual mode
Upper body air pressure
Lower body air pressure
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Manual mode
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Manual mode
Function Description
Airbag massage for the
upper body
Airbag massage for the
lower body
Enable or disable the airbag massage function for the
upper body
Enable or disable the airbag massage function for the
lower body
04).Manual mode (manual button - other massage functions)
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
·Click "OK" to enable or disable the heat treatment function; the back will become
warmer after such heating for 3min.
·Press the "UP" or "DOWN" button to select other massage functions. Press the
"Back" button to return to the operating status information interface.
·Manual mode (other - foot roller)
·Press "OK" to enable or disable the foot roller massage function.
·Press the "UP" or "DOWN" button to select other massage functions. Press the
"Back" button to return to the operating status information interface.
·Manual mode (other - heat treatment on the back)
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
Auto-Fast
"Up&Down" to select,"OK" to confirm.
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
Auto-Fast
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder

2120
Method of Usage Method of Usage
·Manual mode (other - anion)
·Press "OK" to enable or disable the anion function.
·Press the "UP" or "DOWN" button to select other massage functions. Press the "Back"
button to return to the operating status information interface.
·Manual mode (other - Bluetooth)
·Press "OK" to enable or disable the Bluetooth function.
·After a Bluetooth-enabled audio source device (e.g. mobile phone, MID tablet) is
connected with the Bluetooth module of the massage chair, the music played by the
audio source device can be wirelessly transmitted to the audio system of the
massage chair via Bluetooth for music playback.
·Press the "UP" or "DOWN" button to select other massage functions. Press the
"Back" button to return to the operating status information interface.
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
Auto-Fast
"Up&Down" to select,"OK" to confirm.
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
2
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Others
off on
off on
off on
off on
Manual mode
Foot roller
Bluetooth
Heating
Negative ions
ZER O
2
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Adjustment
Massage Area
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Others
Time Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Arms air
Lower air
Foot roller
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Wise
Speed
Width
Intensity
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
7.Adjustment function (Adjustment button: You can also press the
"Adjustment" button directly to enter the adjustment function interface.)
·Press the "Menu" button to enter the main menu interface, and select the
adjustment function icon: including such massage functions as massage technique,
massage area, and massage intensity (only timing available now).
·Press the "Left" or "Right" button to switch among the submenus. Select the
massage function in the menu. Then press the "UP" or "DOWN" button to select
the massage function to be adjusted. Press "OK" to confirm your choice, or press
the "Back" button to return to the operating status information interface.
Alternatively, directly select the adjustment button in the operating status information
interface to enter the adjustment interface.

2322
Method of Usage Method of Usage
·Adjustment function (massage techniques): the massage technique adjustment
function is for the adjustment of massage speed, width and intensity, etc.
·Press the "UP" or "DOWN" button to select the speed or width function. Then
press "OK" to adjust the speed and width.
ZER O
2
Speed Width
Intensity
Arms air
Lower air
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Adjustment
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Wise
Speed
Width
Intensity
01).Adjustment function (adjustment button - massage techniques)
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Wise
Speed
Width
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Wise
Speed
Width
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Wise
Speed
Width
Intensity
Note:
·Speed: The massage speed of manipulators is adjustable; there are 5 speed levels.
·Width: In the massage state of tapping and shiatsu, the width is adjustment, and
there are five width levels in total.
·Adjustment function (massage intensity): including such massage functions as
airbag massage functions for the upper body and the lower body, and foot roller;
there are 3 levels of intensity for switching.
·Press the "UP" or "DOWN" button to select the air pressure intensity or the roller
massage intensity. Then press "OK" to confirm such intensity.
·Adjustment function (massage area): In the fixed point or local massage area state,
such manipulator will move upward if you hold down the "UP" button; after you
release it, such movement will stop. Such manipulator will move downward if you
hold down the "DOWN" button; after you release it, such movement will stop.
·Press the "UP" or "DOWN" button to select the massage area for adjustment.
02).Adjustment function (adjustment button - massage area)
Adjustment
Massage Area
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Adjustment
Massage Area
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
03).Adjustment function (adjustment button - massage intensity)
Adjustment
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Arms air
Lower air
Foot roller
Adjustment
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Arms air
Lower air
Foot roller
Adjustment
Intensity
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Arms air
Lower air
Foot roller

2524
Method of Usage Method of Usage
·Adjustment function (other adjustments): only timing available now. When "OK" is
pressed every time, the duration will increase by 5 minutes; if it exceeds 40min,
40min will be reduced.
·Press "OK" for time adjustment (when "OK" is pressed every time, the duration will
increase by 5 minutes; the minimum duration is 5min, and the maximum duration
is 40min)
·Press the "Menu" button to select "Customize" in the main menu. Then enter the
"Custom Storage" interface to select a specific interface, including: Custom Storage
I, II, III, and other storage or call function.
·Press the "Left" or "Right" button to select the storage or call function. Then press
"OK" to confirm your choice.
·Press the "UP" or "DOWN" key to select Custom Storage I, II or III.
·Storage: Store all the current massage techniques, air pressure, angle, and other
massage functions.
·Call: Call the massage techniques, airbag massage, angle, and other massage
functions previously stored.
·Press the "Back" button to return to the operating status information interface.
04).Adjustment function (adjustment button - other adjustments)
Adjustment
Others
Time Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
8.Customize
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
Customise
iMemory I
iMemory II
Use Save
Use Save
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
iMemory ⅢUse Save
·Settings (language): Select Chinese or English.
·Press the "UP/DOWN" button for language selection. Then press "OK" to confirm
your choice.
·Press the "Menu" button to enter the main menu interface. Select the "Settings"
function icon to enter the setting interface for language, backlight, auto-lock and
other settings.
·Press the "Left" or "Right" button to switch among the submenus. Press the "UP" or
"DOWN" button for function selection. Alternatively, press the "Back" button to
return to the operating status information interface.
9.Settings
Main menu
"Up&Down " to adju st,"OK"to exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Back Light
Light
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Lock Screen
Sleep
Sleep after 02 S of inactivity
English
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Language
China
01).Settings (language)
English
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Language
China
English
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Language
China

2726
Method of Usage Method of Usage
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Back Light
Light
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Lock Screen
Sleep
Never sleep
Never
Setting
"Left&Right" to select sub menu,
"Up&Down" to select,"OK" to confirm.
Lock Screen
Sleep
Sleep after 02 S of inactivity
·Press the "Menu" button to enter the main menu interface and select the equipment
information function. The information on the current equipment will be displayed.
·Press the "UP/DOWN" button for selection. Then press "OK" to confirm your
choice. Alternatively, press the "Back" button to return to the operating status
information interface.
·Set the (backlight) brightness. Press "OK" to adjust the brightness. There are 5
brightness levels for your option.
·Press the "Back" button to return to the operating status information interface.
·Settings (auto-lock): including timing and no auto-lock; in case of no operation, the
auto-lock will be activated after 2 sec.
·Press "OK" to adjust the auto-lock duration. When "OK" is pressed every time, the
auto-lock duration will increase by 15 sec, 30 sec, 1min or 2min; or the auto-lock
will never be activated if you have checked the “No Auto-Lock” option. Press "OK"
for switching.
02).Settings (auto-lock)
03).Settings (backlight)
10.Equipment information
Main menu
"Up&Down" to adjust,"OK"t o exit.
Auto Function
Adjustment
Customise
Setting
Device Information
Manual mode
1 1 1 1 1 1 1 1 1 1 1
Device Information
Code
·Press the "Zero Gravity" key to adjust the position for zero gravity. Upon your
request, you can select the position for "Zero Gravity I" or "Zero Gravity II."
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
ZER O
ZER O
11.Zero gravity key
Button Description
Zero Gravity I: Adjust to the angle for Zero Gravity I.
Zero Gravity II: Adjust to the angle for Zero Gravity II.
12.Back button
·During adjustment of any massage function, if you want to return to the operating
status information interface, you can press the back button to return to the operating
status information interface.
ZER O
2
Speed Width
Intensity
Arms air
Lower air
Adjustment
Shoulder
"Up & Down" to select,"OK"to confirm.
Auto-Fast

2928
Method of Usage Method of Usage
13.Lying angle adjustment button
Button Description
Legrest UP key: Hold down this key, and the legrest will rise slowly;
release it, and the legrest will stop rising. After the leg upward
movement is completed, the legrest will automatically detect the
length of the feet.
Legrest DOWN key: Hold down this key, and the legrest will move
downward slowly; release it, and the legrest will stop downward
movement. After the leg downward movement is completed, the
legrest will automatically detect the length of the feet.
Backrest up button: Hold down the button to make the backrest rise
slowly. Release it to stop such action.
Backrest down button: Hold down the button to make the backrest
move downward slowly. Release it to stop such action.
Linkage sitting key: By holding down this key, the backrest will rise
slowly and the legrest will move downward slowly; by releasing it,
such UP/DOWN action of the backrest and the legrest will be stopped.
After linkage sitting is completed, the legrest will automatically detect
the length of the feet.
Zero-gravity key: After this key is pressed, the positions of the legrest
and the backrest can be automatically adjusted to the positions for
zero gravity. There are two levels of zero-gravity lying modes, which
can be switched.
Footrest retraction button: Hold it down to manually adjust the footrest
and retract it slowly; if it is released, such action will stop.
Footrest extension button: Hold it down to manually adjust the legrest
and extend it slowly; if it is released, such action will stop.
Linkage lying key: By holding down this key, the backrest will move
downward slowly and the legrest will rise slowly; by releasing it, such
DOWN/UP action of the backrest and the legrest will be stopped. After
linkage lying is completed, the legrest will automatically detect the
length of the feet.
2
3D
1
2
3
4
5
6
7
8
9
III.Introduction to Armrest Shortcut Keys
1. Power button: turn on or off the massage chair.
2. 3D massage intensity button: adjust the 3D massage intensity.
3. Footrest extension/retraction: adjust the footrest extension/retraction function.
4. Anion key: click the key to enable or disable the anion function.
5. Heat treatment key: click the key to enable or disable the heat treatment function.
6. AUTO key: press it to enable the automatic massage function.
7. Linkage lying key: adjust the linkage lying angle.
8. Voice control and wake-up button: , Short press to enable the voice control function
long press 3 seconds to turn on or off the voice control function.
9. Zero-gravity key: press it to adjust the massage chair to the angle for zero gravity.

3130
Method of UsageMethod of Usage
2
Button Description
Power button: Short press this button to pause the operation; if it is
hold down for 3 seconds, power will be ON/OFF. If the pause time
during massage exceeds 20 minutes, all the massage functions will
be automatically turned off.
3D massage intensity button: Rotate the button clockwise or
counterclockwise to adjust the 3D massage intensity.
Footrest retraction button: Pull it to let the footrest retract slowly; if it is
released, such action will stop
Footrest extension button: Press it to let the footrest extend slowly; if it
is released, such action will stop.
Linkage sitting key: By pulling this key, the backrest will rise slowly
and the legrest will move downward slowly; by releasing it, such
UP/DOWN action of the backrest and the legrest will be stopped.
After linkage sitting is completed, the legrest will automatically detect
the length of the fee.
Linkage lying key: By pressing this key, the backrest will move
downward slowly and the legrest will rise slowly; by releasing it,
such DOWN/UP action of the backrest and the legrest will be stopped.
After linkage lying is completed, the legrest will automatically detect
the length of the feet.
Heat treatment key: Click the key to enable or disable the heat
treatment function.
Anion key: Hold down the key to enable or disable the anion function.
Automatic mode key: Press it to switch among those automatic
massage functions.
Zero-gravity key: After this key is pressed, the positions of the legrest
and the backrest can be automatically adjusted to the positions for
zero gravity. There are two levels of zero-gravity lying modes, which
can be switched.
Voice control and wake-up button: Short press to enable the voice
control function, long press 3 seconds to turn on or off the voice
control function.
IV.Voice Control Instruction
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Voice control entry
Massage on
Massage close
Comfort Massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Change the other mode
Go little down
Go little up
Answer entry
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: Ok, open the air pressure
Answer: Ok, close the air pressure
Answer: Ok, up the seat position
Answer: Ok, down the seat position
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Note: commands 14 and 15 can only be used after command 13.
Voice Control Entry
Entry: “Hi Alice” or “Hey Alice”. Answer: I am here.
·When the massage chair is turned on or in standby mode, the sound “Hi Alice” or
“Hey Alice” will be produced to enable the voice control function. Alternatively, you
can press the voice control button on the armrest to enable the voice control
function.
·Long press the Voice control button 3 seconds to turn on or off the voice control
function.
·After such function is enabled successfully, the massage chair will reply "I am
here." At this moment, once a corresponding voice control entry to be implemented
is given within six seconds, the corresponding voice control function can be
performed after a reply is received from the massage chair; if no correct voice
control entry is given within six seconds, the voice control function automatically will
be off automatically and needs to be enabled again.
·Note: When waking up the voice control function, please use English, the speech
rate is moderate, Voice commands should be follow up the Voice entry.

3332
Method of Usage Method of Usage
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open “Bluetooth," and Bluetooth will automatically "Search for a New
Bluetooth Device."
2.The smart device will search for the corresponding Bluetooth model (e.g. IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
·If the power button is pressed during massage, all the massage functions will be
turned off immediately, and the backrest and the footrest will go back to their
default positions. If the massage time is up, all the massage functions will be
turned off immediately, but the backrest and the footrest will not go back to their
default positions.
·Shut off the power supply of this product as shown in the attached figure (Power
Shut-off Diagram of the Product).
V.Turn off the Power and Stop Massage
Power Shut-off Diagram of the Product
Disconnection Diagram
Unplugging Diagram
POWER INPUT POWER INPUT
VII.Installation Instructions for Armrests
VI.Operation Instructions for Bluetooth Speaker Play
1.Locate the connector plug and the air pipe from the bottom of the frame, and pass
them out from the center of the frame (Figure 1).
2.Unpack the armrest. The connector plug and the air pipe on the armrest should
correspond to those on the bottom of the frame (connection based on the marks
for connection on the actual items) (Figure 2).
Figure 1 Figure 2
Figure 3 Figure 4
3.Connect the connector plug and the air pipe on the armrest with those on the
bottom of the frame correctly and firmly (Figure 3).
4.After such connection, insert them on the bottom of the frame and pay attention to
avoiding any air pipe bending during insertion (Figure 4).
5.Hold the armrest with both hands. Firstly, hook the front end of the armrest into the
steel frame and press down the front end of the armrest. (Figure 5).
6.Next, connect the lamp wire on the rear end of the armrest with the connector on
the capsule, and insert it into the capsule. Then align the male buckle on the rear
end of the armrest with the female buckle on the capsule. Insert the rear end of
the armrest into the female buckle on the capsule. Tighten the connection firmly
(Note: The clearance between the armrest and the capsule should be even)
(Figure 6).
Figure 5 Figure 6
7.Fasten the rear end of the armrest with a M6*20 screw (Figure 7).
8.Next, pull the upper arm leather cover and fix with a M5*20 screw (Figure 8).
Figure 7 Figure 8

35
34
Method of Usage Method of Usage
1.First of all, cut the connection wire and the air pipe tie fixed on the steel pipe
(Figure 1).
2.Connect the connection wire and the air pipe leading from the lower end of the
backrest to the legrest connectors. Confirm whether butt connection is OK. Then
insert the butt connection wire and air pipe into the bottom of the frame from the
lower hole of the backrest. Pay attention to avoiding any air pipe bending during
insertion (Figure 2).
1
VIII.Installation Instructions for Legrest
2
9.Align the mounting holes on the steel frame on the front end of the fixed armrest
and fasten the armrest to the steel member of the frame with two M5*16 screws
(Figure 9).
10.Attach the screw hole plug on the rear end of the armrest (Figure 10).
Figure 9 Figure 10
3
3. Firstly, insert the rotating inner sleeve and the rotating outer sleeve into the left
and right rotation shafts of the legrest (Note: The large step must face inward)
(Figure 3).
4. Then remove the rotation shaft cover supporting the legrest on the left and right
frames of the massage chair (Figure 4).
4
56
5.Next, hang the legrest (left and right rotation shafts) into the rotation shaft cover
supporting such frames simultaneously (Figure 5).
6.Place the rotation shaft cover. Press the rotating outer sleeve of the legrest. Then
tighten the rotation shaft cover supporting the legrest with two M5×14 black zinc
environmentally-friendly hexagonal socket head screws and a 6×12×1.5 black
zinc environmentally-friendly flat pad by the supplied 4# hex wrench (Figure 6).

3736
Method of Usage Method of Usage
(1)
(2)
7. After the screws are tightened, hook the groove at the back end of the legrest
cover to the hinge pin. Then press down the front end of the legrest cover to make
it completely parallel to the rotation shaft cover. Hook the convex point at the side
of the legrest cover to the hole at the side of the legrest hook. Finally, the legrest
is installed (Figure 7)
Zipper
Hook-and-loop fastener
7
IX.Instructions for Removal and Use of Head Cushion and Backrest
·The use of the head cushion can reduce the intensity of kneading massage on the
neck and shoulders. You can decide whether to use the head cushion according
to your own needs (the head cushion is recommended). The backrest and the
back cushion are connected by a zipper (1). The head cushion and the backrest
are connected by a hook-and-loop fastener (2).
Lifting Pushing
downward
·The prolonged heavy pressure on the massage chair may cause scratches on the
floor. Thus, put a carpet or cushion on the floor where the massage chair is placed
to avoid this damage.
Note: Do not move the massage chair with its wheels on the rough ground or in a
narrow space. At least two persons are required to lift it. During lifting, take the
legrest sealing plate and backrest cover grooves as the acting points. (Do not lift the
armrest directly.)
X.Floor Protection
XI.Instruction for Movement
Warning : The rear moving wheels of the massage chair are only suitable for short-
distance and slow movement. For long-distance transportation, please use other
auxiliary moving tools to move this massage chair!
·When moving the massage chair, make sure that all the wires are pulled out of
the massage chair surface; two persons must work together to move the
massage chair. There should be one person respectively in front of and behind
the massage chair. The person in front of the massage chair should lift it, while
the person behind it should push it downward. When the center of gravity of the
massage chair is completely on the base wheels, you can push the massage
chair forward to a suitable position and then gently restore it to the normal angle.
(Note: During movement, you must turn off the power switch first and then
unplug the power cord and the remote controller connection wire.)
