FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here of and specially disclaims any implied warranties of merchantability or
fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here of without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without first
obtaining the vendor’s approval in writing.
The content of this user’s is subject to be changed without notice and we will not
be responsible for any mistakes found in this user’s manual. All the brand and
product names are trademarks of their respective companies.

C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
ts
s
s
ii
ENGLISH.....................................................................................................1
M7VIG-D Features...........................................................................................................1
Package contents ...........................................................................................................2
Layout of M7VIG-D..........................................................................................................3
CPU Installation ..............................................................................................................4
DDR DIMM Modules: DDR1-2.........................................................................................5
Jumpers, Headers, Connectors & Slots ........................................................................6
ESPAÑOL..................................................................................................12
Características del M7VIG-D ........................................................................................12
Contenido del Paquete.................................................................................................13
Disposición del M7VIG-D..............................................................................................14
Instalación del CPU ......................................................................................................15
Módulos DDR DIMM: DDR1-2.......................................................................................16
Conectores, Cabezales, Puentes y Ranuras...............................................................17
DEUTSCH..................................................................................................23
Merkmals des M7VIG-D................................................................................................23
Verpackungsinhalt........................................................................................................24
Layout des M7VIG-D.....................................................................................................25
Installation der CPU......................................................................................................26
DDR-DIMM-Modules: DDR1-2.......................................................................................27
Jumpers, Headers, Connectors & Slots ......................................................................28
WARPSPEEDER.......................................................................................35
Introduction...................................................................................................................35
System Requirement....................................................................................................35
Installation.....................................................................................................................36
Usage.............................................................................................................................37
TROUBLE SHOOTING .............................................................................45
SOLUCIÓN DE PROBLEMAS..................................................................46
PROBLEMLÖSUNG..................................................................................47

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
1
English
M7VIG-D Features
CPU:
- Supports the single AMD Socket A for AthlonTM (ThunderbirdTM )/ Athlon
XPTM/ DuronTM processors.
- Running at 200/ 266MHz Front Side Bus.
Chipset:
- North Bridge: VIA VT8375 (KM266) Chipset.
- South Bridge: VT8235 Chipset.
Main Memory
- Supports up to 2 DDR devices.
- Supports 200/266MHz (without ECC) devices.
- The largest memory capacity is 2GB.
Slots
- One AMR slot.
- Two 32-bit PCI Bus slots.
- One AGP slot.
Onboard IDE
- Supports IDE hard disk drives.
- Supports Ultra 133/ 100/ 66/ 33, PIO modes, LBA mode.
On Board VGA
- Integrate S3 Graphics 128-bit ProSavage 8 graphics accelerator.
Audio
- AC97 2.2 compatible.
- PC99 complaint.
- Supports 2 speaker out channels.
On Board Peripherals
- Supports 360K, 720K, 1.2MB, 1.44MB and 2.88MB floppy disk drivers.
- Supports 1 serial port.
- Supports 1 VGA port.
- Supports 1 multi-mode parallel port. (SPP/EPP/ECP mode)
- Supports PS/2 mouse and PS/2 keyboard.
- Supports 2 back ports and 4 front ports. (Optional)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
2
BIOS
- AWARD legal Bios.
- Supports APM1.2.
- Supports ACPI.
- Supports USB Function.
Operating System
- Offers the highest performance for Windows 98, Windows NT, Windows
2000, Windows Me, Windows XP, LINUX and SCO UNIX.
Dimensions
- Micro ATX Form Factor: 22.9cm X 21.3cm (W X L)
Package contents
- HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1
- Flash Memory Writer for BIOS update X 1
- USB Cable X 2 (Optional)
- Rear I/O Panel for Micro-ATX Case X 1 (Optional)
- SPDIF OUT Cable X1 (Optional)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
3
Layout of M7VIG-D
JPRNT1
JCOM1
JVGA1
JKBMS1
JUSB4
V
T8375
(KM 266)
JCFAN1
1FDD1
PRIMARY IDE CONN.
JATXPWER1
Winbond
I/O
1
JSFAN1 JPANEL1
12
IDE1 IDE2
JCMOS1
BAT1
23
24
1
V
T 8235
SECONDARY IDE CONN.
DDR2
DDR1
JUSBV2
1
1
JKBV1
PCI2
PCI1
JWOL1
1
JCODECSEL 1
1
2
9
10
Codec
Phy
JUSB3
29
10
1
JUSBV3
1
JUSBV1
1
1
JUSBLAN1
JAUDIO
JGAME1
1
216
15
BIOS
1
1
LAN
Phy

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
4
CPU Installation
1. Pull the lever sideways away from the socket then raise the lever up to
90-degree angle.
2. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU.
Match Pin A with the white dot/cut edge then insert the CPU.
3. Press the lever down. Then Put the fan on the CPU and buckle it and put the
fan’s power port into the JCFAN1, then to complete the installation.
CPU/ System Fan Headers: JCFAN1/ JSFAN1
CPU
JCFAN1
1
Ground
12V
Sense
JSFAN1
Ground
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
5
DDR DIMM Modules: DDR1-2
DRAM Access Time: 2.5V Unbuffered DDR 200/266MHz (without ECC) Type
required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)
DIMM Socket
Location DDR Module Total Memory Size (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
* The list shown above for DRAM configuration is only for reference.
How to install a DIMM Module
1. The DIMM socket has a “ Plastic
Safety Tab”, and the DIMM memory
module has an “Asymmetrical notch”, so
the DIMM memory module can only fit
into the slot in one direction.
2. Push the tabs out. Insert the DIMM
memory modules into the socket at a
90-degree angle, then push down
vertically so that it will fit into the place.
3. The Mounting Holes and plastic tabs
should fit over the edge and hold the
DIMM memory modules in place.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
6
Jumpers, Headers, Connectors & Slots
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100/ 133 functionality. It has
two HDD connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports 360K,
720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the
provided floppy drive ribbon cables.
Audio Modem Riser Slot: AMR1
(Only support slave card)
The AMR specification is an open Industry Standard Architecture and that defines
a hardware scalable riser card interface, which supports audio and modem only.
Peripheral Component Interconnect Slots: PCI1-2
This motherboard is equipped with 2 standard PCI slots. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for expansion cards.
This PCI slot is designated as 32 bits.
Accelerated Graphics Port Slot: AGP1
Your monitor will attach directly to that video card. This motherboard supports
video cards for PCI, but it is also equipped with an Accelerated Graphics Port
(AGP). An AGP card will take advantage of AGP technology for improved video
efficiency and performance, especially with 3D graphics.
Power Connectors: JATXPWR1
JATXPWR1
(ATX Power Conn.)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
7
Wake On LAN Header: JWOL1
Clear CMOS Jumper: JCMOS1
Front USB Header: JUSB3
JCMOS1
Clear CMOS
Data
Pin 1-2 on
Normal
Operation
(default)
Assignment
1
Pin 2-3 on
1
JUSB3
2
1
Pin Assignment Pin Assignment
12
43
56
87
910
+5V +5V
Data (-)Data (-)
Data (+) Data (+)
Ground Ground
Key NA
JWOL1
1
5V_SB Wake up
Ground

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
8
5V/ 5VSB Selection for USB: JUSBV1/2/3
CPU Frequency Selection:
JCLK1
5V/ 5VSB Selection for Keyboard: JKBV1
AMR Codec Primary/ Secondary Selection: JCODECSEL
JUSBV1/2/3
5V_SB
Pin 1-2 on
5V
Assignment
1
Pin 2-3 on
1
JKBV1
5V_SB
Pin 1-2 on 5V
Assignment
1
Pin 2-3 on
1
Pin 1-2 On-board Primary
Codec (Default).
1Pin 2-3 AMR Primary Codec.
Assignment
JCODECSEL
1
1
JCLK1
Close ==> 100 MHz
Open ==> 133 Mhz

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
9
Case Open Connector: JCI1
Front Panel Connector: JPANEL1
Digital Audio Connector: JSPDIF1 (Optional)
JSPDIF1
1
SPDIF_OUT
5V GND
JCI1
Case Open
No jumper
installed
Normal
Operation
(default)
Assignment
1
Pin 1-2 on
1
SPK ==> Speaker Conn.
HLED ==> Hard Driver LED
RST ==> Reset Button
IR ==> Infrared Conn.
SLP ==> Sleep Button
PWR_LED ==> Power LED
ON/ OFF ==> Power-on Button
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
10
Audio Subsystem: JF_AUDIO/ JCDIN1
12
Front Panel AudioConnector/ JumperBlock
910 Audio line out signals are routed
to the back panel audio line out connector.
Pin 5 and 6
Pin 9 and 10
Audio lineout and mic in signals are
available for front panel audio connectors.
3
5
7
4
6
12
910
3
5
7
4
6No jumpers
installed
Jumper Setting Configuration
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
1
2
JF_AUDIO
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
2
JF_AUDIO
1
210
9
Pin
1
3
5
7
9
Pin
2
4
6
8
10
Mic In
Mic Power
RT Line Out
Reserved
LFT Line Out
Assignment Ground
Audio Power
RT Line Out
Key
Assignment
LFT Line Out

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
11
Game Header: JGAME1
Back Panel Connectors
PS/2
Keyboard
PS/2
Mouse Parallel
JPRNT1
JCOM1
JKBMS1
USB
JUSB4
COM1
JVGA1
VGA1 USB
JUSBLAN1
Speaker
Out
Line In
Mic In
JAUDIO
LAN
1
216
15
JGAME1
PinAssignment PinAssignment
1
34
5
7
9
2
6
8
10
12
13
11 14
1615
+5V +5V
GP4GP6
GP2 GP0
Ground
MIDI-OUTR
GP3 Ground
GP1
GP5
+5V
GP7
MIDI-INR
NC

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
12
Español
Características del M7VIG-D
CPU:
- Soporta procesadores single AMD Socket A para AthlonTM (ThunderbirdTM )/
Athlon XPTM/ DuronTM.
- Corre a 200/ 266MHz Front Side Bus.
Chipset:
- North Bridge: VIA VT8375 (KM266) Chipset.
- South Bridge: VT8235 Chipset.
Memoria Principal
- Soporta hasta 2 dispositivos DDR.
- Soporta dispositivos 200/ 266MHz (sin ECC).
- Capacidad máxima de memoria de 2GB.
Ranuras
- Una ranura AMR.
- Dos ranuras PCI Bus 32-bit.
- Una ranura AGP.
IDE Onboard
- Soporta discos duros IDE.
- Soporta Ultra 133/ 100/ 66/ 33, modos PIO, modo LBA.
VGA Onboard
- Integrate S3 Graphics 128-bit ProSavage 8 acelerador gráfico.
Audio
- AC97 2.2 compatible.
- PC99 compatible.
- Soporta 2 canales de salida del altavoz.
Periféricos Onboard
- Soporta 360K, 720K, 1.2MB, 1.44MB y 2.88MB tipos de disquette.
- Soporta 1 puerto serie.
- Soporta 1 puerto VGA.
- Soporta 1 puerto paralelo multi-modo. (modos SPP/EPP/ECP)
- Soporta ratón PS/2 y teclado PS/2.
- Soporta 2 puertos traseros y 4 puertos frontales. (Opcional)
BIOS
- AWARD legal Bios.
- Soporta APM1.2.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
13
- Soporta ACPI.
- Soporta función USB.
Sistemas Operativos
- Ofrece el más alto funcionamiento para Windows 98, Windows NT,
Windows 2000, Windows Me, Windows XP, LINUX y SCO UNIX.
Dimensiones
- Factor de Forma Micro ATX: 22.9cm X 21.3cm (W X L)
Contenido del Paquete
- Cable HDD X 1
- Cable FDD X 1
- Completa Configuración del Driver CD X 1
- Flash Memory Writer para actualización del BIOS X 1
- Cable USB X 2 (Opcional)
- Panel Trasero I/O para Carcasa Micro-ATX X 1 (Opcional)
- Cable SPDIF OUT X1 (Opcional)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
14
Disposición del M7VIG-D
JPRNT1
JCOM1
JVGA1
JKBMS1
JUSB4
V
T8375
(KM 266)
JCFAN1
1FDD1
JATXPWER1
Winbond
I/O
1
JSFAN1 JPANEL1
12
IDE1 IDE2
JCMOS1
BAT1
23
24
1
V
T 8235
DDR2
DDR1
JUSBV2
1
1
JKBV1
PCI2
PCI1
JWOL1
1
JCODECSEL 1
1
2
9
10
Codec
Phy
JUSB3
29
10
1
JUSBV3
1
JUSBV1
1
1
JUSBLAN1
JAUDIO
JGAME1
1
216
15
BIOS
1
1
LAN
Phy

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
15
Instalación del CPU
1. Tire de la palanca del lado del zócalo, luego levante la palanca hasta un
ángulo de 90 grados.
2. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la
CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego
inserte la CPU.
3. Presione la palanca para abajo. Ponga el ventilador en la CPU y abróchelo.
Luego ponga el puerto de corriente del ventilador en el JCFAN1. Y ya
habrá completado su instalación.
CPU/ Cabezales del Sistema de Ventilación: JCFAN1/ JSFAN1
CPU
JCFAN1
Tierra
12V
Sense
1
JSFAN1
Tierra
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
16
Módulos DDR DIMM: DDR1-2
DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/ 266 MHz (sin ECC) Tipo
requerido.
DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 pin)
Localización
del Módulo
DIMM
Módulo DDR Total del
Tamaño de
Memoria (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Máximo de
2GB
* La lista de arriba para la configuración DRAM es solamente para referencia.
Cómo instalar un Módulo DIMM
1. El zócalo DIMM tiene una lengüeta
plástica de seguridad y el módulo de
memoria DIMM tiene una muesca
asimétrica, así el módulo de memoria
DIMM puede caber solamente en la ranura
de una sóla dirección.
2. Tire la lengüeta hacia afuera. Inserte
los módulos de memoria DIMM en el
zócalo a los 90 grados, luego empuje hacia
abajo verticalmente de modo que encaje
en el lugar.
3. Los agujeros de montaje y las lengüetas
plásticas deben caber por sobre el borde y
sostenga los módulos de memoria DIMM
en el lugar.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
17
Conectores, Cabezales, Puentes y Ranuras
Conectores del Disco Duro: IDE1/ IDE2
La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo
PIO 0~4, Bus Master, y funcionalidad Ultra DMA 33/ 66/ 100/ 133. Tiene dos
conectores HDD IDE1 (primario) y IDE2 (secundario).
El conector IDE puede conectar a un master y un drive esclavo, así puede
conectar hasta cuatro discos rígidos. El primer disco duro debe estar siempre
conectado al IDE1.
Conector para el Disquete: FDD1
La placa madre proporciona un conector estándar del disquete (FDC) que
soporta 360K, 720K, 1.2M, 1.44M y 2.88M tipos de disquete. Éste conector utiliza
los cables de cinta proporcionados por el disquete.
Ranura Audio y Módem Riser: AMR1
La especificación AMR es una Arquitectura de Industria Estándar y define una
tarjeta elevadora de interface del hardware en el que soporta solamente audio y
módem.
Ranura de Interconexión del Componente Periférico: PCI1-2
Ésta placa madre está equipada con 2 ranuras estándar PCI. PCI es la sigla para
Interconexión del Componente Periférico, y es un bus estándar para tarjetas de
expansión. Ésta ranura PCI está diseñado con 32 bits.
Ranura del Puerto Acelerado para Gráficos: AGP1
Su monitor se fijará directamente a la tarjeta de video. Ésta placa madre
soporta tarjetas de video para PCI, pero también está equipada con puerto AGP.
La tarjeta AGP tomará ventaja de la tecnología del AGP para el mejoramiento de
la eficiencia y funcionamiento del video, especialmente con gráficos 3D.
Conectores de Corriente: JATXPWR1
JATXPWR1
(Conector de
Corriente ATX)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
18
Cabezal Wake On LAN: JWOL1
Puente de Borrar CMOS: JCMOS1
Cabezal Frontal USB: JUSB3
JWOL1
1
5V_SB Wake up
Tierra
JCMOS1
Borrar Datos
CMOS
Contacto
1-2 on
Operacion
Normal
(Default)
1
Contacto
2-3 on
1
Asignacion
JUSB3
2
1
Contactos Asignacion Contactos Asignacion
12
43
56
87
910
+5V +5V
Data (-)Data (-)
Data (+) Data (+)
Tierra Tierra
Key NA
