BioSure EOS7161-P User manual

Professional
Ozone Spray Bottle
EOS7161-P
O3
1 hr
1
• Do NOT use a power supply voltage other than being specified on the product.
• Do NOT plug or unplug the Power Cord if your hands are wet.
• BioSure Professional Ozone Spray Bottle is not a toy. Supervision is required
when children present.
• Do not spray directly into the eyes.
• Dispose of properly.
PRESS x1
Mode 1:10min standby
Mode 2:25min standby
READY
TO STOP
Breathing
BLUE
ppm
O3
ppm
O3
150
100
50
0
BioSure Professional is a division of Biotek Environmental Science Ltd. (“BES”). BES
warranties new equipment manufactured in BES’s designated facilities to be free of
defects due to poor materials or workmanship for the period of time listed below
(following the date of original installation or purchase):
- 1 Year Parts Only Replacement (excluding spray head and battery)
- Pressurized Spray Head - 6 months parts only
- Lithium Polymer Battery - 6 months
Exclusions: Certain BES parts that are expendable by nature and that need to be
replaced frequently may not be covered. BES is not liable under these warranties for
repairs or damages due to improper operation, attempted repairs or installation by
unauthorized persons, alterations, abuse, fire, flood, or acts of nature. Additionally,
this warranty may be voided in the case of:
- Failure to follow BES (and BioSure Professional) instructions for use, care, or
maintenance
- Removal, alteration, or defacing of the BES-axed serial number and other labels
- Mechanical damage
- Use of fluids other than clean, potable water
This warranty is conditional upon BES receiving notice of any defect subject to this
warranty within thirty (30) days of its original discovery by the Buyer. For service or
warranty questions, contact the BES service department or BES authorized dealer
nearby.
LIMITED WARRANTY ATTENTION
BIOTEK ENVIRONMENTAL SCIENCE LTD.
www.besgroups.com
Version 1.0
©2020 Biotek Environmental Science Ltd.
QUICK START GUIDE 2
Thank you for purchasing BioSure Professional product.
Please read this manual carefully and follow the instructions for using this
product.
O3
USB-C
Desiccant bag
Mode 1 - For single use
PRESS x2 to activate performancein
3.5min, followed by 10min standby.
Mode 2 - For continuous use
PRESS x3 to activate performance in
3.5min, and consistent performance
is maintained for approx. 25min standby.
※Charge the unit full for
the first time for approx. 2hr
x2
5s
Blinking
3.5m
x3
5s
MODE 2
ON
3.5m
MODE 1
This device is designed to generate ozone electrochemically in clean water,
with the amount of ozone well below typical safety limits and regulations when
used correctly. Ozone can be sensed by smell at a level as low as 0.02ppm. It is
normal and expected to be able to detect a mild ozone smell from the open
bottle mouth. However, ozone can be irritable if inhaled in instant large
quantities. For safety, do NOT inhale the ozone gas produced by this device
directly.

PREPARATION
CAUTION
USE
CARE
PRECAUTIONS
CHARGE
If the spray bottle does not operate when activation
button is pressed or a red light is ON after operation.
The spray bottle needs to be recharged.
• Find the charging port on the back of the bottle.
• Connect the charging cable (USB-C, included) to the device.
• Connect the charging cable to an adaptor (output: DC 5V/1A) and plug them into a
standard outlet.
• A breathing RED LED light indicates charging is taking place.
• Charging is complete when the indicator turns to be steady green.
It is NOT recommended to charge and operate the unit at the same time.
FILL
• Turn spray head on top counterclockwise and remove it from the bottle.
• Fill the bottle with cold tap water ONLY.
• Reattach the spray head to the bottle and turn clockwise to fasten it tightly.
Do NOT submerge under water. Do NOT add chemicals or soap. Use tap water
ONLY.
※Recommended water quality:
Clean or filtered water, TDS 60-200 ppm, Hardness < 180 ppm as CaCO3.
SPECIFICATIONS
BE FAMILIAR WITH YOUR NEW
PROFESSIONAL OZONE SPRAY BOTTLE.
SPRAY NOZZLE
PRESSURIZED SPRAY HEAD
INDICATOR LIGHT
ACTIVATION BUTTON
CHARGING PORT
5V/1A
WATER LEVEL WINDOW
SANITIZE
• Generate ozonated water solution in the bottle.
• Continuously spray surfaces with ozonated water.
• Effectively kill germs especially on hard and non-porous surfaces.
• Wipe surface dry with clean cloth.
CLEAN
• Rinse the inside of the spray bottle with clean water ONLY. (※NOT dishwasher safe)
• Wipe the bottle surface with a soft cotton, microfiber, or paper textile.
• If the tap water quality in your region is hard, it can cause scaling on the spray bottle.
It there is scaling, fill the bottle with warm citric acid solution and then wait for 30
minutes. After descaling, pour out the citric acid solution and wash the bottle with
clean water.
MAINTENANCE
To maintain consistent performance, follow these care instructions.
• Do NOT operate the bottle when it is empty or at low water level, this may damage the
ozone generator.
• Clean and empty the bottle at the end of each day.
• Use only attachments and replacement parts sold or recommended by manufacturer.
• Use citric acid for every 3 months or every 4 weeks (depends on usage and water
quality).
STORAGE
• Empty water from the spray bottle.
• Spray out the remaining water in the sprayer tube.
• Remove the spray head.
• Wait for the bottle dry, and then fasten the head.
• Store the spray bottle at room temperature, avoid dust.
ON SAFETY
• Important information such as the model name and product serial number are
located on the bottom exterior.
ON PLACEMENT
• Do not set the unit in an inclined position.
• Do not leave the unit in a place subject to high temperature, such as direct sunlight,
near a heat source or under lighting equipment.
ON CLEANING
• Do not use detergent nor solvents such as alcohol, benzine, thinner, to clean the
bottle exterior surface.
• Do not clean the unit in a dishwasher.
OTHERS
• Do not use or leave the unit in an extremely cold or hot environment (temperature
outside the range of 5 - 35°C).
• Even if you do not intend to use the unit for a long time, charge the battery to its full
capacity once every 6 months to maintain its performance.
※How to care for the unit when wet:
If the unit gets wet on the surface, wipe off the moisture using a soft, dry clean cloth.
Be sure to wipe off excess moisture after filling the unit. After using the unit, drain all
the water and leave it at room temperature, dry it until no moisture remains. Do not
put the unit in a dish dryer to dry.
※System requirements for charging battery using USB-C:
Using a USB power supply capable of feeding in DC 5V 1A.
OZONE TECHNOLOGY
Ozone generator: Built-in parallel plate electrodes electrolytic ozone
generator
Ozonated water concentrations:
Up to 3.0ppm*1
*1Actual performance concentrations may vary from the listed data due to
operating conditions.
WATER
Max. fill capacity: 150ml (5 oz.)
Water temperature: 5 - 35°C (41 - 95°F)
Water quality requirements:
Total Dissolved Solids (TDS) 60 - 200ppm;
Hardness 180ppm as CaCO3
BATTERY
Battery spec.: Lithium polymer 3.7V 1000mAh
Charging power: DC 5V 1A (using the USB power supply)
Charging time: 60 minutes approx. (first time charge 120min.)
Battery performance time:
Approx. 500hr in idle state; approx. 2.5hr in total for both
modes 1&2 (collective time, including standby). If the mode
1 is repeated without standby the usage life will be approx.
50min.*2
*2Actual performance time may vary from the listed time due to usage
conditions.
Designed by BES in Taiwan. Assembled in China.
Design and specifications are subject to change without notice.
OZONE TECHNOLOGY
Ozone generator: Built-in parallel plate electrodes electrolytic ozone
generator
Ozonated water concentrations:
Up to 3.0ppm*1
*1Actual performance concentrations may vary from the listed data due to
operating conditions.
WATER
Max. fill capacity: 150ml (5 oz.)
Water temperature: 5 - 35°C (41 - 95°F)
Water quality requirements:
Total Dissolved Solids (TDS) 60 - 200ppm;
Hardness 180ppm as CaCO3
BATTERY
Battery spec.: Lithium polymer 3.7V 1000mAh
Charging power: DC 5V 1A (using the USB power supply)
Charging time: 60 minutes approx. (first time charge 120min.)
Battery performance time:
Approx. 500hr in idle state; approx. 2.5hr in total for both
modes 1&2 (collective time, including standby). If the mode
1 is repeated without standby the usage life will be approx.
50min.*2
*2Actual performance time may vary from the listed time due to usage
conditions.
Designed by BES in Taiwan. Assembled in China.
Design and specifications are subject to change without notice.
• To reduce the risk of fire, do not expose the appliance to naked flame sources (for
example, lighted candles).
• Do not expose the batteries (batteries installed) to excessive heat such as sunshine,
fire or the like for a long time.
• Do not dismantle, open or shred batteries.
• In the event of a cell leaking, do not allow the liquid to come in contact with the skin
or eyes. If contact has been made, wash the affected area with copious amounts of
water and seek medical advice.
• Batteries need to be charged before use. Always refer to the manufacturer’s
instructions or equipment manual for proper charging instructions.
• After extended period of storage, it may be necessary to charge and discharge the
cells or batteries several times to obtain maximum performance.
TROUBLESHOOTING
Professional Ozone Spray Bottle
EOS7161-P
INSTRUCTIONS & REFERENCE GUIDE
When the USB plug is inserted in a wet condition, a short circuit occurs due to the liquid (tap
water) attached to the main unit and charging cable or foreign matter, it may cause abnormal
heat generation or malfunction.
Never insert USB plug when the main unit or charging cable is in wet condition.
CAUTION ON CHARGING
Problem Possible Cause
5 sec RED LED ON
after operation Battery low
No response after pressing
the activation button
Blinking RED/GREEN LED
during activation
※Function suspended
Battery empty
Bad battery
RED LED not ON
during recharging
Bad adaptor or loosen
connection
Bad battery
Breathing BLUE/RED LED
during standby
Blinking RED/BLUE LED
during activation
※Function suspended
Blinking RED/BLUE LED
during activation
※Function suspended
Ozone Generator near end of
life (2%)
Quick Blinking RED LED
during activation
※Function suspended
Ozone Generator life finished
Shorter operating time Battery near end of life
Less ozone performance
Water TDS low
Generator scaled
Solution
Recharge
Recharge
Contact service agent
Contact service agent
Contact service agent
Contact service agent
Replace adaptor or
reconnect the charger
Correct water source
Clean bottle with citric acid
solution
Correct water source
Correct water source
TDS too high (>200ppm)
TDS too low (<60ppm)
Fill waterLack of water
Clean bottle with citric acid
solution
Generator is heavily scaled
GENERAL
Room temperature: 5 - 40°C (41 - 104°F)
Dimensions (including spray head):
53mm (2”) dia. x 255mm (10”) [H], approx. 310g (0.68lbs)
including battery (empty bottle)
Supplied accessory: USB Type-C cable (1), Spray head (1) [attached to the unit]
