Bischoff & Bischoff Mobifit Pro User manual

Instruction manual
Mobifit Pro
Motion trainer
Bischoff & Bischoff GmbH
Becker-Goering-Straße 13 • D-76307 Karlsbad
Tel.: [phone] • Fax: [phone]
www.bischoff-bischoff.com
[email protected] Enjoy mobility.
Guarantee Certificate
Product:
Model Name: Mobifit Pro
Mod. No.:
Serial No.:*
* (to be filled in by retailer)
Retailer:
Date & stamp

1. Important safety instructions
When using the electric device, always carefully mind the safety
instructions as well as following:
Before use read all instructions.
Danger – to minimize risk of electric shocks:
Pull plug connector out of power socket immediately after use and
before cleaning.
Warning – to minimize risk of burns, fire, electric shocks or physical
injury:
1. Never leave device unattended, while plugged in, even though add
on or remove other parts.
2. Never use underneath a blanket or pillow. Ultra heat can lead to
fire, electric shocks and physical injury.
3. Proper observation is necessary if device is used in the nearness of
children, sick or handicapped persons.
4. Device is to be used for destined purpose only, as written in this
instruction. Do not use options that have not been recommended
by the manufacturer.
5. Device is not to be used if cable or plug connecter are damaged.
If it doesn’t work properly, if it has been dropped down or dam-
aged, if it has fallen into water, please bring device to customer
service for examination and repair.
6. Do not carry device and cable like a handle.
7. Keep cable away from heated surfaces.
8. Device is not to be used if air outlets are blocked. Keep air outlets
free from fuzz, hair etc.
9. Do not let objects fall into openings, neither put something in it.
10. Device is not to be used outside.
11. Device is not to be used near sprays or the use of oxygen.
12. To unplug the device, switch off all switches, than unplug connector
from power outlet.
13. Keep children away from out-folded pedals.
12. Um das Gerät aus zu stecken, schalten Sie alle Schalter auf aus
und ziehen dann den Stecker aus der Steckdose.
13. Halten Sie Kinder fern von den ausgeklappten Pedalen.
Mobifit Pro
EN
02 03Bischoff & Bischoff GmbH | 01.05.2011

Mobifit Pro
EN
04 05Bischoff & Bischoff GmbH | 01.05.2011
2. Remote control
Main Power Switch (ON/OFF)
The red-colored main power switch is located at the bottom of the
controller. When the button is pushed to “0” position, the power will be
disconnected. To switch on the unit, just push the button to “-” position
and its red indicator light will turn on.
Power
When the main power switch is turned on, press “Power” button once
and the LCD display will be turned on. All function keys are now ready
to use.
Mode
This function key is use to select for operation modes. 5 operation
modes are available for choices (0 to 5).
Mode 0: Manual operation; time, speed and direction can be set
according to individual’s preference.
Mode 1: Auto operation(km/h) with a speed change of 3-4-3-4-3-4.
Mode 2: Auto operation(km/h) with a speed change of 3-4-5-4-3-5
Mode 3: Auto operation(km/h) with a speed change of 3-4-5-6-5-4
Mode 4: Auto operation(km/h) with a speed change of 4-5-6-5-4-3
Mode 5: Auto operation(km/h) with a speed change of 4-3-4-5-6-5
Speed
Mode 0: Manual operation. Press “+” or “-” to adjust speed levels of
3km/h, 4km/h, 5km/h or 6km/h.
Time
Mode 0: Manual operation. Press “+” or “-” to adjust its running time of
3min, 6min, 9min or 12 min.
Reverse
When the unit is turned on and running in any operation mode, press
“reverse” button once to change the motor rotating direction.
Timer
Distance
increase time
setting
decrease speed
setting
reverse
01
Speed
increase speed
setting
decrease time
setting
Main Power switch
Calorie
Mode
Mode


Mobifit Pro
EN
06 07Bischoff & Bischoff GmbH | 01.05.2011
3. Assembling
Please kindly note that you need to tighten the head screw ( D ) &
Anti-slip screw ( G ) tightly with the tool ( F ). Please do match the Foot
with the Crank as the picture showed, that means the Left Foot needs
to be fixed to the Crank on the left side of the product, it is the same
for the right one.
5. Additional Informations
Power source: AC220V – 50Hz
Engine power: 40 W
Motor: AC220V – 50Hz
Weight: 5,5 kg
Measures: 410 x 290 x 480 mm
 When the unit is not in used, it will turn off auto-
matically after 60 seconds. To restart the unit, just
press the “Power” button once to switch it on again.
When using the unit, the legs and arms must be fully
relaxed so that proper physical exercise can be carry
out on the legs and arms. Do not stop exercise by
external force or perform reverse-direction exercise
that can harm the legs and arms.
Over weight might cause mechanism damage,
do not use if weight over 100kgs
4. Auto-Protection Function
When the unit is running abnormally due to sudden break down of the
motor or human error, the power will automatically cut off after 10
seconds to protect its motor and other electronic components.
02
03
