Bison BA803 User manual

1
P A R T S L I S T
Item Qty Description Item Qty Description
A 1 BASE K 4 5/16” HEX NUT
B 1H-FRAME L 2 3/8” X 3” HEX BOLT
C 1 REAR SUPPORT M 6 3/8” FLAT WASHER
D 2 ADJUSTABLE POLE N 6 3/8” LOCK WASHER
E 1 BACKBOARD (BA600) O 1 BACKBOARD SUPPORT PLATE
F 1 RIM (BA26) P 8 3/8” HEX NUT
G 2 WHEEL Q 2 3/8” LOCKING SPRING PIN
H 4 5/16” X 3 1/2” CARRIAGE BOLT R 6 3/8”-16 X 2-1/2” HEX BOLT
I 4 5/16” FLAT WASHER S 1 PADDING (BA803PP)
J 4 5/16” LOCK WASHER
♦ Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦ Read all instructions before proceeding.
—— Instruction Manual ——
BA803
Elementary Basketball Standard
Date: 6/09/06 Rev: 3 B.A. N.J.C. File: \INSTRUCTIONS\BA803INS Ref#:930366
Customer Service
[phone]
1. Attach Wheels (G) to Base (A) with 3/8” X 3” Hex Bolts (L), 3/8” Flat Washers (M), 3/8” Lock
Washers (N) and 3/8” Hex Nuts (P). See Figure 1.
2. Position the H-Frame (B) and Rear Support (C) in the gussets on Base (A). Install Rear Support (C) into
the short tube on H-Frame (B) with 3/8” X 2 1/2” Hex Bolt (R), 3/8” Flat Washer (M), 3/8” Lock
Washer (N) and 3/8” Hex Nut (P). Attach H-Frame (B) and Rear Support (C) with 3/8” X 2 1/2” Hex
Bolts (R), 3/8” Flat Washers (M), 3/8” Lock Washers (N) and 3/8” Hex Nuts (P). See Figure 1.
3. IMPORTANT! Please install a 3/8” X 2 1/2 Hex Bolt (R) and 3/8” Hex Nut (P) in the 2 places shown
in figure #1. These bolts are intended to provide a positive stop for the backboard assembly. See Figure 1.
4. Insert Adjustable Poles (D) into the H-Frame (B). Orient the Adjustable Poles (D) so the “top” 2 holes
spaced 15 1/2” apart are up to mount Backboard (E) using the 5/16” X 3 1/2” Carriage Bolts (H), 5/16”
Flat Washers (I), 5/16” Lock Washers (J) and 5/16” Hex Nuts (K). The square shoulders of the 5/16” X 3
1/2” Carriage Bolts (H) must be seated in the square holes in Backboard (E) before tightening the
hardware. See Figure 1 and 2.
5. Mount Rim (F) and Backboard Support Plate (O) to the backboard assembly as shown using the hardware
included with Rim (F). See Figure 1.
6. Install the net.
7. Install Padding (S) to the front uprights of the H-frame (B) toward the playing area. See Figure 1.

2
Note: Some hardware not shown for Illustration clarity.
Warning!!!
The unit must be lowered to the 6 1/2’ position for transport. Failure to do so may result in injury!!
Do not leave outside as wind may cause tip over.
This system is not suitable for any player contact with the rim.
Height Adjustment:
To Raise rim, stand under the rim, push in an upward direction, align desired height hole to H-frame
and install Locking Spring Pin (Q) on both sides. Lower the rim in the same manner, using caution to
not drop the rim/backboard assembly as risk of damage or injury is present.
15 1/2" Backboard Mount Holes
Rim Height Adjustment Holes
6 1/2'
7'
7 1/2'
8'
MNP
G
L
IJK O
H
Q
MN P
F
S
P
R
D
E
Read Instruction #3
A
C
B
FIGURE 2
FIGURE 1
