BK RESOURCES BKF-SMPR-WB-G User manual

Pre-Rinse Faucet Kits
Installation Instructions
BKF-8HDDPR-WB-G
BKF-DMPR-WB-G
BKF-4HDDPR-WB-G
BKF-BDMPR-WB-G
BKF-BWMPR-WB-G
BKF-SMPR-WB-G
BKF-SDMPR-WB-G
Step 1
Mount your faucet body to the sink or other application utilized in the
drawings below.
Sink Deck
Mounting Kit
Not Included
Sink Deck
Tighten Coupling
Sink Deck
Sink
Backsplash
Tighten Coupling
Sink
Backsplash
Mounting Kit
Not Included
Sink Deck
Deck Mount Dual Valve Splash Mount Dual Valve
Single Splash Mount
Deck Mount Single Valve
Single Deck Mount
Deck Mount Dual Valve
Install riser pipe into faucet body.
After applying Teon tape or
appropriate compound to threads on
bottom of the riser pipe (BK-PR-18-
RP-G) to prevent leaks, thread it into
the faucet body of the pre-rinse unit.
Step 2
Install wall bracket and hook.
Arm must be cut to proper length.
Mount the Riser Pipe (BK-PR-18-
RP-G) to the wall with the Wall Bracket
(BK-PR-WB). Measure distance from
back of the Riser Pipe to the wall and
deduct ¼”. After cutting the arm on
the non-threaded end, securely mount
to wall and riser pipe. Then mount
Spray Head Retaining Hook (BK-PR-
SHR) to riser pipe.
Step 3
Install spring stop onto riser pipe.
Apply Teon tape or appropriate
compound to the threaded top of
the Riser Pipe ( BK-PR-18-RP-G)
to prevent leaks and thread Spring
Stop/Retainer (BK-PR-SPR) to pipe.
Securely tighten with wrench.
Step 4
Insert washer into hose.
Make sure that the appropriate washer
that is included separately in your box
is placed in the end of the pre-rinse
hose (BKH-44-G).
Step 5
Required Tools and Installation Notes:
You will need the following tools to install your new BK
Resources faucet. Two adjustable wrenches, Phillips
screwdriver, saw for cutting metal, Teon tape or approved
compound for sealing the threaded pipe connections.
Faucet Installation Notes:
Mounting kits are not included with all models. Kits (BK-DMMK
or BK-DMMK-90) are available if needed or inquire with your
plumbing professional. Some models include couplings that allow for
connection to ½” threaded pipe. Pipe is not included with the unit.

Parts List
1
3
5
7
9
11
13
2
4
6
8
10
12
1
1
2
1
1
2
1
1
1
2
1
2
1
Reference Faucet
Body Part List
BK-PR-SPR
BKF-SBH
BK-PR-SHR
BK-PR-WB
BKF-ESC-WASHER
BK-PRV-G
BK-PR-SPRING
BK-PR-18-RP-G
BKF-(HV)(CV)-G
BKH-44-G
BKF-ESC-G
BKH-HANDLE
Faucet Body style
may vary
Spring Stop
Blade Handle
Retainer Hook
Wall Bracket
Washer
Spray Head
Spring
Riser Pipe
Hot / Cold Valve
44” Prerinse Hose
Coupling
Handle
Quantity Part Number DescriptionItem
Available Faucet Bodies
Attach 3 ¼” threaded pipe to your faucet
body in place of the standard riser pipe.
Then attach your Add A Faucet body to the
top of the pipe. Once secure then attach the
pre-rinse unit riser pipe to the top of the Add
A Faucet body, then complete the installation
instructions for your pre-rinse unit.
Add A Faucet
Warranty
Information
Thank you for purchasing a BK Resources faucet. A dedication to quality has enabled
us to provide what we believe to be the nest quality commercial faucet available. To
support this claim, we are pleased to offer this guarantee against defects in material
and/or workmanship for a period of two years from date of purchase. Liability, in the
event of defect(s) is limited to, at BK Resources’ discretion, replacement of the defec-
tive unit. BK Resources will neither bear any responsibility for freight damages or labor
costs as a result of any defects. The customer must handle any claims against the
carrier. Returned product will neither be accepted, replaced nor credited without prior
written authorization from BK Resources. This warranty shall take precedence over
any other warranty, either expressed or implied by BK Resources or any of its agents.
Deck Mount Dual Valve Splash Mount Dual Valve
Single Splash Mount
Deck Mount Single Valve
Single Deck Mount
Deck Mount Dual Valve
8” BKF-8HDDPR-G
4” BKF-4HDDPR-G
BKF-SMPR-G
BKF-BWMPR-G
BKF-SDMPR-G
BKF-BDMPR-G
BKF-DMPR-G
Installation Completion Notes:
If any leaking is noted after the water supply is turned on, shut off
water supply once again and check the affected area. Tighten the
connection and repeat process until leak is no longer present. If
problem persists, remove and reapply Teon tape or appropriate
compound.
Insert hose into spring.
Insert the end of your hose through
the Support Spring ( BK-PR-
SPRING) starting at the end with a
90 degree bend which is considered
the top.
Step 6
Attach hose to spring stop.
Attach the hose to the end of the
Spring Stop/Retainer (BK-PR-SPR)
after applying teon tape or appro-
priate compound to prevent leaks.
Tighten with a wrench.
Step 7
Mount spring on spring stop.
Slide Support Spring (BK-PR-
SPRING) all the way down onto the
Spring Stop/Retainer (BK-PR-SPR ).
Step 8
Tighten all ttings with wrench.
Check and tighten all connections
before turning on water supply.
Step 9
2
3
8
7
4
10
10
11
9
5
6
1
6
5
12
13
9
9
120 Frontage Rd, Altamont, IL 62411
888-310-4393 Phone • 888-310-4394 Fax
www.bk-resources.com bkf-smpr-wb-g 0416
