Black & Decker BDBB26 User manual

UK
Ireland
Australia
New Zealand

2

3
English
Intended use
Your Black & Decker light bar has been
designed for providing illumination for
DIY projects and leisure use. This product
is intended for consumer use only.
Safety instructions
Warning! When using battery-powered
appliances, basic safety precautions,
including the following, should always be
followed to reduce the risk of fire, leaking
batteries, personal injury and material
damage.
XRead all of this manual carefully before
using the appliance.
XThe intended use is described in this
manual. The use of any accessory or
attachment or the performance of any
operation with this appliance other
than those recommended in this
instruction manual may present a risk
of personal injury.
XRetain this manual for future reference.
Using your appliance
Always take care when using the
appliance.
XThis appliance is not intended for use
by young or infirm persons without
supervision.
XThe appliance is not to be used as a
toy.
XUse in a dry location only. Do not allow
the unit to become wet.
XDo not immerse the appliance in water.
XDo not open body casing. There are no
user-serviceable parts inside.
XDo not operate the appliance in
explosive atmospheres, such as in the
presence of flammable liquids, gases
or dust.
XTo reduce the risk of damage to plugs
and cords never pull the cable to
remove the plug from a socket outlet.
After use
XWhen not in use, the appliance should
be stored in a dry, well ventilated place
out of the reach of children.
XChildren should not have access to
stored appliances.
XWhen the appliance is stored or
transported in a vehicle it should be
placed in the boot or restrained to
prevent movement following sudden
changes in speed or direction.
XThe appliance should be protected
from direct sunlight, heat and moisture.
Inspection and repairs
XBefore use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may
affect its operation.
XDo not use the appliance if any part is
damaged or defective.
XHave any damaged or defective parts
repaired or replaced by an authorised
repair agent.
XNever attempt to remove or replace
any parts other than those specified in
this manual.
Specific safety instructions for light
bars
XInspect the lens for damage following
impact or if the light bar is dropped. Do
not operate without the lens in place or
with a damaged lens.
XNever look directly into the light or
shine the light into another person's
eyes.
XDo not immerse light bar in water.
XUse only with the Black & Decker
charging adapters that are provided
with unit. Plug in the charging adapter
at the light bar first, then plug into the
charging source.
Additional safety instructions for
batteries and chargers
Batteries
XNever attempt to open for any reason.
XDo not expose the battery to water.
XDo not store in locations where the
temperature may exceed 40 °C.
XCharge only at ambient temperatures
between 10 °C and 40 °C.
XCharge only using the chargers
provided with the tool.

4
XWhen disposing of batteries, follow
the instructions given in the section
"Protecting the environment".
XUnder extreme conditions, battery
leakage may occur. When you notice
liquid on the batteries, carefully wipe
the liquid off using a cloth. Avoid skin
contact.
XIn case of skin or eye contact, follow
the instructions below.
Warning! The battery fluid is a diluted
sulphuric acid and may cause personal
injury or damage to property. In case of skin
contact, immediately rinse with water. If
redness, pain or irritation occurs seek
medical attention. In case of eye contact,
rinse immediately with clean water and
seek immediate medical attention.
Chargers
Your charger has been designed for a
specific voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate.
Warning! Never attempt to replace the
charger unit with a regular mains plug.
Use your Black & Decker charger only to
charge the battery in the tool with which
it was supplied. Other batteries could
burst, causing personal injury and
damage.
XNever attempt to charge non-
rechargeable batteries.
XHave defective cords replaced
immediately.
XDo not expose the charger to water.
XDo not open the charger.
XDo not probe the charger.
The battery must be placed in a well
ventilated area when charging.
DO NOT OVERCHARGE:
XAC recharge up to 10 hours maximum.
XAfter recharge, disconnect the
charging adapter and wait 5 minutes
before use.
The following symbols are found on
your charger:
Your charging base is double
insulated; therefore no earth
wire is required.
Fail-safe isolating
transformer. The mains
supply is electrically
separated from the
transformer output.
The charger automatically
shuts off if the ambient
temperature becomes too
high. As a consequence the
charger will be inoperable.
The charging base must be
disconnected from the mains
supply and taken to an
authorised service centre for
repair.
The charging base is intended
for indoor use only.
Electrical safety
This tool is double insulated;
therefore no earth wire is
required. Always check that
the power supply corresponds
to the voltage on the rating
plate.
XIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
This appliance includes some or all of the
following features:
1. Hook
2. LED light bar
3. Battery status LED
4. On/off/brightness switch
5. 12 Vdc charging socket
6. Mains charging adaptor
Charging the light bar (fig. A)
XMake sure that the light bar is
switched off (the on/off/brightness
switch is in the OFF position).
Warning! Do not charge for longer than 10
hours.
XInsert the charger jack plug (7) into the
12 Vdc charging socket (5).
XInsert the mains charging adaptor (6)
into a mains power socket.
130oC

5
XThe red battery status LED (3) will
illuminate to show that the product is
charging (do not charge for more than
10 hours).
Use
Using the hook (fig. B)
XThe hook (1) may be used to store or
suspend the light bar. The hook rotates
so that the light bar (1) can be set to any
position. Make sure that the hook is
secure around the supporting object.
Operating the light bar (fig. C)
XTo illuminate half of the LED's move
the on/off/brightness switch (4) to the
position.
XTo illuminate all of the LED's move the
on/off/brightness switch (4) to the
position.
XTo turn the unit off, move the on/off/
brightness switch (4) to the OFF
position.
Maintenance
Your Black & Decker tool has been
designed to operate over a long period of
time with a minimum of maintenance.
Continuous satisfactory operation
depends upon proper tool care and
regular cleaning.
Warning! Before performing any
maintenance or cleaning of the tool, unplug
the unit from the power supply.
XFrom time to time wipe the tool with a
damp cloth. Do not use any abrasive or
solvent-based cleaner. Do not immerse
the tool in water.
Protecting the environment
Separate collection. This
product must not be disposed
of with normal household
waste.
Should you find one day that your
appliance needs replacement, or if it is of
no further use to you, think of the
protection of the environment. Black &
Decker repair agents will accept old Black
& Decker tools and ensure that they are
disposed of in an environmentally safe
way.
Separate collection of used
products and packaging allows
materials to be recycled and
used again. Re-use of recycled
materials helps prevent
environmental pollution and
reduces the demand for raw
materials.
Local regulations may provide for
separate collection of electrical products
from the household, at municipal waste
sites or by the retailer when you purchase
a new product.
Black & Decker provides a facility for the
collection and recycling of Black & Decker
products once they have reached the end
of their working life. To take advantage of
this service please return your product to
any authorised repair agent who will
collect them on our behalf.
You can check the location of your
nearest authorised repair agent by
contacting your local Black & Decker
office at the address indicated in this
manual. Alternatively, a list of authorised
Black & Decker repair agents and full
details of our after-sales service and
contacts are available on the Internet at:
www.2helpU.com.

6
Technical data
EC declaration of conformity
BDBB26
Black & Decker declares that these
products conform to:
Standards & Legislation.
2006/95/EC, 89/336/EEC, 95/54/EC,
EN60335, EN61000, EN60598, EN61347,
EN55014
Kevin Hewitt
Director of Consumer Engineering
Spennymoor, County Durham
DL16 6JG,
United Kingdom
02-04-2007
Guarantee
Black & Decker is confident of the quality
of its products and offers an outstanding
guarantee. This guarantee statement is in
addition to and in no way prejudices your
statutory rights. The guarantee is valid
within the territories of the Member
States of the European Union and the
European Free Trade Area.
If a Black & Decker product becomes
defective due to faulty materials,
workmanship or lack of conformity, within
24 months from the date of purchase,
Black & Decker guarantees to replace
defective parts, repair products subjected
to fair wear and tear or replace such
products to make sure of the minimum
inconvenience to the customer unless:
XThe product has been used for trade,
professional or hire purposes.
XThe product has been subjected to
misuse or neglect.
XThe product has sustained damage
through foreign objects, substances or
accidents.
XRepairs have been attempted by
persons other than authorised repair
agents or Black & Decker service staff.
To claim on the guarantee, you will need
to submit proof of purchase to the seller
or an authorised repair agent. You can
check the location of your nearest
authorised repair agent by contacting
your local Black & Decker office at the
address indicated in this manual.
Alternatively, a list of authorised Black &
Decker repair agents and full details of
our after-sales service and contacts are
available on the Internet at:
www.2helpU.com
Please visit our website
www.blackanddecker.co.uk to
register your new Black & Decker product
and to be kept up to date on new products
and special offers. Further information on
the Black & Decker brand and our range of
products is available at
www.blackanddecker.co.uk.
BDBB26
Input voltage Vdc 12
Input current mA 300 max
Weight kg 0.46
Battery Type 3.6V 1.5Ah SLA
Charger
Input Vac 230
Approx. charging
time h10
Weight kg 0.2

7

$XVWUDOLD %ODFN'HFNHU$XVWUDOLD3W\/WG 7HO 
 )OHWFKHU5RDG0RRURROEDUN )D[ 
 9LFWRULD
1HZ=HDODQG %ODFN'HFNHU 7HO 
 7H$SXQJD3ODFH )D[ 
 0W:HOOLQJWRQ
 $XFNODQG
8QLWHG.LQJGRP %ODFN'HFNHU 7HO 
 %DWK5RDG )D[ 
 6ORXJK%HUNVKLUH6/<' +HOSOLQH 
90518279 04/07
