ENGLISH
3.6V Li-ion Screwdriver
AS36LN
Technical Data
Cordless Screwdriver AS36LN
Voltage VDC 3.6
No Load Speed RPM 180
Max. Torque Nm 4.8
Bit Holder mm (Hex) 6.35
Weight kg 0.5
Battery
Voltage V 3.6
Type Li-ion
Capacity Ah
1.5
Charger
Approx. Charging Time Hour
8(fully charged)
Weight kg 0.4
Intended Use
Your Black & Decker compact screwdriver has been designed for screwdriving applications.
The tool is intended for consumer use only.
Your Black & Decker charger has been designed for charging Black & Decker batteries of
the type supplied with this tool.
Safety Instructions
When using power tools, always observe the safety regulations applicable in your
country to reduce the risk of fire, electric shock, personal injury and material damage.
Read the following safety instructions before attempting to operate this product. Keep
these instructions in a safe place!
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the tool in case of non-
observance of the instructions in this manual.

5
ENGLISH
Denotes risk of electric shock.
Fire hazard.
1. Keep work area clean. Cluttered areas and benches can cause accidents.
2. Consider work area environment. Do not expose power tool to humidity. Keep work
area well lit (250-300 Lux). Do not use power tools in the presence of inflammable liquids
or gases.
3. Keep children away. Do not let children come into contact with the tool or extension
cord. Keep all people away from the work area.
4. Dress properly. Do not wear loose clothing or jewelry. They can be caught in moving
parts. Preferably wear rubber gloves and non-slip footwear when working outdoors.
Wear protective hair covering to keep long hair out of the way. When working outdoors,
preferably wear suitable gloves and non-slip footwear.
5. Personal protection. Always use safety glasses. Everyday eyeglasses only have impact
resistant lenses, they are not safety glasses. Use a face or dust mask whenever the
operations may produce dust or flying particles. If these particles might be considerably
hot, also wear a heat-resistant apron. Wear ear protection whenever the sound level
seems uncomfortable, i.e. if the sound pressure stated in this manual exceeds 85 dB(A).
6. Do not overreach. Keep proper footing and balance at all times.
7. Stay alert. Watch what you are doing. Use common sense. Do not operate the tool
when you are tired.
8. Secure workpiece. Use clamps or a vice to hold the workpiece. It is safer and it frees
both hands to operate the tool.
9. Remove adjusting keys and wrenches. Always check that adjusting keys and
wrenches are removed from the tool before switching on.
10. Use appropriate tool. The intended use is laid down in this instruction manual. Do not
force small tools or attachments to do the job of a heavy-duty tool. The tool will do the
job better and safer at the rate for which it was intended. Do not force the tool.
Warning! The use of any accessory or attachment or performance of any operation
with this tool, other than those recommended in this instruction manual may present a
risk of personal injury.
11. Check for damaged parts. Before using the tool, carefully check it for damage
to ensure that it will operate properly and perform its intended function. Check for
misalignment and seizure of moving parts, breakage of parts and any other conditions
that may affect its operation. Have damaged guards or other defective parts repaired or
replaced as instructed. Do not use the tool if the switch is defective. Have any damaged
or defective parts replaced by an authorized repair agent. Never attempt any repairs
yourself.

6
ENGLISH
12. Avoid unintentional starting. Do not carry the plugged-in tool with a finger on the
switch. Be sure that the switch is released when plugging in.
13. Do not abuse cord. Never carry the tool by its cord or yank it to disconnect from the
socket. Keep the cord away from heat, oil and sharp edges.
14. Store idle tools. When not in use, power tools must be stored in a dry place and locked
up securely, out of reach of children.
15. Maintain tools with care. Keep the tools in good condition and clean for better and
safer performance. Follow the instructions for maintenance and changing accessories.
Inspect the tool cords at regular intervals and, if damaged, have them repaired by an
authorized repair agent. Inspect the extension cords periodically and replace them if
damaged. Keep all controls dry, clean and free from oil and grease.
16. Have your tool repaired by an authorized repair agent. This power tool is in
accordance with the relevant safety regulations. To avoid danger, electric appliances
must only be repaired by qualified technicians using original spare parts.
Additional Safety Instructions for Batteries and Chargers
Batteries
17. Never attempt to open for any reason.
18. Do not store in locations where the temperature may exceed 40ºC.
19. Charge only at ambient temperatures between 4ºC and 40ºC.
20. Charge only using the charger provided with the tool (see technical data).
21. When disposing of batteries, follow the instructions given in the section
“Protecting the environment”.
22. Leaks from battery cells can occur under extreme conditions. The battery fluid,
a 25-30% solution of potassium hydroxide, can be harmful. In case of skin contact:: (a)
wash quickly with soap and water; or (b) neutralize with a mild acid such as lemon juice
or vinegar. If the liquid gets into the eyes, flush them immediately with clean water for a
minimum of 10 minutes. Seek medical attention.
23. Fire hazard! Avoid short-circulating the contacts of a detached battery.
24. Do not incinerate the battery.
Chargers
25. Use your Black & Decker charger only to charge the battery in the tool with which it was
supplied. Other batteries could burst, causing personal injury and damage.
26. Never attempt to charge non-rechargeable batteries.

7
ENGLISH
27. Have defective cords replaced immediately.
28. Do not expose to water.
29. Do not open the charger.
30. Do not probe the charger.
31. The charger is intended for indoor use only.
Specific Safety Rules
32. When fitting and changing accessories, always use the instructions supplied with the
accessory.
33. Should your screwdriver develop a fault, do not try to fix it yourself, but take it to one of
our authorized repair agents.
34. Warning: Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber (CCA).
Your risk from these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals: work in a well ventilated area, and work
with approved safety equipment, such as those dust masks that are specially designed
to filter out microscopic particles.
Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling,
and other construction activities. Wear protective clothing and wash exposed
areas with soap and water. Allowing dust to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful chemicals.

8
ENGLISH
Labels on your tool
They may include the following symbols.
V ............. volts
A ............. Amperes
Hz ............. Hertz
W ............. Watts
Min. ............. Minutes
............. Alternating current
............. Direct current
no............. No load speed
............. Class II Construction
............. Earthing terminal
............. Safety alert symbol
.../min ............. Revolutions or reciprocation per minute
.../bpm ............. Beats per minute
Save these instructions!
Electrical safety
Your charger is double insulated; therefore no earth wire is required. Always check
that the mains voltage corresponds to the voltage on the rating plate. Never attempt to
replace the charger unit with a regular mains plug.
Using an Extension Cable
An extension cable should not be used unless absolutely necessary. Use of an improper
extension cable could result in a risk of fire and electric shock. If an extension cable must be
used, use only those that are approved by the country’s Electrical Authority. Make sure that
extension cord is in good condition before using. Always use the cord that is suitable for the
power input of your charger (see technical data on name plate).
When using a cable reel, always unwind the cable completely.

9
ENGLISH
Fig. A
1. On/off switch
2. Forward/reverse slider
3. Forward/reverse window
4. Bit holder
5. LED light
6. Mode selector / torque adjustment collar
7. Screw holder
8. Charger
9. Charging base
10. Charging indicator
11. Bit storage
Assembly
Fitting the charging base to the wall (fig. A & B)
The charging base (9) can be placed on a worktop or fitted to the wall to provide a
convenient storage and charging point for the tool. Screws and wall anchors are not
included.
Drive screws in the wall with the same distance apart as the slots (13) on the back of the
charging base (9).
The distance between the slots must be 75 mm.
Slide the charging base over the screws to fit the base to the wall.
Plug in the charger (8).
Place the tool on the charging base making sure the charging indicator (10) lights up.
Warning! Avoid damaging the power cord when mounting the charging base to the wall.
Fitting and removing a drill bit or a screwdriver bit (fig. C)
This tool uses screwdriver bits and drill bits with a 6.35 mm (1/4”) hexagonal shank.
To fit a bit, insert the bit shaft into the bit holder (4).
To remove a bit, pull the bit shaft out of the bit holder (4).
◆
◆
◆
◆
◆
◆

10
ENGLISH
Use
Warning! Let the tool work at its own pace. Do not overload.
Before first use, the battery must be charged for at least 9 hours.
Charging the battery (fig. A)
Place the tool on the charging base (9).
Plug in the charger (8).
Leave the tool connected to the charger for 6 hours.
The red light illuminates when the unit is on charge and will stay red as long as there is
power to the charger. The red light will not go off to indicate a full charge.
The charger may hum and become warm while charging; this is normal and does not
indicate a problem.
Warning! Do not charge the battery at ambient temperatures below 4 °C or above 40 °C.
Selecting the direction of rotation (fig. D)
For drilling and for tightening screws, use forward (clockwise) rotation. For loosening screws
or removing a jammed drill bit, use reverse (counterclockwise) rotation.
The forward/reverse window (3) displays the rotation direction with an arrow.
To select forward rotation, push the forward/reverse slider (2) to the forward position.
To select reverse rotation, push the forward/reverse slider (2) to the rearward position.
To lock the tool, set the forward/reverse slider into the centre position.
Selecting the torque (fig. E)
This tool is fitted with a collar to set the torque for various screwdriving and drilling
applications. Large screws and hard workpiece materials require a higher torque setting than
small screws and soft workpiece materials. The collar has a range of 6 settings to suit your
application.
To set the torque, rotate the torque adjustment collar (6) clockwise or counterclockwise.
For screwdriving, set the collar to the desired setting.
If you do not yet know the appropriate setting, proceed as follows:
- Set the collar (6) to the lowest torque setting.
- Tighten the first screw.
◆
◆
◆
◆
◆
◆
◆
◆
◆

11
ENGLISH
- If the clutch ratchets before the desired result is achieved, increase the collar setting
and continue tightening the screw. Repeat until you reach the correct setting. Use this
setting for the remaining screws.
Screwdriving applications
Torque range: low torque for small screws and high torque for large screws
Drilling/screwdriving
Select forward or reverse rotation using the forward/reverse slider (2).
To switch the tool on, press the on/off switch (1).
To switch the tool off, release the on/off switch (1).
Screwdriving using the screw holder (fig. F1-F3)
The screw holder (7) can be used with 1” and 2” screwdriver bits. The screw holder cannot
be used with bit tip holder extensions.
Pull the screw holder (7) out the tool (fig. F1).
Place the screw onto the screw holder (fig. F2).
Push the screw holder towards the screw making sure the bit tip and the screw are fully
engaged (fig. F3).
The screw is securely held to the screw holder with a magnet. The magnet does not work on
non-ferrous screws.
Drive the screw into the wall.
When screwdriving, the screw holder retracts in order to allow the screw to be driven to its
required depth.
LED light
The LED light (5) is activated automatically when the trigger is depressed. The LED will also
illuminate when the trigger is depressed and the forward/reverse slider (2) is in the locked off
position (central position).
Hints for optimum use
◆
◆
◆
◆
◆
◆
◆

12
ENGLISH
Screwdriving
Always use the correct type and size of screwdriver bit.
If screws are difficult to tighten, try applying a small amount of washing liquid or soap as
a lubricant.
Use the spindle lock to loosen very tight screws or to firmly tighten screws.
Always hold the tool and screwdriver bit in a straight line with the screw.
When screwing in wood, it is recommended to drill a pilot hole with a depth equal to the
length of the screw. A pilot hole guides the screw and prevents splintering or distortion of
the wood. For the optimum size of the pilot hole, refer to the table below.
When screwing in hardwood, also drill a clearance hole with a depth equal to half the
length of the screw. For the optimum size of the clearance hole, refer to the table below.
Screw size Pilot hole ø
(softwood)
Pilot hole ø
(hardwood) Clearance hole
No. 6 (3.5 mm) 2.0 mm 2.5 mm 3.6 mm
No. 8 (4 mm) 2.5 mm 3.0 mm 4.5 mm
No. 10 (5 mm) 3.0 mm 3.5 mm 5.0 mm
Drilling
Always apply a light pressure in a straight line with the drill bit.
Just before the drill tip breaks through the other side of the workpiece, decrease
pressure on the tool.
Use a block of wood to back up workpieces that may splinter.
Make an indentation using a centre punch at the centre of the hole to be drilled in order
to improve accuracy.
Drilling using a countersink drill bit (fig. G1-G3)
The countersink drill bit (12) is used to remove material to seat the screw head flush to the
surface.
Warning! Always gear the diameter of the drill bit to the diameter of the screw.
Place the drill bit into the tool.
Drive the drill into the material (fig. G1).
Drive the cutter on the drill bit as far into the material as necessary. Cut away sufficient
material to sink the screw head into the material (fig. G2).
Drive the screw into the material with a screwdriver bit (fig. G3).
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆

13
ENGLISH
Maintenance
Your Black & Decker power tool has been designed to operate over a long period of time
with a minimum of maintenance. Continuous satisfactory operation depends upon proper
tool care and regular cleaning.
This tool is not user-serviceable. Take it to an authorized Black & Decker repair agent for
service.
Your charger does not require any maintenance apart from regular cleaning.
Unplug the charger before cleaning it.
• Regularly clean the motor housing using a damp cloth. Do not use any abrasive or
solvent-based cleaner.
Important
To ensure product SAFETY and RELIABILITY, repairs, maintenance and adjustment (other
than those listed in this manual) should be performed by authorized service centers or other
qualified organizations, always using identical replacement parts. Unit contains no user
serviceable parts inside.
Accessories
The performance of any power tool is dependent upon the accessory used. Black & Decker
accessories are engineered to high quality standards and are designed to enhance the
performance of your power tool. By using Black & Decker accessories you will get the very
best from your tool.
Black & Decker offers a large selection of accessories available at our local dealer or
authorized service center at extra cost.
CAUTION: The use of any non-recommended accessories may be hazardous.
Protecting The Environment
Separate collection. This product must not be disposed of with normal household
waste.
Should you find one day that your Black & Decker product needs replacement, or if it is of no
further use to you, do not dispose of it with household waste. Make this product available for
separate collection.
Separate collection of used products and packaging allows materials to be recycled
and used again.

14
ENGLISH
Re-use of recycled materials helps prevent environmental pollution and reduces the demand
for raw materials.
If necessary, contact your local municipality for proper disposal instructions in your city/town.
Batteries
Black & Decker batteries can be recharged many times. At the end of their useful life, discard
batteries with due care for our environment:
• Run the battery down completely, and then remove it from the tool.
• NiCd, NiMH, and Li-ion batteries are recyclable. Take them to a local recycling station.
Service Information
Black & Decker offers a full network of company-owned and authorized service locations
throughout Asia. All Black & Decker Service Centers are staffed with trained personnel to
provide customers with efficient and reliable power tool service.
Whether you need technical advice, repair, or genuine factory replacement parts, contact the
Black & Decker location nearest to you.
Notes
• Black & Decker’s policy is one of continuous improvement to our products and, as such,
we reserve the right to change product specifications without prior notice.
• Standard equipment and accessories may vary by country.
• Product specifications may differ by country.
• Complete product range may not be available in all countries. Contact your local Black &
Decker dealers for range availability.

15
ENGLISH
EC declaration of conformity
AS36LN
Black & Decker declares that these products conform to:
98/37/EC, EN 60745
LpA(sound pressure) 58.9 dB(A), LWA (acoustic power) 69.9 dB(A),
Vibration Total value (triax vector sum) according to EN60745
KpA(sound pressure uncertainty): 3 dB(A),
KWA (acoustic power uncertainty): 3 dB(A)
Kevin Hewitt
Director of Consumer Engineering
Spennymoor, County Durham DL16 6JG,
United Kingdom
1-5-2008

16
中文（简体字）
3.6V 锂电池充电起子
型号: AS36LN
技术参数
充电起子 AS36LN
电压 伏(直流电) 3.6
空载转速 每分钟转数 180
最大扭力 牛顿米 4.8
套筒 毫米(六角形) 6.35
净重 千克 0.5
充电电池
电压 伏 3.6
种类 锂电池
容量 安培*时
1.5
充电器
充电大约需 小时
8 (充满电)
净重 千克 0.4
设计用途
本百得充电起子主要用于旋紧和卸下螺丝之用。它乃一非专业用充电起
子。
本百得充电器设计为本充电起子充电之用。

17
中文（简体字）
安全指导
当使用电动工具时，必须遵循当地安全规则以减少导致火灾、触电和人身
伤害的危险。请在操作本产品前阅读并理解本操作手册；并把本手册妥善
保存！
下列标志会在本说明书内使用：
表示如不依本说明书指示操作，会有人身伤亡、工具损坏的危险。
表示会有电击的危险。
表示会有火灾危险。
1. 保持工作区清洁。凌乱的工作区和工作台，会导致人身伤害。
2. 切勿在危险环境中使用电动工具。切勿在潮湿的环境使用电动工具。不
要让工具受到雨淋。工作区要保持良好照明 (250-300照度)。若有导致
火警或爆炸的风险，切勿使用电动工具。
3. 勿让孩童接近。切勿让参观者接触工具或延长线，所有参观者都要与工
作区保持安全距离。
4. 穿着适当衣服。勿穿宽大的衣服或戴首饰；因为这些对象可能会卡在运
行的机件中。在户外工作，请戴塑料手套及穿防滑鞋，长发者应把头发
束起。当在户外工作时，应戴适当的手套并穿防滑鞋。
5. 个人保护。配戴护眼罩，日常所戴的眼镜，只备有防撞镜片，不是防
护眼镜。如果切割操作粉尘多，或在封闭的环境下操作，应配戴防尘面
具。如果这些粒子是热的话，请使用防热围裙。若声音水平令您不适，
即是上述声压高于85分贝，应戴护耳罩。
6. 切勿伸展过远操作。双脚站稳，随时保持平衡。
7. 保持警觉。留意您的工作，运用您的常识，疲倦时勿使用电动工具。
8. 夹紧工件。使用夹具夹紧工件，这比用手拿住安全，还可腾出双手操作
工具。
9. 取下调整键和调整扳手。要养成在启动前先检查工具的习惯，确保已取
下了各个调整键和扳手，并把它们妥善保存。
10.使用适当的工具。本工具的正确用途已详列在本说明书内。切勿强用小
的工具或附件做重型的工作，按设计的速度使用工具，工效较高，也比
较安全。不要施加蛮力。
警告！使用未经本说明书推荐的配件，可能造成人身伤害。
11.检查损坏的零件。使用工具前，应该仔细检查安全护罩或其它部件，
确认能正常运作，执行其原设计功能。检查工具的移动部件是否位置准
确，部件是否安装固定、有无破裂，以及其它可能影响运作的情况。切

18
中文（简体字）
勿使用开关不能正常操作的工具。损坏的安全护罩或其它部件，除非说
明书有指示，否则，应该由指定的维修中心适当修理或更换，切勿试图
自行修理。
12.避免工具意外启动。在接通电源前，要确保开关已在“关”的位置。提
携工具时，手指不可放在开关上；勿在开关开着时接通电源，这会导致
意外发生。
13.切勿滥用电线。切勿使用电线搬运工具或拉扯电线使插头脱离插座。勿
让电线接近高热、油脂、锐利的边角或移动的部件。
14.妥善贮藏闲置工具。工具在非使用期间，应贮藏在干燥及高的位置并锁
上以防孩童玩耍。
15.细心保养工具。保持工具锋利清洁，使其性能最佳、使用最安全。遵循
润滑和更换配件的守则。定期检查电线，如有损坏，应由百得指定维修
机构更换。保持握把干燥、清洁及无油脂。
16.只有合格的维修人员，方可维修工具。本工具符合相关的安全需求，必
须由合格的维修人员进行维修或维护，并使同相同的零件更换，否则，
可能会对用户构成危险。
充电电池及充电器的附加安全守则
充电电池
17.任何情况下切勿尝试开启充电电池。
18. 切勿把工具贮藏在温度40ºC以上的地方。
19.只在室温4ºC至40ºC的环境下充电。
20.只用本工具附上的充电器充电(见上文技术参数)。
21.如要废弃充电电池，请参阅下文“环境保护”。
22.在极端的使用或温度情况下，充电电池可能会有少量液体流出。若发现
电池外部密封破裂：小心以布抹掉液体，避免液体沾到皮肤上。电池液
体为25-30%的有害氧化钾溶液，若沾到皮肤上，应立即用肥皂和水洗
掉，再用弱酸如柠檬汁或醋中和；若液体进入眼睛，则要用净水至少冲
洗十分钟，并立找医生诊治。
23. 火灾危险！勿让充电电池短路。
24. 切勿胡乱废弃充电电池。

19
中文（简体字）
充电器
25.只使用百得充电器为百得工具的充电电池充电，使用其它充电电池会有
爆炸、导致人身伤害及物件损毁的危险。
26.切勿试图为非充电电池充电。
27.立即更新损坏的电线。
28.切勿让充电器沾水。
29.切勿开启充电器。
30.切勿以外物探入充电器内。
31. 本充电器只可于室内使用。
其它安全守则
32.当更换或装上配件时，必须依从配件的说明书上所述而行。
33.如本工具有问题，切勿试图自行修理，请把它送到当地的百得指定维修
中心检查。
34. 警告：某些因砂光、割锯、磨光、钻孔及其它建造业活动所产生的尘
屑所含化学物质可能引致癌症、先天缺陷、或会危害生育。其中一些化
学物质的例子为：
・含铅的油漆；
・墙砖及水泥中的透明二氧化硅及其它砖石产品；及
・经化学处理木材中的砷及铬(CCA)。
这些物质对您的危害与您做这类工作的频密程度相关。要减低接触此类
化学品，请在空气流通的地方工作，并使用证明安全的器具（如特别为
过滤极细微尘设计的防尘面罩）。
切勿长时期在因砂光、割锯、磨光、钻孔及其它建造业活动而产生尘屑
的环境下工作，请使用保护衣物并用肥皂和水清洗无衣物遮掩的部位。
若任由这些尘屑进入您的口、眼或皮肤上，您会吸有害的化学品而危害
健康。
35. 警告：

20
中文（简体字）
工具上的标签
工具上的标签可能会有下列符号：
V ............. 伏特
A ............. 安培
Hz ............. 赫兹
W ............. 瓦
Min. ............. 分钟
............. 交流电
............. 直流电
no ............. 空载转速
............. 双重绝缘
............. 接地终端
............. 安全警告符号
.../min ............. 每分钟转速或往复次数
.../bpm ............. 每分钟冲击次数
请保存本说明书！
电气安全
本充电器是双绝缘的；故无需接地线。本充电器只适用于某一特定的
电压；使用前，先要检查并确保电源电压与铭牌上的电压相符。
使用延长线
如非必要，请勿使用延长线。使用不正确的延长线会引致火灾或电击的
危险。如果非要使用不可，请用当地电力机构认可的延长线。使用前先确
定延长线的性能良好，并且符合充电器的电源输入（见铭牌上的技术数
据）。
如果使用卷轴电线，必须把卷轴电线全部松开。
