Black & Decker Dustbuster V1250 User manual

1
V1250
V1250N
V4800
V4810
V4820
V7210
V9650
1
2
3
Powerful Solutions TM
www.blackanddecker.co.uk

2
English (Original instructions) 5

3
4
5
6
7
8
9
V9650
1
2
3
A B
C D
E F

4
10
11
G
12
H

5
Intended use
Your Black & Decker Dustbuster® hand
held vacuum cleaner has been designed
for light dry vacuum cleaning purposes.
This product is intended for household
use only.
Safety instructions
uWarning! When using battery-
powered appliances, basic safety
precautions, including the following,
should always be followed to reduce
the risk of re, leaking batteries,
personal injury and material damage.
uRead this manual carefully before
using the appliance.
uThe intended use is described in this
manual. The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
uRetain this manual for future reference.
Using your appliance
uDo not use the appliance to pick up
liquids or any materials that could
catch re.
uDo not use the appliance near water.
Do not immerse the appliance in water.
uNever pull the charger lead to
disconnect the charger from the
socket. Keep the charger lead away
from heat, oil and sharp edges.
After use
uUnplug the charger before cleaning
the charger or charging base.
uWhen not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspection and repairs
uBefore use, check the appliance for
damaged or defective parts. Check
for breakage of parts, damage to
switches and any other conditions
that may affect its operation.
uDo not use the appliance if any part
is damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorised
repair agent.
uRegularly check the charger lead for
damage. Replace the charger if the
lead is damaged or defective.
uNever attempt to remove or replace
any parts other than those specied
in this manual.
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use, etc.
Even with the application of the relevant
safety regulations and the implementation
of safety devices, certain residual risks
can not be avoided. These include:
uInjuries caused by touching any
rotating/moving parts.
uInjuries caused when changing any
parts, blades or accessories.
uInjuries caused by prolonged use of
a tool. When using any tool for
prolonged periods ensure you take
regular breaks.
uImpairment of hearing.
uHealth hazards caused by breathing
dust developed when using your tool
(example: working with wood,
especially oak, beech and MDF).
Safety of others
uThis appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by
a person responsible for their safety.
uChildren should be supervised to
ensure that they do not play with the
appliance.

6
Additional safety instructions for
batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not expose the battery to heat.
uDo not store in locations where the
temperature may exceed 40 °C.
uCharge only at ambient temperatures
between 10 °C and 40 °C.
uCharge only using the charger
provided with the appliance/tool.
uWhen disposing of batteries, follow
the instructions given in the section
"Protecting the environment".
uDo not damage/deform the battery
pack either by puncture or impact, as
this may create a risk of injury and re.
uDo not charge damaged batteries.
uUnder extreme conditions, battery
leakage may occur. When you notice
liquid on the batteries, proceed as
follows:
uCarefully wipe the liquid off using
a cloth. Avoid skin contact.
uIn case of skin or eye contact, follow
the instructions below.
Warning! The battery uid may cause
personal injury or damage to property.
In case of skin contact, immediately rinse
with water. If redness, pain or irritation
occurs seek medical attention. In case of
eye contact, rinse immediately with clean
water and seek medical attention.
Chargers
Your charger has been designed for a
specic voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate.
Warning! Never attempt to replace the
charger unit with a regular mains plug.
uUse your Black & Decker charger
only to charge the battery in the
appliance/tool with which it was
supplied. Other batteries could burst,
causing personal injury and damage.
uNever attempt to charge non-
rechargeable batteries.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised Black & Decker Service
Centre in order to avoid a hazard.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
uThe appliance/tool/battery must be
placed in a well ventilated area when
charging.
Electrical safety
Your charger has been designed for a
specic mains voltage. Always check that
the mains voltage corresponds to the
voltage on the rating plate.
#Your charger is double insulated.
Features
1.On/off switch
2.Release button
3.Dust bowl
Fig. A
4.Charging base
5.Charger
Installation
Fitting the charging base to the wall
The charging base can be tted to the
wall to provide a convenient storage and
charging point for the appliance.
Before rst use
Before rst use, the battery must be
charged for at least 24 hours.
Use
Charging the battery (g. D)
uMake sure that the appliance is
switched off. The battery will not be
charged with the on/off switch in the
on position.
uPlace the appliance on the charging
base as shown.
uPlug in the charger.
uSwitch on at the mains.

7
uLeave the appliance to charge for at
least 24 hours.
Whilst charging, the charger may become
warm. This is normal and does not
indicate a problem. The appliance can be
left connected to the charger indenitely.
Important! Place the appliance on the
charging base whenever it is not in use.
Do not charge the battery at ambient
temperatures below 10 °C or above
40 °C.
Operating the appliance (g. E)
uTo switch on, slide the on/off switch
(1) forward.
uTo switch off, slide the on/off switch
back.
Accessories (g. B & C)
V1250/V4810/V4820/V7210/V9650
These models are supplied with the
following accessories:
ua hard brush (6) for furniture and
stairs (not for V4820)
u a crevice tool (7) for conned spaces
ua soft brush (8) for keyboards and
lamp shades (V4820)
V1250/V9650
Two additional accessories are stored in
a portable caddy located in the charging
base:
ua soft brush (8) for keyboards and
lamp shades
uan extendable crevice tool (9) for
longer reach in conned spaces
V1250N
This model is not supplied with accessories.
To t an accessory, proceed as follows:
uTake the accessories from the
appliance.
uInsert the appropriate accessory into
the front of the appliance.
Cleaning and maintenance
Warning! Regularly clean the lters.
Cleaning the dust bowl and lters
(g. F & G)
The lters are re-usable and should be
cleaned regularly.
uPress the release button (2) and
remove the dust bowl (3).
uEmpty the dust bowl.
u Remove the lters (10) by twisting
them clockwise.
u Brush any loose dust off the lters.
u Wash the lters in warm, soapy
water. The bowl can also be washed
if necessary. Do not immerse the
appliance in water.
u Make sure the dust bowl and lters
are dry.
u Ret the lters (10) onto the appliance,
twisting them counterclockwise until
they lock into place.
u Ret the dust bowl onto the appliance.
Make sure the dust bowl clicks into
place.
Warning! Never use the appliance
without the lters. Optimum dust collection
will only be achieved with clean lters
and an empty dust bowl.
Replacing the lters
The lters should be replaced every 6 to
9 months and whenever worn or
damaged. Replacement lters are
available from your Black & Decker
dealer (cat. no. VF20).
u Remove the old lters as described
above.
u Fit the new lters as described above.
Maintenance
Your tool has been designed to operate
over a long period of time with a minimum
of maintenance. Continuous satisfactory
operation depends upon proper tool care
and regular cleaning.
Warning! Before performing any
maintenance, switch off and unplug the
tool.

8
uSwitch off and unplug the appliance/
tool.
uOr switch off and remove the battery
from the appliance/tool if the appliance/
tool has a separate battery pack.
uOr run the battery down completely
if it is integral and then switch off.
uUnplug the charger before cleaning it.
Your charger does not require any
maintenance apart from regular
cleaning.
uRegularly clean the ventilation slots
in your tool using a soft brush or dry
cloth.
uRegularly clean the motor housing
using a damp cloth. Do not use any
abrasive or solvent-based cleaner.
uRegularly open the chuck and tap it
to remove any dust from the interior
(when tted).
Protecting the environment
ZSeparate collection. This product must not be disposed of with
normal household waste.
Should you nd one day that your
Black & Decker product needs
replacement, or if it is of no further use to
you, do not dispose of it with household
waste. Make this product available for
separate collection.
zSeparate collection of used products and packaging allows
materials to be recycled and
used again. Re-use of recycled
materials helps prevent
environmental pollution and
reduces the demand for raw
materials.
Local regulations may provide for separate
collection of electrical products from the
household, at municipal waste sites or by
the retailer when you purchase a new
product.
Black & Decker provides a facility for the
collection and recycling of Black & Decker
products once they have reached the end
of their working life. To take advantage of
this service please return your product to
any authorised repair agent who will
collect them on our behalf.
You can check the location of your nearest
authorised repair agent by contacting your
local Black & Decker ofce at the address
indicated in this manual. Alternatively,
a list of authorised Black & Decker repair
agents and full details of our after-sales
service and contacts are available on the
Internet at: www.2helpU.com
Battery (g. H)
ZBlack & Decker batteries can be recharged many times.
At the end of their useful life,
discard batteries with due care
for our environment.
If you want to dispose of the product
yourself, the battery must be removed
as described below and disposed of in
accordance with local regulations.
uDischarge the battery by operating
the appliance until the motor stops.
The battery is located under the back
end of the appliance.
uRemove the crevice tool from the
accessory holder.
uPush the slider (12) towards the front
of the product.
uRemove the accessory holder.
u Strike the product on a rm and stable
surface as shown in g. H to dislodge
the battery.
uPlace the battery in suitable packaging
to ensure that the terminals cannot
be short-circuited.
uTake the battery to your service agent
or a local recycling station.
Warning! Once removed, the battery
cannot be retted.

9
Technical data
V1250 H2 V1250N H2
Voltage V 12 12
Weight kg 1.8 1.7
V4800 H2 V4810 H2
Voltage V 4.8 4.8
Weight kg 1.2 1.2
V4820 H2 V7210 H2
Voltage V 4.8 7.2
Weight kg 1.2 1.4
V9650 H2
Voltage V 9.6
Weight kg 1.6
Charger
5102404-08 VA090020D
Model V48 V72
Input voltage VAC 230/240 230
Output voltage VAC 6.4 9
Amperage mA 250/265 200
Approx.
charging time h 24 24
Weight kg 0.30.3
5102404-11 CHA002014*
Model V96 V12
Input voltage VAC 230/240 100-240
Output voltage VAC 14 7.2-24 Vdc
Amperage mA 130/140 85
Approx.
charging time h 24 24
Weight kg 0.30.3
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 85 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according
to EN 60745:
Hand/arm weighted vibration 2.5 m/s
2
Guarantee
Black & Decker is condent of the quality
of its products and offers an outstanding
guarantee. This guarantee statement is
in addition to and in no way prejudices
your statutory rights. The guarantee is
valid within the territories of the Member
States of the European Union and the
European Free Trade Area.
If a Black & Decker product becomes
defective due to faulty materials,
workmanship or lack of conformity, within
24 months from the date of purchase,
Black & Decker guarantees to replace
defective parts, repair products subjected
to fair wear and tear or replace such
products to ensure minimum inconvenience
to the customer unless:
uThe product has been used for trade,
professional or hire purposes;
uThe product has been subjected to
misuse or neglect;
uThe product has sustained damage
through foreign objects, substances
or accidents;
uRepairs have been attempted by
persons other than authorised repair
agents or Black & Decker service staff.
To claim on the guarantee, you will need
to submit proof of purchase to the seller or
an authorised repair agent. You can check
the location of your nearest authorised
repair agent by contacting your local
Black & Decker ofce at the address
indicated in this manual. Alternatively,
a list of authorised Black & Decker repair
agents and full details of our after-sales
service and contacts are available on the
Internet at: www.2helpU.com
Please visit our website
www.blackanddecker.co.uk to register
your new Black & Decker product and to
be kept up to date on new products and
special offers. Further information on the
Black & Decker brand and our range of
products is available at
www.blackanddecker.co.uk

TYP.
www.2helpU.com 13 - 01 - 10
E15938
V1250N
Partial support - Only parts shown available Nur die aufgefuerten teile sind lieferbar Reparation partielle - Seules les pieces indiquees sont disponibles Supporto parziale - Sono disponibili soltanto le parti evidenziate Solo estan disponibles las peizas listadas So se encontram disponiveis as pecas listadas Gedeeltelijke ondersteuning - alleen de getoonde onderdelen zijn beschikbaar
170
103
104
160
H2
101

ENGLISH
Do not forget to register your product!
www.blackanddecker.co.uk/productregistration
Register your product online at www.blackanddecker.co.uk/productregistration or
send your name, surname and product code to Black & Decker in your country.

Australia
Black & Decker (Australia) Pty. Ltd. Tel. [phone]
20 Fletcher Road, Mooroolbark, Fax [phone]
Victoria, 3138
New Zealand
Black & Decker Tel. [phone]
5 Te Apunga Place Fax [phone]
Mt Wellington
Auckland 1060
United Kingdom
Black & Decker Tel. [phone]
210 Bath Road Fax [phone]
Slough, Berkshire SL1 3YD Helpline 01753 574277
S/T-12/0990558582 REV 0
