Black & Decker DV9610F-XE User manual

Australia
New Zealand
DV9610F-XE
DV7210F-XE
www.blackanddecker.com.au
®

2
C
E
B
A
E
D
F

3
I
H
G
J

4
ENGLISH
(Original instructions)
Intended use
Your Black & Decker Dustbuster® handheld vacuum cleaner
has been designed for light dry vacuum cleaning purposes.
This appliance is intended for household use only.
Safety instructions
@
@
Using your appliance
Inspection and repairs
uBefore use, check the appliance for damaged or defective
parts. Check for breakage of parts, damage to switches
and any other conditions that may affect its operation.
Warning! Read all safety warnings and all
instructions.Failure to follow the warnings and
instructions listed below may result in electric shock,
fire and /or serious injury.
Warning!When using battery-powered appliances,
basic safety precautions, including the following,
should always be followed to reduce the risk of fire,
leaking batteries, personal injury and material
damage.
uRead all of this manual carefully before using the
appliance.
uThe intended use is described in this manual. The use of
any accessory or attachment or the performance of any
operation with this appliance other than those
recommended in this instruction manual may present a risk
of personal injury.
uRetain this manual for future reference.
uDo not use the appliance to pick up liquids or any materials
that could catch fire.
uDo not use the appliance near water.
uDo not immerse the appliance in water.
uNever pull the charger lead to discon-nect the charger
from the socket. Keep the charger lead away from heat, oil
and sharp edges.
uThis appliance can be used by chil-dren aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appli-ance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
uDo not use the appliance if any part is damaged or
defective.
uHave any damaged or defective parts repaired or replaced
by an authorized repair agent.
uRegularly check the charger lead for damage. Replace the
charger if the lead is damaged or defective.
uNever attempt to remove or replace any parts other than
those specified in this manual.
Additional safety instructions
After use
uUnplug the charger before cleaning the charger or charg-
ing base.
uWhen not in use, the appliance should be stored in a dry
place.
uChildren should not have access to stored appliances.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
uInjuries caused by touching any rotating/moving parts.
uInjuries caused when changing any parts, blades or ac-
cessories.
uInjuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
breaks.
uImpairment of hearing.
uHealth hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
Batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not expose the battery to heat.
uDo not store in locations where the temperature may
exceed 40°C.
uCharge only at ambient temperatures between 10°C and
40°C.
u
u
Charge only using the charger provided with the appli-
ance/tool. Using the wrong charger could result in an
electric shock or overheating of the battery.
When disposing of batteries, follow the instructions given

5
ENGLISH
(Original instructions)
Warning!
damage to property. In case of skin contact, immediately rinse
with water. If redness, pain or irritation occurs seek medical
attention. In case of eye contact, rinse immediately with clean
water and seek medical attention.
Chargers
check that the mains voltage corresponds to the voltage on
the rating plate.
Warning! Never attempt to replace the charger unit with a
regular mains plug.
uUse your Black & Decker charger only to charge the bat-
tery in the appliance/tool with which it was supplied. Other
batteries could burst, causing personal injury and damage.
uNever attempt to charge nonrechargeable batteries.
uIf the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
uThe appliance/tool/battery must be placed in a well venti-
lated area when charging.
Electrical safety
check that the mains voltage corresponds to the voltage on
the rating plate. Never attempt to replace the charger unit with
a regular mains plug.
Symbols on the charger
Read all of this manual carefully before using the
appliance.
#This tool is double insulated; therefore no earth wire is required. Always check that the power supply
corresponds to the voltage on the rating plate.
wShort circuit proof safety isolating transformer. The mains supply is electrically separated from the
transformer output.
xThe charger automatically shuts off if the ambient temperature becomes too high. As a consequence
the charger will be inoperable. The charging base
must be disconnected from the mains supply and
taken to an authorised service centre for repair.
$The charging base is intended for indoor use only.
in the section "Protecting the environment".
uDo not damage/deform the battery pack either by puncture
uDo not charge damaged batteries.
uUnder extreme conditions, battery leakage may occur.
When you notice liquid on the batteries carefully wipe the
liquid off using a cloth. Avoid skin contact.
uIn case of skin or eye contact, follow the instructions
below.
Features
This tool includes some or all of the following features.
1. On/off switch
2. Bowl release button
3. Charging indicator
4. Charging socket
5. Dust bowl
6. Nozzle
7. Extention tubes
8. Floor head
Fig. A
9.
10. Filter
Installation
The product can be attached to a wall to provide a convenient
storage and charging point for the appliance.
suitable for the wall type and is appropriate to the weight of
the appliance.
uMark the location of the screw holes (within reach of an
electrical outlet for chargeing the vac while it is on the wall
bracket).
uInsert the charger cord into the curved slot in the wall
mount bracket leaving approximately 8-9 inches excess.
uHang the appliance on the wall by placing the opening
on the base of the vac over the hooks in the wall mount
bracket.

6
ENGLISH
(Original instructions)
Use
u
24 hours.
Charging the battery (Fig. D)
uMake sure that the appliance is switched off. The battery
will not be charged with the on/off switch in the on posi-
tion.
uPlug the jack plug of the charger into the charging socket
(4) of the appliance.
uPlug in the charger. Switch on at the mains. The charging
indicator (3) will be lit.
uLeave the appliance to charge for at least 16 hours.
While charging, the charger may become warm. This is
normal and does not indicate a problem. The appliance can
indicator (3) will be lit as long as the appliance is connected to
the plugged-in charger.
Warning! Do not charge the battery at ambient temperatures
below 4 °C or above 40 °C.
uTo switch the appliance on, slide the on/off switch (1)
forward to position 1.
uTo switch the appliance off, slide the on/off switch (1) back
to position 0.
the bristles on the brush.
uLower the bristles for cleaning carpets or rugs.
u
tile or marble.
Optimising the suction force
cleared regularly during use.
Emptying and cleaning the product.
(DV9610F-XE)
Pre-filter (fig. I) (DV7210F-XE)
uPress the release latchs (12) and pull the nozzle (6)
uTwist the pre-filter (15) in a clockwise direction and lift from
the filter (13).
The Filter and pre- filter can be separated to allow better
cleaning.
straight off.
uEmpty the contents of the bowl.
uTo replace the nozzle, place it back onto the handle until it
Assembly
These models may be supplied with some of the following
accessories:
uExtention tubes (7).
uFloor head (8).
uFit the extention tubes (7) together.
u
tubes.
uFit the narrow end of the extention tubes (7) into the appli-
ance.
uAlternatively, to use as a hand-held cleaner with brush on
appliance.
Warning!
regularly.
uPress the release latch (2) and pull the dust bowl (5)
straight off.
u
assembly (13) to empty the contents of the bowl.
uTo replace the dust bowl, place it back onto the handle
Warning! -
u
u
u
for more thorough cleaning.
u
water.
u
-
ever worn or damaged.
dealer:
For DV7210F-XE use filter part number VF110-XJ.
For DV9610F-XE use filter part number VF110FC-XJ.

7
ENGLISH
(Original instructions)
Protecting the environment
ZSeparate collection. This product must not be disposed of with normal household waste.
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
zSeparate collection of used products and packaging allows materials to be recycled and used again.
Re-use of recycled materials helps prevent environ-
mental pollution and reduces the demand for raw
materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
the address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Battery
ZIf you want to dispose of the product yourself, the battery must be removed as described below and
disposed of in accordance with local regulations.
uPreferably discharge the battery by operating the appli-
ance until the motor stops.
uPress the release button (2) and remove the dust bowl (5).
uRemove the seven screws holding the body of the appli-
ance together.
uLift the housing cover away from the assembly.
uDetach all lead connections from the battery pack.
uRemove battery pack.
uPlace the battery in a suitable packaging to ensure that
the terminals cannot be short-circuited.
uTake the battery to your service agent or to a local recy-
cling station.
Maintenance
Your Black & Decker corded/cordless appliance/tool has been
designed to operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on corded/
cordless power tools:
uSwitch off and unplug the appliance/tool.
uOr switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
uOr run the battery down completely if it is integral and then
switch off.
uUnplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
uRegularly clean the ventilation slots in your appliance/tool/
charger using a soft brush or dry cloth.
uRegularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent
indicated in this manual. Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-
sales service and contacts are available on the Internet at:
www.2helpU.com
Please visit our website www.blackanddecker.com.au to register
your new Black & Decker product and to be kept up to date
on new products and special offers. Further information on the
Black & Decker brand and our range of products is available
at www.blackanddecker.com.au

8
ENGLISH
(Original instructions)
Australia & New Zealand
Stanley Black & Decker
82 Taryn Drive, Epping, VIC 3076 Australia
Tel.[phone] (Aust) or Tel. [phone] (NZ)
90586851 06/12
Technical data
DV9610F-XE
(H1)
DV7210F-XE
(H1)
Voltage Vdc
9.6 7.2
Battery Type
NICD NICD
Weight kg
1.58 1.13
Charger
SA140020D SA110020D
Input voltage Vac
240 240
Output voltage Vac
14 11
Current mA
200 200
Approximate
charge time
h
16 16
Weight kg 0.22 0.17
