Black Box KVT317A-T User manual

For server control that gets to the point,
choose this ServView with a touch screen LCD.
For server control that gets to the point,
choose this ServView with a touch screen LCD.
ServView KVM Drawer with Touch Screen
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com

2 of 2
FEATURES
• Reduces clutter in your server room.
• Mounts in a standard 19" cabinet.
• All mounting brackets included.
• Models available with 17" or 19"
LCD monitor.
• Integrated PS/2 trackball mouse
and a full-size PS/2 keyboard.
• Front-access lock secures the monitor,
keyboard, and mouse.
• Full range of on-screen controls.
• Maximum resolution of 1280 x 1024.
• Connects to a ServSwitch with
included 3-in-1 composite KVM cable.
OVERVIEW
The ServView KVM Drawer with Touch Screen features
an integrated PS/2®trackball mouse, a full-size PS/2 keyboard,
plus a 17" or 19" LCD monitor. For security, it includes a front-
access lock for the monitor and keyboard and mouse.
Using the ServView™is easy. Just slide out the drawer
when you have to make an adjustment to your servers;
push the drawer in when you’re done.
The monitor features an on-screen display (OSD). OSD
controls are included for brightness, contrast, color, clock,
horizontal and vertical positioning, phase, scaling, auto
configuration, input select, multi-window, clear EEPROM,
and OSD adjust.
The ServView KVM Drawer with Touch Screen also has
on-screen menus that support seven languages—use it in
data centers just about anywhere!
Included mounting brackets adjust from 15.4" to 25.6"
(39.1 to 65 cm) (front-to-rear 19" mounts). The ServView
KVM Drawer with Touch Screen also includes a 12-VDC power
adapter with cord as well as an integrated 3-in-1 KVM cable
to connect it to a ServSwitch™.
1/29/2007
#26568
724-746-5500 blackbox.com
Item Code
ServView KVM Drawer with Touch Screen
17" LCD KVT317A-T
19" LCD KVT319A-T
✦ (1) ServView KVM Drawer with Touch Screen
and 17" or 19" LCD
✦ (1) touch screen driver CD
✦ (1) power adapter
✦ (1) power cord
✦ (1) monitor support bracket
✦ (1) set of mounting brackets
✦ (4) fasteners for mounting brackets
✦ (2) keys for front-access lock
✦ (1) three-to-one ServView KVM cable, 6-ft. (1.8-m)
✦ (1) user’s manual
WHAT‘S INCLUDED
TECH SPECS
Colors — KVT317A-T: 16.2 million;
KVT319A-T: 16.7 million
Contrast Ratio — 700:1
Display Area — KVT317A-T: 10.6"H x 13.3"W (26.9 x 33.8 cm);
KVT319A-T: 11.9"H x 14.8"W (30.2 x 37.6 cm)
Connectors — Video input: (1) HD15 F
Power — 12-VDC adapter, VESA DPMS power management
Size — KVT317A-T: 1.75"H (1U) x 17.4"W x 25.6"D
(4.4 x 44.2 x 65 cm);
KVT319A-T: 2.6"H x 17.4"W x 26.3"D (6.6 x 44.2 x 66.8 cm)
