Black Box AC425A User manual

MARCH 2000
AC425A
AC426A
S-Video Breakout BNC or RCA
CUSTOMER SUPPORT INFORMATION
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
YC
RCA
Breakout
YC
BNC
Breakout

1
S-VIDEO BREAKOUT BNC OR RCA
TRADEMARKS USED IN THIS MANUAL
RCA®is a registered trademark of Verizon
Communications.
Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owners.
Contents
1. Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Typical Application. . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2
S-VIDEO BREAKOUT BNC OR RCA
1. Specifications
Connectors — AC425A: (2) 75-ohm BNC,
(1) 4-pin mini-DIN female;
AC426A: (2) gold RCA®,
(1) 4-pin mini-DIN female
Size — 0.5"H x 1.4"W x 1.9"D (1.3 x 3.6 x 4.8 cm)
Weight (for two units) — 1 lb. (0.5 kg)

3
S-VIDEO BREAKOUT BNC OR RCA
2. Introduction
2.1 Description
S-Video is a form of video found on most consumer-
grade VCRs, camcorders, and televisions. It is also a
video output on some PC video cards. S-Video is made
up of the Luminance component (also known as “Y”)
and the Chrominance component (also known as “C”).
S-Video can normally be run only over 50 feet or so of
S-Video Cable before the signal degrades so badly that
it’s of little use. To run S-Video over a longer distance
(as is common), you can put the components that make
up S-Video on two separate co-axial cables. To do this,
use the S-Video Breakout, a passive bi-directional
breakout device. Two models are available: The BNC
model lets you run your S-Video signal from one 4-pin
female mini-DIN connector to two 75-ohm BNC
connectors. The RCA model lets you run your S-Video
signal from one 4-pin female mini-DIN connector to
two gold RCA connectors.

4
S-VIDEO BREAKOUT BNC OR RCA
2.2 Features
• Connectors are encased in epoxy, so cables are not
subject to flexing.
• Perfect for presentation and home-theater systems.
• Smaller, lighter, and more rugged than standard
breakouts.
• Waterproof.
2.3 Typical Application
Figure 2-1. Typical Application.
Camera S-Video Breakout BNC
TV or Composite Monitor
S-Video Cable

5
S-VIDEO BREAKOUT BNC OR RCA
3. Installation
NOTE
You must use two S-Video Breakouts to complete
installation (one at the S-Video source and one a
S-Video termination).
1. Connect your S-Video source’s output (VCR,
camcorder, distribution amplifier, etc.) to the
Breakout’s 4-pin female mini-DIN input.
2. Connect one coaxial cable to each output (the
connector type is determined by the breakout you
have). It is helpful to mark the cables as “Y” and
“C” respectively.
3. At the terminating end of the cable run, connect
the “Y” cable to the “Y” input connector and the
“C” cable to the “C” input connector.
4. Finally, connect an S-Video cable to the 4-pin
female mini-DIN.

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
© Copyright 2000. Black Box Corporation. All rights reserved.
