Black Box LGC5600A User manual

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
USER MANUAL
LGC5600A, LGC5700A
GIGABIT ENET
POE++ MEDIA
CONVERTER

2
TABLE OF CONTENTS
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
1. 8 7 7. 8 7 7. 2 26 9 BLACKBOX.COM
CONTENTS
1. SPECIFICATIONS........................................................................................................................................................................... 3
1.1 IEEE ............................................................................................................................................................................................... 3
1.2 LGC5600A MEDIA CONVERTER ................................................................................................................................................. 3
1.3 LGC5700A INDUSTRIAL MEDIA CONVERTER .......................................................................................................................... 4
2. OVERVIEW...................................................................................................................................................................................... 5
2.1 INTRODUCTION........................................................................................................................................................................... 5
2.2 INSTALLATION PROCEDURE OVERVIEW ................................................................................................................................. 6
3. INSTALLATION .............................................................................................................................................................................. 7
Step 1: Configure DIP Switches ....................................................................................................................................................................7
Step 2: Apply Power .....................................................................................................................................................................................10
Step 3: Connect Cables................................................................................................................................................................................12
Step 4: Verify Operation ...............................................................................................................................................................................12
A.1 FCC STATEMENT ...................................................................................................................................................................... 14
A.2 NOM STATEMENT.................................................................................................................................................................... 15
B.1 DISCLAIMER.............................................................................................................................................................................. 16
B.2 TRADEMARKS USED IN THIS MANUAL.................................................................................................................................. 16

3
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 1: SPECIFICATIONS
Description LGC5600A
Gigabit Media Converter with 802.3bt 60W, AC power, Commercial temperature range
Standard Compliances
IEEE 802.3,
IEEE 802.3af (15.40 watts max), IEEE 802.3at (30 watts max),
IEEE 802.3bt (60 watts max)
PoE++ Supported Modes IEEE Alternate A (Alt A) and 4-Pair
Regulatory Compliances UL, CE, FCC Class A, RoHS, WEEE, REACH
Frame Size Up to 10,240 bytes
AC Power Requirements 100 to 240 VAC/50 to 60 Hz
0.62 A at 120 VAC (typical)
Dimensions 1.0" H x 4.5" W x 6.0" D (2.5 x 11.4 x 15.2 cm)
Weight Module Only: 1.1 lb. (0.5 kg)
Module w/Adapter: 2.8 lb. (1.3 kg)
Operating Temperature Commercial: 32 to 122° F (0 to 50° C)
Storage: -40 to +176° F (-40 to +80° C)
Humidity 5 to 95% (non-condensing)
Altitude -328 to +13,123 ft. (-100 to +4,000 m)
MTBF (hours) Module Only: 474,000
AC Adapter: 100,000
1. SPECIFICATIONS
1.1 IEEE
1.2 LGC5600A MEDIA CONVERTER
IEEE SPECIFICATION
Description 802.3af PoE 802.3at PoE+ 802.3.bt PoE++ Type 3
Power available at PD 12.95 watts 25.5 watts 51 watts
Max power delivered by PSE 15.4 watts 30.0 watts 60 watts
Voltage range at PSE 44.0 to 57.0 VDC 50.0 to 57.0 VDC 50.0 to 57.0 VDC
Voltage range at PD 37.0 to 57.0 VDC 42.5 to 57.0 VDC 42.5 to 57.0 VDC

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 1: SPECIFICATIONS
1.3 LGC5700A INDUSTRIAL MEDIA CONVERTER
Description LGC5700A
Gigabit Media Converter with 802.3bt 60W, DC power, Industrial temperature range
Standard Compliances
IEEE 802.3,
IEEE 802.3af (15.40 watts max), IEEE 802.3at (30 watts max),
IEEE 802.3bt (60 watts max)
PoE++ Supported Modes IEEE Alternate A (Alt A) and 4 Pair
Regulatory Compliances UL, CE, FCC Class A, RoHS, WEEE, REACH
Frame Size Up to 10,240 bytes
DC Power Requirements
±44 to ±57 VDC;
1.16 A at 56 VDC
3-pin terminal (isolated)
Dimensions 1.0" H x 4.5" W x 6.0" D (2.5 x 11.4 x 15.2 cm)
Weight 1.1 lb. (0.5 kg)
Operating Temperature Industrial: -40 to +167° F (-40 to +75° C)
Storage: -40 to +176° F (-40 to +80° C)
Humidity 5 to 95% (non-condensing)
Altitude -328 to +13,123 ft. (-100 to +4,000 m)
MTBF (hours) 474,000

5
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
2. OVERVIEW
2.1 INTRODUCTION
This User Manual describes the functions of the Gigabit 802.3bt PoE++ and the Gigabit Industrial 802.3bt PoE++ media converters.
The LGC5600A and LGC5700A are media converters that convert 10/100/1000BASE-T RJ-45 to 1000BASE-X or 100BASE-X ber and
support Power-over-Ethernet (60 W PoE++).
GIGABIT 802.3BT POE++ MEDIA CONVERTER
Equipment that provides DC power over twisted-pair cable is called Power Sourcing Equipment (PSE). Equipment that is powered over
twisted-pair cable is called a Powered Device (PD).
The LGC5600A and LGC5700A are PSE equipment supporting IEEE 802.3af PoE, IEEE 802.3at PoE+, and IEEE 802.3bt PoE++ 60 W
on the RJ-45 port.
MEDIA CONVERTER DESCRIPTIONS
Model Number Description
LGC5600A
Gigabit Media Converter with (1) SFP and (1) 10/100/1000 RJ-45,
External AC Adapter, 100-240 VAC, with U.S. Power Cord,
Commercial Temperature: 32 to 122° F (0 to 50°C)
LGC5700A
Gigabit Media Converter with (1) SFP and (1) 10/100/1000 RJ-45,
Direct DC input, with 3-pin DC Terminal Connector,
Industrial Temperature -40 to 167° F (-40 to 75°C)

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 2: OVERVIEW
COMPATIBLE FIBER SFPS
PART NUMBER DESCRIPTION DISTANCE
100-MBPS CONNECTIONS
LFP401 SFP, 155-Mbps, Extreme Temperature, 850 nm Multimode Fiber, 2 km, LC 2 km
LFP402 SFP, 155-Mbps, Extreme Temperature, 1310 nm Multimode Fiber, 2 km, LC 2 km
LFP403 SFP, 155-Mbps, Extreme Temperature, 1310 nm Singlemode Fiber, 30 km, LC 30 km
1000-MBPS CONNECTIONS
LFP411 SFP, 1.25-Gbps, Extreme Temperature, 850 nm Multimode Fiber, 550 m, LC 550 m
LPF412 SFP, 1.25-Gbps, Extreme Temperature, 1310 nm Multimode Fiber, 2 km, LC 2 km
LFP413 SFP, 1.25-Gbps, Extreme Temperature, 1310 nm Singlemode Fiber, 10 km, LC 10 km
LFP414 SFP, 1.25-Gbps, Extreme Temperature, 1310 nm Singlemode Fiber, 40 km, LC 40 km
LFP420 SFP, 1.25-Gbps, Extreme Temperature, 1550/1310 nm Singlemode Simplex Fiber, 10 km, LC 10 km
LFP421 SFP, 1.25-Gbps, Extreme Temperature, 1310/1550 nm Singlemode Simplex Fiber, 10 km, LC 10 km
LFP441 SFP, 1.25-Gbps, 850nm Multimode Fiber, 550 m, LC 550 m
LFP442 SFP, 1.25-Gbps, 1310nm Singlemode Fiber, 20 km, LC 20 km
NOTES:
1. All Black Box SFPs feature Extended Diagnostics (excluding LFP441 and LFP442).
2. Black Box Media Converters also support generic SFPs.
2.2 INSTALLATION PROCEDURE OVERVIEW
1. Congure DIP switches
2. Apply Power
3. Connect Cables
4. Verify Operation

7
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 3: INSTALLATION
3. INSTALLATION
STEP 1: CONFIGURE DIP SWITCHES
DIP switches are located on the side of the module. The DIP switches are used to congure ports, link modes, and PoE++/PSE options.
DIP SWITCH BANK LOCATIONS
The table below provides a description of each DIP switch position and function.
DIP SWITCH DEFINITIONS
Switch DOWN UP Function
1Auto 100 SFP Port
Fiber Speed
2 N/A N/A N/A
3 AN MAN RJ-45 Port
Auto/Manual
4 100 10 RJ-45 Port Speed
(Only in MAN mode)
5FDX HDX RJ-45 Port Duplex
(Only in MAN mode)
6 Off On Pause Capability
7 On Off RJ-45 Port
PSE Power
8 N/A N/A N/A
9 Norm Force RJ-45 Port
PSE Power Override
10 N/A N/A N/A
11 N/A N/A N/A
12 See DIP switch
Description
Link Mode Selection
13 Link Mode Selection
14 Off P1 Lk Loss PSE Reset
15 N/A N/A N/A
16 N/A N/A N/A

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 3: INSTALLATION
SW1 - Fiber Speed: Auto/100
This DIP switch congures the speed of the transceiver installed in the SFP receptacle. If this DIP switch is in the DOWN “Auto”
(default) position, the port will automatically detect the data rate of the transceiver installed and operate at 100 Mbps or 1000 Mbps
accordingly.
If the automatic detection fails to detect the speed of the installed SFP, then the speed will be set to 1000 Mbps.
If this DIP switch is in the UP “100” position, a 100 Mbps capable transceiver must be installed in the SFP receptacle.
When an RJ-45 transceiver is installed in a SFP receptacle, setting this DIP switch to UP “100” position enables the port to operate
at 100 Mbps.
SW2 - Reserved
This DIP switch must be left in the DOWN (default) position.
SW3, SW4 and SW5 - RJ-45 Conguration
RJ-45 PORT CONFIGURATION MATRIX
SW3
RJ-45
AN/Man
SW4
RJ-45
100/10
SW5
RJ-45
FDX/HDX
RJ-45 Mode of Operation
AN
(DOWN)
10 or 100
(N/A)
FDX or HDX
(N/A)
The RJ-45 port is set to auto-negotiation with the following modes advertised:
1000FDX, 1000HDX, 100FDX, 100HDX, 10FDX, 10HDX
MAN
(UP)
100
(DOWN)
FDX
(DOWN) The RJ-45 port is set to manual negotiation and is forced to 100FDX
MAN
(UP)
100
(DOWN)
HDX
(UP) The RJ-45 port is set to manual negotiation and is forced to 100HDX
MAN
(UP)
10
(UP)
FDX
(DOWN) The RJ-45 port is set to manual negotiation and is forced to 10FDX
MAN
(UP)
10
(UP)
HDX
(UP) The RJ-45 port is set to manual negotiation and is forced to 10HDX
SW6 - Pause: Off/On
In auto-negotiation mode, setting this DIP switch to the UP “On” position allows the module to advertise Symmetrical and
Asymmetrical Pause capability. In auto-negotiation mode, setting the DIP switch to the DOWN “Off” (default) position allows the
module to advertise no Pause capability. In the manual mode, this DIP switch determines the Pause behavior.
SW7 - Power Sourcing Function: On/Off
The RJ-45 port automatically detects the attached PD and provides the PD with the necessary power.
This DIP switch controls the power sourcing function for the RJ-45 port. When this DIP switch in the DOWN “On” (default) position,
the power sourcing function is enabled. When the DIP switch is in the UP “Off” position, the power sourcing function is disabled.
SW8 - Reserved
This DIP switch must be left in the DOWN (default) position.

9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 3: INSTALLATION
SW9 - PSE Power Override: Norm/Force
This DIP switch allows the PoE++ power to be forced ON when connected to a PD with non-standard detection characteristics.
When this DIP switch is in the DOWN “Norm” (default) position, the RJ-45 port will automatically perform the detection, classication,
and powering functions for the attached PD. When this DIP switch is in the UP “Force” position, a maximum of 60 watts of power will be
available to the PD.
SW10 and SW11 - Reserved
These DIP switches must be left in the DOWN (default) position.
SW12 and SW13 - Link Modes
The LGC5600A and LGC5700A feature Link Segment and Asymmetrical Link Propagate fault detection modes.
Link Segment
In Link Segment mode, all ports operate independently. A loss of a receive link signal will only affect the port detecting the loss
of signal. The other port will continue to generate a link signal. A loss of link on the RJ-45 port will only affect the RJ-45 port,
and the ber port will remain unaffected.
Asymmetrical Link Propagate
In Asymmetrical Link Propagate mode, faults are propagated based on the port notation. Port 1 (ber) to Port 2 (RJ-45) notation
indicates the direction the loss of link signal will propagate. A loss of receive link on the Fiber Port 1 causes the RJ-45 Port 2
to drop its link due to the propagated state (Port 1 to Port 2). The loss of link on the RJ-45 Port 2 does not cause the loss of link
to propagate. The loss only propagates in the Port 1 to Port 2 direction.
NOTE: A loss of link or loss of signal is when the optical receiver on the media converter can no longer detect the presence
of an optic signal.
LINK MODES
SW12 SW13 Function
DOWN DOWN Link Segment (LS)
UP DOWN Asymmetrical Link Propagate Port 1 (ber) to Port 2 (RJ-45)
DOWN UP Asymmetrical Link Propagate Port 2 (RJ-45) to Port 1 (ber)
UP UP Invalid Conguration
SW14 - PSE Reset: Off/P1 Lk Loss
The module can be congured to reset the PoE++ output power for 2 seconds after a loss of receive link on the ber port. This feature
is typically used to allow a PD to re-initialize after a failure on the incoming ber.
When this DIP switch is in the UP “P1 Lk Loss” position, the module will disable PoE++ output power for 2 seconds following a loss
of receive link on the ber port. When this DIP switch is in the DOWN “Off” (default) position, PoE++ output power does not reset
on a ber loss.
SW15 and SW16 - Reserved
This DIP switch must be left in the DOWN (default) position.

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7.877. 2269
CHAPTER 3: INSTALLATION
STEP 2: APPLY POWER
AC Power for LGC5600A
To power the module using the AC/DC adapter, connect the DC plug at the end of the wire on the AC/DC adapter to the DC connector
on the module. Then connect the AC/DC adapter to the AC outlet. Conrm that the module has powered up properly by checking
the Power LED located on the front of the module.
Installation of the equipment should be such that the air ow in the front, back, side and top vents of the chassis are not compromised
or restricted.
Secure the grounding wire to the ground screw. See the gure below for the location of the grounding screw.
REAR VIEW OF THE LGC5600A WITH AC POWER CONNECTOR
NEVER ATTEMPT TO OPEN THE CHASSIS OR
SERVICE THE POWER SUPPLY. OPENING THE
CHASSIS MAY CAUSE SERIOUS INJURYOR DEATH.
THERE ARE NO USER REPLACEABLE OR
SERVICEABLE PARTS IN THIS UNIT.
WARNING!!!
DC Power for LGC5700A
A power source should be available within 5 ft. (1.5-m) of the module. The over-current protection for connection with centralized
DC shall be provided in the building installation, and shall be a UL listed circuit breaker rated 20 Amps, and installed per the National
Electrical Code, ANSI/NFPA-70.
The LGC5700A requires 50 to 57 VDC @ 1.16 Amp max rated power (see specication table). Appropriate overloading protection
should be provided on the DC power source outlets used.
WARNING: OnlyaDC power source that complies with
safety extra low voltage (SELV) requirements can be
connected to the DC-input power supply.
