Black Box LE1502A-R3 User manual

Instant media conversion without the expense
or hassle of installing external crossover cables.
Instant media conversion without the expense
or hassle of installing external crossover cables.
Crossover Media Converters • Economy Crossover Media Converters
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com

2 of 3
9/10/2007
#22392
724-746-5500 blackbox.com
FEATURES
• Uplink switch eliminates the need for
crossover cables.
• 100-Mbps models convert twisted pair
to single- or multimode fiber.
• 10-Mbps models convert twisted pair to
single- or multimode fiber or ThinNet.
• Comply fully with all Ethernet and Fast
Ethernet protocol and cabling standards.
• LEDs provide instant network and
diagnostic information.
Simply flip the uplink switch to
convert your twisted-pair, fiber,
and ThinNet media types.
OVERVIEW
Convert the 10- and 100-Mbps copper and fiber within
your network. Simply invest in Crossover Media Converters or
their Economy versions.
With these converters, you can flip a switch to convert
cable. The crossover feature is built-in, so the conversion takes
place automatically—and you don’t need to worry about the
expense or hassle of using external crossover cables.
Crossover Media Converters and Economy Crossover Media
Converters enable you to translate between twisted pair and
fiber and twisted pair and ThinNet. Models support
conversion from:
• 100-Mbps twisted pair to multimode fiber with ST®or
SC connectors. The LH1506A even connects 100-Mbps
twisted pair to multimode fiber with MT-RJ connectors;
• 100-Mbps twisted pair to single-mode fiber with SC
connectors. The LH1508A even enables long-haul links
of up to 40 kilometers (24.8 mi.);
• 10-Mbps twisted pair to single-mode fiber with ST
connectors.
• 10-Mbps ThinNet to twisted pair;
• 10-Mbps ThinNet to multimode fiber with ST connectors
or multimode fiber with ST connectors and link pass-
through;
The converters enable you to take advantage of the latest
Ethernet switch technology and improve your network’s
performance.
These media converters also save you the expense
of installing repeaters on every port, thus reducing overall
network operating costs.
The converters also include an external 110-VAC,
95–125-VAC, 230-VAC, or 200–250-VAC power supply that you
can plug into a 110- or 230-VAC wall socket or power strip.
Both the 10- and 100-Mbps models are small enough to
fit in the palm of your hand, so they take up very little space.
You can mount them easily in the available racks or you can
VELCRO®mount them.
Note that the Economy Crossover Media Converter does
not support autosensing half- or full-duplex operation,
however the 100-Mbps Crossover Media Converters
(LH1500A-ST-R3, LH1500A-SC-R3, LH1501A-R2) do support this
feature.
All the converters include a metal bracket for
wallmounting.
Crossover
Media Converter
UPLINK
RX
TX
12VDC ... 1AMP
Pwr
Jab
Link
Tx
Col
Rx
Col
Rx
Pol
Link
Jab
FIBER
TWISTED PAIR
Crossover
Media Converter
UPLINK
12VDC ... 1AMP
Col
Rx
Col
Rx
Pol
Link
Pwr
Jab
COAX
TWISTED PAIR
Uplink switch
LH1501A-R2
LE1502A-R3

3 of 3
9/10/2007
#22392
724-746-5500 blackbox.com
TECH SPECS
Compliance —
FCC Part 15, Class A: LH1500A-ST-R3, LH1500A-SC-R3, LH1501A-R2,
LE1501A-R2–LE1502A-R3, LE1505A–LE1506A;
FCC Part 15, Class B: LH1503A–LH1504A, LH1506A–LH1508A;
UL®1950: LH1501A-R2, LH1503A–LH1504A, LH1506A–LH1508A;
UL 1310: LE1501A-R2, LE1502A-R3, LE1505A–LE1506A;
CSA: LE1501A-R2, LE1502A-R3, LE1505A–LE1506A
Speed —
100 Mbps: LH1500A-ST-R3, LH1500A-SC-R3, LH1501A-R2,
LH1503A–LH1504A, LH1503AE–LH1504AE, LH1506A–LH1508A,
LH1507AE–LH1508AE;
10 Mbps: LE1501A-R2, LE1501AE-R2, LE1502A-R3, LE1502AE-R4,
LE1505A–LE1506A, LE1505AE
Connectors — LH1500A-SC-R3, LH1501A-R2, LH1503A, LH1503AE,
LH1507A–LH1508A, LH1507AE–LH1508AE: (1) RJ-45, (1) pair of SC;
LH1500A-ST-R3, LE1501A-R2, LE1501AE-R2, LE1505A–LE1506A,
LE1505AE, LH1504A, LH1504AE: (1) RJ-45, (1) pair of ST;
LE1502A-R3, LE1502AE-R4: (1) RJ-45, (1) BNC;
LH1506A: (1) RJ-45, (1) MT-RJ
Indicators — (3) LEDs: LH1500A-ST-R3, LH1500A-SC-R3, LH1501A-R2;
(5) LEDs: LE1501A-R2, LE1501AE-R2, LE1505A–LE1506A, LE1505AE;
(8) LEDs: LE1502A-R3, LE1502AE-R4;
(10) LEDs: LH1503A–LH1504A, LH1503AE–LH1504AE,
LH1506A–LH1508A, LH1507AE–LH1508AE
Operating Environment — Temperature: 32 to 120°F (0 to 49°C);
Humidity: 10 to 95%, noncondensing
Power — LH1500A-ST-R3, LH1500A-SC-R3, LH1501A-R2: 110-VAC,
60-Hz external power supply;
LE1501A-R2, LE1502A-R3, LE1505A–LE1506A, LH1503A–LH1504A,
LH1506A–LH1508A: 95–125-VAC, 60-Hz external power supply;
LE1501AE-R2, LE1502AE-R4, LE1505AE, LH1503AE–LH1504AE,
LH1507AE–LH1508AE: 200–250-VAC, 50-Hz external power supply
Size — LH1500A-ST-R3, LH1500A-SC-R3: 3"H x 3.5"W x 1"D
(7.6 x 8.9 x 2.5 cm);
LH1501A-R2: 0.9"H x 2.8"W x 3.6"D (2.3 x 7.1 x 9.1 cm);
LE1501A-R2, LE1501AE-R2, LE1502A-R3, LE1502AE-R4,
LE1505A–LE1506A, LE1505AE: 0.8"H x 2.1"W x 3"D
(2 x 5.3 x 7.6 cm);
LH1503A–LH1504A, LH1503AE–LH1504AE, LH1506A–LH1508A,
LH1507AE–LH1508AE: 3.5"H x 3"W x 1"D (8.9 x 7.6 x 2.5 cm)
Item Code
Crossover Media Converters
100-Mbps
100BASE-TX/Multimode ST LH1500A-ST-R3
100BASE-TX/Multimode SC LH1500A-SC-R3
100BASE-TX/Single-Mode SC LH1501A-R2
Economy Crossover Media Converters
10-Mbps
10BASE-T/ThinNet LE1502A-R3
230-VAC Version LE1502AE-R4
10BASE-T/Multimode ST LE1505A
230-VAC Version LE1505AE
10BASE-T/Multimode ST
w/Link Pass-Through LE1506A
10BASE-T/Single-Mode ST LE1501A-R2
230-VAC Version LE1501AE-R2
100-Mbps
100BASE-TX/Multimode ST LH1504A
230-VAC Version LH1504AE
100BASE-TX/Multimode SC LH1503A
230-VAC Version LH1503AE
100BASE-TX/Multimode MT-RJ LH1506A
100BASE-TX/Single-Mode SC LH1507A
230-VAC Version LH1507AE
100BASE-TX/Single-Mode, Long-Haul SC LH1508A
230-VAC Version LH1508AE
Rack for Crossover Media Converters RM1500
Rackmount Tray for Economy Crossover
Media Converters LE1505-RACK
Powered Rackmount Tray for Economy Crossover
Media Converters LH1505P-RACK
Spare Power Supplies
115-VAC PS1500
Crossover Media Converters and Economy Crossover
Media Converters:
✦Media converter
✦Bracket for rackmounting
✦User’s manual
WHAT‘S INCLUDED
LH1504A
