The Black Box MTU9XXX range of Fibre Converters provide a simple economic way of
converting from one type of transmission medium to another. Examples include:
Electrical signals on copper to optical signals on fibre, and vice-versa. Single-mode optical
fibre to multimode and vice-versa.
The MTU9XXX range of converters has been designed to be plug and go, conforming to
appropriate standards, physically very compact, and rack mountable in sets of 2 using a
dual face plate, or 18 units in a rack mount kit for large installations. MTU9XXX units often
enable substantial savings to be made in cable costs by utilising the cheapest effective cable
type without incurring the costs of additional router or switch interfaces. Black Box are
continually developing new models, so if the interface combination required is not listed in
this guide, please contact Black Box.
Where electrical signal cabling is connected to MTU9XXX models, do not connect to cabling
which would be required by BS6701 to be equipped with over-voltage protection. Electrical
signal ports should only be connected to SELV ports on other equipment in accordance with
EN60950 clause 2.3.
In order to ensure EMC compliance all electrical signal and data cables and connectors must
use a screened connector shell with a screened cable. The cable screen must be terminated
to the screened connector shell and not connected to any pins of the connector. Failure to
use the correct connector may compromise EMC compliance.
MTU9XXX units are a Class A product. In a domestic environment it may cause radio
interference in which case the user may be required to take adequate measures.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at its own expense.
1.1 About the MTU9XXX produ t range
1.2 Safety
1.3 Ele tromagneti Compatibility
1.4 EN55022 De laration
1.5 FCC De laration

Abeo/Opticon Fibre Converters
3
1.6 Regulatory Noti e
The MTU9XXX range are powered by an internal mains-fed power supply. The mains input
voltage is 100-250VAC, 50/400Hz. An alternative -48VDC power supply is available on all units
as a custom order item. The power consumption of each model in the range is shown below,
together with the current consumption over the operating voltage ranges..
Safety Instructions
The MTU9XXX mus be connec ed o mains safe y ear h for correc opera ion. The MTU9XXX
power supply should be connec ed o a supply socke ha is physically loca ed close o he
uni and is easily accessible.
SSaaffeeyy NNooeess::Excessive vol ages are presen inside he uni . There are no user serviceable
par s inside he uni , and he cover should no be removed by unqualified personnel. The uni
mus no be exposed o damp or condensing condi ions.
Model Watts Power
Consumption
Current Range mA
for 100-250 VAC
Current Range mA
for -40 to -72 VDC
MTU9009 3.5 35 - 15 100 - 50
MTU9010 4.5 45 - 20 125 - 65
MTU9011 4.5 45 - 20 125 - 65
MTU9200 6.0 60 - 25 200 - 100
MTU9210 6.0 60 - 25 200 - 100
MTU9220 6.0 60 - 25 200 - 100
MTU9230 6.0 60 - 25 200 - 100

Abeo/Opticon Fibre Converters
4
2. 1 MTU9XXX rear panels

Abeo/Opticon Fibre Converters
5
2.2 Unpa k and inspe t the equipment.
The carton should contain a single Black Box MTU9XXX model and a power cable. If there is
any visible damage, do not attempt to connect the device. Contact us for advice and
assistance. The rear panels of typical MTU9XXX units are shown on the previous page. Note
that the current rating shown on the rear panel label is the maximum current, which
corresponds to the lowest input voltage.
2.3 Optional ra kmounting pro edure
A Rackmounting kit may be used to mount two MTU9XXX units side by side in a 19” rack.
First remove the two rear panel screws securing each unit’s lid. Fasten the two MTU9XXX
units to the rack mount adaptor plate using the screws that you have removed, as
shown in the illustrations below.
Then secure the rack mounting plate complete with the two MTU9XXX units to the 19” rack
using the locating holes at the ends of the adaptor plate. The recessed twin unit rack will
accept either AC or DC MTU9XXX models.
If you wish to use the optional 18 unit mounting rack, instructions are provided with the
rack.

Abeo/Opticon Fibre Converters
6
2.4 Power up the MTU9XXX
2.5 Conne t the Customer and Network Ports
Pin Contact
1 Normally Closed
2 Normally Open
3 Common
4 Not Connected
5 Not Connected
6 Not Connected
7 Not Connected
8 Not Connected
2.6 Optionally onne t the alarm relay
The unit requires 100-250 VAC, 50-60 Hz AC supply. An alternative -48VDC power supply
is available for all models. See Section1 for further details on power consumption.
Plug an IEC mains cable into the back of the MTU9XXX and switch on. Check that the Alarm
LED on the rear panel is illuminated red or green, flashing or steady. If the LED is off, mains
power is not being supplied to the unit.
When the ports are connected, the Alarm LED should give a steady Green display. See
Section 3 for set-up information for the various models in the MTU9XXX range.
The unit requires 100-250 VAC, 50-60 Hz AC supply. An alternative -48VDC power supply
is available for all models. See Section1 for further details on power consumption.
The MTU9XXX offers an Alarm relay to provide an external warning of problems which may
arise. The interface is presented on an R 45 connector, and offers both normally open and
normally closed contacts. Maximum contact rating is 1.5 Amp at 125 VDC. Normal is the
powered up, non-alarmed state. The connections are shown in the table below:

Abeo/Opticon Fibre Converters
7
2.7 Alarm LED Status
MT 9009 Fibre/Fibre
LED Status Indication
Off No mains power present
Red Steady SM Alarm
Red/Off Flashing Both MM and SM Alarms
Green/Off Flashing MM Alarms
Green Steady Status OK
MT 9010/9011
Fibre/BNC LED Status Indication
Off No mains power present
Red Steady BNC Alarm
Red/Off Flashing BNC and Fibre Alarms
Green/Off Flashing Fibre Alarm
Red/Green Flashing CMI errors
Green Steady Status OK
MT 9200/9210/9220
LED Status Indication
Off No mains power present
Red Steady E1 Alarm
Red/Off Flashing E1 and Fibre Alarms
Green/Off Flashing Fibre Alarms
Green Steady Status OK
MT 9230
LED Status Indication
Off No mains power present
Red Steady E3/DS-3 Alarm
Red/Off Flashing E3/DS-3 and Fibre Alarms
Green/Off Flashing Fibre Alarm
Green Steady Status OK

Abeo/Opticon Fibre Converters
8
3.1 MTU9200/9210/9220 set-up
The base panel bit-switches must be set for R 45 or BNC connection of the E1 line and to
enable the test loops which apply Outside Loop tests to both ports simultaneously.
The network is connected to the BNC connectors at the rear of the unit.
Note: The total maximum attenuation of each of the cables attached to the BNC (network)
port must not exceed 6dB when measured at 1 ⋅024 MHz. The frequency/attenuation
characteristic of the cables attached to this port shall follow a root frequency law.
3.2 Unbalan ed BNC E1 G.703 Network port
Cable lengths should be restricted to those defined below.
Pin Function
Tip Shield
Ring Shield
Cable Max Length (metres)
UR202 720
RG59U 600
BT2002 650
BT2003 680

Abeo/Opticon Fibre Converters
9
3.3 Balan ed RJ-45 E1 G.703 Network Port
Pin Function
1 Tx tip
2 Tx ring
3 Tx shield
4 Rx tip
5 Rx ring
6 Rx ring
7 Not connected
8 Not connected
3.3.1 Conne ting to a terminal devi e
A connecting cable from the network port to a terminal port such as a router or a PABX is
straight through. Connections are defined in the table below.
DS port
pin
DS port
function
Terminal
port pin
Terminal port
function
1 Tx tip 1 Rx tip
2 Tx ring 2 Rx ring
3 Tx shield 3 Rx shield
4 Rx tip 4 Tx tip
5 Rx ring 5 Tx ring
6 Rx shield 6 Tx shield
7 Not connected Not connected Not connected
8 Not connected Not connected Not connected

Abeo/Opticon Fibre Converters
10
3.3.2 Conne ting to a network devi e
A connection from the network port to a network device such as an E1 line or an NTU
requires a crossover cable. Connections are defined in the table below.
DS port
pin
DS port
function
Terminal
port pin
Terminal port
function
1 Tx tip 1 Rx tip
2 Tx ring 2 Rx ring
3 Tx shield 3 Rx shield
4 Rx tip 4 Tx tip
5 Rx ring 5 Tx ring
6 Rx shield 6 Tx shield
7 Not connected Not connected Not connected
8 Not connected Not connected Not connected
3.3.3 RJ-45 Conne tor layout
The diagram below shows both the plug and socket head on so that any connecting wires
are behind the connector. The connector numbering is shown.

Abeo/Opticon Fibre Converters
11
Cable lengths should be restricted to those defined below.
3.3.4 Cable lengths and types
Note: The total maximum attenuation of the cable attached to the network port must not
exceed 6dB when measured at 1 ⋅024 MHz. The frequency/attenuation characteristic of the
cables attached to the network port shall follow a root frequency law. This port type is
approved to CTR12, CTR13.
Cable Max Length (metres)
Belden 8132 (28 AWG) 175
Belden 9841 (24 AWG) 300

Abeo/Opticon Fibre Converters
12
3.4 MT 9009 set-up
MTU9009
MM-SM SH FIBRE MEDIA
CONVERTER (AC)
SM and MM Alarms
MM
3.5 MT 9230 set-up
SM
There are no bit-switches to be set on the MTU9009, so the base label is abbreviated
to basic product and serial number information together with LED status indication.
The base panel bit-switches must be set for E3 or DS-3 connection of the line and to enable
the test loops which apply Outside Loop tests to both ports simultaneously.

Abeo/Opticon Fibre Converters
13
3.6 nbalanced BNC E3/DS-3 G.703 Customer Port
The customer equipment is connected to the BNC connectors at the rear of the unit.
Pin Function
Tip Signal
Ring Shield
Cable lengths should be restricted to those defined below.
Cable E3 Max Length
(metres)
DS-3 Max Length
(metres)
UR202 180 155
RG59U 150 130
BT2002 160 140
BT2003 165 140
Note: The total maximum attenuation of each of the cables attached to the BNC (network)
port must not exceed 6dB when measured at 1 ⋅024 MHz. The frequency/attenuation
characteristic of the cables attached to this port shall follow a root frequency law.

Abeo/Opticon Fibre Converters
14
3.7 MT 9010/9011 set-up
There are no bit-switch settings for the unit’s normal operation. The switches are used to set
up Outside Loop tests for the unit. The User (port (STM1 BNC) and the Network port (STM
1 Fibre optical) can be selected separately (i.e. not at the same time) for test action.
The Outside loop test loops the incoming signal at the interface and transmits it back upon
itself to validate the line that feeds the port.
Two types of label may appear on a MTU9010/9011 unist. The bit-switch layout is different
for each type of unit. There are no other functional differences between the two types of
unit.

Abeo/Opticon Fibre Converters
15
4.1 MTU9200/9210/9220 Produ t Spe ifi ations
Item Description
E1 Interface
G.703 compliant, Sensitivity - 10dB. Line coding HDB3.
Bit rate: 2.048 Mbps +/- 50ppm
Interface types:
75 Ohm unbalanced coax (BNC) or
120 Ohm balanced R -45
itter Tolerance Per G.823.
Barrier EN 41003 compliant barrier provided on the E1 interface
Performance PD7024 (NTR4)
Diagnostics Loop Test initiated by the bit-switch
MTU9200 Fibre Interface
G.957, Dual SC Multimode 62.5/125 um
Transmit power: -14 to -19 dBm
Max Rx input power: -14 dBm
Receive sensitivity: -14 to -30 dBm
Optical loss budget: = -19 - (-30) = 11dB
MTU9210 Fibre Interface
G.957, Dual SC SH Single-mode 8/125 um (Short haul)
Transmit power: -8 to -15 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -31 dBm
Optical loss budget: = -15 - (-31) = 16dB
MTU9220 Fibre Interface
G.957, Dual SC LH Single-mode 8/125 um (Long haul)
Transmit power: 0 to -5 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -34 dBm
Optical loss budget: = -5 - (-34) = 29dB
Safety EN41003, EN50082
EMC EN55022, EN50082
Power Supply
100-250 VAC, 50-60Hz, 60mA to 25mA or
-40 to -72VDC, 200mA to 100mA
See Section 1 for detailed power consumption data
Dimensions 20.2(W) x 13.2(D) x 4.8(H) cm
Ambient Temperature 0oC to + 45oC
Storage Temperature -20oC to + 70oC
Relative Humidity 0% - 95% non condensing

Abeo/Opticon Fibre Converters
16
4.2 MTU9009 Produ t Spe ifi ations
Item Description
Customer Interface
G.957, Dual SC Multimode 62.5/125 um
Bit rate: up to 155Mbps
Transmit power: -14 to -19 dBm
Max Rx input power: -14 dBm
Receive sensitivity: -14 to -30 dBm
Optical loss budget: = -19 - (-30) = 11dB
MTU9009 Short Haul
Line Interface
G.957, Dual SC Single-mode 8/125 um)
Bit rate: up to 155Mbps
Transmit power: -8 to -15 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -31 dBm
Optical loss budget: = -15 - (-31) = 16dB
Safety EN41003, EN50082
EMC EN55022, EN50082
Power Supply
100-250 VAC, 50-60Hz, 35mA to 15mA or
-40 to -72VDC, 100mA to 50mA
See Section 1 for detailed power consumption data
Dimensions 20.2(W) x 13.2(D) x 4.8(H) cm
Ambient Temperature 0oC to + 45oC
Storage Temperature -20oC to + 70oC
Relative Humidity 0% - 95% non condensing

Abeo/Opticon Fibre Converters
17
4.3 MTU9230 Produ t Spe ifi ations
Item Description
STM-1 Electrical Interface Per G.823.
Barrier EN 41003 compliant barrier provided on the E1 interface
Performance PD7024 (NTR4)
Diagnostics Loop Test initiated by the bit-switch
MTU9200 Fibre Interface
G.957, Dual SC Multimode 62.5/125 um
Transmit power: -14 to -19 dBm
Max Rx input power: -14 dBm
Receive sensitivity: -14 to -30 dBm
Optical loss budget: = -19 - (-30) = 11dB
MTU9210 Fibre Interface
G.957, Dual SC SH Single-mode 8/125 um (Short haul)
Transmit power: -8 to -15 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -31 dBm
Optical loss budget: = -15 - (-31) = 16dB
MTU9220 Fibre Interface
G.957, Dual SC LH Single-mode 8/125 um (Long haul)
Transmit power: 0 to -5 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -34 dBm
Optical loss budget: = -5 - (-34) = 29dB
Safety EN41003, EN50082
EMC EN55022, EN50082
Power Supply
100-250 VAC, 50-400Hz, 60mA to 25mA or
-40 to -72VDC, 200mA to 100mA
See Section 1 for detailed power consumption data
Dimensions 20.2(W) x 13.2(D) x 4.8(H) cm
Ambient Temperature 0oC to + 45oC
Storage Temperature -20oC to + 70oC
Relative Humidity 0% - 95% non condensing

Abeo/Opticon Fibre Converters
18
Item Description
STM-1 Electrical Interface
G.703, 750 Ohm BNC, Line coding CMI,
Bit rate: 155.52Mbps +/- 15ppm
Barrier: Fully barriered per EN41003
MTU9010 Multimode
Line Interface
G.957, Dual SC Multimode 62.5/125 um
Bit rate: up to 155Mbps
Transmit power: -14 to -19 dBm
Max Rx input power: -14 dBm
Receive sensitivity: -14 to -30 dBm
Optical loss budget: = -19 - (-30) = 11dB
MTU9011 Short Haul
Line Interface
G.957, Dual SC Single-mode 8/125 um
Bit rate: up to 155Mbps
Transmit power: -8 to -15 dBm
Max Rx input power: -8 dBm
Receive sensitivity: -8 to -31 dBm
Optical loss budget: = -15 - (-31) = 16dB
Safety EN60950
EMC EN55022, EN50082
Power Supply
100-250 VAC, 50-60Hz, 45mA to 20mA or
-40 to -72VDC, 200mA to 100mA
See Section 1 for detailed power consumption data
Dimensions 20.2(W) x 13.2(D) x 4.8(H) cm
Ambient Temperature 0oC to + 45oC
Storage Temperature -20oC to + 70oC
Relative Humidity 0% - 95% non condensing
Barometric Pressure 86 kPa - 106 kPa
4.3 MTU9010/9011 Produ t Spe ifi ations
Disclaimer
Black Box Network Services (UK) Ltd makes no representations or warranties with respect to
the contents hereof and specifically dis-claims any implied warranties or merchantability or
fitness for any particular purpose. Further, BBNS (UK) Ltd reserves the right to revise this
publication and to make changes from time to time in the content hereof without obligation
of BBNS (UK) Ltd to notify any person of such revision or changes.
Trademarks
The Trademarks of other Corporations which may be used in this manual are hereby
acknowledged.

FREE tech support 24 hours a day, 7 days a week: Call
0118 965 6000
Address: Black Box Network Services (UK) Ltd., 464 Basingstoke Road, Reading, Berkshire, RG2 0BG
Web:www.blackbox.co.uk • E-mail: [email protected]
© Copyright 2007. Black Box Corporation. All rights reserved.
Customer Support Information:
