Black Box AC215A User manual

CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
MARCH 1998
AC215A
Advanced Video Scaler
FUNCTION SELECT
OUTPUT
FORMAT
640 X 480
852 X 480
800 X 600
832 X 624
1024 X 768
1280 X 1024
OUTPUT
RATE
60 Hz
75 Hz
INPUT
SOURCE
COMPOSITE
S-VIDEO
INPUT
FORMAT
NORMAL
PROCESS
BRIGHTNESS
CONTRAST
SATURATION
HUE
POSITION
HORIZONTAL
VERTICAL
LETTER
BOX
Advanced
Video Scaler

3
ADVANCED VIDEO SCALER
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
This unit is CE certified.

4
ADVANCED VIDEO SCALER
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El parato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.

5
ADVANCED VIDEO SCALER
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

6
ADVANCED VIDEO SCALER
TRADEMARKS
The trademarks mentioned in this manual are the sole property of their owners.

7
ADVANCED VIDEO SCALER
CONTENTS
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 What the Package Includes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Connecting the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Connecting Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Selecting the Output Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Processing the Video on the Output Display . . . . . . . . . . . . . . . . . . . 12
4.2 Positioning the Image on the Output Display . . . . . . . . . . . . . . . . . . 12
4.3 Special Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. Internal DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 Accessing the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2 S1 DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.3 S2 DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6. Output Timing Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Appendix A: Rear Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Appendix B: Listing of Native Resolutions . . . . . . . . . . . . . . . . . . . . . . . . . 20

8
ADVANCED VIDEO SCALER
1. Specifications
Controls — Contrast, brightness, color saturation, hue, horizontal
and vertical positioning
Input Decoding — 16-bit YUV with comb filter processing
Input Formats — Normal (4:3), Letterbox (16:9)
Input Types — Composite and S-video (Y/C), both terminating into 75 Ohms
Input Video Standards — NTSC, NTSC-Japan, PAL (B, D, G, H, I, M, N, N-3.58),
SECAM
Output Resolutions — 640 x 480, 800 x 600, 832 x 624, 852 x 480, 1024 x 768,
1280 x 1024 (60 Hz only)
Connectors — Input: (1) Composite: BNC female, S-video: (1) 4-pin mini-DIN
female; Output: (1) HD15F with standard VGA pinout, (5) BNC connectors
configurable as RGBHV, RGBS, or RGSB (RGB Sync on Green)
Power — 95-250 VAC, 47-Hz, autosensing external power supply
Size — 1.5”H x 7.3”W x 8”D (3.8 x 18.5 x 20.3 cm)
Weight — 3 lb. (1.4 kg), including power supply

9
ADVANCED VIDEO SCALER
2. Introduction
2.1 Description
The Advanced Video Scaler converts standard TV video from any composite or
S-video source to one of six computer resolutions. These six resolutions were
chosen to match the native resolution of almost any LCD, DLP, or plasma
projector or display available today. In addition, the Video Scaler uses advanced
motion compensation to eliminate the artifacts typically noticed when interlaced
TV video is de-interlaced.
2.2 What the Package Includes
Your Advanced Video Scaler package should include the following items. If any
of these items are missing or damaged, please contact Black Box at 724-746-5500.
• (1) Advanced Video Scaler unit
• (1) 12-ft. (3.6-m) S-Video Cable
• (1) 12-ft. (3.6-m) Composite BNC Video Cable male-to-male
• (1) BNC/RCA Adapter
• (1) Power Cord
• (1) Universal Power Supply
• This User Manual

10
ADVANCED VIDEO SCALER
3. Installation
Installing the Advanced Video Scaler consists of three easy steps: connecting the
power, connecting inputs and outputs, and selecting the desired output
parameters.
3.1 Connecting the Power
Connect the provided AC power cord to the power supply and connect the power
cord to an AC outlet. The power supply is auto-sensing, so it will automatically
adapt to your voltage anywhere in the world.
Connect the DC power plug from the power supply to the connector marked
POWER on the rear panel of the Advanced Video Scaler.
3.2 Connecting Inputs and Outputs
Connect a video source to either the Composite or S-Video input on the rear
panel.
Connect a computer monitor, projector, or display to either the BNC
connectors or the VGA compatible connector on the rear panel. Both outputs
may be connected at the same time to two different displays.
3.3 Selecting the Output Parameters
On the front panel of the Scaler, press the Function button to light the LED next
to Output Format. Use the Select button to select the desired output resolution.
NOTE
The resolution selected should match the native resolution of the
projector or display, not the highest resolution that the device will
support. An extensive listing of the native resolutions of various
projectors and displays starts on page 20.

11
ADVANCED VIDEO SCALER
Press the Function button to select Output Rate and use the Select button to set
the desired output refresh rate.
Press the Function button to select Input Source and use the Select button to
select either the Composite or S-Video video source.
Press the Function button to select Input Format. If your video source is in a
standard 4:3 aspect ratio that fills the entire screen of a normal video monitor,
then select Normal. If your video source has an active picture area that has a 16:9
aspect ratio (such as a letterbox movie on tape or DVD), and your output display
is also a 16:9 widescreen display, then select Letterbox.

12
ADVANCED VIDEO SCALER
4. Operation
The Advanced Video Scaler has many features to facilitate proper operation with
any projector or display. For a particular installation, you don’t need to adjust any
controls after the unit is installed. However, you can improve the picture quality by
processing the video as detailed below.
4.1 Processing the Video on the Output Display
Push the Function button to select Process on the front panel. Use Select to select
one of the four processing functions (Brightness, Contrast, Color Saturation, or
Hue). The + and - buttons on the right side of the front panel allow you to increase
or decrease the amount of processing for that function (for example, more or less
color saturation).
When you have reached the limit for that function, the corresponding LED will
flash. You may press the + and - buttons at the same time for two seconds to reset a
selected processing function to its nominal or default value.
4.2 Positioning the Image on the Output Display
You may also move the image on the output display left, right, up, or down. To do
so, press the Function button to select Position. Use Select to select either
Horizontal or Vertical positioning. Press the + or - buttons to move the image.
4.3 Special Key Functions
You can activate several functions by pressing a combination of keys
simultaneously:
• Key Panel Lockout: Press the Function and -buttons at the same time for two
seconds to lock out the key panel. All the LEDs will flash momentarily to
indicate that the key panel is locked.
• Key Panel Unlock: Press the Function and +buttons at the same time for two
seconds to unlock the key panel and allow normal operation. All the LEDs will
flash momentarily to indicate that the key panel is locked.
• System Reset: Press the Select button for three seconds to reset the unit and
return all settings to their factory defaults.

13
ADVANCED VIDEO SCALER
5. Internal DIP Switch Settings
Inside the Advanced Video Scaler are several DIP switches for installation setup
only that you do not need to access during normal operation. This section
describes how to access these switches and what they are used for.
5.1 Accessing the DIP Switches
Slide off the top cover by doing the following:
1. Remove all power and I/O connections to the unit.
2. Remove the two screws on the front panel.
3. Carefully pull off the front bezel and keypanel (which is attached to the main
circuit board by a ribbon cable), leaving the keypanel attached to the circuit
board.
4. Slide the top cover towards the front of the unit, exposing the circuit board
with the DIP switches on it.

14
ADVANCED VIDEO SCALER
5.2 S1 DIP Switch
The three-position DIP switch S1 is used to set the input video standard that the
Advanced Video Scaler will look for on its inputs. All video standards are based on
either 525 or 625 lines per frame. Most of the world is either NTSC-M or PAL-B
and the default setting should be adequate for almost all applications. However, if
the format of the video you are using is not either one of these, you can adjust the
DIP switch S1 as follows:
S1-1 S1-2 S1-3 525 lines detected 625 lines detected
ON* ON* ON* NTSC-M* PAL-B*
OFF ON ON NTSC-M PAL-B
ON OFF ON NTSC-J PAL-B
OFF OFF ON NTSC-M PAL-B
ON ON OFF PAL-M PAL-B
OFF ON OFF NTSC-M PAL-N/4.43
ON OFF OFF NTSC-M SECAM
OFF OFF OFF NTSC-M PAL-N/3.58
*Default settings.

15
ADVANCED VIDEO SCALER
NOTE
DO NOT change the five-position DIP switch S3. If it’s changed by
mistake, reset it to the following factory default settings:
S3-1 ON
S3-2 OFF
S3-3 OFF
S3-4 OFF
S3-5 OFF
5.3 S2 DIP Switch
DIP switch S2 is used to set the type of sync on the outputs. Vertical sync is always
present on the BNC connector labeled V. Separate horizontal and vertical syncs
are always present on the VGA Compatible connector. The BNC connector labeled
H/CS can output either horizontal sync or composite sync as follows:
S2-1 S2-2 Function of H/CS connector
ON EITHER Horizontal sync only
OFF OFF Composite sync with serrations
OFF ON Composite sync without serrations

16
ADVANCED VIDEO SCALER
Regardless of what is on the H/CS connector, composite sync may be added to
the Green video signal on both the Green BNC and the Green pin of the VGA
Compatible connector if composite sync (with or without serrations) is selected
above and S2-3 is set as follows:
S2-1 S2-2 S2-3 Sync added to Green?
EITHER OFF ON Yes, composite with serrations
EITHER ON ON Yes, composite without serrations
EITHER EITHER OFF No sync added to Green
NOTE
The factory default for this DIP switch is shown in the table below.
S2-1 S2-2 S2-3
OFF OFF OFF
Composite sync with serrations on H/CS connector. No sync on green.

17
ADVANCED VIDEO SCALER
6. Output Timing Specifications
The timing specifications for the six output resolutions follow VESA specifications
or Macintosh specifications where applicable. The 852 x 480 specification is based
on the Fujitsu 42” plasma display specification.
Resolution Refresh H (KHz) V (Hz)
640 x 480 60 31.48 59.96
640 x 480 75 37.51 75.03
852 x 480 60 31.73 59.98
852 x 480 75 38.07 71.97
800 x 600 60 37.89 60.33
800 x 600 75 46.89 75.02
832 x 624 60 39.29 60.07
832 x 624 75 49.19 75.10
1024 x 768 60 48.38 60.19
1024 x 768 75 60.04 75.05
1280 x 1024 60 64.00 60.04
NOTE
The Advanced Video Scaler does not support 1280 x 1024 at 75 Hz
refresh.

18
ADVANCED VIDEO SCALER
7. Troubleshooting
If you are experiencing: Then check this:
Nothing works or no Are any of the LEDs lit? Is the power supply
video output connected and plugged into the AC wall outlet?
Is the video source connected to the unit? Is it putting
out a video signal as viewed on a video monitor?
No video on outputs Is the VCR or video source in the proper mode to
(just a blue screen) output video as required?
Have you selected the proper input on the unit
(Composite or S-Video) for the desired source?
Is the source of the video ON?
There is video on the If you are using 5 BNC connections to the unit, try
output display but it appears reversing the H and V sync connectors.
out of sync.
Make sure the display is capable of supporting the
resolution you selected on the front of the unit. Try a
lower resolution.

19
ADVANCED VIDEO SCALER
Appendix A: Rear Connector
Pinouts
Power Center Outer +5 VDC in Ground
VGA Compatible Output 1 Red
(HD-15 Connector) 2 Green
3 Blue
4 N/C
5 Ground
6 Red Ground
7 Green Ground
8 Blue Ground
9 N/C
10 Ground
11 N/C
12 N/C
13 H-Sync Out
14 V-Sync Out
15 N/C
S-Video Input 1 Ground
2 Ground
3 Luminance
4 Chrominance

20
ADVANCED VIDEO SCALER
Appendix B: Native Resolutions of
Popular Projectors, Panels, and
Displays
Manufacturer Model Native Resolution Device Type
3M 6750 1024x768 LCD Panel
3M 6100 640x480 LCD Panel
3M 6400 640x480 LCD Panel
3M MP8030 640x480 LCD Projector
3M 6050 800x600 LCD Panel
3M 6650 800x600 LCD Panel
3M MP8630 800x600 LCD Projector
3M MP8650 800x600 LCD Projector
AmPro 5000 (Alice) 1280x1024 DLP Projector
AmPro 5000MX (Alice) 1280x1024 DLP Projector
AmPro LCD-100 640x480 LCD Projector
AmPro LCD-151 800x600 LCD Projector
Apollo Explorer II 1024x768 LCD Projector
Apollo IM-Q45A-D 1024x768 LCD Panel
Apollo IM-2.1 640x480 LCD Panel
Apollo Escort 800x600 LCD Projector
Apollo Express 800x600 LCD Projector
Apollo IM-2.1V 800x600 LCD Panel
Apollo IM-Q20 800x600 LCD Panel
Apollo IM-Q30 800x600 LCD Panel
Apollo IM-Q35 800x600 LCD Panel
Apollo Passport 800x600 LCD Projector
Apollo Synergy 800x600 LCD Projector
ASK 960 1024x768 LCD Projector
ASK 970 1024x768 LCD Projector
ASK 960-AS 1024x768 LCD Projector

21
ADVANCED VIDEO SCALER
Manufacturer Model Native Resolution Device Type
ASK Impression 960 1024x768 LCD Projector
ASK Impression 970 1024x768 LCD Projector
ASK Impact WSX 1280x1024 LCD Projection Panel
ASK 970-AS 640x480 LCD Projector
ASK Campus 300 640x480 LCD Panel
ASK 8300 800x600 DLP Projector
ASK 860-AC 800x600 LCD Projector
ASK 880-AS 800x600 LCD Projector
ASK A4 800x600 LCD Projector
Aurora S350 800x600 LCD Projector
Barco BarcoGraphics 9200 1024x768 LCD Projector
Barco BarcoGraphics 2100 1024x768 LCD Projector
Barco BarcoGraphics 8200 1024x768 LCD Projector
Barco BarcoReality 9200 1280x1024 LCD Projector
Barco BarcoData 3200 720x480 LCD Projector
Barco BarcoVision 3200 720x480 LCD Projector
Barco BarcoData 8200 756x556 LCD Projector
Barco BarcoData 9200 756x556 LCD Projector
Barco BarcoVision 8200 756x556 LCD Projector
Barco BarcoVision 9200 756x556 LCD Projector
Barco Barcodata 2100 800x600 LCD Projector
Boxlight 1701 1024x768 LCD Projection Panel
Boxlight 2700 1024x768 LCD Projector
Boxlight 2001 640x480 LCD Projector
Boxlight 2002 800x600 LCD Projector
Boxlight 2020 800x600 LCD Projector
Boxlight 3000 800x600 LCD Projector
Boxlight 3600 800x600 LCD Projector
Boxlight 3700 800x600 LCD Projector
Boxlight 4801 800x600 LCD Projector
Chisholm Databook 10/05 640x480 LCD Projection Panel
