BLACK DECKER BDCGG12U User manual

1
8
2
3 4
5
6
7
3
10
BDCGG12U
Bahasa Indonesia

23
3
ENGLISH
(Original instructions)
23
5
1
D
B
E
A10
7
6
34
11
C
Intended use
Your BLACK+DECKERTM BDCGG12U glue gun has been
designed for leisure and DIY activities in the home to join
materials together including paper, card and material. This
appliance is intended for consumer use only.
General appliance safety
warnings
Warning! When using mains
powered/cordless appliances,
basic safety precautions,
including the following, should always be
shock, personal injury and material
damage.
Read all of this manual carefully before
using the appliance, be familiar with
the controls and the proper use of the
appliance.
The intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
The term "appliance" in all of the warn-
ings listed below refers to your mains
operated (corded) appliance or battery
operated (cordless) appliance.
Save all warnings and instructions for
future reference.
Using your appliance
Always take care when using the
appliance.
Keep work area clean and well lit. Clut-
tered or dark areas invite accidents.
109
Do not expose the appliance to rain or
wet conditions. Water entering the ap-
pliance will increase the risk of electric
shock.
Do not immerse the appliance in water.
Only use the appliance in daylight or
Do not operate your appliance in
explosive atmospheres, such as in the
or dust.
The appliance is not to be used as a
toy.
Do not open body casing. There are
no user serviceable parts inside.
Disconnect the battery from the appli-
removing parts and before cleaning.
Appliance use and care
Before use, check the appliance for
damaged or defective parts.
Check for breakage of parts, damage
to switches and any other conditions
that may affect its operation.
Do not use the appliance if the switch
does not turn it on and off. Any appli-
ance that cannot be controlled with
the switch is dangerous and must be
repaired.
Disconnect the plug from the power
source and/or the battery pack from
the appliance before making any
adjustments, changing accessories,
or storing appliances. Such preventive
safety measures reduce the risk of
starting the appliance accidentally.
12

23
ENGLISH
Intended use
Your BLACK+DECKERTM BDCGG12U glue gun has been
designed for leisure and DIY activities in the home to join
materials together including paper, card and material. This
appliance is intended for consumer use only.
General appliance safety
warnings
Warning! When using mains
powered/cordless appliances,
basic safety precautions,
including the following, should always be
followed to reduce the risk of re, electric
shock, personal injury and material
damage.
 Read all of this manual carefully before
using the appliance, be familiar with
the controls and the proper use of the
appliance.
 The intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
The term “appliance” in all of the warnings
listed below refers to your mains operated
(corded) appliance or battery operated
(cordless) appliance.
 Save all warnings and instructions for
future reference.
Using your appliance
 Always take care when using the
appliance.
 Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
 Do not expose the appliance to rain
or wet conditions. Water entering the
appliance will increase the risk of
electric shock.
 Do not immerse the appliance in water.
 Only use the appliance in daylight or
good articial light.
 Do not operate your appliance in
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust.
 The appliance is not to be used as a toy.
 Do not open body casing. There are
no user serviceable parts inside.
 Disconnect the battery from the
appliance when not in use, before
tting or removing parts and before
cleaning.
Appliance use and care
 Before use, check the appliance for
damaged or defective parts.
Check for breakage of parts, damage
to switches and any other conditions
that may affect its operation.
 Do not use the appliance if the switch
does not turn it on and off. Any
appliance that cannot be controlled
with the switch is dangerous and must
be repaired.
 Disconnect the plug from the power
source and/or the battery pack from
the appliance before making any
adjustments, changing accessories,
or storing appliances. Such preventive
safety measures reduce the risk of
starting the appliance accidentally.
 Do not use the appliance if any part is
damaged or defective.
 Have any damaged or defective parts
repaired or replaced by an authorised
repair agent.

45
ENGLISH
 Never attempt to remove or replace
any parts other than those specied in
this manual.
After Use
 Switch off and remove the battery
before leaving the appliance unattended
and before changing, cleaning or
inspecting any parts of the appliance.
 When not in use, the appliance should
be stored in a dry, well ventilated place
out of the reach of children.
 Children should not have access to
stored appliances.
Service
 Have your appliance serviced by a
qualied repair person using only
identical replacement parts. This will
ensure that the safety of the appliance
is maintained.
Additional Safety instructions for
heat guns
The intended use is described in this
manual. The use of any accessory
or attachment or performance of any
operation with this appliance other than
those recommended in this instruction
manual can present a risk of personal
injury and/ or damage to property.
 A re may result if the appliance is not
used with care, therefore:
 be careful when using the appliance
in places where there are combustible
materials;.
 do not apply to the same place for a
long time;
 do not use in presence of an
explosive atmosphere;
 be aware that heat may be
conducted to combustible materials
that are out of sight;
 allow the appliance to cool down
before storage;
 do not leave the appliance
unattended when it is switched on.
 Do not touch the heated nozzle
of the Glue Gun. The operating
temperature of this appliance is
approximately 199 °C.
 Keep hands away from the heated
attachment and work area. Heat may
be conducted through the work piece.
Use clamps or pliers to hold the work
piece.
 The heating element will begin to
heat up as soon as the appliance
is switched on. To avoid injury or
damage to property always assume
that the appliance is hot.
 Protect the work surface and
materials from heat damage. Heat
may be conducted through the work
piece. Use a heat resistant material to
protect the work surface.
 Glue sticks are not intended for
ingestion and should not come in
contact with food, etc.
If swallowed, seek medical attention.
Keep out of the reach of children.
 Before cleaning. Remove the battery
from the appliance and allow it to cool.
 Never attempt to force cool the
appliance after use by immersing
any part of it in water or any other
liquid. Allow the appliance to air cool
only.

45
ENGLISH
 Keep the appliance away from
all ammable material. Be aware
that this product may ignite material.
Where this is a concern, test a piece of
scrap material.
 Never leave the appliance unattended.
After use, remove the battery from the
appliance, allow it to cool and store
in a safe place out of the reach of
children.
 Fumes resulting from heating
materials for craft activities may
be hazardous. Always work in a well
ventilated area. Seek advice on the
materials being used.
 Never attempt to insert any material
other than recommended glue
sticks, sealer, or caulk sticks in
the glue gun. For example: Do not
attempt to melt crayons or candles.
 DO NOT use hot melt glue to take
the place of structural fasteners.
 The glue sticks used with this glue
gun will begin to soften at about
60 °C. Don’t use the glue on objects or
materials that are subjected to heat.
 Avoid accidental glue discharge.
Forcing glue sticks into an unheated
appliance may damage the appliance
or cause hot glue to be unexpectedly
expelled from nozzle when the
operating temperature is achieved.
Glue may discharge from a heated
appliance without pressure applied to
the trigger (1). Use a heat resistant
material to protect the work surface.
 This appliance is not a toy. Keep out
of the reach of children.
 The appliance is only to be used
with the USB power supply unit. The
appliance must only be supplied at
safety extra low voltage corresponding
to the marking on the appliance.
Safety of others
 This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
 Children should be supervised to
ensure that they do not play with the
appliance.
Labels on Appliance
The following symbols, along with the
date code, are shown on the appliance:
:
Warning! To reduce the risk of
injury, the user must read the
instruction manual.
Warning! Hot surface do not
touch.

67
ENGLISH
Additional safety instructions for
batteries and chargers (not
supplied)
Batteries
 Never attempt to open for any reason.
 Do not expose the battery to water.
 Do not store in locations where the
temperature may exceed 40 °C.
 Charge only at ambient temperatures
between 10 °C and 40 °C.
 Charge only using the charger
provided with the tool.
 When disposing of batteries, follow
the instructions given in the section
“Protecting the environment”.
p
Do not attempt to charge
damaged batteries.
Chargers
 Use your recommended
BLACK+DECKER charger only to
charge the battery in the appliance
with which it was supplied. Other
batteries could burst, causing personal
injury and damage.
 Never attempt to charge non-
rechargeable batteries.
 Have defective cords replaced
immediately.
 Do not expose the charger to water.
 Do not open the charger.
 Do not probe the charger.
$
The charger is intended for
indoor use only.
4
ENGLISH (Original instructions)
uThe charger must be placed in a well
ventilated area when charging.
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc. Even with the application of
the relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
rotating/moving parts.
uInjuries caused when changing any
parts, blades or accessories.
uInjuries caused by prolonged use of a
tool. When using any tool for
prolonged periods ensure you take
regular breaks.
uImpairment of hearing.
uHealth hazards caused by breathing
dust developed when using your
tool (example:- working with wood,
especially oak, beech and MDF.)
Symbols on the charger
The following symbols are shown on the
appliance along with the date code:
Warning! To reduce the risk of
injury, the user must read the
instruction manual.
Do not attempt to charge dam-
aged batteries.
The charger is intended for
indoor use only.
Electrical safety
#Your charger is double insu-
lated; therefore no earth wire is
required. Always check that the
mains voltage corresponds to the
voltage on the rating plate. Never
attempt to replace the charger
unit with a regular mains plug.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Features
This appliance includes some or all of the following features.
1. Charger
2. Charging indicator
Assembly
Warning! Before assembly, remove the battery from the
appliance/tool.
Fitting and removing the battery
uTo t the battery, line it up with the receptacle on the tool.
Slide the battery into the receptacle and push until the
battery snaps into place.
uTo remove the battery, push the battery release button
while at the same time pulling the battery out of the
receptacle.
Use
Warning! Let the tool work at its own pace. Do not overload.
Charging the battery
The battery needs to be charged before rst use and
whenever it fails to produce sufcient power on jobs that were
easily done before. The battery may become warm while
charging; this is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging
temperature: approx. 24 °C.
Note: The charger will not charge a battery if the cell
temperature is below approximately 10°C or above 40 °C.
The battery should be left in the charger and the
charger will begin to charge automatically when the cell
temperature warms up or cools down.
uTo charge the battery, insert it into the charger (1). The
battery will only t into the charger in one way. Do not
force. Be sure that the battery is fully seated in the
charger.
uPlug in the charger and switch on at the mains.
The charging indicator (2) will blink.
The charge is complete when the charging indicator (2)
switches to continuously on. The charger and the battery can
be left connected indenitely.
The LED will switch on as the charger occasionally
tops up the battery charge.
Read the instruction manual
before use.
Features
This appliance includes some or all of the following features:
1. Trigger
2. Nozzle
3. Glue chamber
4. Glue stick inlet tube
5. On/Off switch
6. Battery housing
7. Battery release button
Assembly
Warning! Before cleaning. Remove the battery from the
appliance and allow to cool.
Charging the battery (g. A) (not supplied)
The battery needs to be charged before rst use and
whenever it fails to produce sufcient power on jobs that were
easily done before. The battery may become warm while
charging; this is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging
temperature: approx. 24 °C.
Note: The charger will not charge a battery if the cell
temperature is below approximately 10 °C or above 40 °C.
The battery should be left in the charger and the charger
will begin to charge automatically when the cell temperature
warms up or cools down.
 To charge the battery (10) (not supplied), insert the USB
charger (9) (not supplied).
 Connect the USB charger (9) to a power source.
 The USB charger and the battery can be left connected
indenitely.
 Charge discharged batteries within 1 week. Battery life will
be greatly diminished if stored in a discharged state.
State of charge indicator
The BLACK+DECKER battery is equipped with a state of
charge button with a four LED display.
The state of charge is an indication of approximate levels of
charge remaining in the battery according to the following
indicators:

67
ENGLISH
96 - 100% charged
76 - 95%
51 - 75%
26 - 50%
Pack needs to be charged
Note: The state of charge LED will only display once the state
of charge button is pressed.
Fitting and removing the battery (g. B)
(not supplied)
Warning! Before tting and removing the battery ensure the
On/Off switch (5) is in the off position by pressing the On/Off
switch (5) to the down position.
 To t the battery (10) (Not supplied), line it up with the
receptacle (6) on the appliance. Slide the battery into the
receptacle and push up until the battery snaps into place.
 To remove the battery, push the release button (7) while at
the same time pulling the battery out of the receptacle.
Fitting the glue stick (g. C)
Warning! Only use BLACK+DECKER low temperature glue
sticks. Replacement glue sticks are available from your
BLACK+DECKER dealer. Other brands may cause dangerous
malfunctions.
Warning! Do not attempt to remove an unused portion of
a glue stick from the appliance.
 Insert a glue stick into the inlet tube located at the rear of
the appliance (4).
 Gently squeeze the trigger (1) to locate the glue stick
rmly in position.
 On rst use, the glue stick may be completely inserted into
the appliance. A second glue stick may be required.
Use
Warning! Be aware that this product may ignite material.
Where this is a concern, test a piece of scrap material.
This appliance will become warm during use. This is normal
and does not indicate a problem. Avoid contact with the
nozzle.
Turning the appliance on and off (g. D)
 To turn on the appliance push the On/Off switch (5) to the
up position.
 To turn off the appliance push the On/Off switch (5) to the
down position.
 The LED indicator light (8) will illuminate and ash to
indicate the heating element is warming up.
 After approximately 60 seconds the LED indicator light (8)
will stop ashing and remain lit to show the appliance is
hot enough for use.
 The LED indicator light (8) will no longer be illuminated,
this indicates that the heating element is off.
Warning! Molten glue and nozzle (2) area will remain
hot even after the appliance is turned off or the battery is
removed. Squeezing the trigger (1) after the appliance is
turned off may dispense melted glue. Allow the appliance to
cool for 30 minutes before storing.
Applying glue (g. E)
 After the glue gun has been turned on for at least 60
seconds, apply the glue by squeezing the trigger (1).
 To glue objects together apply glue to one object and
press second object into the melted glue.
 Hold glued objects together for 5-10 seconds. Heavy
applications may require up to a minute for the glue to
reach full strength.
Warning! Molten glue reaches 150 °C. Do not touch applied
glue. Keep away from children.
Warning! Glue dispersion may be delayed longer than time
claimed due to the presence of solidied glue in the unit.
Battery Terminal Safety Cap (g. F)
A power source storage and carrying cap (12) is provided for
use whenever the power source is out of the tool. Remove the
cap as shown before placing power source onto tool.

89
ENGLISH
Troubleshooting
Problem Possible cause Possible solution
Appliance will
not start or heats
slowly
Battery not installed Check battery is properly
installed
Battery will not
charge
USB charger not
connected
Insert the USB charger,
connect to power source
USB charger not
connected to
power source
Connect USB charger to
power source
Refer to “Charging the
battery (g. A)” for more
details
Surrounding air
temperature too
hot or too cold
Surrounding temperature
too hot or too cold
Move USB charger and
battery to a surrounding
air temperature of above
4.5 °C or below +40.5 °C
Appliance shuts off
abruptly
Battery has reached its
maximum thermal limit
Allow battery to cool
down
Out of charge Connect USB charger
to battery and power
source
Allow to charge (To
maximise the life of the
battery it is designed to
shut off abruptly when the
charge is depleted.
Hints for Optimum Use
The basic instructions given below are provided as a guide to
craft and DIY applications. The operator should practise the
various applications on scrap materials to obtain the required
effect and prevent damage to the work piece.
Tips on using your glue gun
 Choose the right glue stick for the appliance. Low
temperature glue sticks suitable for this appliance.
 Make sure that the surfaces are clean and free from dirt or
oily lms before gluing.
 Assemble the part to conrm that they can be joined
together in the required position before applying glue.
 Make arrangements to hold the parts in position while the
glue hardens.
The heat from the glue may be conducted to the material.
Clamps or pliers should be used to protect the operator
from the heat.
 Working in a cold environment will reduce the time
required for the glue to harden.
Warm environments will increase the time for the glue to
set.
 The amount of glue applied will affect the hardening time.
Large heavy pools of glue will take up to fty percent
longer to dry than small drops. Very thin beads will dry in
as few as 10 seconds. Some experimentation with your
glue gun on scrap material will help to determine the best
method to use for your particular project.
 Some paints and stains containing petroleum distillates
can weaken the adhesive. Test before using.
You may need to paint or stain before gluing.
 Excess glue is not easily removed from materials when it
has hardened. Removal of excess glue may be attempted
by scraping, peeling, or softening the glue by applying
heat e.g. with the hot tip of the appliance. Adhesive may
be removed from fabric by dry cleaning.
Maintenance
Your BLACK+DECKER tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
Warning! Before performing any maintenance on the tool,
remove the battery from the tool. Unplug the charger before
cleaning it.
 Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
 Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
 Regularly open the chuck and tap it to remove any dust
from the interior.
 Regularly clean the appliance using a damp cloth. Do not
use any abrasive or solvent-based cleaner. Never let any
liquid get inside the appliance and never immerse any part
of the appliance into liquid.
Protecting the environment.
Separate collection. This product must not be
disposed of with normal household waste.
needs replacement, or if it is of no further use to you, do
not dispose of it with household waste. Make this product
available for separate collection.
z
Separate collection of used products and
packaging allows materials to be recycled and
used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand
for raw materials.
Service Information
Black+Decker offers a full network of company-owned
and authorized service locations throughtout Asia. All
Black+Decker Service Centers are staffed with trained
personnel to provide customers with efcient and reliable
product service. Whether you need technical advice,
repair, or genuine factory replacement parts, contact the
Black+Decker location nearest to you.

89
ENGLISH
NOTE
 Black+Decker’s policy is one of continuous improvement
to our products and, as such, we reserve the right to
change product specications without prior notice.
 Standard equipment and accessories may vary by country.
 Product specications may differ by country.
 Complete product range may not be available in all
countries.
Contact your local Black+Decker dealers for range availability.
Batteries
There are no user servicable parts inside.
 At the end of your products life return the whole unit
to your service agent or to a local recycling station to
have the battery recycled. Do not throw the unit out with
household waste.
Technical data
BDCGG12U
Input Voltage VDC 12
Operating temperature °C 150
Glue stick diameter mm 7
Weight kg 0.3
Battery BDCB12U
Voltage VDC 12
Capacity Ah 1.5
Type Li-Ion

10 11
BAHASA INDONESIA
23
BAHASA INDONESIA
Tujuan penggunaan
Pistol lem BDCGG12U BLACK+DECKERTM Anda telah
dirancang untuk aktivitas santai dan DIY di rumah untuk
menempelkan bahan termasuk kertas, kartu, dan bahan.
Peralatan ini hanya ditujukan untuk penggunaan non-profesional.
Peringatan keselamatan
peralatan umum
Peringatan! Bila menggunakan
peralatan listrik, tindakan
pencegahan dasar untuk
keselamatan, termasuk yang berikut,
harus selalu diikuti untuk mengurangi
risiko kebakaran, sengatan listrik, cedera
tubuh, dan kerusakan bahan.
 Bacalah seluruh isi panduan ini dengan
saksama sebelum mengoperasikan
peralatan, kenalilah semua tuas
pengendali serta cara penggunaan
peralatan yang benar.
 Tujuan penggunaan dijelaskan dalam
panduan ini. Penggunaan aksesori
atau peralatan tambahan atau
pengoperasian peralatan selain yang
disarankan dalam panduan ini dapat
menimbulkan risiko cedera diri.
Istilah "peralatan" dalam seluruh
peringatan yang tercantum di bawah
ini merujuk pada peralatan bertenaga
listrik (berkabel) atau peralatan
bertenaga baterai (nirkabel) Anda.
 Simpan semua peringatan dan
petunjuk untuk referensi di masa
mendatang.
Menggunakan peralatan Anda
 Saat menggunakan peralatan ini,
selalu berhati-hatilah.
 Jaga agar area kerja tetap bersih dan
terang. Area kerja yang tidak rapi atau
gelap dapat memicu kecelakaan.
 Jangan biarkan peralatan ini terkena
hujan atau berada dalam kondisi basah.
Air yang masuk ke peralatan akan
meningkatkan risiko sengatan listrik.
 Jangan masukkan peralatan ke
dalam air.
 Gunakan peralatan ini hanya di siang
hari atau di bawah pencahayaan
yang cukup.
 Jangan mengoperasikan peralatan
Anda di lingkungan yang mudah
menimbulkan bahaya ledakan, seperti
di tempat yang terdapat cairan, gas,
atau debu yang mudah terbakar.
 Jangan biarkan alat digunakan sebagai
mainan.
 Jangan membuka casing bodi. Tidak
ada bagian dalam yang dapat diservis
oleh pengguna.
 Lepaskan baterai dari peralatan saat
sedang tidak digunakan, sebelum
memasang atau melepas komponen,
dan sebelum dibersihkan.
Penggunaan dan perawatan
peralatan
 Sebelum digunakan, periksa apakah
ada komponen peralatan yang rusak
atau cacat.
Periksa apakah ada bagian yang patah,
kerusakan tombol, dan kondisi lain yang
dapat memengaruhi pengoperasiannya.
 Jangan gunakan peralatan ini jika sakelar
dayanya tidak dapat menyalakan atau
mematikan peralatan. Peralatan apa
pun yang tidak dapat dikendalikan
dengan sakelar adalah berbahaya dan
harus diperbaiki.
