BLACK DECKER GL933 User manual

www.blackanddecker.co.nz
www.blackanddecker.com.au
GL933

23
A B
C D
E F

23
G H
I J
K L
20 O

45
M N
OP

5
ENGLISH
(Original instructions)
45
Intended use
Your BLACK+DECKERTM GL933 trimmer has been designed
for trimming and nishing lawn edges and to cut grass in
conned spaces. This appliance is intended for consumer use
only.
Safety instructions
Warning! When using mains-powered
appliances, basic safety precautions,
including the following, should always be
followed to reduce the risk of re, electric
shock, personal injury and material
damage.
Warning! When using the machine the
safety rules must be followed. For your
own safety and bystanders please read
these instructions before operating the
machine. Please keep the instructions
safe for later use.
uRead all of this manual carefully before
operating the appliance.
uThe intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future
reference.
Using your appliance
Always take care when using the
appliance.
uAlways use safety glasses or goggles.
uNever allow children or people
unfamiliar with the instructions to use
the appliance.
uDo not allow children or animals to
come near the work area or to touch
the appliance or power supply cord.
uClose supervision is necessary when
the appliance is used near children.
uThis appliance is not intended for use
by young or inrm persons without
supervision.
uThis appliance is not to be used as a
toy.
uOnly use the appliance in daylight or
good articial light.
uUse in a dry location only. Do not allow
the appliance to become wet.
uDo not immerse the appliance in water.
uDo not open the body casing. There
are not user-serviceable parts inside.
uDo not operate the appliance in
explosive atmospheres, such as in the
presence of ammable liquids, gases
or dust.
uTo reduce the risk of damage to
plugs or cords, never pull the cable to
remove the plug from a socket.
Safety of others
uNever allow children, persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge or people unfamiliar with
these instructions to use the machine,
local regulations may restrict the age
of the operator.
uNever operate the machine while
people, especially children, or pets are
nearby.
Vibration
The declared vibration emission values
stated in the technical data and the
declaration of conformity have been
measured in accordance with a standard
test method provided by EN50636 and
may be used for comparing one tool with

6
ENGLISH (Original instructions)
another. The declared vibration emission
value may also be used in a preliminary
assessment of exposure.
Warning! The vibration emission value
during actual use of the power tool can
differ from the declared value depending
on the ways in which the tool is used.
The vibration level may increase above
the level stated.
When assessing vibration exposure to
determine safety measures required by
2002/44/EC to protect persons regularly
using power tools in employment, an
estimation of vibration exposure should
consider, the actual conditions of use and
the way the tool is used, including taking
account of all parts of the operating
cycle such as the times when the tool is
switched off and when it is running idle in
addition to the trigger time.
Residual risks.
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc.
Even with the application of the
relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
rotating/moving parts.
uInjuries caused when changing any
parts, blades or accessories.
uInjuries caused by prolonged use
of a tool. When using any tool for
prolonged periods ensure you take
regular breaks.
uImpairment of hearing.
uHealth hazards caused by breathing
dust developed when using your
tool (example:- working with wood,
especially oak, beech and MDF.)
After use
uWhen not in use, the appliance should
be stored in a dry, well ventilated place
out of reach of children.
uChildren should not have access to
stored appliances.
uWhen the appliance is stored or
transported in a vehicle it should be
placed in the boot or restrained to
prevent movement following sudden
changes in speed or direction.
Inspection and repairs
uDisconnect the machine from the
mains before checking, cleaning or
working on the machine and when it is
in use.
uBefore use, check the appliance
for damaged or defective parts.
Check for breakage of parts and any
other conditions that may affect its
operation.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorised
repair agent.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Using an extension cable
Always use an approved extension
cable suitable for the power input of
this appliance (see technical data). The
extension cable must be suitable for

7
ENGLISH
(Original instructions)
outdoor use and marked accordingly. Up
to 30 m of 1.5 mm2 HO5VV-F extension
cable can be used without loss of product
performance. Before use, inspect the
extension cable for signs of damage,
wear and ageing. Replace the extension
cable if damaged or defective. When
using a cable reel, always unwind the
cable completely.
Additional safety instructions for
grass trimmers
Warning! Cutting elements continue to
rotate after the motor is switched off.
uBe familiar with the controls and the
proper use of the appliance.
uBefore use, check the power supply
cord and extension cord for signs
of damage, ageing and wear. If a
cord becomes damaged during
use, disconnect the cord from the
mains supply immediately. DO
NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY.
uDo not use the appliance if the cords
are damaged or worn.
uWear stout shoes or boots to protect
your feet.
uWear long trousers to protect your
legs.
uBefore using the appliance, check that
your cutting path is free from sticks,
stones, wire and any other obstacles.
uOnly use the appliance in the upright
position, with the cutting line near the
ground. Never switch the appliance on
in any other position.
uMove slowly when using the appliance.
Be aware that freshly cut grass is
damp and slippery.
uDo not work on steep slopes. Work
across the face of slopes, not up and
down.
uNever cross gravel paths or roads
while the appliance is running.
uNever touch the cutting line while the
appliance is running.
uDo not put the appliance down until the
cutting line has come to a complete
standstill.
uUse only the appropriate type of
cutting line. Never use metal cutting
line or shing line.
uBe careful not to touch the line
trimming blade.
uTake care to keep the mains cable
away from the cutting line. Always be
aware of the position of the cable.
uKeep hands and feet away from the
cutting line at all times, especially
when switching on the motor.
uBefore using the appliance and after
any impact, check for signs of wear or
damage and repair as necessary.
uNever operate the appliance with
damaged guards or without guards in
place.
uTake care against injury from any
device tted for trimming the lament
line length. After extending new cutter
line always return the machine to
its normal operating position before
switching on.
uAlways ensure that the ventilation slots
are kept clear of debris.
uDo not use the lawn trimmer (edge
trimmer), if the cords are damaged or
worn.
uKeep extension cords away from
cutting elements.

8
ENGLISH (Original instructions)
Labels on appliance
The following pictograms are shown on
the tool along with the date code:
Read the manual prior to
operation.
Wear safety glasses or goggles
when operating this appliance.
Wear suitable ear protectors
when operating this appliance.
Always remove the plug from
the socket before inspecting
a damaged cable. Do not use
your strimmer if the cable is
damaged.
Beware of ying objects. Keep
bystanders away from the
cutting area.
Do not expose the appliance to
rain or high humidity.
Directive 2000/14/EC
guaranteed sound power.
Electrical safety
This appliance is double
insulated; therefore no earth wire
is required. Always check that
the power supply corresponds to
the voltage on the rating plate.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
uElectric safety can be further improved
by using a highsensitivity 30 mA
Residual Current Device (RCD).
Features
This appliance includes some or all of the following features.
1. On/Off switch
2. Handle
3. Cable restraint
4. Power inlet
5. Secondary handle
6. Adjustment button
7. Tube
8. Spare spool storage
9. HDL cap
10. Guard
11. Line trimming blade
12. Spool housing
13. Cutting line
14. Edge wheel
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fitting the guard (g. A & B)
uRemove the screw (15) from the guard (10).
uPlace the guard (10) onto the tool as shown.
uFirmly press the guard until it snaps into place.
uSecure the guard with the screw.
uTighten the screw.
Warning! Never use the tool unless the guard is properly
tted.
Attaching the secondary handle (g. C)
uPress in and hold the adjustment button (6) on the side of
the main body.
uSlide the secondary handle (5) in place over the
adjustment button (6).
Warning! Ensure that the teeth on the button are correctly
aligned in slots in the handle and that the handle is secure.
Adjusting the position of the secondary handle
(g. D)
The secondary handle (5) can be adjusted to provide optimum
balance and comfort.
uPress in the adjustment button (6) on the left side of the
handle.
uRotate the second handle (5) into the required position.
uRelease the adjustment button (6).
Warning! Ensure that the teeth on the button are correctly
aligned in slots in the handle and that the handle is secure.
Adjusting the height of the tool (g. E & F)
This tool has a telescopic mechanism, allowing you to set it to
a comfortable height. There are multiple height settings.

9
ENGLISH
(Original instructions)
To adjust the height setting, proceed as follows:
uRelease the height adjust locking clamp (16).
uGently pull the tube (7) up or down to the desired height.
uClose the height adjust locking clamp (16).
Releasing the cutting line
In transit, the cutting line is taped to the spool housing.
uRemove the tape holding the cutting line to the spool
housing (12).
Storing the spool not in use (g. G)
The tool has two cutting systems:.
uAFS: Single line autofeed for light trimming and edging.
uHDL: Heavy Duty Dual Line cutting system for more
overgrown areas.
Note: The HDL spool may be used in trimming mode only.
The cutting system not in use can be stored in the spare spool
storage.
uAlign the tabs (17) on the spool cover with the cut outs
(18) in the spare spool storage (8).
uPush the cover onto the spare spool storage until it snaps
securely into place.
Connecting the tool to the mains (g. H)
uConnect the female plug of a suitable extension cable to
the power inlet (4).
uLoop the cable through the cable restraint (3).
uInsert the mains plug into a mains outlet.
For wired in cable units: Make sure the cable is looped
through the cable restraint prior to connecting the plug to the
mains outlet.
Warning! The extension cable must be suitable for outdoor
use.
Use
Warning! Let the tool work at its own pace. Do not overload.
Setting the tool to trimming or edging mode
(g. I & J)
The tool can be used in trimming mode as shown in g. I or in
edging mode to trim overhanging grass along lawn edges and
ower beds as shown in g. J.
Trimming mode (g. I)
For trimming, the trimmer head should be in the position
shown in g. I. If it is not:
uRelease the height adjust locking clamp (16).
uRotate the tube (7) clockwise.
uWhen the head is in position, close the height adjust
locking clamp (16).
Note: The tube will only rotate in one direction.
Note: The HDL spool may be used in trimming mode.
Edging mode (g. J)
For edging, the trimmer head should be in the position shown
in g. J. If it is not:
uRelease the height adjust locking clamp (16).
uRotate the tube (7) anti-clockwise.
uWhen the head is in position, close the height adjust
locking clamp (16).
Note: The tube will only rotate in one direction.
Switching on and off
uTo switch the tool on, squeeze the on/off switch (1).
uTo switch the tool off, release the trigger lever.
Warning! Never attempt to lock the trigger lever in the on
position.
Hints for optimum use
General
uIn order to achieve optimum cutting results, only cut dry
grass.
Trimming
uHold the tool as shown in g. K.
uGently swing the trimmer from side to side.
uWhen cutting long grass, work in stages from the top. Take
small cuts.
uKeep the tool away from hard objects and delicate plants.
uCutting line will wear faster and require more feeding if
the cutting is done along pavements or other abrasive
surfaces or heavier weeds are being cut.
uIf the tool starts running slowly, reduce the load.
Edging
Optimum cutting results are achieved on edges deeper than
50 mm.
uDo not use the tool to create edges. To create edges, use
an edging spade.
uGuide the tool on its wheel as shown in g. L.
uTo make a closer cut, slightly tilt the tool.
Fitting a new spool of cutting line (g. M & N)
Replacement spools of cutting line are available from your
BLACK+DECKER dealer (cat. no. A6482). Packs containing 3
spools of cutting line are also available (cat. no. A6486).
uUnplug the tool.
uKeep the tabs (17) depressed and remove the spool cover
(21) from the housing (12) (g. M).
uRemove the empty spool (22) from the spool cover.
uRemove any dirt and grass from the spool cover and
housing.
uUnclip the end of of the cutting line and guide the line into
the eyelet (23) (g. M). The line should protrude approx.
11 cm from the spool cover.

10
ENGLISH
(Original instructions)
Note: Take care not to allow the the line on the spool to
uTake the new spool and push it onto the boss in the spool
cover. Rotate the spool slightly until it is seated.
uAlign the tabs (17) on the spool cover with the cut outs
(24) in the housing (12).
uPush the cover onto the housing until it snaps securely
into place.
Warning! If the cutting lines protrude beyond the trimming
blade (11), cut it off so that it just reaches the blade.
Fitting a new piece of heavy duty cutting line
Replacement packs of 10 heavy duty cutting lines are
available from your BLACK+DECKER dealer (cat. no. A6489).
uUnplug the tool.
uKeep the tabs (17) depressed and remove the HDL cap
(9) from the housing (12).
uRemove any dirt and grass from the HDL cap (9) and
housing.
uRemove the used piece of line from the HDL cap (9).
uThread a new piece of line (20) through the eyelets (27) in
either side of the HDL cap.
uPut the central ferrule (28) in the indicated position
(Fig. P).
u
Warning! Only use the appropriate type of BLACK+DECKER
cutting line.
Troubleshooting
If your tool seems not to operate properly, follow the
instructions below. If this does not solve the problem, please
contact your local BLACK+DECKER repair agent.
Warning! Before proceeding, unplug the tool.
Tool runs slowly
uCheck that the spool housing can rotate freely. Carefully
clean it if necessary.
uCheck that the cutting line does not protrude more than
11 cm from the spool housing. If it does, cut it off so that it
just reaches the line trimming blade.
Automatic line feed does not work
uKeep the tabs depressed and remove the spool cover
from the housing.
uPull the cutting line until it protrudes 11 cm from the
install a new spool of cutting line as instructed above.
uAlign the tabs on the spool cover with the cut outs in the
housing.
uPush the cover onto the housing until it snaps securely
into place.
uIf the cutting line protrudes beyond the trimming blade, cut
it off so that it just reaches the blade.
If the automatic line feed still does not work or the spool is
jammed, try the following suggestions:
uCarefully clean the spool cover and housing.
uRemove the spool and check if the lever can move freely.
uRemove the spool and unwind the cutting line, then wind it
on neatly again as described above. Replace the spool as
instructed.
Protecting the environment
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
GL933
(Type 1)
Voltage VAC 230
Power input W 900
No-load speed min-1 7000
Weight kg 3.2
Level of sound pressure:
Sound pressure (LpA) 80 dB(A), uncertainty (K) 0.55 dB(A)
Sound power (LWA) 94 dB(A), uncertainty (K) 0.55 dB(A)
Vibration total values (triax vector sum) according to EN 50636-2-91:2014:
Vibration emission value (ah) 6.0 m/s2, uncertainty (K) 1.5 m/s2

90635941 03/2016
Australia & New Zealand
Stanley Black & Decker
www.blackanddecker.com.au
www.blackanddecker.co.nz
Tel.[phone] (Aust) or Tel. [phone] (NZ)
