Black Stone 1620 User manual

Owner’s Manual
Grill+Kabob
VIDEO ASSEMBLY
www.blackstoneproducts.com/kabob
North Atlantic Imports LLC | 513 West 2500 North, North Logan UT 84341 | www.blackstoneproducts.com
FOR OUTDOOR USE ONLY
Please read manual carefully before assembly
Retain this manual for future reference
MODEL #1620

2
PRODUCT REGISTRATION
DANGER
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING
WARNING: Be alert to the possibility of serious bodily
injury if the instructions are not followed. Be sure to
read and carefully follow all of the messages.
CAUTION
CAUTION: Indicates a potentially hazardous
situation which,if not avoided, may result in minor or
moderate injury.
CALIFORNIA PROPOSITION
65 WARNING
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. (California law
requires this warning be given to customers in the
State of California.)
For more information: www.watts.com/prop65
SAFETY SYMBOLS
The symbols and boxes shown below explain what each
heading means. Read and follow all of the messages
found throughout the manual.
To register your BLACKSTONE product please go to
www.blackstoneproducts.com/register
TABLE OF CONTENTS
Product Registration ......................2
For Your Safety...............................3
Parts List ........................................4
Assembly Instructions ....................6
Operating Instructions..................12
Customer Service.........................13
Grill Warranty................................14
Model Number: __________________________________
Serial Number: ___________________________________
Date Purchased: _________________________________
To Installer/Assembler:
Leave these instructions with consumer.
To Consumer:
Keep this manual for future reference.

3
This instruction manual contains important information
necessary for the proper assembly and safe use of this
appliance. Read all warnings and instructions before
assembling and using the appliance. Follow all warnings
and instructions when assembling and using the
appliance.
Failure to follow these instruction could result in re which
could cause property damage, personal injury, or death.
FOR YOUR SAFETY
CAUTION
THIS UNIT IS HEAVY. FOR SAFE ASSEMBLY, TWO
PEOPLE ARE REQUIRED.
Some parts may contain sharp edges, especially as
noted in these instructions. Wear protective gloves if
necessary.
Call the BLACKSTONE Products Information Center
for help and missing parts, assembly questions, and
operation problems. Before returning this product to the
store, call: USA 435.252.3030 or email us at
[email protected]
• Keep a re extinguisher near the grill at all times.
• This grill is for outdoor use only in well-ventilated
areas. NEVER USE INDOORS.
• Use caution when lifting and moving the unit to avoid
back strain or back injury.
• Never move grill while in operation or still hot.
• DO NOT operate the unit near or under ammable
or combustible materials such as decks, porches
or carports. A minimum clearance of 36 in. is
recommended. DO NOT operate the unit under
overhead construction.
• DO NOT use this appliance as a heater.
• Operate the unit on a stable, level, non-ammable
surface such as asphalt, concrete or solid ground. DO
NOT operate the unit on ammable material such as
carpet or wood deck.
• DO NOT use this product in a manner other than its
intended purpose. It is NOT intended for commercial
use. It is not intended to be installed or used in or on a
recreational vehicle and/or boats.
• DO NOT store this unit near gasoline or other
combustible liquids or where other combustible vapors
may be present.
• DO NOT store or operate this product in an area
accessible to children or pets. Store this unit in a dry
protected location.
• DO NOT leave the unit unattended while in use.
• DO NOT leave hot ashes unattended until the grill
cools completely.
• DO NOT move the unit while in use or while ashes
are still hot. Allow the unit to cool completely before
moving or storing.
• NEVER use gasoline or other highly volatile uids as a
starter.
• Always cook your food after the ame is burned out.
• Dispose of cold ashes by wrapping them in heavy-
duty aluminum foil and placing in a noncombustible
container. Make sure that there are no other
combustible materials in or near the container.
• If you must dispose of ashes in less time than it takes
for the ashes to completely cool down, then remove
the ashes from the unit, keeping them in the heavy-
duty foil, and soak them completely with water before
disposing of them in a noncombustible container.
• Allow the unit to cool completely before conducting
any routine cleaning or maintenance.
• Clean grill often, preferably after each cookout.
• Use long-handled barbecue utensils and oven mitts to
avoid burns and splatters.
• The use of alcohol, prescription, or non-prescription
drugs may impair the user’s ability to properly
assemble and safely operate this grill.
• If you have a problem with your grill please call
customer support at 435.252.3030 or
email [email protected].

4
PARTS LIST
Logo Plate (1 pc.) M4 Screw (2 pcs.)
M6x12 Screw (4 pcs.)
Lid (1 pc.)
Handle (2 pcs.) Handle Spacer (4 pcs.) Crank Handle (1 pc.) Thermometer (1 pc.)
Main Body (1 pc.) Chimney (1 pc.) Skewer (11 pcs.) Grill Grate (3 pcs.)
Ash Tray (1 pc.)
M5x10 Screw (6 pcs.) M5x12 Screw (2 pcs.)
M6x38 Bolt (4 pcs.) M6x62 Bolt (8 pcs.)
Cotter Pin (6 pcs.)
M4 Nut (4 pcs.)
M6x20 Screw (2 pcs.)
Leg Supports (2 pcs.)
M8 Screw (4 pcs.)
M5 Nut (4 pcs.)
M6 Flange Nut (16 pcs.)

5
PARTS LIST
Short Thumbscrew (2 pcs.)
Charcoal Door Knob with door
catch, ST3.9 Screw, and mica
plate thermal shield (1 pc.)
Crank Handle Collar (1 pc.)
Charcoal Tray (1 pc.)
Leg Frame (1 pc.) Side Shelf (1 pc.) Leg Frame with Wheels (1 pc.)
Charcoal Tray Bracket (2 pcs.)
Air Vent (2 pcs.)
Short Hitch Pin (4 pcs.)
Long Hitch Pin (2 pcs.) Motor (1 pc.) Gear Drive (1 pc.)

6
VIDEO ASSEMBLY
Watch an actual
BLACKSTONE Grill+Kabob
assembly. Use a QR Code
App and scan the QR code.
www.blackstoneproducts.com/grill+kabob
WARNING
The manufacturer has made every eort to eliminate
any sharp edges. However, you should handle all
components with care to avoid accidental injury.
Please read all instructions thoroughly before proceeding.
Find a large, clean area in which to assemble your
BLACKSTONE Grill. Please refer to the assembly diagram
as necessary.
NOTICE: Make sure all the plastic protection and
packaging is removed before assembling
ASSEMBLY INSTRUCTIONS
STEP 1
Use (2) M5x12 screws and (2) M5 nuts to install the crank
handle collar. Install the collar from the inside of the grill
body.
STEP 2
Remove the ash tray from
the main body.
TOOLS REQUIRED
Phillips head screwdriver and an adjustable wrench.
M5x12 screws
M5 nuts

7
M6x62 bolts
M6x62 bolts
M6 flange nuts
M6 flange nuts
STEP 4
Use (4) M6 bolts and (4) M6 flange nuts to attach the bottom
leg support.
STEP 5
Turn the grill upright. Use (4) M6x62 bolts and (4) M6 flange
nuts to attach the other leg support to the back of the legs.
STEP 6
Use (2) M5 screws to secure the legs to the back of the
main body.
STEP 3
Use (4) M6x38 bolts and (4) M6 flange nuts to attach
the legs to the main body. Use (2) M5 screws through
the front of the main body to secure the legs.
M5 screws
M6x38 bolts
M5 Screws

8
STEP 9
Use the ST3.9 screw to attach the charcoal door knob to
the charcoal door. Make sure the door catch and mica plate
are on the inside of the door and the knob is on the outside.
STEP 10
Use (2) long hitch pins and (2) cotter pins to attach the lid to
the main body.
ST3.9 Screw
Door Catch
Mica Plate
Knob
Cotter Pin
Long Hitch Pin
STEP 7
Use (4) short hitch pins and (4) cotter pins to attach the
charcoal tray brackets.
STEP 8
Use (4) M6x12 screws and (4) M6 flange nuts to attach the
charcoal tray to the charcoal tray brackets.
Short Hitch Pins
M6x12 Screws
M6 Flange Nuts
Cotter Pins

9
STEP 11
Install the thermometer.
STEP 13
Use (2) M5 nuts and install the logo plate.
STEP 14
Use the handle spacers and M8 screws to install the handles
on the lid and side of the grill.
STEP 12
Use (2) M5x10 screws and (2) M5 nuts to install the
chimney.
M5 Nut
M5 Nut
Handle Spacer
M8 Screw
M5x10 Screw

10
STEP 17
Install the crank handle. Remove the retention screw at the
end of the crank handle before installation. One the crank
handle is installed into the crank handle collar, replace the
retention screw.
STEP 18
Replace the ash tray.
Retention Screw
STEP 15
Use (2) short thumbscrews to attach the side tray.
STEP 16
Install the air vents with (2) M4 screws and (4) M4 nuts. Use
(2) M4 nuts on the inside of the grill to lock the M4 screw
and air vent.
M4 Nuts
M4 Screw
Short Thumbscrews

11
STEP 19
Install the gear drive with (2) M6x20 screws.
STEP 20
Install the motor on the gear drive.
STEP 21
Install the grill grates, the skewers, or a combination
of both.
Grill Grates
Skewers
M6x20

12
This grill has an adjustable charcoal tray. By turning
the crank handle, the charcoal tray can be raised or
lowered to desired height. This allows for dierent heat
settings depending on the food you are cooking and the
temperature at which you want to cook. It also allows
easy cleaning of the interior of the rebox after the unit
has cooled down completely. It is not recommended to
raise a fully loaded charcoal tray higher than the middle
height setting.
CHARCOAL LIGHTING INSTRUCTIONS
• Open grill top.
• Remove cooking grates.
• Adjust charcoal tray to the center position.
• Place one even row of charcoal briquettes in the
charcoal tray. Make sure that charcoal does not go
above the top of the tray.
• Light briquettes.
• Move charcoal tray to the bottom position.
• With the top open, allow the briquettes to fully ignite
(to the point where there is no further lame).
• Once the briquettes are lit, put the grates back in the
grill.
• Adjust charcoal tray as required to achieve the proper
temperature.
• The two side air vents on the lid should be kept open
during cooking to allow air low.
NOTE: The temperature should not go above 500ºF. If the
temperature goes above 500ºF, you should reduce the
quantity of briquettes that you have placed in the charcoal
tray. The proper cooking temperature should not exceed
500ºF.
SEASONING UNIT
1. Before your rst cooking you should season the unit
to enhance the cooking and to provide better overall
durability. Failure to properly follow these steps may
damage the nish and/or impart metallic avors to
foods.
2. Place about 60 briquettes in the charcoal pan. Do not
place any briquettes against walls of the pan.
3. Coat interior surfaces with vegetable cooking oil.
4. Light briquettes and set ash pan at medium height by
cranking the crank handle.
5. Sustain burn for about two hours with lid closed and
all dampers to 1/4 of the way open. Allow the unit to
cool down properly.
6. Once this is completed, the unit is ready for use.
Rust can appear on the inside of your grill. Maintaining a
light coating of vegetable oil on interior surfaces will aid
in the protection of your grill. Exterior surfaces of the grill
may need occasional touch up. We recommend the use
of commercially available black high temperature spray
paint.
NEVER PAINT THE INTERIOR OF THE UNIT!
OPERATING THE FRONT DOOR, AIR VENTS, AND
SMOKE STACK
• To open the door, rotate the knob left or right and pull.
• To close the door, push the door in and rotate the
knob to engage the door catch.
• To adjust the side air vents, rotate them until desired
air ow is achieved.
• To adjust the chimney, rotate the damper until the
desired air ow is achieved.
OPERATING INSTRUCTIONS
DANGER
CARBON MONOXIDE HAZARD. Burning charcoal
inside can kill you. It gives o carbon monoxide,which
has no odor. NEVER burn charcoal inside homes,
vehicles or tents.
WARNING
WARNING: These metal parts could be very hot while
grilling. Always operate these parts while wearing a
heat-resistant glove.

13
GRILLING
Charcoal is recommended, however wood or a
combination of both may be used as the fuel source for
grilling if the fuel source is placed and ignited on the
charcoal pan. Do not build too large a re. We recommend
starting a re with no more than 4 lbs. of charcoal
(approximately 60 briquettes) and adding more as needed
during cooking through the front access door. After
allowing the re to burn down, place the cooking grates
or the skewers in the unit. Failure to read and follow
instructions for lighting charcoal may result in serious
personal injury and or property damage.
OPERATING INSTRUCTIONS
WARNING
• Most surfaces on this unit are hot when in use.
Use extreme caution. Keep others away from unit.
• Always wear protective clothing to prevent injury.
• Keep children and pets away.
• DO NOT move this unit during operation.
• Never substitute gasoline, kerosene or alcohol
for charcoal lighter uid. In some states, the use
of charcoal lighter uid is prohibited by law. In
this case, paran-based starter cubes can be
substituted, or use a charcoal chimney. Never use
lighter uid with an electric starter.
CARE & MAINTENANCE
Regularly clean your BLACKSTONE grill between uses
and especially after extended periods of storage. Ensure
that the grill and its components are suciently cool
before cleaning. Never handle hot parts with unprotected
hands.
In order to extend and maintain the life and condition of
your grill, we strongly recommend that the unit be covered
when left outside for any length of time, especially during
the winter months. Store the grill in a cool, dry place.
CUSTOMER SERVICE
Our Customer Service sta is here to
help you!
For questions regarding your BLACKSTONE product,
or if you need replacement parts, contact us at:
USA Support: 435.252.3030
[email protected]
We’re pleased to help you with any questions concerning
replacement parts or your warranty. Our customer service
sta can be reached Monday through Friday from 9:00
am to 5:00 pm Mountain Standard Time. If all operators
are busy or you call after hours, you may leave a message
and your call will be returned or send an email.
SAFE COOKING TEMPERATURES
Use a thermometer to ensure safe internal temperature.
GROUND MEAT
• Be, Pork, Veal, Lamb ........................................ 160°F
• Turkey, Chicken................................................... 165°F
FRESH BEEF, PORK, VEAL, AND LAMB................ 145°F
with a 3 minute rest time
Poultry
• Chicken and Turkey, Whole or Parts, Duck, Goose,
Stung (cooked alone or in bird)........................ 165°F
SEAFOOD
• Fin Fish................................................................ 145°F
or esh is opaque and separates easily with fork
• Shrimp, Lobster, Crab...............Flesh pearly & opaque
• Scallops ....................... Milky with or opaque and rm

14
WARRANTY
North Atlantic Imports LLC,
90 Day & Limited Warranty
North Atlantic Imports LLC, the manufacturer of
BLACKSTONE Products, will warranty for 90 days from
purchase all parts, workmanship, and nishes (against
rust). It will be the manufacturer’s option as to whether to
repair or replace any of the above items.
If this BLACKSTONE grill fails due to a defect in material
or workmanship within 90 days from the date of purchase,
call [phone] to arrange for replacement parts.
Please retain a copy of your proof of purchase to validate
your warranty. You may be requested to send in a copy of
your receipt to conrm any warranty requests.
All warranties are limited to the original purchaser only.
This warranty does not cover any liability on the part of
North Atlantic Imports LLC, its agents or employees,
for any indirect or consequential damages for breach of
warranty.
The purchaser must follow the manufacturer’s usage
instructions. Warranty coverage is void if this product
is ever used for commercial or rental purposes. Under
no circumstances is the manufacturer responsible for
damages from the failure to operate this product properly.
All warranty coverage excludes paint loss, discoloration
or surface rusting, which are either expendable parts that
can wear out from normal use within the warranty period,
or are conditions that can be the result of normal use,
accident or improper maintenance.
After 90 days from the date of purchase, or if a valid
proof of purchase cannot be provided, you can purchase
replacement parts by calling [phone]. (Part
purchase price with shipping and handling to be paid by
customer.)
For more detailed explanation of
the warranty, read below:
North Atlantic Imports LLC warrants to the owner that the product
covered by this agreement is free from defects in material and
workmanship under normal use and service for which it was intended
if, but only if, it has been operated in accordance with North Atlantic
Imports LLC instructions exclusively for domestic use, and not for
private or public club, institutional, or commercial purposes. North
Atlantic Imports LLC obligation under this warranty is limited to replacing
or repairing, free of charge, any part or parts that may prove, to the
satisfaction in North Atlantic Imports LLC, to be defective under normal
home use and service within the following stated periods of time from
the date of purchase; a) for 90 days from purchase, all parts, nish, and
workmanship. Should any failure to conform to this warranty become
apparent during applicable warranty periods stated above, the original
purchaser must notify North Atlantic Imports LLC of breach or warranty
within the applicable warranty period. North Atlantic Imports LLC
shall upon notice and compliance by the original purchaser with such
instructions, correct such nonconformity by repair or replacement of the
defective part or parts. Correction in the manner provided above shall
constitute a fulllment of all obligations of North Atlantic Imports LLC
with respect to the quality of the product.
North Atlantic Imports LLC does not warrant this equipment to meet
the requirement of any safety code of any state, municipality or other
jurisdiction, and the original purchaser assumes all risk and liability
whatsoever resulting from the use thereof, whether used in accordance
with North Atlantic Imports LLC instructions or otherwise. This warranty
does not cover and is intended to exclude any liability on the part of
North Atlantic Imports LLC its agents, servants or employees whether
under this warranty or implied by law for any indirect or consequential
damages for breach on any warranty. The purchaser must establish
all applicable warranty periods pursuant to this warranty by verifying
the original purchase date by producing the dated sales receipt. This
warranty shall not apply to this product or any other part thereof which
has been subject to accident, negligence, alteration, abuse, or misuse
or which has been repaired or altered without North Atlantic Imports
LLC written consent, outside of North Atlantic Imports LLC factory.
North Atlantic Imports LLC makes no warranty whatsoever in respect to
accessories or parts not supplied with it. This warranty shall apply only
within the boundaries of the Unites States of America. This warranty
gives the original purchaser specic rights, and the original purchaser
may also have other rights, which vary from state to state.
