Black Stone 6001 User manual

BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
SAFETY ALERT KEY
⚠DANGER
Indicates a hazardous situation
that, if not avoided, will result in
death or serious injury.
⚠CAUTION
Indicates a hazardous situation
that, if not avoided, could result
in minor or moderate injury.
⚠WARNING
Indicates a hazardous situation
that, if not avoided, could result
in death or serious injury.
NOTICE
Indicates information considered
important, but not hazard-
related (e.g. messages related to
property damage).
OWNER’S MANUAL
IMPORTANT:
This instruction manual contains important
information necessary for the proper assembly and safe
use of the appliance.
Read and follow all warnings and instructions before
assembling and using the appliance.
Follow all warnings and instructions when using
the appliance.
Keep this manual for future reference.
Installer/Assembler: Leave these instructions with the consumer.
For the latest version of this manual,
scan this code or visit
BlackstoneProducts.com/support
| CONTACT CUSTOMER SUPPORT BEFORE RETURNING APPLIANCE TO RETAILER.
MODEL:  v06
5' X 8' BAR & GRILL
TABLE OF CONTENTS
ASSEMBLY GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USING YOUR BLACKSTONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
ASSEMBLY GUIDE
{A1} Post 1 (1 piece) {A2} Post 2 (1 piece) {A3} Post 3 (1 piece) {A4} Post 4 (1 piece) {A5} Post 5 (1 piece) {A6} Post 6 (1 piece)
{A7} Post 7 (1 piece) {A8} Post 8 (2 pieces) {A9} Foot base
(5 pieces) {B} Foot base (5 pieces) {C} Foot base cover (5 pieces) {D1} Cross beam 1 (1 piece)
{D2} Cross beam
2 (1 piece) {D3} Cross beam 3 (1 piece) {D4} Cross beam 4 (1 piece) {D5} Cross beam 5 (1 piece) {E1} Cross beam connector 1 (3 pieces) {E2} Cross beam connector 2 (2 pieces)
{E3} Cross beam
connector 3 (2 piece) {E4} Cross beam connector 4 (1 piece) {F1} Roof rib 1 (1 piece) {F2} Roof rib 2 (1 piece) {G1} Roof top rib 1 (1 piece) {G2} Roof top rib 2 (1 piece)
{H1} Gutter 1 (1 piece) {H2} Gutter 2 (1 piece) {J1} Top support
1 (1 piece) {J2} Top support 2 (1 piece) {J3} Bottom support 1 (1 piece) {J4} Bottom support 2 (1 piece)
{K1} Support bracket
1 (1 piece) {K2} Support bracket 2 (1 piece) {K3} Support bracket 3 (2 pieces) {L1} Shelf 1 (1 piece) {L2} Shelf 2 (1 piece) {M1} Roof panel 1 (1 piece)
{M2} Roof panel
2 (1 piece) {M3} Roof panel 3 (1 piece) {M4} Roof panel 4 (1 piece) {M5} Roof panel 5 (2 pieces) {N} Bottle opener (1 piece) {P} Electrical power cover (1 piece)
PARTS LIST
FRONTFRONT
FRONFRONTT
FFRROONNTT
FFRROONNTT
FRONTFRONT
FRONTFRONT
FFRROONNTT
FRONTFRONT
FRONTFRONT
FFRROONNTT


BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
HARDWARE
[AA]M6*20 bolts
(107+5 pieces) [BB]M6*30 bolts (2 pieces) [CC]M6*35 bolts (22+4 pieces) [DD]M6*14 Flat washer (14+2 pieces) [EE]Sealant washer (12+2 pieces) [FF]M3x10 bolts (4 pieces)
[GG]M6 nuts
(4 pieces) [HH]M6*16 flat washer (121+10 pieces)
[JJ]M8×70 Concrete
anchor (20 pieces) [KK]Plastic cap (12 pieces) [LL]Magnetic hook (15 pieces)
TOOLS INCLUDED
[Z1]Double end open
wrench (1 piece) [Z2]Angle drill adapter (1 piece) [Z3]Hex socket driver 10mm×65mm (1 piece) [Z4]Hex drill bit 4mm×50mm (1 piece) [Z5]M3 Screwdriver (1 piece) Follow all safety warnings provided
with your tools.
A step-ladder (not included) is required for assembly.
Check the components against the parts list and make sure there are
no missing parts.
Lay pieces on cardboard or a soft mat to help protect the pieces from
scratches.


ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE
ASSEMBLY INSTRUCTIONS
Find a large, clean area to assemble your appliance.
Remove all packing material before assembling.
⚠CAUTION
Sharp edges. Wear gloves while assembling.
NOT INCLUDED (OPTIONAL):
Two (2) D batteries
ELECTRIC REQUIREMENTS:
120V 60Hz
MODEL: 
STEP 01 Slide one (1) foot base cover {C} onto one (1) post 8 {A8}.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach one (1)
foot base {B} to the bottom of post 8 {A8}.
Repeat with the other post 8 {A8}, and posts {A7}, {A5}, and {A2}.
For ease of assembly, it is recommended to have 3 or more people
and allow enough time to completely finish the assembly.
(Assembly can take 6-8 hours.)
DO NOT tighten screws until all the screws and washers are properly
installed.
STEP 02 Pull the electric cord out through the plug on post 5 {A5}.
Use three (3) [KK]plastic caps, three (3) [AA]bolts, and three (3)
[DD]flat washers to attach post 4 {A4} and post 5 {A5}. Note: The
FRONT arrows should face each other.
Repeat with post 6 {A6} to one (1) post 8 {A8}.
Use three (3) [KK]plastic caps, three (3) [AA]bolts, and three (3)
[DD]flat washers to attach post 3 {A3} and one (1) post 8 {A8}.
Repeat with post 1 {A1} and post 2 {A2}.
STEP 03 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach cross beam 3 {D3} and cross beam 4 {D4}.
STEP 04 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach cross beam 1 {D1} and cross beam 2 {D2}.
A8
A8
A7
A5
A2
[AA]× 20
[HH]× 20
CB
D3
D4
[AA]× 2
[HH]× 2 D1
D2
[AA]× 2
[HH]× 2
A8
A6
A8
A3
A5
A4
A2
A1
[AA]× 12
[DD]× 12
[KK]× 12


BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
STEP 05 Use two (2) [CC]bolts and two (2) [HH]flat washers to
attach post assembly {A3} to roof rib 2 {F2}.
Repeat with post assembly {A1} and roof rib 1 {F1}.
Use two (2) [CC]bolts and two (2) [HH]flat washers to attach one (1)
cross beam connector 1 {E1} and post assembly {A6} to roof rib 2 {F2}.
Repeat with one (1) cross beam connector 1 {E1}, post assembly {A4}
and roof rib 1 {F1}.
STEP 06 Use four (4) [AA]bolts and four (4) [HH]flat washers to
attach one (1) cross beam connector 2 {E2} to roof rib 2 {F2} and post
assembly {A3}.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach one (1)
cross beam connector 2 {E2} to roof rib 1 {F1} and post assembly {A1}.
STEP 07 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach one (1) cross beam connector 1 {E1} to roof rib 1 {F1}.
STEP 08 Use two (2) [BB]bolts, four (4) [HH]flat washers, and two (2)
[GG]nuts to attach cross beam connector 4 {E4} and one (1) cross
beam connector 3 {E3} to roof rib 2 {F2}.
E1
[CC]× 8
[HH]× 8
A3
F2
A6 A4
A1
F1
F1
E1
[AA]× 2
[HH]× 2 F2
[BB]× 2
[HH]× 4
[GG]× 2
E3
E4
[GG]
[BB]
E2
F2
A3 A1
F1
[AA]× 8
[HH]× 8


ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
STEP 09 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach
one (1) support bracket 3 {K3} to post assembly {A3} and roof rib
assembly {F2}.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach
one (1) support bracket 3 {K3} to post assembly {A1} and roof rib
assembly {F1}.
STEP 10 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach cross beam {D1} to one (1) cross beam connector 1 {E1}.
Note: the FRONT labels should face forward.
Use two (2) [AA]bolts and two (2) [HH]flat washers to attach cross
beam {D2} to one (1) cross beam connector 3 {E3}.
STEP 11 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach cross beam {D4} to one (1) cross beam connector 1 {E1}.
Use two (2) [AA]bolts and two (2) [HH]flat washers to attach cross
beam {D3} to one (1) cross beam connector 1 {E1}.
STEP 12 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach
support bracket 1 {K1} to post assembly {A4} and cross beam {D3}.
Use four (4) [AA]bolts and four (4) [HH]flat washers to attach
support bracket 2 {K2} to post assembly {A6} and cross beam {D4}.
F2 F1
A3 A1
[AA]× 8
[HH]× 8
K3
E1
A6
E1
A4
D4
D3
[AA]× 4
[HH]× 4
K1 K2
D4
D3
A4
A6
[AA]× 8
[HH]× 8
D1
A1
A3
D2
E1
E3
[AA]× 4
[HH]× 4


BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
STEP 13 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach roof top rib 1 {G1} to roof top rib 2 {G2}.
Note: the ARROWS should face the same direction.
STEP 15 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach roof top rib 1 {G1} to roof rib {F1}.
Use two (2) [AA]bolts and two (2) [HH]flat washers to attach roof
top rib 2 {G2} to roof rib {F2}.
STEP 14 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach top support 1 {J1} to top support 2 {J2}.
STEP 16 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use three (3) [AA]bolts and three (3) [HH]flat washers to attach top
support 1 {J1} to post assembly {A1}.
Use three (3) [AA]bolts and three (3) [HH]flat washers to attach top
support 2 {J2} to post assembly {A3}.
G1
G2
F2
F1
[AA]× 4
[HH]× 4
A1
A3
[AA]× 6
[HH]× 6
J1
J2
G1
G2
[AA]× 2
[HH]× 2
J1
J2
[AA]× 2
[HH]× 2


ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
STEP 18 Use four (4) [AA]bolts and four (4) [GG]flat washers
to attach bottom support 1 {J3} to post assembly {A2} and post
assembly {A7}.
STEP 19 Use four (4) [AA]bolts and four (4) [HH]flat washers to
attach bottom support 2 {J4} to posts {A5} and {A2}.
STEP 20 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach shelf 2 {L2} to post {A1}.
Use three (3) [AA]bolts and three (3) [HH]flat washers to attach
shelf 2 {L2} to post {A7}.
STEP 17 Use four (4) [AA]bolts and four (4) [HH]flat washers
to attach cross beam 5 {D5} to post assembly {A6} and post
assembly {A3}.
J3
A2
A7
[AA]× 4
[HH]× 4
L2
A1
A7
[AA]× 5
[HH]× 5
J4 A2
A5
[AA]× 4
[HH]× 4
A3
A6 D5
[AA]× 4
[HH]× 4


BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
STEP 21 Use two (2) [AA]bolts and two (2) [HH]flat washers to
attach shelf 1 {L1} to post {A4}.
Use two (2) [AA]bolts and two (2) [HH]flat washers to attach shelf 1
{L1} to post {A1}.
Use two (2) [CC]bolts, four (4) [HH]flat washers, and two (2) [GG]
nuts to attach shelf 1 {L1} to shelf 2 {L2}.
STEP 22 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use six (6) [CC]bolts, six (6) [HH]flat washers, and six (6) [EE]
sealant washers to attach roof panels {M1}, {M2}, {M3}, {M4}, and {M5}
to roof top ribs {G1} and {G2}.
Use two (2) [CC]bolts, two (2) [HH]flat washers, and two (2) [EE]
sealant washers to attach roof panels {M1}, {M2}, {M3}, {M4}, and {M5}
to cross beams {D3} and {D4}.
Note: If the holes don't align during the assembly, pull the cross-
beams outward to align the holes.
STEP 23 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use two (2) [CC]bolts, two (2) [HH]flat washers, and two (2) [EE]
sealant washers to attach gutter 2 {H2} to the roof panels and cross
beam {D4}.
STEP 24 Note: DO NOT tighten the bolts completely until all the bolts
and washers are properly installed.
Use two (2) [CC]bolts, two (2) [HH]flat washers, and two (2) [EE]
sealant washers to attach gutter 1 {H1} to the roof panels and cross
beam {D3}.
L2
A1
A4 L1
[AA][AA]
[AA]× 4
[CC]× 2
[HH]× 8
[GG]× 2
[GG]
[AA]
[CC]
[GG]
[CC]
[AA]
[CC]× 2
[EE]× 2
[HH]× 2
D4
H2
[EE]
[HH]
[CC]× 2
[EE]× 2
[HH]× 2
D3
H1
[EE]
[HH]
[EE]
[HH]
[EE]
[HH]
M1
M2
M3
M4
M5
D3
D4
[CC]× 8
[EE]× 8
[HH]× 8


ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE MODEL: 
STEP 25 Use four (4) [FF]bolts to attach the electrical power cover
{P} to post {A4}.
Use two (2) [AA]bolts and two [DD]flat washers to attach the bottle
opener {N} to post {A1}.
Stick the magnetic hooks [LL]to the front cross beams and roof ribs.
(5 per side is recommended.)
STEP 26 Use four (4) [JJ]expansion bolts to anchor each post
foot base {B}. OUTDOOR STRUCTURE ANCHORING GUIDE
⚠WARNING
If your BLACKSTONE BAR & GRILL is not properly anchored,
damage could occur.
It is highly recommended for maximum safety that you mount
and secure to wood or concrete footers. This is far better and
safer than using ground stakes.
If digging for foundation, please double check for possibility of any
underground utilities such as gas, telephone, cable or sprinkler lines.
Refer to your local building and city codes, ordinances, neigh-
borhood covenants, or height restrictions regarding this type of
structure for guidance on acceptable installation requirements.
Consider consulting a licensed contractor for assistance in the
anchoring of this product.
WOOD
Anchors should be drilled into
joists or reinforced blocking (not
only deck boards).
CONCRETE
Use a " drill bit (not
included) to pre-drill holes for
concrete anchors.
[JJ]× 20
N
P
[LL]
N
[AA][DD]
P
[FF]
[
AA
]× 2
[DD]× 2
[FF]× 4
[LL]× 15

