Blackbird 15750 User manual

4K 4x4 HDMI®Matrix
PN 15750 RS-232 GUIDE

2
INTRODUCTION
This Blackbird™ device can be controlled by a computer using an RS-232 serial connection
and by issuing commands using RS-232 control software.
CONNECTION
This device includes a 3-pin Euroblock Terminal. Use this terminal to construct an RS-232
cable, which can be used to connect your PC to the matrix to allow for matrix control. The
following images show how to create and connect an RS-232 cable. If your PC lacks a DB-9
serial port, you will need to use a USB to Serial adapter cable (available separately P/N
3726).

3
SOFTWARE
This device does not include either a built-in control system or custom RS-232 control
software. If you wish to control this device from your PC using an RS-232 connection, you
will need to use a third party RS-232 control software package, such as CommWatch.exe,
whose interface is depicted below.
Set the communications parameters to the following:
Baud Rate: 115200
Data Bits: 8
Stop Bits: 1
Parity Bits: None
TCP/IP Port: 8000

4
RS-232 COMMANDS
The following guidelines apply to the RS-232 control commands.
1. The brackets [and ]in the commands are for clarity purposes to make the variable
more obvious. Do not type these symbols when typing the commands.
2. Other than the brackets, type in all commands exactly as they appear, including any
spaces. These commands are case sensitive and require the trailing exclamation
point (!) as part of the command.
3. Disconnect all HDBaseT™ receivers from the matrix/transmitter prior to performing
any of the upgrade commands.
Power Commands
Command
Function
Feedback Example
s power [z]!
Power the device on or off. (z=0~1, where
0 is off and 1 is on)
power on
System Initializing...
Initialization Finished!
power off
r power!
Displays the current power status.
power on / power off
s reboot!
Reboots the device.
Reboot...
System Initializing...
Initialization Finished!
System Commands
help!
Lists all commands
r type!
Displays the device model designation.
HDP-MXB44P

5
Command
Function
Feedback Example
r status!
Displays the current device status.
Get the unit all status:
power, beep, lock,
in/out connection,
video/audio
crosspoint, edid, scaler,
hdcp, network status
r fw version!
Displays the firmware version.
MCU FW version
x.xx.xx
r link in [x]!
Displays the connection status of input
port [x]. (x=0~4, where 0 is all ports)
hdmi input 1: connect
r link out [y]!
Displays the connection status of output
port [y]. (y=0~4, where 0 is all ports)
hdmi output 1: connect
s reset!
Resets the device to its factory default
settings.
Reset to factory
defaults
System Initializing...
Initialization Finished!
s beep [z]!
Enable or disable the buzzer function.
(z=0~1, where 0 is off and 1 is on)
beep on
r beep!
Displays the buzzer status.
beep off
s lock [z]!
Locks or unlocks the front panel buttons.
(z=0~1, where 0 is off and 1 is on)
panel button lock on
r lock!
Displays the panel button lock status.
panel button lock off
s save preset [z]!
Saves the current connection settings to
preset [z]. (z=1~4)
save to preset 1
s recall preset [z]!
Loads the connection settings from
preset [z]. (z=1~4)
recall from preset 1

6
Command
Function
Feedback Example
s clear preset [z]!
Deletes the saved connection settings of
preset [z]. (z=1~4)
clear preset 1
r preset [z]!
Displays the connection settings for
preset [z]. (z=1~4)
video/audio crosspoint
s baud rate [z]!
Sets the serial port baud rate. (z=115200,
57600, 38400, 19200, 9600, or 4800)
Baudrate: 115200
r baud rate!
Displays the serial port baud rate.
Baudrate: 115200
s id [z]!
Sets the control ID for the device.
(z=000~999)
id 888
Output Commands
s in [x] av out [y]!
Connects input [x] to output [y]. (x=1~4,
y=0~4, where 0 is all outputs)
input 1 -> output 2
r av out [y]!
Displays the connection settings for
output [y]. (y=0~4, where 0 is all outputs)
input 1 -> output 1
input 2 -> output 2
input 3 -> output 3
input 4 -> output 4
s hdmi [y] stream
[z]!
Enables or disables the stream for output
[y]. (y=0~4, where 0 is all outputs)
enable hdmi all
outputs stream
r hdmi [y] stream!
Displays the stream status for output [y].
(y=0~4, where 0 is all outputs)
enable hdmi output 1
stream
s hdmi [y] scaler
[z]!
Sets the scaler mode for HDMI® output
[y]. (y=0~4, where 0 is all outputs, z=1~3,
where 1=bypass, 2=4K -> 1080p, and
3=auto)
hdmi all outputs set to
bypass mode
r hdmi [y] scaler!
Displays the scaler mode for output [y].
(y=0~4, where 0 is all outputs)
hdmi output 1 set to
bypass mode

7
EDID® Commands
Command
Function
Feedback Example
s edid in [x] from
[z]!
Sets the EDID® for input [x] to EDID [z]
from the internal EDID table or from an
output. (x=1~4, z=1~27, where:
1. 1080p, Stereo Audio 2.0
2. 1080p, Dolby®/DTS® 5.1
3. 1080p, HD Audio 7.1
4. 1080i, Stereo Audio 2.0
5. 1080i, Dolby/DTS 5.1
6. 1080i, HD Audio 7.1
7. 3D, Stereo Audio 2.0
8. 3D, Dolby/DTS 5.1
9. 3D, HD Audio 7.1
10. 4K2K30_444, Stereo Audio 2.0
11. 4K2K30_444, Dolby/DTS 5.1
12. 4K2K30_444, HD Audio 7.1
13. 4K2K60_420, Stereo Audio 2.0
14. 4K2K60_420, Dolby/DTS 5.1
15. 4K2K60_420, HD Audio 7.1
16. 4K2K60_444, Stereo Audio 2.0
17. 4K2K60_444, Dolby/DTS 5.1
18. 4K2K60_444, HD Audio 7.1
19. 4K2K60_444, Stereo Audio 2.0 HDR
20. 4K2K60_444, Dolby/DTS 5.1 HDR
21. 4K2K60_444, HD Audio 7.1 HDR
22. User define1
23. User define2
24. Copy_From_Hdmi_Tx_1
25. Copy_From_Hdmi_Tx_2
26. Copy_From_Hdmi_Tx_3
27. Copy_From_Hdmi_Tx_4
input 2 EDID:
1080p,Stereo Audio 2.0

8
Command
Function
Feedback Example
r edid in [x]!
Displays the EDID® settings for input [x].
(x=0~4, where 0 is all inputs)
input 1 EDID:
4K2K60_444,Stereo
Audio 2.0
input 2 EDID:
4K2K60_444,Stereo
Audio 2.0
input 3 EDID:
4K2K60_444,Stereo
Audio 2.0
input 4 EDID:
4K2K60_444,Stereo
Audio 2.0
r edid data hdmi
[y]!
Displays the EDID settings for output [y].
(y=1~4)
EDID: 00 FF FF FF FF FF
FF 00 . . . . . . . . . . . . .
Audio Commands
s hdmi [y] arc [z]!
Enables or disables the Audio Return
Channel (ARC) functionality of HDMI®
output [y]. (y=0~4, where 0 is all outputs)
hdmi all outputs arc off
r hdmi [y] arc!
Displays the ARC status of HDMI output
[y]. (y=0~4, where 0 is all outputs)
hdmi output 1 arc on
CEC Commands
s cec in [x] on!
Issues a CEC Power On command to
input [x]. (x=0~4, where 0 is all inputs)
input 1 power on
s cec in [x] off!
Issues a CEC Power Off command to
input [x]. (x=0~4, where 0 is all inputs)
input 2 power off
s cec in [x] menu!
Issues a CEC Menu command to input [x].
(x=0~4, where 0 is all inputs)
input 3 open menu

9
Command
Function
Feedback Example
s cec in [x] back!
Issues a CEC Back command to input [x].
(x=0~4, where 0 is all inputs)
input 4 back operation
s cec in [x] on!
Issues a CEC Up command to input [x].
(x=0~4, where 0 is all inputs)
input 1 up operation
s cec in [x] off!
Issues a CEC Down command to input [x].
(x=0~4, where 0 is all inputs)
input 2 down
operation
s cec in [x] menu!
Issues a CEC Left command to input [x].
(x=0~4, where 0 is all inputs)
input 3 left operation
s cec in [x] back!
Issues a CEC Right command to input [x].
(x=0~4, where 0 is all inputs)
Input 4 right operation
s cec in [x] enter!
Issues a CEC Enter command to input [x].
(x=0~4, where 0 is all inputs)
input 1 enter operation
s cec in [x] play!
Issues a CEC Play command to input [x].
(x=0~4, where 0 is all inputs)
input 2 play operation
s cec in [x] pause!
Issues a CEC Pause command to input [x].
(x=0~4, where 0 is all inputs)
input 3 pause
operation
s cec in [x] stop!
Issues a CEC Stop command to input [x].
(x=0~4, where 0 is all inputs)
Input 4 stop operation
s cec in [x] rew!
Issues a CEC Rewind command to input
[x]. (x=0~4, where 0 is all inputs)
input 1 rewind
operation
s cec in [x] mute!
Issues a CEC Mute command to input [x].
(x=0~4, where 0 is all inputs)
input 2 volume mute
s cec in [x] vol-!
Issues a CEC Volume Decrease command
to input [x]. (x=0~4, where 0 is all inputs)
input 3 volume down
s cec in [x] vol+!
Issues a CEC Volume Increase command
to input [x]. (x=0~4, where 0 is all inputs)
Input 4 volume up

10
Command
Function
Feedback Example
s cec in [x] ff!
Issues a CEC Fast Forward command to
input [x]. (x=0~4, where 0 is all inputs)
input 1 fast forward
operation
s cec in [x]
previous!
Issues a CEC Previous command to input
[x]. (x=0~4, where 0 is all inputs)
input 2 previous
operation
s cec in [x] next!
Issues a CEC Next command to input [x].
(x=0~4, where 0 is all inputs)
input 3 next operation
s cec hdmi out [y]
on!
Issues a CEC Power On command to
output [y]. (y=0~4, where 0 is all outputs)
hdmi out 1 power on
s cec hdmi out [y]
off!
Issues a CEC Power Off command to
output [y]. (y=0~4, where 0 is all outputs)
hdmi out 2 power off
s cec hdmi out [y]
mute!
Issues a CEC Mute command to output
[y]. (y=0~4, where 0 is all outputs)
hdmi out 3 volume
mute
s cec hdmi out [y]
vol-!
Issues a CEC Volume Decrease command
to output [y]. (y=0~4, where 0 is all
outputs)
hdmi out 4 volume
down
s cec hdmi out [y]
vol+!
Issues a CEC Volume Increase command
to output [y]. (y=0~4, where 0 is all
outputs)
hdmi out 1 volume up
s cec hdmi out [y]
active!
Issues a CEC Active Source command to
output [y]. (y=0~4, where 0 is all outputs)
hdmi out 2 active
source

11
Network Commands
Command
Function
Feedback Example
r ipconfig!
Displays the current IP status.
IP Mode: Static
IP: 192.168.1.72
Subnet Mask:
255.255.255.0
Gateway: 192.168.1.1
TCP/IP port=8000
Telnet port=10
Mac address:
00:1C:91:03:80:01
r mac addr!
Displays the current MAC address.
Mac address:
00:1C:91:03:80:01
s ip mode [z]!
Sets the network IP mode to Static IP or
DHCP. (z=0~1, where 0 is Static IP and 1 is
DHCP)
IP mode: Static. (Please
use "s net reboot!"
command or repower
device to apply new
config!)
r ip mode!
Displays the current network IP mode.
IP mode: Static
s ip addr
xxx.xxx.xxx.xxx!
Sets the network IP address if the IP
mode is set to Static or displays an error
message if IP mode is set to DHCP.
Set IP address:
192.168.1.100
DHCP on, Device can't
config static address,
set DHCP off first.
r ip addr!
Displays the current network IP address.
IP address: 192.168.1.100

12
Command
Function
Feedback Example
s subnet
xxx.xxx.xxx.xxx!
Sets the network subnet mask if the IP
mode is set to Static or displays an error
message if IP mode is set to DHCP.
Set subnet Mask:
255.255.255.0
(Please use "s net
reboot!" command or
repower device to
apply new config!)
r subnet!
Displays the current network subnet
mask.
Subnet Mask:
255.255.255.0
s gatgeway
xxx.xxx.xxx.xxx!
Sets the network gateway if the IP mode
is set to Static or displays an error
message if IP mode is set to DHCP.
Set gateway: 192.168.1.1
DHCP on, Device can't
config static address,
set DHCP off first.
r gateway!
Displays the current network gateway.
Gateway: 192.168.1.1
s tcp/ip port [x]!
Sets the TCP/IP port. (x=1~65535)
Set TCP/IP port:8000<
r tcp/ip port!
Displays the current TCP/IP port.
TCP/IP port:8000
s telnet port [x]!
Sets the network telnet port. (z=1~65535)
Set Telnet port port:23
r telnet port!
Displays the current network telnet port.
Telnet port:23
s net reboot!
Reboots the network modules.
Network reboot...
IP Mode: Static
IP: 192.168.1.72
Subnet Mask:
255.255.255.0
Gateway: 192.168.1.1
TCP/IP port=8000
Telnet port=10
Mac address:
00:1C:91:03:80:01

13
Monoprice™, Blackbird™, the Blackbird logo, and all Monoprice logos are trademarks of
Monoprice Inc.
HDBaseT™ and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.
EDID® is a registered trademark of the Video Electronics Standards Association.
HDCP™ is a trademark of Digital Content Protection LLC.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
Dolby®, Dolby Audio™, and the double-D symbol are trademarks of Dolby Laboratories.
DTS®, the Symbol, and DTS and the Symbol together are registered trademarks of DTS, Inc.

TECHNOLOGY AT PRICES THAT MAKE SENSE
Need Help? We’re here for you!
Contact us www.monoprice.com/contactus
Product pictures are for reference only.
Specifications described herein are subject to change without prior notification.
All trademarks are the sole property of their respective companies.
Blackbird™ is a Sub-brand of Monoprice Inc.
Copyright © 2021 Monoprice, Inc. All rights reserved.
www.monoprice.com
