SINK SPECIFICATIONS
BLANCO STEELART
BLANCO PRECISION™ MICROEDGE™ SUPER SINGLE BOWL With Ledge (1 Hole)
Model 516194
FEATURED MODEL
516194 10" bowl depth
ADDITIONAL MODELS
516197 Super Single Bowl with Ledge (3 Hole)
516201 Super Single Bowl
FEATURES
• 18 gauge, 304 series stainless steel
• 18/10 chrome/nickel content
• Satinpolishednish
• Versatile design with Inset (Similar to Drop-in)
or Flushmount installation capabilities
• Polished "MicroEdge" rim with
1/4" corner radius
• Stylish drain grooves for improved functionality
• New design allows for easy installation in standard
25" countertop
CODE/STANDARDS COMPLIANCE
ASME 112.19.3-00
IAPMO/UPC listed
OPTIONAL ACCESSORIES
Sink Grid: 223-192
Colander: 224387 (Available May 2009)
Glass Cutting Board: 224390 (Available May 2009)
WARRANTY
Blanco America’s BLANCO PRECISION MICROEDGE
sinks feature a LIMITED LIFETIME WARRANTY to be free
of all manufacturing defects under normal use. See our
complete warranty for details.
While Blanco America endeavors to provide accurate
information, all dimensions are nominal, cannot be
guaranteed, and are subject to change or cancellation.
Blanco America assumes no responsibility for use of
supersededorvoidedspecications.
© 2008 BLANCO AMERICA
11/08 SPEC-003
MODEL 516194
BLANCO AMERICA
800.451.5782
www.blancoamerica.com
PRODUCT SPECIFICATION
Inset or Flushmount sink to be 32-1/2" in length
and 20-1/2" in front-to-back depth. Each sink
is handcrafted from a single panel of 18 gauge,
304 series stainless steel, with 18/10 chrome/
nickel content and satin polished nish. Sink
to feature polished "MicroEdge" 1/16" rim
with 1/4" corner radius edge and rear drain
placement. Sink to be Blanco Model 516194,
with a bowl depth of 10".
JOB INFORMATION
Job Name:
Contact:
DateSpecied:
Specier:
Contractor:
254
10
762
30
825.5
32-1/2
82.25
3-1/4
40
1-5/8
202.25
8
31.75
1-1 /4
31.75
1-1 /4
1-1/4
31.75 406
16
520
20-1/2
35
1-3/8
254
10
762
30
825.5
32-1/2
82.25
3-1/4
40
1-5/8
202.25
8
31.75
1-1/4
31.75
1-1/4
1-1/4
31.75 406
16
520
20-1/2
35
1-3/8
NOMINAL DIMENSIONS
DRAIN
MODEL OVERALL DEPTH DIAMETER
516194 32-1/2 x 20-1/2 10 3-1/2
DXF cutout templates available on our web site.
BOWL
