Blanco Precision Microedge Sinks 516195 User manual

NOMINAL DIMENSIONS
BOWL DEPTH DRAIN
MODEL OVERALL LEFT RIGHT DIAMETER
516195 33-1/2 x 20-1/2 10 10 3-1/2
DXF cutout templates available on our web site.
SINK SPECIFICATIONS
STEELART
BLANCO PRECISION™ MICROEDGE™ 1-3/4 BOWL With Ledge (1 Hole)
Model 516195
FEATURED MODEL
516195 10" bowl depths
ADDITIONAL MODELS
516198 1-3/4 Bowl with Ledge (3 Hole)
516202 1-3/4 Bowl
FEATURES
• 18 gauge, 304 series stainless steel
• 18/10 chrome/nickel content
• Satinpolishednish
• Versatile design with Inset (Similar to Drop-in)
or Flushmount installation capabilities
• Polished "MicroEdge" rim with
1/4" corner radius
• Stylish drain grooves for improved functionality
• New design allows for easy installation in standard
25" countertop
CODE/STANDARDS COMPLIANCE
ASME 112.19.3-00
IAPMO/UPC listed
OPTIONAL ACCESSORIES
Sink Grids: 223-190 (Lg), 223-189 (Sm)
Colander: 224387 (Available May 2009)
Glass Cutting Board: 224390 (Available May 2009)
WARRANTY
Blanco America’s BLANCO PRECISION MICROEDGE
sinks feature a LIMITED LIFETIME WARRANTY to be free
of all manufacturing defects under normal use. See our
complete warranty for details.
While Blanco America endeavors to provide accurate
information, all dimensions are nominal, cannot be
guaranteed, and are subject to change or cancellation.
Blanco America assumes no responsibility for use of
supersededorvoidedspecications.
© 2008 BLANCO AMERICA
11/08 SPEC-003
MODEL 516195
BLANCO AMERICA
800.451.5782
www.blancoamerica.com
PRODUCT SPECIFICATION
Inset or Flushmount sink to be 33-1/2" in length
and 20-1/2" in front-to-back depth. Each sink
is handcrafted from a single panel of 18 gauge,
304 series stainless steel, with 18/10 chrome/
nickel content and satin polished nish. Sink
to feature polished "MicroEdge" 1/16" rim
with 1/4" corner radius edge and rear drain
placement. Sink to be Blanco Model 516195,
with both left and right bowl equal depths
of 10".
JOB INFORMATION
Job Name:
Contact:
DateSpecied:
Specier:
Contractor:
254
10
202.25
8
40
1-1/2
374.25
14-3/4
82.25
3-1/4
406
16
520
20-1/2
31.75
1-1/4
31.75
1-1 /4
31.75
1-1 /4
25
1
431
17
330
13
849
33-1/2
254
10
202.25
8
40
1-1/2
374.25
14-3/4
82.25
3-1/4
406
16
520
20-1/2
31.75
1-1/4
31.75
1-1/4
31.75
1-1/4
25
1
431
17
330
13
849
33-1/2
