Blaupunkt TRAVELPILOT LUCCA 3.3 User manual

Operating Instructions
(long version)
Mobile Navigation
TravelPilot Lucca 3.3
Lucca3_3_long_GB.indd 1Lucca3_3_long_GB.indd 1 18.10.2006 15:05:18 Uhr18.10.2006 15:05:18 Uhr

2
Device Overview
Device Overview
Lucca3_3_long_GB.indd 2Lucca3_3_long_GB.indd 2 18.10.2006 15:05:19 Uhr18.10.2006 15:05:19 Uhr

3
The following button are located be-
side the display:
1. Power (Screen ON/OFF):
Long press (longer than three
seconds): Switches the power
on/off.
Short press: Switches the screen
on/off. (battery saving mode)
2. Menu:
Long press (longer than three
seconds): Opens the main menu
screen of the device.
Short press: Opens the quick set-
tings menu.
3. 3.5" LCD Touchscreen:
All entries and the control of
Lucca are carried out in a simple
and intuitive way by touching the
buttons displayed on the touch-
screen.
4. Headphone jack
5. SD card slot
6. DC power input jack
Device Overview
Lucca3_3_long_GB.indd 3Lucca3_3_long_GB.indd 3 18.10.2006 15:05:20 Uhr18.10.2006 15:05:20 Uhr

4
The underside features the following controls:
7. USB Port
8. Connects the Lucca to the suction cup
Device Overview
Lucca3_3_long_GB.indd 4Lucca3_3_long_GB.indd 4 18.10.2006 15:05:20 Uhr18.10.2006 15:05:20 Uhr

5
Contents
Device Overview ......................2
Safety notes .............................9
Safety Notes for Navigation ............ 9
Safety Notes for Handling the
Lucca .............................................. 9
Initial Startup of Lucca ..........10
Lucca Scope of Delivery ............... 10
Protective Films and Covers ......... 11
Power On/Off.........................11
Setting the Language .............12
Charging the Battery .............12
Installation in the Vehicle .....13
Attaching the Suction Cup......... 13
Removing the Suction Cup ........ 14
Installing Lucca in the Suction
Cup ............................................ 14
Removing the Lucca................... 14
Power On/Off.........................15
Power-on.................................... 15
Activating the Idle State............. 15
Power-off ................................... 15
Reactivating ............................... 15
Menu Button ..........................16
Quick Settings ........................... 16
Info ............................................ 16
Additional Functions.................. 16
Operating the Navigation
Menus.....................................17
Software Keyboard ....................... 17
Entering Blank Spaces ............... 17
Deleting Characters ................... 17
Switching between Number,
Umlaut and Character Input ...... 18
Lists .............................................. 18
Buttons ......................................... 19
Information ................................... 19
GPS Status ................................ 19
Navigation ..............................21
General Notes about the
Navigation..................................... 21
Starting the Navigation................. 21
Entering a Destination ............... 22
Navigating Home........................ 22
Showing a Map .......................... 22
Settings...................................... 22
Lucca3_3_long_GB.indd 5Lucca3_3_long_GB.indd 5 18.10.2006 15:05:21 Uhr18.10.2006 15:05:21 Uhr

6
Contents
Exiting the Menu ....................... 22
Additional Functions.................. 22
GPS Info..................................... 23
Route Planning........................... 23
Select Map................................. 23
Performing Basic Settings ............ 23
Setting the Time Zone ............... 23
Entering the Home Address ....... 24
Specifying a Destination............... 25
Entering a Destination ............... 25
Entering a Destination Country . 25
Entering a Destination Address . 26
Additional Functions ................. 27
Selecting a Point of Interest ......... 28
Point of Interest in the Current
Vicinity ....................................... 28
Additional Functions ................. 30
Point of Interest at a Specific
Location..................................... 30
Special National Destination ..... 32
Copying a Destination from
the Map......................................... 34
Moving the Map Section ............ 34
Copying the Destination from the
Favourites ..................................... 37
Copying a Favourite for
Destination Guidance ................ 37
Additional Functions ................. 38
Copying one of the Recent
Destinations.................................. 38
Additional Functions ................. 39
Using Home Address as
Destination ................................... 39
Managing Destinations ..........40
Saving Destinations ...................... 40
Saving one of the Recent
Destinations............................... 41
Renaming a Destination............. 41
Deleting a Destination ............... 42
Deleting the Complete List ........ 42
Route Planning with Stages...43
Entering Destination Points ....... 43
Editing, Saving and Managing
Routes........................................ 44
Changing the Order ................... 45
Deleting a Route Point ............... 45
Deleting a Complete Route List . 45
Lucca3_3_long_GB.indd 6Lucca3_3_long_GB.indd 6 18.10.2006 15:05:21 Uhr18.10.2006 15:05:21 Uhr

7
Contents
Managing Routes .......................... 45
Saving a route ............................ 45
Loading a route.......................... 46
Calculating a Route....................... 46
Displaying the Route on the Map. 47
Simulation (demo mode)........... 47
Specifying Route Options......47
Destination Guidance ............49
Disturbed GPS Reception.......... 50
Quitting the Destination
Guidance.................................... 50
Reaching the Place of
Destination ................................ 50
Working with the Map ...........51
Map Operation.............................. 51
Showing a Map .......................... 51
Touching the Map ...................... 51
Buttons ......................................... 52
With Map View without GPS
Reception................................... 52
With Map View with GPS
Reception................................... 52
Additional Functions.................. 54
Day/Night Mode......................... 54
Mute........................................... 54
Settings...................................... 54
Block Road, Unblocking ............. 54
Inserting an Interim Destination .. 55
Route Options............................ 55
Next Destination ........................ 55
Map Display during
Destination Guidance ............56
Navigation Tools......................... 56
Route Information...................... 57
Signpost Information ................. 57
Speed Limit ............................... 57
Showing Additional Map
Information ................................... 58
Map Information ........................ 58
Route Information...................... 59
Signpost Information ................. 59
Speed ........................................ 59
Additional Functions during
Navigation ..............................61
Inserting an Interim Destination... 61
Approaching the Next Destination .. 62
Blocking route segments .......62
Manual Blocking......................... 62
Lucca3_3_long_GB.indd 7Lucca3_3_long_GB.indd 7 18.10.2006 15:05:21 Uhr18.10.2006 15:05:21 Uhr

8
Contents
Unblocking................................. 63
Configuring Lucca/
Basic Settings ........................64
Settings ........................................ 64
Language ................................... 64
Home Address ........................... 65
Map Information ........................ 65
Route Information...................... 65
Routing Options......................... 66
Route Planning........................... 66
Signpost Information ................. 66
Speed Limit ............................... 66
Auto Mode ................................. 67
Time Zone .................................. 68
Format ....................................... 68
Representation .......................... 69
Voice command ......................... 69
Factory Settings......................... 69
Touchscreen............................... 69
Product Information .................. 70
GPS Mode of Operation ........70
MP3 Mode..............................71
Preparing the SD Card.................. 71
Inserting the SD Card ................... 71
Selecting MP3 Mode..................... 72
Starting Playback.......................... 72
Selecting a MP3 file ...................... 72
Playback the MP3 File................... 73
Repeated Play (Repeat)................ 73
Quitting Playback.......................... 73
Removing the SD Card.................. 74
Picture Viewer Mode .............74
Starting the Picture Viewer........... 74
Selecting a Picture file............... 75
Starting the Slide Show................ 75
Starting the Full Screen................ 76
Removing the SD Card.................. 77
Installing Street Maps ...........77
Removing the SD Card............... 78
Technical Data........................78
Disposal of old unit ...............79
Service ...................................79
Warranty ................................80
Fault Removal / Frequently
Asked Questions FAQ ............80
Lucca3_3_long_GB.indd 8Lucca3_3_long_GB.indd 8 18.10.2006 15:05:21 Uhr18.10.2006 15:05:21 Uhr

9
Safety notes
For your personal benefit, please
carefully read the following safety
notes and warnings before operating
your Lucca for the first time.
Safety Notes for Navigation
Caution:
Do not operate the Lucca while driv-
ing to protect yourself and others
against accidents!
View the display only if you are in a
safe travel situation!
The street routing and traffic signs
have priority over the instructions of
the navigation system.
Follow the instruction of the Lucca
only if circumstances and traffic regu-
lations allow! Lucca will bring you to
your destination even if you have to
deviate from the planned route.
Notes:
•Routes are best planned before
starting your trip. If you want to
enter a new route while on the
road, please head for the next
parking or rest area!
•If you did not understand the voice
information or if you are not sure
what to do at the next intersec-
tion, use the map or arrow display
for quick orientation.
Safety Notes for Handling
the Lucca
Caution:
Protect the device against moisture
since it is not waterproof and not
splashproof.
Notes:
•Remove the power supply connec-
tor of the Lucca if you switch off
Safety notes
Lucca3_3_long_GB.indd 9Lucca3_3_long_GB.indd 9 18.10.2006 15:05:21 Uhr18.10.2006 15:05:21 Uhr

10
the engine since the GPS receiver
constantly uses electricity and
could discharge the vehicle bat-
tery.
•Do not unplug the connector by
pulling on the wire. The wire could
be damaged!
•Do not use harsh solvents to clean
the device; use only a damp, lint-
free cloth.
Initial Startup of Lucca
If you are starting up the Lucca for
the first time, you must set your pre-
ferred language for the menus and
the voice output.
Note:
Upon purchasing the Lucca the
battery maybe empty. Please
charge the battery before using
the device.
When starting up the Lucca for the
first time please allow the unit a
few minutes to enter navigation
mode.
Lucca Scope of Delivery
The scope of delivery contains the
following components:
•Lucca Unit
•Suction Cup
•Connector charger for connecting
to cigarette lighter (Cigar Plug)
•User's Manual (short version)
Safety notes Initial Startup
Lucca3_3_long_GB.indd 10Lucca3_3_long_GB.indd 10 18.10.2006 15:05:22 Uhr18.10.2006 15:05:22 Uhr

11
•CD/DVD with european road map
and operating instructions (long
versions)
Optional Accessories:
• Carrying Case
• DC Adapter
• USB Cable
•Second car kit
• VAN/SUV Suction Cup
• Holder for air vent opening
Protective Films and Covers
Prior to the initial use, remove the
protective films from the display and
front of the housing. Before inserting
an SD card, please remove the dum-
my card. To protect the contacts, you
can apply the elastic cover and dum-
my card again after using the Lucca.
Power On/Off
The Power button allows for turning
the Lucca on or off. In its delivery
state, the Lucca is switched off.
Press the Power button on the
bottom left-hand corner of the
Lucca for longer than three sec-
onds.
➜
Initial Startup Power on/off
Lucca3_3_long_GB.indd 11Lucca3_3_long_GB.indd 11 18.10.2006 15:05:22 Uhr18.10.2006 15:05:22 Uhr

12
Setting the Language
If the Lucca is switched on for the
first time, US English is used as the
standard language. If necessary, you
may have to set the desired language
for the menus and the voice output:
Turn on the Lucca using the
Power button.
A dialogue menu displays. In this
menu you can select your pre-
ferred language.
➜ Please follow the instructions.
The language is loaded and the
main menu is displayed.
➜
Charging the Battery
The rechargeable battery allows for
operating the Lucca battery-operated
without the external power supply.
The charge indicator of the battery
is located in the top center of the
screen. The symbols have the follow-
ing meaning:
– : The device is supplied by
an external power source. The
battery is fully charged.
– : The device is supplied by
an external power source. The
battery is being charged.
– : The device is supplied by
its internal battery. The charge
state of the battery is suffi-
cient.
– : The device is supplied by
its internal battery. The charge
state of the battery is low.
The number of dark block segments
on the battery indicates the charge
Setting the Language Charging the Battery
Lucca3_3_long_GB.indd 12Lucca3_3_long_GB.indd 12 18.10.2006 15:05:22 Uhr18.10.2006 15:05:22 Uhr

13
state of the battery (0 to 3 seg-
ments).
Note:
If the charge state of the battery
is very low, a warning message is
displayed.
To charge the battery, attach the
supplied charger to the charging
socket.
Note:
Use only original chargers for op-
erating and charging the battery.
Note:
Do not discard any batteries in the
household trash; instead, return
them to the corresponding collec-
tion sites.
➜
Installation in the
Vehicle
For temporary installation in a vehi-
cle, the Lucca features a suction cup
to attach it to the windshield.
Caution:
Install the Lucca so that it does not
block your view and does not distract
from the traffic.
Do not install the Lucca in the airbag
deployment area.
Ensure that the Lucca does not pose
a threat to passengers in the vehicle
in case of emergency braking.
Attaching the Suction Cup
The Lucca can be installed in the ve-
hicle in a simple and safe way using
the supplied suction cup.
Locate a suitable place for install-
ing the Lucca.
To ensure a perfect hold, the glass
must be free of dust and oil. If nec-
essary, clean the glass first.
➜
➜
Charging the Battery Installation in the Vehicle
Lucca3_3_long_GB.indd 13Lucca3_3_long_GB.indd 13 18.10.2006 15:05:22 Uhr18.10.2006 15:05:22 Uhr

14
Press the suction plate of the sup-
port against the glass.
Push the lever on the suction cup
towards the glass.
The track for mounting the Lucca
must be aligned vertically.
Removing the Suction Cup
If you change vehicles, you can simply
remove the suction cup.
Push the lever on the suction cup
away from the glass.
Carefully loosen the suction plate
at the edge from the glass so that
air can enter between suction cup
and glass.
Carefully pull the suction cup off
of the glass.
➜
➜
➜
➜
➜
➜
Installing Lucca in the Suction Cup
The suction cup features a track for
mounting the Lucca on the inside.
Carefully push the guide of the
Lucca over the track of the suc-
tion cup.
Removing the Lucca
Pull the Lucca up and out of the
suction cup.
➜
➜
Installation in the Vehicle
Lucca3_3_long_GB.indd 14Lucca3_3_long_GB.indd 14 18.10.2006 15:05:22 Uhr18.10.2006 15:05:22 Uhr

15
Power On/Off
Power-on
To power on the Lucca, push the
Power button.
The device switches on and dis-
plays the logo screen.
Activating the Idle State
To activate the idle state, briefly
push the Power button.
The Lucca switches to the idle
state (screen off state).
Power-off
To power off the device, press and
hold the Power button for longer
than 4 seconds.
The Lucca is switched off.
Note:
In the power-off mode the Lucca
is still using small amount of en-
ergy from the battery. After long
period of time there is a possibil-
ity that the battery may need to be
re-charged.
➜
➜
➜
Reactivating
Briefly push the Power button to
power on the Lucca.
➜
Power on/off
Lucca3_3_long_GB.indd 15Lucca3_3_long_GB.indd 15 18.10.2006 15:05:23 Uhr18.10.2006 15:05:23 Uhr

16
Menu Button
Quick Settings
In the Quick Settings menu volume
and brightness can be adjusted. The
Quick Settings menu can be entered
at any time independent of the cur-
rent menu being active.
Touch the Menu button.
The Quick Settings menu displays.
Touch the / buttons to adjust
volume or brightness.
✚ Touch this button to re-
turn to the previous menu.
Note:
After 5 seconds without touching
the display Lucca returns automat-
ically to the previous menu.
Info
Prerequisite:
• A Navigation is active.
Touch the Info button in the Quick
Settings menu.
The last voice instruction is re-
peated.
➜
➜
➜
➜
Additional Functions
Touch the More button in the
Quick Settings menu to gain ac-
cess to additional functions.
• Information
– Touch the Information button
to gain access to product infor-
mation.
• Battery
– Touch the Battery button.
The battery status displays.
• Power Saving
– Touch the Power Saving but-
ton. The Power Saving menu
displays.
– Backlight Time Out: Touch the
square on the right side to set
the time until the backlight will
be switched off after the last
operation (for battery saving).
Press the OK button to con-
firm.
– Battery Warning Time Out:
Touch the square on the right
side to set the timing for the
battery warning. The battery
warning will be displayed ac-
➜
Menu Button
Lucca3_3_long_GB.indd 16Lucca3_3_long_GB.indd 16 18.10.2006 15:05:23 Uhr18.10.2006 15:05:23 Uhr

17
cordingly before the battery
runs out. Press the OK button
to confirm.
Operating the
Navigation Menus
Software Keyboard
If text entries are required, the touch-
screen displays a software keyboard.
You can perform all entries using your
finger. Only capital letters can be en-
tered.
You do not have to enter any special
characters or umlauts when entering
city or street names. The Lucca com-
pletes these characters automati-
cally.
Entering Blank Spaces
To enter a blank space, touch the
button.
Deleting Characters
To delete the last character, touch
the button.
➜
➜
Menu Button Operating the Navigation Menus
Lucca3_3_long_GB.indd 17Lucca3_3_long_GB.indd 17 18.10.2006 15:05:23 Uhr18.10.2006 15:05:23 Uhr

18
Switching between Number, Umlaut
and Character Input
To enter numbers, such as postcode,
touch the button
To return to the character entry
mode,
touch
To enter an umlaut,
touch the button. The umlaut
keyboard is displayed.
As soon as you enter an umlaut,
the character keyboard is auto-
matically displayed again.
Note:
Umlauts do not have to be en-
tered when entering address
information, but they may be
helpful for the description of
stored destinations and routes.
➜
➜
➜
List
In many cases, you can display lists
from which you can select an entry.
This is the case, for example, if you
do not enter the complete name of a
place during the entry. After every en-
try of a letter, the text field shows the
first entry that starts with the previ-
ously entered characters. To display a
list with additional matching entries,
touch the List button.
The end of the list features entries
what contain the sequence of previ-
ously entered characters not at the
beginning, but in the middle or at the
end.
One entry of the list is always se-
lected.
The selected entry can be selected
by touching the OK button.
These lists contain the following but-
tons:
: Touch the OK button to
accept the selected entry. Howev-
➜
➜
Operating the Navigation Menus
Lucca3_3_long_GB.indd 18Lucca3_3_long_GB.indd 18 18.10.2006 15:05:23 Uhr18.10.2006 15:05:23 Uhr

19
er, you can also directly touch an
entry to accept it.
:Touch this button to scroll
up in the list by one page (5 ele-
ments).
: Touch this button to scroll
down in the list by one page
(5 elements).
To scroll through the list by several
pages, repeatedly touch the corre-
sponding button.
Note:
If the list features more than 5 ele-
ments, the scroll bar indicates the
current position in the list.
: Touch this button to return
to the entry without selecting a
list element.
Buttons
Buttons are located on all menus of
the Lucca:
: Touch this button to return
to the previously opened menu.
If you are in the Navigation menu,
this button takes you to the Blau-
➜
➜
➜
➜
➜
punkt start screen. Here, you can
open another application, such
as the MP3 player or the Picture
Viewer, or reopen the navigation.
More: Touch this button to obtain
access to additional functions. De-
pending on the menu in which this
button is located, different func-
tions are offered.
If this button is deactivated, no ad-
ditional functions are available.
Information
From the Navigation menu, you can
display the current GPS status at any
time.
GPS Status
The GPS status menu contains infor-
mation about your current position
and your current speed. In addition,
you can also save your current posi-
tion.
In the Navigation menu, touch the
More button.
The following window displays:
➜
➜
Operating the Navigation Menus
Lucca3_3_long_GB.indd 19Lucca3_3_long_GB.indd 19 18.10.2006 15:05:24 Uhr18.10.2006 15:05:24 Uhr

20
Touch the GPS Info button.
The GPS Status menu displays.
•GMT: Greenwich Mean Time Lon-
don time without daylight savings
time.
•Longitude/Latitude, current Posi-
tion: Information of the east longi-
tude and north latitude.
➜
•Satellites: Number of satellites
received. The navigation requires
signals from at least three satel-
lites.
•HDOP: Horizontal Dilution of Pre-
cision. Indicates the quality of the
positioning. Theoretically, values
from 0 to 50 are possible, whereby
the following applies: The lower
the value, the more precise the
positioning (value 0 = no deviation
from the actual position). Values
up to 8 are acceptable for naviga-
tion.
•Speed: Indicates the current
speed of the vehicle.
•Position: Indicates the address of
the current position (if possible).
•Save current position: Touch this
button to save the current posi-
tion to the favourites.
•Touch the button to close the
GPS window.
Operating the Navigation Menus
Lucca3_3_long_GB.indd 20Lucca3_3_long_GB.indd 20 18.10.2006 15:05:24 Uhr18.10.2006 15:05:24 Uhr
