CONTROLS
i
[v button to release the control
panel.
Button to switch the unit on/off.
Volume control.
CD compartment.
Arrow buttons.
MENU button to open the basic
settings menu.
Short press: SOURCE button, to
select the CD, radio and CD
changer sources.
Long press: CD eject.
AUDIO button to adjust the
bass, treble, balance and fader
settings.
Short press: EQ button to select
the sound presets.
Long press: X-BASS, X-Bass
function.
Keys 1 - 6.
Short press: BAND button to
select the FM memory bank
and the AM waveband, source
selection to radio mode.
Long press: TS, starts the
Travelstore function.
@ button to display the time.
4 0 BLAUPl4NKl

CONTENTS k
Notes and accessories ............ 6
Road safety ..................................... 6
Installation ....................................... 6
Accessories .................................... 6
Removable control panel ......... 7
Theft protection ............................... 7
Detaching the control panel ............. 7
Attaching the control panel .............. 7
Switching on/off ...................... 8
Adjusting the volume ............... 9
Setting the power-on volume ........... 9
Instantaneously reducing
the volume (mute) ............................ 9
Mute while telephoning .................... 9
Radio mode.. .......................... 10
Switching to radio mode ................ 10
Selecting the frequency band I
memory bank.. ............................... 10
Tuning into a station ....................... 10
Setting the sensitivity of station
seek tuning.. .................................. 10
Storing station presets.. ................. 10
Storing stations automatically
(Travelstore) .................................. 11
Listening to station presets ............ 11
CD mode.. .............................. 11
Switching to CD mode .................. 11
Selecting tracks ............................ 12
Fast track selection ....................... 12
Fast searching (audible) ................ 12
Random track play (MIX) ............... 12
Scanning tracks (SCAN) ............... 12
Repeating tracks (Repeat) ............. 12
Pausing playback (PAUSE) ............ 13
Removing the CD from the unit.. .... 13
CD changer mode.. ................ 13
Switching to CD changer mode ..... 13
Selecting CDs.. ............................. 13
Selecting tracks ............................ 13
Fast searching (audible) ................ 14 Ill
Repeating individual tracks or
whole CDs (REPEAT). ................... 14
Random track play (MIX) ............... 14
Scanning all tracks on all CDs
(SCAN) ......................................... 14
Pausing playback (PAUSE) ............ 15
Clock - Time ........................... 15
Displaying the time ........................ 15
Setting the clock ........................... 15
Selecting 12/24-hour clock mode . 15
Displaying the time when the unit
is off and the ignition is on ............. 16
Sound and volume
distribution settings ............... 16
Adjusting the bass ......................... 16
Adjusting the treble ....................... 16
Adjusting the balance settings ....... 17
Adjusting the fader settings ........... 17
Equalizer and X-BASS ........... 18
X-BASS ........................................ 18
Selecting preset sound effect ........ 18
Specifications ........................ 18
Amplifier ........................................ 18
Tuner ............................................. 18
CD ................................................ 18
Pre-Amp Out ................................. 18
Installation instructions.. ........ 65
l BLAUPUNKT
5

NOTES AND ACCESSORIES !
/ A
Thank you for deciding to use a
Blaupunkt product. We hope you enjoy
using this new piece of equipment.
Please read these operating instructions
before using the equipment for the first
time. The Blaupunkt editors are con-
stantly working on making the operat-
ing instructions clearer and easier to
understand. However, if you still have
any questions on how to operate the
equipment, please contact your dealer
or the telephone hotline for your coun-
try. You will find the hotline telephone
numbers printed at the back of this
booklet.
Installation
If you want to install your car radio by
yourself, please read the installation and
connection instructions that follow these
operating instructions.
Accessories
Only use accessories approved by
Blaupunkt.
Remote control
The supplied RC 04 remote control al-
lows you to operate the main functions
of your car radio safely and conveniently
(only with the Las Vegas CD32).
The RC 04 remote control is optionally
available for the Santa Fe CD32 unit.
The San Diego CD32 unit cannot be
remotely controlled.
Amplifier
All Blaupunkt and Velocity amplifiers can
be used.
CD changer
The Blaupunkt CD changer CDC A 01
(7607 700 022) can be connected to the
Las Vegas CD32 unit. No CD changer
can be connected to either the San Di-
ego CD32 or the Santa Fe CD32 units.
6 ~ 0 BLAUPUNKT

REMOVABLE CONTROL PANEL 1
Removable control panel
Theft protection
As a way of protecting your equipment
against theft, the unit is equipped with
a detachable control panel (release
panel). Without this control panel, the
car radio is worthless to a thief.
Protect your equipment against theft by
taking the control panel with you every
time you leave your vehicle. Do not
leave the control panel in your vehicle -
not even in a hiding place.
The control panel has been designed
to be easily to use.
Note:
. Never drop the control panel.
. Never expose the control panel to
direct sunlight or other heat
sources.
. Avoid making direct skin contact
with the control panel’s contacts. If
necessary, clean the contacts with
a lint-free cloth and some alcohol.
Detachins the control panel
0 Press the [V button 01.
The control panel locking mechanism
opens.
I First, pull the control panel straight
off the unit and then out towards
the left.
The unit switches off after the
control panel is removed.
All current settings of the radio are
saved.
CD already inserted in the unit
remains there.
Attachinq the control Dane1
c
0
Slide the control panel from left to
right into the unit’s guide.
Press the left-hand edge of the
control panel into the unit until it
clicks into place.
:- #. c’/
0
t b
Note:
o When attaching the control panel,
make sure you do not press on the
display.
If the unit was still switched on when
you removed the control panel, the unit
will automatically switch back on with
the last settings activated i.e. radio, CD
or CD changer (CD changer only with
the Las Vegas CD32) when the panel
is reinserted.
0 BLAUPUNKT
7

SWITCHING ON/OFF
Switching on/off
Switching on by inserting a CD
There are various ways of switching the If the unit is switched off and there is no
unit on/off: CD inserted in the drive,
Switching on/off using the vehicle
ignition
If the unit is correctly connected to the
vehicle’s ignition and itwas not switched
off using button 0, it will switch on/off
simultaneously with the ignition.
Switching on/off using the
removable control panel
0 Remove the control panel.
The unit switches off.
0 Attach the control panel again.
The unit switches on. The last settings
i.e. radio, CD or CD changer (CD
changer only with the Las Vegas CD32)
will be reactivated.
Switching on/off using button @
0 To switch the unit on, press button
@
The unit can only be switched on when
the ignition is turned on.
0 To switch the unit off, press button
@for longer than two seconds.
The unit switches off.
0 gently insert the CD with the
printed side uppermost into the
drive until you feel some resis-
tance.
The CD is drawn into the drive automati-
cally.
You must not obstruct or assist the drive
as it draws in the CD.
Once the CD has been drawn in, the
unit switches on again.
8 l BLAUPUNKT

ADJUSTING THE VOLUME 1,
Adjusting the volume
The system volume can be adjusted in
steps from 0 (off) to 100 (maximum).
To increase the system volume,
D turn the volume control @ clock-
wise.
To decrease the volume,
0 turn the volume control @ anti-
clockwise.
Settina the Dower-on volume
You can set the units default power-on
volume.
0 Press the MENU button 0.
0 Keep pressing the iX or Y button
@ until “ON VOL” appears in the
display.
0 Set the power-on volume using the
< and > buttons 0.
To help you adjusting the volume more
easily, the volume will be increased /
decreased as you make your changes.
When you have finished making your
changes,
0 press the MENU button @twice.
lnstantaneouslv reducinq the
volume (mute)
You can instantaneously reduce the
volume (mute) to a level preset by you.
0 Briefly press button 0.
“MUTE” appears in the display.
Setting the mute level
You can set the unit’s mute volume level.
0 Press the MENU button 0.
D Keep pressing the X or Y button Ill
@ until “MUTE LVL” appears in
the display.
0 Set the mute level using the < and
> buttons 0.
When you have finished making your
changes,
0 press the MENU button @twice.
Mute while telephoning
Ifyour unit is connected to a mobile tele-
phone, the car radio’s volume will be
muted as soon as you “pick up” the tele-
phone. “TEL CALL” flashes in the dis-
play.
This requires to the mobile telephone
be connected to the car radio as de-
scribed in the installation instructions.
The volume will be reduced to the con-
figured mute volume level.
0 BLAUPUNKT 9

RADIO MODE
Radio mode
Settino the sensitivitv of station
Switchina to radio mode seek tuning
If you are in CD or CD changer mode You can choose whether to tune only
(CD changer only with the Las Vegas to strong reception stations or to also
mnon\ tune to those with a weak reception.
bV.x),
0 keep pressing the SOURCE @ 0 Press the hiIENU button 0.
button until the radio mode - 0 Keep pressing the Y or X button
appears in the display together with @ until “SENS Ht” or “SENS LO”
the memory bank and frequency. appears in the display
Selectina the freauencv band /
memorv bank
This unit can receive programs broad-
cast over the FM and AM frequency
band. There are three preset memory
bank for the FM range and one for the
AM range. Six stations can be stored
on each memory bank.
Selecting the FM memory bank
Toswitch between the FM memory bank
FM1 , FM2 and FMT,
0 press the BANDITS button @.
Selecting the AM waveband
To select the AM waveband,
“SENS HI” means that the tuner is set
high to sensitivity. “SENS LO” means it
is set to the low sensitivity setting. If
“SENS LO” is selected, “LOC” lights up
in the display.
0 Set the required sensitivity using
the < and > buttons 0.
When you have finished making your
changes,
0 press the MENU button 0.
Tuning into stations manually
You can also tune into stations manu-
ally.
0 Press the < or > button @
0 keep pressing the BANDITS button Storing station oresets
@ until AM appears in the display. Storing stations manually
Tuning into a station 0 Select the required memory bank
There are various ways of tuning to a (FM1 , FM2 or FMT) or the AM
station. waveband.
Automatic seek tuning D Tune into the station.
0 Press the Y or 7I button @. 0 Press one of the station buttons
The unit tunes to the next receivable l-6 @for longer than one second
station. to store the station in that preset
memory.
10
0 BLAUPUNKT

RADIO MODE CD MODE 1 ‘h
Storinq stations automatically
(Travelstore)
You can automatically store the six sta-
tions with the strongest reception in the
region. The stations are stored in the
FMT or AM memory depending on the
selected frequency band.
Note:
. Any stations that were previously
stored on this memory bank are
deleted in the process.
0 Press and hold the BANDmS
button @ until seek tuning begins.
The station storing procedure begins.
Once the procedure finishes, all the
stored stations are played briefly.
Listening to stat@ r>resets
0 Select the memory bank on which
the station was stored.
0 Press the preset station button 1-6
@ of the station you want to listen
to.
CD mode
You can use this unit to play standard
CDs with a diameter of 5 inches.
A Risk of severe damage to the II
CD drive!
CD singles with a diameter of
3 inchesandcontouredCDs (shape
CDs)arenotsuitablefor playbackin
th8sunit.
CDs.
Switching to CD mode
l If there is no CD inserted in the
drive.
0 Gently insert the CD with the
printed side uppermost into the CD
compartment until you feel some
resistance.
The CD is drawn into the drive automati-
cally.
Do not use force when inserting the CD.
You must not obstruct or assist the drive
as it draws in the CD.
CD playback begins.
l If a CD is already inserted in the
drive.
0 Keep pressing the SOURCE@
button until the CD mode display
appears.
Playback begins from the point at which
it was last interrupted.
0 BLAUPUNKT 11

1
CD MODE
Selectinn tracks
0 Pressoneofthe7V>or</Y
buttons @to select the next or
previous track.
If you press the < / Y button @ once,
the current track will be played again
from the beginning.
Fast track selection
To quickly select tracks backwards or
forwards,
D keep one of the Y IX buttons @
pressed until fast-reverse /fast-
forward track selection begins.
Fast searching (audible)
To fast search backwards or forwards,
0 keep one of the < > buttons @
pressed until fast searching
backwards I forwards begins.
Random track olav (MIX)
0 Press button 4 (MIX) @.
“S--MIX” and the track number appears
in the display. The next randomly se-
lected track will then be played.
Canceling MIX
0 Press button 4 (MIX) @ again.
The standard CD display appears.
Scanninn tracks (SCAN)
You can play briefly all the tracks on the
CD.
0 Press button 2 (SCAN) @).
Setting the scantime
You can set the scanning time to be-
tween 5 and 30 seconds in the menu.
0 Press the MENU button 0.
0 Keep pressing the 7I or Y button
@ until “SCANTIME” appears in
the display.
0 Set the required scantime using
the < and > buttons 0.
When you have finished making your
changes,
0 press the MENU button @twice.
Note:
l The set scantime also applies to
scanning in CD changer mode.
Stopping SCAN and continuing
playback
To stop scanning,
0 press button 2 (SCAN) @ again.
The current track will then continue to
be played.
Reoeatinn tracks (REPEAT)
If you want to repeat a track,
0 press button 3 (RPT) @.
“S--RPT’ and the track number appears
in the display. The track is repeated until
you deactivate RPT.
Deactivating REPEAT
Ifyou want to deactivate the repeat func-
tion,
0 press button 3 (RPT) @ again.
The standard CD display appears. Nor-
mal playback is then resumed.
12 l BLAUPUNKT

CD MODE
Pausing plavback (PAUSE)
0 Press button 1 A, 0.
“S--PAUSE” appears in the display.
Canceling pause
Q Press button 2 IF @ while in
pause mode.
Playback is resumed.
Removina the CD from the unit
To remove the CD from the unit,
0 keep the SOURCE button @
pressed until the CD is ejected.
CD CHANGER MODE 1:
CD changer mode
You can connect a CD changer to the
Las Vegas CD32 unit. You can obtain
further information on available CD I
changers from your dealer.
Note:
l Information on handling CDs,
inserting CDs and operating the
CD changer can be found in the
operating instructions supplied with
your CD changer.
Switchina to CD changer mode
0 Keep pressing the SOURCE@
button until the display shows, for
instance, “CDC 1--I”.
The first digit in this display represents
the CD number (in this case l), and the
second digit represents the track num-
ber (in this case 1).
Playback begins with the first CD that
the CD changer detects.
Selectinn CDs
To move up or down to another CD,
0 press the X or Y button @ once or
several times.
Selecting tracks
To move up or down to another track
on the current CD,
0 press the > or < button @ once or
several times.
9 BLAUPUNKT
13

CD CHANGER MODE
Fast searchina (audible)
To fast search backwards or forwards,
0 keep one of the < > buttons @
pressed until fast searching
backwards I forwards begins.
Reoeatina individual tracks or
whole CDs (REPEAT)
To repeat the current track,
0 briefly press button 3 (RPT) 0.
“S--RPT” appears briefly in the display.
To repeat the current CD,
0 keep the 3 (RPT) button @
pressed for longer than two
seconds.
“D--RPT” appears briefly in the display.
Deactivating REPEAT
To stop the current track or current CD
from being repeated,
0 press button 3 (RPT) @ until
“S--RPT” or “D--RPT” disappears
and the standard CD changer
display reappears.
Random track olav (MIX)
To play the tracks on the current CD in
random order,
0 briefly press button 4 (MIX) @.
“S--MIX” appears briefly in the display.
To play the tracks on all inserted CDs in
random order,
0 keep the 4 (MIX) button @
pressed for longer than two
seconds.
“D--MIX” appears briefly in the display.
Canceling MIX
To stop the tracks from being played in
random order,
0 press button 4 (MIX) @ until
“S-MIX” or “D--MIX” disappears
and the standard CD changer
display reappears.
Scanning all tracks on all CDs
(SCAN)
Scanning tracks on the current CD
To briefly play all the tracks on the cur-
rent CD in ascending order,
0 press button 2 (SCAN) @).
“S--SCN” appears in the display.
Scanning the first track on all CDs
You can briefly play the first track all CDs
in the CD changer.
0 keep the 2 (SCAN) button @
pressed for longer than two
seconds.
“D--SCAN” appears in the display.
14 0 BLAUPUNKT

CD CHANGER MODE CLOCK - TIME
Stopping SCAN
To stop scanning,
0 briefly press the 2 (SCAN) button
@ again.
The currently scanned track will then
continue to be played normally.
Note:
. You can set the scanning time
(scantime). For further details, read
the section entitled “Setting the
scantime” in the “CD mode”
chapter.
CLOCK - Time
Displavinn the time
To display the time,
0 briefly press the 8 button 0.
Settinq the clock
0 Press the MENU button 0.
0 Keep pressing the K or Y button
@ until “CLOCKSET” appears in
the display.
0 Press the > button 0.
Pausinq plavback (PAUSE)
0 Press button 1 (IIF)@.
The time appears in the display. The
minutes flash on and off and can be
adiusted.
’
“S--PAUSE” appears in the display.
Canceling pause
0 Adjust the minutes using the 77N
buttons @
0 Press button 2 (I,) @while in
pause mode.
Playback is resumed.
Once the minutes are set,
0 press the <button @.
The hours flash on and off.
0 Adjust the hours using the 7V Y
buttons @.
When you have finished making your
changes,
0 press the MENU button ($,I twice.
Selectino 12/24-hour clock
mode
0 Press the MENU button @.
0 Keep pressing the K or Y button
@ until “24 H MODE” or “12 H
MODE” appears in the display.
0 Press the < or > button @ to
switch between the modes.
l BLAUPUNKT
15

CLOCK - TIME SOUND AND VOLUME 1
DISTRIBUTION SETTINGS
When you have finished making your Sound and volume
changes,
0 press the MENU button 0.
DisPlavina the time when the
distribution settings
Jtian settings
Adiustina the bassgothe bass
AL-^nrcr.2
unit is off and the innition is on
To adjust the BASS,
To disolav the clock when the unit is off 0 press the
AUDIO button 0.
and the ignition is on,
the AUDIO button 0.
“BAS” appears in the display.
press the MENU button 0. To increase the bass,!the bass,
Keep pressing the 77or Y button 0 turn the volume control @ clock-volume control @ clock-
@ until “CLOCK OFF” or “CLOCK wise.
ON” appears in the display. To decrease the bass,e the bass, .^.A
Press the < or > button @ to 0 turn the volume control u antl-
switch between the displays. clockwise.
When you have finished making your When you have finished making your
changes, changes
0 press the MENU button 0. 0 wait 8 seconds, the settings are
saved and the audio source display
appears.
Adiustinn the treble
To adjust the TREBLE,
0 keep pressing the AUDIO @
button until “TRE” appears k the
display.
To increase the treble,
0 turn the volume control 9 clock-
wise.
To decrease the treble,
0 turn the volume control @ anti-
clockwise.
When you have finished making your
changes,
0 wait 8 seconds, the settings are
saved and the audio source display
appears.
16 - 0 BLAUPUNKT

To move the volume distribution toward
Adiustinn the balance settings
the right,
To adjust the left/right volume distribu-
tion (balance),
0 turn the volume control @ clock-
0 keep pressing the AUDIO @
wise.
button until “BAL” appears in the
display.
To move the volume distribution toward
the left,
0 turn the volume control @ anti-
clockwise.
When you have finished making your
changes,
0 wait 8 seconds, the settings are
saved and the audio source display
appears.
SOUND AND VOLUME 1
DISTRIBUTION SETTINGS i
Adiustina the fader settings
To adjust the front/back volume distri-
bution (fader), Ill
To move the volume distribution toward
the back,
0 turn the volume control @ clock-
wise.
0 keep pressing the AUDIO @
button until “FAD” appears in the
display.
To move the volume distribution toward
the front,
0 turn the volume control @ tanti-
clockwise.
When you have finished making your
changes,
0 wait 8 seconds, the settings are
saved and the audio source display
appears.
l BLAUPUNKT
17

EQUALIZER AND X-BASS SPECIFICATIONS
Equalizer and X-BASS Specifications
X-BASS Amplifier
The X-BASS feature can be used to Output power:
boost the bass at low volume levels. Las Vegas CD32: 4 x 22 watts sine
To activate X-BASS,
D keep the EWX-BASS button @
pressed until “XBASS ON” appears
in the display.
“X-BASS” appears in the display.
To deactivate X-BASS,
0 keep the EWX-BASS button @
pressed until “XBASS OFF”
aooears in the displav.
San Diego CD32:
in accordance
with DIN 45 324
at 14.4 V 4 x 50
watts max. power
4 x 15 watts sine
in accordance
9~ I . _
“X-BASS” disappears.
with DIN 45 324
at 14.4V4x40
watts max. power
Santa Fe CD32: 4 x 18 watts
Sine
in accordance
with DIN 45 324
Selectinn preset sound effect
at 14.4V4x45
You can select preset sound effect for watts max. power
the following styles of music:
Tuner
0 CLASSIC Frequency ranges US:
l POPM
l ROCKM
FM:
AM: 87.5 - 107.9 MHz
530 - 1710 kHz
The settings for these music styles have FM mono sensitivity:
already been programmed. 15dBf
To select one of the sound presets,
0 keep pressing the ECU%BASS
FM frequency response:
button @ until the required setting 35 - 16,000 Hz
appears in the display. CD
If you want to deactivate the sound pre- Frequency response:
set, 20 - 20,000 Hz
0 keep pressing the EQIX-BASS
button @ until “DSP OFF” appears
Pre-Amr> Out
in the display. (not applicable to San Diego CD32)
output: 1.5 Vrms+2.5 dB
Subject to changes!
18
0 BLAUPUNKT

Installation instructions l Notice de montage l !
lnstrucciones de instalach l Instruqbes de montagem
0 A Indications de s&wit6
Consignes de montage et de I
@ A Safety precautions
Installation and connection
regulations branchement
- In the event that this equipment is
installed or repaired incorrectly, this
could cause malfunctions in the
vehicle electronics.
- To avoid causing damage to your
radio, use the corresponding
Blaupunkt adapter cable to connect
the 8-pin +/- IS0 plug in the
vehicle.
- En cas d’erreur d’installation ou I
d’entretien, des perturbations
peuvent survenir au niveau des
systemes electroniques du I .
’
vehicule. .
- Pour ne pas deteriorer votre
autoradio, branchez le connecteur
IS0 +/- 8 poles du vehicule I
;
While installing and connecting
this equipment, please observe the
following safety notes:
- Disconnect the negative battery
termina.
- Observe the car manufacturer’s
safety instructions.
- If you drill any holes, make sure
that you do not damage any parts
of the vehicle.
uniquement via un cable adapta-
teur Blaupunkt correspondant.
Pendant le montage et le branche- :
ment, observe2 les consignes de I ’
.&curitk suivantes :
- Debrancher le pole (-) de la
batterie.
- Observer ce faisant les indications
de securite du constructeur
automobile.
- The diameter of the positive/
negative cable must not be less
than 1.5 mm*.
- Veiller a ne pas endommager les
pieces du vehicule en percant des
trous.
- La section transversale du cable
(+) et (-) ne doit pas etre inferieure
ti 15 mm*.
0 BLAUPUNKT 65

Supplied Mounting Hardware
Materiel de montage fourni
Ferreteria de montaje
suministrada
Elementos de fixa@o
‘ornecidos
only
Las Vegas CD32
1.
A
! - I
I
,
.
P
;
I
t
2.
Bend as many taps as possible.
Plier si possible toutes les attaches.
Lo ideal es poder doblar todas las bridas
de sujeci6n.
Devem ser dobradas o maxim0 possivel
de braqadeiras.
0 BLAUPlJiVKT 67
