Blaupunkt CDC A071 User manual

Einbauanleitung 5edienu~gsan~eitung
Fitting Instructions
Operation instructions
instructions de montage
Mode d’emploi
lstruzioni di montaggio struzioni d’uso
Inbouwinstrukties uiksaanwijzing
Monteringsanvisning Bruksanvisning
lnstrucciones de montaje
lnstrucciones de manejo
Instru@es de montagem
Instru@fio de serviG0

English
Preparatory steps
Loading the disc magazine
Figure 1
To load the magazine, move it into the position
shown in the picture (arrow up).
Pull out the empty tray.
To be sure that all trays are correctly loaded with
the right orientation, never remove more than one
disc tray at a time.
Insert one CD per tray with the labelling facing up.
Insert the tray with the disc into the magazine until it
stops (locks).
You can load the magazine with a maximum of 10
discs. You can also leave individual disc trays
unoccupied.
Figure 2
Note:
Make sure not to use discs measuring 8 cm in
diameter. Avoid getting fingerprints or scratches on
the CD. After having removed a CD tray, take care
that the disc lying on it does not fall down.
You may leave individual disc trays empty, though
you should insert all of the trays into the magazine.
Inserting the disc magazine
Figure 3
Figure 4
Figure 5
Slide the door to the rightmost position.
Insert the magazine with the arrow showing up until
it stops and locks.
Close the door sliding it back to the leftmost
position.
Note: Be sure that the slider is always closed. This will
protect the changeps laser lens against
contamination.
Removing the disc magazine
Figure 6
Make sure to open the door completely moving it to
the rightmost end and press the Eject button 8.
The magazine will come out automatically.
Attention: Failure to open the door completely may very likely
result in damages of the changer and the magazine!
Notes on moisture condensation
.’
On a rainy day or when the temperature varies considerably
moisture may condense on the laser lens and the unit will not
operate properly.
In this case remove the disc and wait for about one hour until
the moisture has evaporated.
Notes on CD
A contaminated or damaged CD can produce drop-outs in
playing. To optain optimum sound, handle the disc as follows:
Keep the CD clean, and handle the disc by its edge only.
If required, clean the disc with an optional cleaning cloth. Wipe
the disc surface from the middle towards the edge!
Do not use any solvants such as benzine, thinner, antistatic spray
or a conventional cleaning agent intended for analog discs!
Do not stick paper or tape anywhere on the disc!
Do not expose the disc to direct sunlight or high temperatures.
Do not leave the discs in a car parked in the sun.
High temperatures in the car can damage the disc.
Notes on the disc magazine
Do not expose the magazine to high temperatures and humidity.
Store the magazine where it is not exposed to direct sunlight
(not on the dashboard or rear shelf)!
Protect the magazine against vibration!
Operation
Please refer to car stereo’s owner’s manual.
Technical data
Frequency response:
5-20000Hz+l dB
Wow and flutter: below measurable limit
Signal-to-noise ratio: 94 dB
Operating temperature:
-10 “C to +50 “C
(Subject to modifications without notice)
FCC warning for USA
The equipment has been tested and found to comply with the
limits for a Class B device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy, and, if not installed and used in
accordance with instructions, may cause harmful interference
with radio communications. However, there is no guarantee that
radio interference will not occur in particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to contact the dealer or an
experienced RadioflV technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority to
operate this equipment.
The shielded interface cable recommended in this manual must
be used with this equipment in order to comply with limits for a
digital device pursuant to Sub-part B of Part 15 of the FCC rules.
Caution
-
The use of optical instruments with this product will increase
eye hazard.
-
Because the laser beam in this compact disc player is
harmful to the eyes, do not attempt to disassemble this
cabinet. Refer servicing to qualified personnel only.
Safety certification
This Compact Disc Player is made and tested to meet exacting
safety standards. It meets FCC requirements and complies with
safety performance standards of the US Department of Heath
and Human Services.
Notice:
This Class B digital .apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Warranty: Refer to radio warranty.

l an ein Blaupunkt-Autoradio mit Disc-Management-System.
l to a Blaupunkt car stereo with Disc Management System.
l ad un’autoradio Blaupunkt dotata di un sistema Disc-Management.
l aun autoradio de Blaupunkt avec Systeme Disc Management.
l op een Blaupunkt autoradio met DSC (Disc Management System).
l a un autorradio Blaupunkt con Disc Management System.
l till en Blaupunkt bilstereo med Disc Management System.
l a urn auto-radio Blaupunkt corn sistema Disc-Management.
br
rt
bl
gr
or
bllwt
CDCA071
1 Kl.30 r --
/
1 Battery 1
/
Sperrzunge, Blocking tongue,
\
braun, brown, marron, marrone.
hnlin hnm m~rri\n cat&&o
rot, red, rouge, rosso, rood, rod, rojo, vermelho
blau, blue. bleu, blu, blauw, bla, azul, azul
grau, grey, gris, grigio, grijs, gra, gris, cinzento
orange, orange, orange, aranqio, oranje,
orangefargad, naranja, car de laranja
blau/wei8, blue/white, bleu/blanc, blulbianco,
blauw/wit, bltivit, azullblanco, azul/branco
Languette de blocage,
Linguetta di bloccaggio,
Blokkeertong, Spbrrtunga,
Lengijeta de bloqueo, Ressalto
deb>, ,
1 Battery 1
Blaupunkt-Werke GmbH
+ Bosch Gruppe
6197
K7NKD
8 622 400 969
PM
864-1020-00

Einbauanleitung l Fitting / Installation Instructions l Notice d’installation l lstruzior
Mitgelieferte Befestigungsteile l Supplied Mounting Hardware l Materiel de montage fourni l
Ferreteria de montaje suministrada l Componenti di fissaggio comprese nella fornitura l
Meegeleverde montagematerialen l Medfijljande monteringsdetaljer l Elementos de fixa@o fornecidos
@ @
x2 x2
A 071+
A 072
(5 4
A 071
0.3
xl
Zur besonderen Beachtung
.
Bei der Wahl des Einbauortes ist folgendes zu beachten:
-
Der Tank darf durch die Blechschrauben nicht beschidigt werden.
-
Unter der Flgche, auf die das Ger.3 montiert werden soll, dtirfen sich keine Drahte oder Rohrleitungen befinden.
-
Ersatzreifen, Werkzeug usw. dtirfen durch die Blechschrauben nicht beschgdigt werden. Achten Sie such darauf,
daB die Herausnahme des Ersatzreifens. Werkzeuqs usw. nicht durch das Gertiit behindert wird.
.lnstallieren Sie das Gerat nicht an einem Ort,
-
der Temperaturen iiber 55” C (7.B in einem in der Sonne geparkten Wagen) ausgesetzt ist
dcr sich in der NBhe von Warmluflausl~ssen (lici7ung usw.) befindet.
-
der Regen oder Feuchtigkeit ausgesetzt ist.
-
der Staub oder Schmutz ausgesetzt ist.
-
der starken Vibrationen ausgesetzt ist.
.
Fi.ir sicheren und stabilen Einbau verwenden Sie ausschliel3lich die mitgelieferten Befestigungsteile.
I
Precautions
.
Choose the mounting location carefully, observing the following:
-
The fuel tank must not be damaged by the tapping screws.
-
There should be no wire harnesses nor any tubes located under the place where you are going to install the unit.
-
The spare wheel, tools or other equipment in or under the trunk must not be blocked or damaged by the screws
or the unit itself.
.Do not install the unit at a place,
-
which is exposed to temperatures of more than 55” C (e.g. in a car parked in the sun).
-
which is close to hot air outlets (heating, etc.).
-
which is exposed to rain or humidity.
-
which is exposed to dust or dirt.
-
which is exposed to considerable vibrations.
.Be sure to use only the supplied mounting hardware for a safe and secure installation.

LASER PRODUCT
Vor der Montage die drei Transportsicherungsschrauben entfernen.
Undo the three transport security bolts before you start with the installation.
Avant d’effectuer le montage, enlever les trois vis de securite de transport.
Prima di effettuare il montaggio svitate le tre viti di fissaggio per sicurezza di trasporto.
Verwijder voor de montage de drie transportbeveiligingsschroeven. .
lnnan monteringen skall de tre transportsakringsskruvarna av Iagsnas.
Remover 10s tres tornillos de seguridad de transporte antes de comenzar con la
instalacion.
Antes de montar e necessario retirar OS tres parafusos de seguranca de transporte.
Horizontaler Einbau l Horizontal Installation l Installation horizontale de I’appareil l lnstalacidn horizontal l
Montaggio orizzontale l Horizontale montage l Horisontell montering l Montagem horizontal
.
0 So gekennzeichnete L&her mit Aufkleber @ abdecken (Staubschutz).
0 Cover the holes marked -> using the adhesive sticker @ (for dust protection).
0 Couvrir les trous marques de => avec I’autocollant @ (protection antipoussiere).
e I fori cosi contrassegnati vanno coperti con un nastro adesivo @ (protezione contra la polvere).
I$ Dek de met fi gemerkte gaten af met de stickers @ (bescherming tegen stof).
t$ De markerate halen tacks med dekaler @ (demmaskydd).
Cubra 10s huecos marcados I$ mediante 10s adhesivos @ (protection contra polvo).
0 Orificios marcados assim, devem ser cobertos corn adesivos @ (proteccao contra ~6).

Vertikaler Einbau l Vertical Installation l installation verticale l Instalacih vertical l Montaggio verticale l
Vertikale montage l Vertikal montering l Montagem vertical
.
