Blaze King BRIARWOD BRII/90 User manual

OM-BRII90 E V1.03 wo739 July 14, 2015
e authority having jurisdiction (such a municipal building department, re department, etc.) should be
consulted before installation to determine the need to obtain a permit.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
Manufactured By
Valley Comfort Systems Inc., 1290 Commercial Way, Penticton, BC, V2A 3H5, Canada
Phone: [phone] Fax: [phone] www.blazeking.com inf[email protected]m
OPERATION & INSTALLATION MANUAL
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please SAVE THESE INSTRUCTIONS for future reference.
BRIARWOD BRII/90
SOLID FUEL STOVE
is heater meets the 2015 U.S. Environmental Protection Agency’s particulate emission limits for wood heaters sold aer May 15, 2015.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 2 BRII/90
TABLE OF CONTENTS
INTRODUCTION _____________________________________________________________ 4
SPECIFICATIONS _____________________________________________________________ 5
EMISSIONS __________________________________________________________________ 5
PRODUCT INFORMATION _____________________________________________________ 6
APPLIANCE DIMENSIONS—Briarwood........................................................................................ 6
CERTIFICATION LABEL________________________________________________________ 7
SAFETY PRECAUTIONS ________________________________________________________ 8
INSTALLATION INSTRUCTIONS_________________________________________________ 11
PARTS INCLUDED WITH THE BRIARWOOD.............................................................................. 11
OPTIONAL EQUIPMENT............................................................................................................... 11
DECORATIVE OPTIONS ................................................................................................................ 11
FLOOR PROTECTION .................................................................................................................... 11
MINIMUM CLEARANCES for BRII/90........................................................................................... 12
COMBUSTION AIR......................................................................................................................... 13
DRAFT............................................................................................................................................. 13
ROLE OF THE CHIMNEY............................................................................................................... 13
VENTING SYSTEMS ...................................................................................................................... 14
MOBILE HOME (AND RESIDENTIAL ALCOVE INSTALLATIONS)........................................... 17
OPTIONAL ACCESSORIES............................................................................................................. 18
OPERATING INSTRUCTIONS ___________________________________________________ 20
YOUR FIRST FIRE!.......................................................................................................................... 20
SELECTING WOOD........................................................................................................................ 20
HOW TO USE MOISTURE METERS.............................................................................................. 21
EFFICIENCY.................................................................................................................................... 21
LIGHTING THE FIRE ..................................................................................................................... 22
RELOADING PROCEDURE............................................................................................................ 22
FAN OPERATION ........................................................................................................................... 23
ICE - FORMATION AND PREVENTION ....................................................................................... 23
WOOD BURNING IN THE SHOULDER SEASON ......................................................................... 23
MAINTENANCE ______________________________________________________________ 24
RUN-AWAY OR CHIMNEY FIRE.................................................................................................... 24
CREOSOTE FORMATION AND REMOVAL .................................................................................. 24
CHIMNEY MAINTENANCE........................................................................................................... 25
FIRE EXTINGUISHERS AND SMOKE DETECTORS..................................................................... 25
ASH REMOVAL ...............................................................................................................................25
LOADING DOOR GASKET INSPECTION...................................................................................... 26
LOADING DOOR GASKET REPLACEMENT................................................................................. 26
DOOR GLASS GASKET INSPECTION ........................................................................................... 27
DOOR GLASS GASKET REPLACEMENT ...................................................................................... 27
DOOR GLASS, CLEANING............................................................................................................. 27
LOADING DOOR TENSION ADJUSTMENT ................................................................................. 28
BAFFLE REPLACEMENT................................................................................................................ 29

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 3
BRII/90
TABLE OF CONTENTS cont.
CHIMNEY DRAFTS ........................................................................................................................ 29
OPTIONAL FAN ASSEMBLY .......................................................................................................... 29
TROUBLESHOOTING__________________________________________________________ 30
WARRANTY _________________________________________________________________ 34
INSTALLER NOTES____________________________________________________________ 40

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 4 BRII/90
INTRODUCTION
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND IS
PROHIBITED BY FEDERAL AND STATE LAWS.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to
operating instructions could cause fire or injury.
• Before installing this appliance, contact the local building or fire authority and follow their guidelines.
• This appliance must be installed by a qualified installer.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not operate without fully assembling all components.
• Do not let the appliance become hot enough for any part to glow red.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or
clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children
and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals
in the house. To restrict access to an appliance or stove, install an adjustable safety gate to keep toddlers, young children and
other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance. Objects placed in front of the appliance
must be kept a minimum of 48” away from the front face of the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants / toddlers from touching hot surfaces.
• Even after the appliance is out, all surfaces, including the glass and/or any attachment will remain hot for an extended period
of time.
• Check with your local hearth specialty dealer for safety hearth guards to protect children from hot surfaces. These guards
must be fastened to a wall and/or to the floor.
• Any safety guard removed for servicing must be replaced prior to operating the appliance.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe servicing a separate solid fuel burning appliance.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Operate only with the doors tightly closed.
• Stove will over-fire if door is not shut and latched.
• Only certified doors / optional fronts / and surrounds for inserts with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags,
these are not toys and should be kept away from children and infants.
• If the appliance is not properly installed, a house fire may result. Do not expose the appliance to the elements (ex. rain, etc.)
and keep the appliance dry at all times.
• The chimney must be sound and free of cracks and obstructions. Clean your chimney regularly as required.
• Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or ‘freshen up’ a fire in
this heater. Keep all such liquids well away from the heater while it is in use.
• Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to smoke spillage in
your home.
• Higher efficiencies and lower emissions will generally result when burning air dried seasoned woods, as compared to wet,
green or freshly cut wood. Burning wet unseasoned wood can cause excessive creosote accumulation. When ignited it can
cause a chimney fire that may result in a serious house fire.
• The appliance is designed to burn natural wood only. Do not burn treated wood, coal, charcoal, colored paper, cardboard,
solvents or garbage.
• Burn wood directly on the firebricks. Do not use a grate or elevate the fire.
• Do not store wood within appliance installation clearances or within the space required for re-fueling and ash removal.
• Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well away from the
home or structure until completely cool.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 5
BRII/90
SPECIFICATIONS
Model BRII/90 (non-catalytic)
Height 30 7/8” (785 mm)
Width 27 1/2” (699 mm) (without door handle)
Depth 22 7/8” (581 mm) (without optional fan kit)
28 5/8” (727 mm) (with optional fan kit)
Flue collar 6” I.D.
Recommended flue draft .05” water column (on high burn)
Fire door opening 21 13/16” x 10” (554 mm x 254 mm)
Firebox depth 12 1/2” (318 mm) brick to brick, 14 5/8” (372 mm) brick to glass
Firebox width 22 1/2” (572 mm)
Firebox height 12” (305 mm)
Fire box capacity 2.1 cu. ft.
Recommended Fuel length 22” (559 mm)
Wood capacity (approximate): White oak - 44 lbs. (19.96 kg)
Fir - 35 lbs. (15.88 kg)
Construction 3/16” & 1/4” firebox, brick lined
18 gauge outer shields
Shipping Weight 330 lbs. (150 kg)
Chimney recommendation 15’ from stove top to chimney cap.
is unit was tested and listed UL 1482-1988 and ULC S627-M93 by
Intertek testing laboratories.
is manual describes the installation and operation of the
Briarwood BRII/90 wood heater.
is heater is certied to comply with the 2015 U.S. Environmental
Protection Agency’s particulate emission limits for wood heaters sold
aer May 15, 2015.
Under specic test conditions this heater has been shown to deliver heat at rates ranging from 10600 to 36000 Btu/hr.
is wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations
to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this
manual.
It is against federal regulations to operate this wood heater in a manner inconsistent with operating instructions in this
manual, or if the catalytic element is deactivated or removed.
EMISSIONS CO Average(%) g/hr
Low Burn 1.11 1.66
Med-low Burn 0.92 3.481
Med-high Burn 0.69 2.6
High Burn 0.33 7.682

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 6 BRII/90
APPLIANCE DIMENSIONS—Briarwood
PRODUCT INFORMATION





















 











ZRSWLRQDOIDQV












OM-BRII90 E V1.03 wo739 July 14, 2015
Page 7
BRII/90
CERTIFICATION LABEL
BRIARWOOD II/90 STOVE
LISTED ROOM HEATER, SOLID FUEL TYPE
Also for use in MOBILE HOMES
MODEL: BRII/90 Tested to : UL1482-1998 / ULC S627-M93 CERTIFIED IN BOTH UNITED STATES AND CANADA
PREVENT HOUSE FIRES - Install and use only in accordance with Blaze King’s installation and operation instructions. Contact local building or fire officials about
restrictions and installation inspection in your area.
CHIMNEYS: DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. Chimney must be a minimum of 6” listed factory built chimney
suitable for use with solid fuels and conforming to, ULC629 in Canada or UL
-103HT in the USA. If a non-listed chimney is to be used it must comply with all local
and national codes, in Canada a non -listed chimney requires a full reline with a listed solid fuel chimney liner.
Mobile Home, residential close clearance, and residential alcove installations require 6” listed double wall close clearance chimney connector, with matching
listed factory built chimney suitable for use with solid fuels and conforming to, ULC629 in Canada or UL-103HT in the USA .
Mobile Home installations are only allowed with a roof exit. Do not install in a sleeping room.
Alcove minimum width55.5” / 1410 mm , minimum height from top of stove 36” / 914 mm, maximum depth 32” / 813 mm.
Passing through a wall or ceiling requires special methods: see local building codes.
DO NOT PASS A CHIMNEY CONNECTOR THROUGH A COMBUSTIBLE WALL OR CEILING.
Electrical rating: 115 VAC, 60 Hz, 0.58 Amps. Risk of electrical shock. Disconnect power before servicing unit. Do not route power cord in front of or beneath
heater.
MINIMUM CLEARANCES TO COMBUSTIBLES (See owners manual for complete description of all requir ements)
** Mobile Home and Alcove Installations must use double wall listed pipe, side shields and rear shield. Mobile Home Installations
require Outside Combustion Air Kit# Z1526.
Floor protection may be any non-combustible material or Listed Floor Prot ector, and must extend at least 18”
/ 406 mm in front of the
loading door opening. Minimum size is 44x 36”
.
U.S. ENVIRONMENTAL PROTECTION AGENCY- Certified to comply with July, 1990 particulate emission standards.
*Operate with doors closed. Open door to feed fire ONLY. Do not obstruct combustion air openings. Provide adequate outside air
for combustion.* Use only high temp erature ceramic glass if replacement is necessary, 5 mm. thickness
KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIALS WELL AWAY FROM HEATER. DO NOT
OVERFIRE! IF HEATER OR CHIMNEY GLOWS YOU ARE OVERFIRING.
For use with solid fuel only. Use of other fuels may cause a house fire or endanger your safety.
Refer to Installation and Operations manual for installation and operation instructions.
CAUTION:
HOT WHILE IN OPERATION. DO NOT TOUCH. KEEP CHILDREN, CLOTHING AND FURNITURE
AWAY. CONTACT MAY CAUSE SKIN BURN. READ THIS LABEL AND INSTRUCTION MANUAL BEFORE
OPERATION OF STOVE.
MANUFACTURED IN:
MANUFACTURE DATE
USA: Canada:
Blaze King Industries Valley Comfort Systems
146A Street 1290 Commercial Way
Walla Walla, WA. Penticton, B.C.
99362 V2A 3H5
WH-
JAN FEB MAR APR MAY JUN
JUL AUG SEP OCT NOV DEC
2001 2002 2003 2004 2005 2006
0164 Rev 08/2001
Residential Installations A B C D E
Single Wall Pipe (24 MSG Black) 15” / 381 mm 15” / 381 mm 25.75” / 654 mm 18” / 457 mm 15” / 381 mm
Listed Double Wall Pipe—Close Clearances
Use side shields and rear shield.
(Must use for Mobile / Manufactured Home
Installations, Alcove Installation and Close
Clearance Installations)
14” / 356 mm 8” / 203 mm 24.75” / 629
mm
11” / 279 mm 8” / 203 mm
19"

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 8 BRII/90
This appliance must be connected to a listed high temperature (ULC629 IN CANADA OR
UL-103HT IN THE USA) residential type factory built solid fuel chimney or an approved
masonry chimney with a flue liner.
Chimney and chimney connector must be in good condition and kept clean.
NEVER vent the stove to other rooms of the building. Must be vented to the outside ONLY.
NEVER use a chimney or chimney connector smaller then the stove exhaust, unless
approved by your local inspector.
NEVER vent the stove into a “Class B” gas vent chimney.
DO NOT CONNECT IN CONJUNCTION WITH ANYAIR DISTRIBUTION DUCTWORK
UNLESS SPECIFICALLYAPPROVED FOR SUCH INSTALLATIONS.
Inspect the chimney connector and chimney regularly during each burning season and
clean when necessary.
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
NEVER intentionally start a chimney fire to clean the flue.
When installed in a mobile home, this appliance must be bolted to the floor and provided
with outside air. WARNING: DO NOT INSTALL IN A SLEEPING ROOM
CAUTION: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED.
Check with local building officials.
If the Optional Fan Kit is
installed, connect this unit to
a properly grounded, 110-volt
electrical outlet. Do not route
the power cord in front of or
under the stove.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney
to install this appliance. Do
not make any changes to
the appliance to increase
combustion air.
SAFETY PRECAUTIONS
IF THIS BLAZE KING STOVE IS NOT PROPERLY INSTALLED OR OPERATED, A HOUSE FIRE MAY
RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. CONTACT LOCAL
BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM HEATER. FAILURE
TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 9
BRII/90
Never try to repair or replace
any part of this appliance
unless instructions are given
in this manual. All other work
must be done by a trained
technician.
Allow the appliance to cool
down before carrying out any
maintenance or cleaning.
Maintain the door and glass
seal and keep them in good
condition. A leaking door seal
will shorten burn times.
Avoid placing wood against
the glass when loading. Do
not slam the door or strike the
glass.
Do not throw this manual
away. This manual has
important operating and
maintenance instructions that
you will need at a later time.
Always follow the instructions
in this manual.
Do not place clothing or other
flammable items on or near
this appliance.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Ashes should be placed in a
steel container with a tightly
fitting lid and moved outdoors
immediately. If the ashes are
disposed of by burial in soil or
otherwise locally dispersed,
they should be retained in
the closed container until
all cinders have thoroughly
cooled. Other waste shall not
be placed in this container.
SAFETY PRECAUTIONS cont.
It is recommended to install smoke and carbon monoxide detectors where heaters are
installed. Install at least one smoke detector on each floor of your home to ensure your
safety. It should be located away from the wood stove and close to the sleeping areas.
Locating a smoke detector too close to a wood stove can cause the smoke detector alarm
to sound if a puff of smoke is emitted while the wood stove door is open during reloading.
Follow the smoke detector manufacturers placement, installation, and maintenance
instructions.
DO NOT OVER FIRE THIS
HEATER. Attempts to
achieve heat output rates
that exceed heater design
specifications can result
in permanent damage to
the heater. Over firing the
appliance may cause a house
fire. Never burn the stove so
hot that the stove or chimney
connector begins to glow.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 10 BRII/90
Never burn the stove with the
loading door open.
Never block free airflow
through vents on this
appliance.
HOT WHILE IN OPERATION.
KEEP CHILDREN,
CLOTHINGAND FURNITURE
AWAY.
CONTACT MAY CAUSE SKIN
BURNS.
Do not touch the appliance
when it is hot and educate all
children of the danger of a
high temperature appliance.
Young children should be
supervised when they are
in the same room as the
appliance.
This appliance must be
properly installed to prevent
the possibility of a house
fire. The instructions must
be strictly adhered to. Do not
use makeshift methods or
compromise in the installation.
Never use gasoline, gasoline-
type lantern fuel, kerosene,
charcoal lighter fluid, or similar
liquids to start or ‘freshen up’ a
fire in this heater.
Keep all such liquids well away
from the heater while it is in use.
Some fuels could generate
carbon monoxide and are very
dangerous.
Keep furniture, curtains,
wood, paper and other
combustibles a minimum of
48in (1219mm) away from
the front of the appliance.
ALSO, DO NOT STORE
COMBUSTIBLES UNDER
THE APPLIANCE (WOOD,
PAPER etc.).
Contact local building officials
to obtain a permit and
information on any installation
restriction or inspection
requirements in your area.
Notify your insurance
company as well.
SAFETY PRECAUTIONS cont.
This appliance is designed and approved for burning cord wood only. DO NOT burn trash,
garbage; artificial or paper logs; gift wrappings; coal; lighter fluids; chemical cleaners;
chemical starters; treated or painted wood; salt water driftwood or foil-backed paper such
as gum wrappers or cigarette packages; lawn clippings or yard waste; materials containing
rubber (including tires), plastic, asbestos; waste petroleum products, paints or paint
thinners, or asphalt products; construction or demolition debris; railroad ties or pressure-
treated wood; manure or animal remains; unseasoned wood or paper products, cardboard,
plywood, or particleboard. The prohibition against burning these materials does not prohibit
the use of fire starters made from paper, cardboard, saw dust, wax and similar substances
for the purpose of starting a fire in an affected wood heater. Burning these materials may
result in the release of toxic fumes or render the heater ineffective and cause smoke. Burn
natural wood only. It will void all warranties and safety listings.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 11
BRII/90
INSTALLATION INSTRUCTIONS
FLOOR PROTECTION
If the stove sits on a combustible oor, a non-combustible shield must be used underneath the
stove and extending 16” out from the front and 8” on either side of the fuel-loading door in the
USA. In Canada a non-combustible shield must be used underneath the stove and extending 8”
on either side and rear and 18” out in front of the loading door.
A non-combustible shield is also required underneath the chimney connector and extending at
least 2” (50.8mm) on either side of the chimney connector.
See the next page for minimum sizes depending on model. is oor protection is required to
prevent sparks from falling onto the combustible oor. See CSA B365-M87). is product does
not require thermal hearth pad protection.
Blaze King grants no warranty, implied or
stated, for the installation or maintenance of the
appliance and assumes no responsibility of any
consequential damage(s).
PARTS INCLUDED WITH THE BRIARWOOD
1. Poker
2. Manual kit (w/ warranty cards, fire starter)
OPTIONAL EQUIPMENT
1. Fan kit (Z1514) 2. Rear shield (ZRSBRII)
3. Side shields (ZSSBRII, requires rear sheild)
DECORATIVE OPTIONS
1. Door trim kit gold 2. Door trim kit satin
• BEFORE INSTALLING THIS APPLIANCE, CONTACT THE LOCAL BUILDING OR FIRE OR OTHER
AUTHORITY HAVING JURISDICTION AND FOLLOW THEIR GUIDELINES.
• THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. FOLLOW THE
INSTALLATION DIRECTIONS. DO NOT OPERATE WITHOUT FULLY ASSEMBLING ALL
COMPONENTS.
• IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF
CONTACTED. CHILDREN AND PETS MUST BE KEPT FROM TOUCHING THE APPLIANCE
WHEN IT IS HOT.
• COMBUSTIBLE MATERIAL SUCH AS FIRE WOOD, WET CLOTHING, ETC. PLACED TOO CLOSE
CAN CATCH FIRE. OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A
MINIMUM OF 48”(1219 MM) FROM THE FRONT OF THE APPLIANCE.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 12 BRII/90
INSTALLATION INSTRUCTIONS cont.
MINIMUM CLEARANCES for BRII/90
Residential Installations A B C D E F
Single wall pipe (24 MSG Black). 15”
381 mm 15” 381 mm 28.75” 731 mm 22” 559 mm 15” 381 mm 28.875” 734 mm
Listed double wall pipe - close clearances. Use side shields and rear
shield. (Must use for mobile / manufactured home installations. Alcove
Installation and close clearance installations)
14”
356 mm 8” 204 mm 27.75” 705 mm 15" 381 mm 8” 203 mm 21.875” 556 mm
Check with local codes and pipe manufacturer for pipe clearances. In Canada, 18” clearances from single wall pipe is required.
Mobile home and alcove installations must use double wall listed pipe, side shields, and rear shield.
Mobile home installations also require an outside air kit #Z1526
2"
D
C
A
G
H
G
B
I
G = 5 3/8” (137mm) in USA
8” (203mm) in Canada H = 16” (406mm) in USA 18” (456mm) in Canada I = 0” (0mm) in USA 8” (203mm) in Canada K = 18” (456mm) for single wall pipe in Canada
Ember protection shield (not required to have an insulation value)
is to be listed under UL 1618-2009 (type 1) and must have a minimum size of:
In USA: 38 1/4”wide x 33 3/4”deep (972 x 858 mm)
In Canada: 43 1/2”wide x 43 3/4”deep (1105 x 1112 mm)
Min. Alcove minimum width 55 1/2”, maximum depth 32”, minimum height above stove top 36”
This stove must be installed in compliance with all local codes and regulations.
*1
*1
I
H
G
F
E
" in USA
8
*1= 312" in Canada and 218" in USA
*2 = 6558" in Canada and 635
*2
0,1IW
-
.
IW5(&200(1'('

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 13
BRII/90
INSTALLATION INSTRUCTIONS cont.
COMBUSTION AIR
Ensure adequate combustion air allowing for all other exhausting type appliances in the dwelling (range hoods,
dryers, etc.). In air tight homes and modern constructions, careful considerations must be taken into account
when using a wood burning appliance. Heat recovery ventilators (HRV) systems along with constant running
pan motors in air handlers must be taken into account when balancing the system. Failure to do so may result in
air starvation, smoke spillage and carbon monoxide threats. Consult a HVAC specialist for proper installation.
Ensure adequate combustion air allowing for all other exhausting type appliances in the dwelling (range hoods,
dryers, etc.). In airtight houses it is recommended to install a fresh air inlet into the room where the stove is
located, to prevent air starvation.
DRAFT
Dra in the chimney system is initiated by the air pressure dierence between the top and bottom of the
chimney. Heat generated within the rebox will rise and accelerate the dra in the chimney. Recommended
dra is .05 in. w.c. operated on high. Too little dra results in a sluggish re and smoke spillage into the room
when the stove door is opened. Too much dra (over 0.06 in. w.c.) makes it unsafe to operate the stove and will
void manufacturers warranty.
ROLE OF THE CHIMNEY
Without a proper installed chimney, this appliance will not burn correctly.
e role of the chimney is to pull the proper amount of air into the rebox for the purpose of complete
combustion. Incomplete combustion will lead to more smoke and pollution of the outside air. A proper
operating chimney will allow the user to enjoy peak performance at all burn operating levels from low to high.
Blaze King therefore recommends vertical installations with a minimum length of 15’ from stove top to chimney
cap. In all freestanding stove installations, use double wall stove pipe from the stove top to the ceiling support
box. e use of double wall stove pipe does allow for reduced clearances, however most importantly, it helps to
keep the chimney warm and improve dra.
For wall exits, the same suggestion applies. With the addition of the recommendation to use two 45 degree
elbows rather than a single 90 degree elbow. e use of two 45 degree elbows will allow for both a smoother
transition to the exterior chimney and will also shorten the horizontal run to the outside chimney. A minimum
36” rise is recommended prior to any elbows being used. When possible, outside chimney systems should be
isolated from direct exposure to winter weather by building a chase around the chimney, observing all clearances
as specied by the venting manufacturer. Doing so will help to keep the chimney warmer and improve dra.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 14 BRII/90
VENTING SYSTEMS
e venting system consists of a chimney connector and a chimney. ese get extremely hot during use.
Temperatures inside the chimney may exceed 2000 degrees in the event of a creosote re. To protect against the
possibility of a house re, the chimney connector and chimney must be properly installed and maintained. A
listed thimble must be used when a connection is made through a combustible wall to a chimney. A chimney
support package must be used when a connection is made through the ceiling to a listed prefabricated chimney.
ese accessories are absolutely necessary to provide safe clearances to combustible wall and ceiling material.
is stove may be connected to a lined masonry chimney or a listed factory built chimney suitable for use with
solid fuels and conforming to, ULC629 in Canada or UL-103HT in the USA. Do not connect it to a chimney
serving another appliance. To do so will aect the safe operation of both appliances, and will void the stove
warranty. You must comply with the local authority having jurisdiction and/or in Canada, CSA installation
standard B365-M87.
e chimney connector must be 8” diameter, 24 MSG Black/Blue steel. Do not use aluminum or galvanized
steel. ey cannot properly withstand the extreme temperatures of a wood re. e chimney connector between
the stove and the chimney should be as short and direct as possible.
e chimney connector must be attached to either an approved masonry chimney or one of the listed factory
built chimneys suitable for use with solid wood fuel. All joints must be tight and fastened with sheet metal
screws.
THE CHIMNEY CONNECTOR IS TO BE USED ONLY WITHIN THE ROOM, BETWEEN THE STOVE
AND CEILING / WALL. NEVER USE A CHIMNEY CONNECTOR TO PASS THROUGH AN ATTIC
OR ROOF SPACE, CLOSET OR SIMILAR CONCEALED SPACE, OR A FLOOR, OR CEILING. AN
EFFECTIVE VAPOR BARRIER MUST BE MAINTAINED AT THE LOCATION WHERE THE CHIMNEY
OR COMPONENT PENETRATES TO THE EXTERIOR OF THE STRUCTURE. ALWAYS MAINTAIN
THE MINIMUM CLEARANCES TO COMBUSTIBLES AS REQUIRED BY THE APPLICABLE BUILDING
CODES.
INSTALLATION INSTRUCTIONS cont.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 15
BRII/90
INSTALLATION INSTRUCTIONS cont.
CONNECTION TO A METAL PREFABRICATED CHIMNEY
When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed
precisely. You must also purchase (from the same manufacturer) and install the ceiling support package or wall
pass through and “T” section package, re stops (when needed), insulation shield, roof ashing, chimney cap,
etc. Maintain the proper clearance to the structure as recommended by the manufacturer. is clearance is
usually a minimum of 2 inches, although it may vary by manufacturer or for certain components.
ere are basically two methods of metal chimney installation. One method is to install the chimney inside the
residence through the ceiling(s) and the roof. e other method is to install an exterior chimney that runs up
the outside of the residence (not recommended). If it is necessary to run the chimney outside, build an outside
chase around the chimney.
e chimney must be the required height above the roof or other obstruction for safety and for proper dra
operation. e requirement is that the chimney must be at least 3 feet higher than the highest point where it
passes through the roof and at least 2 feet higher than
the highest part of the roof or structure that is within
10 feet of the chimney, measured horizontally (Fig. 1).
e height requirement is necessary in the interest of
safety and does not necessarily assure proper ue dra.
Use a minimum total system height of 15 feet, measured
from the stove ue collar to the top of the chimney, not
including the chimney cap.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 16 BRII/90
INSTALLATION INSTRUCTIONS cont.
CONNECTION TO A MASONRY CHIMNEY
Masonry chimney***
Ensure that a masonry chimney meets the minimum standards
(NFPA) by having it inspected by a professional. Make sure there are
no cracks, loose mortar or other signs of deterioration and blockage.
Have the chimney cleaned before the stove is installed and operated.
When connecting the stove through a combustible wall to a masonry
chimney, special methods are needed.
In Canada, the wall cut away is to provide 18” clearance for the
connector. e resulting space must remain empty. A ush mounted
sheet metal cover may be used on one side only. If covers are to be
used on both sides, each cover must be mounted on noncombustible
spacers at least 1” clear of the wall.
***Blaze King recommends the use of a Stainless steel liner,
preferably insulated, inside a masonry chimney. is to maintain
proper dra and overall better operation of the unit.
Your local dealer or local jurisdiction can provide details of
approved methods of passing a chimney connector through
a combustible wall in your area. In USA, the National Fire
Protection Association has minimum standards to comply
with. In Canada , this type of installation must conform to
CAN/CSA-B365, Installation Code for Solid Fuel Burning
Appliances and Equipment.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 17
BRII/90
INSTALLATION INSTRUCTIONS cont.
MOBILE HOME (AND RESIDENTIAL ALCOVE INSTALLATIONS)
Use double wall listed pipe, side shields, and rear shield (See next page for kits and part numbers). Mobile home
installations also requires an outside air kit #Z1526. ey are easiest to mount before the stove is installed.
See instructions packed with each kit. NOTE: UNDER NO CIRCUMSTANCES SHOULD THE FRESH
AIR TUBE EVER BE INSTALLED HIGHER THAN THE BOTTOM OF THE APPLIANCE FIREBOX
FLOOR
When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed
precisely. You must also purchase (from the same manufacturer) and install the ceiling support package, re
stops (when needed), insulation shield, roof ashing, chimney cap, etc. Maintain the proper clearance to the
structure as recommended by the manufacturer.
Chimney connector must be double wall close clearance type with either ULC629 or ULCS610 designation.
Single wall pipe is not allowed in Mobile Homes or in Alcove Installations. Insulated chimney components
must be a listed factory built chimney suitable for use with solid fuels and conforming to, ULC629 in Canada or
UL-103HT in the USA. For Mobile home, the chimney needs to be removable to allow for transportation of the
mobile home.
DO NOT INSTALL IN SLEEPING ROOM. THE STRUCTURAL INTEGRITY OF THE MOBILE
HOME FLOOR, WALL AND CEILING / ROOF MUST BE MAINTAINED.
In mobile home installations the stove must be
securely fastened to the oor using the lag bolts
provided in the outside air kit:
1. Position the stove on the oor protector so that
the minimum clearances are met.
2. Remove the back pedestal cover.
3. Drill down through the holes in the base of the
stove, penetrating both the oor protector and
the oor of the home.
4. Place two lag screws through the holes and fasten
them securely to the oor of the structure. (Make
sure the stove cannot shi or move.)
ALSO, a #8 ground wire must be attached to the
stove and an appropriate ground.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 18 BRII/90
INSTALLATION INSTRUCTIONS cont.
OPTIONAL ACCESSORIES
Outside air kit, side shields, and rear shield are optional accessories, but are required for the
following installations:
MOBILE HOME INSTALLATION — Requires outside air kit, side shields, and rear shield.
RESIDENTIAL ALCOVE — Requires outside air kit, side shields, and rearshield.
REAR SHIELD KIT (ZRSBRII)
REQUIRED FOR:
MOBILE HOME, any installation
RESIDENTIAL ALCOVE
INSTALLATION : e rear shield goes across the back of the stove. Remove the four 1/4” x 1/2”
hex bolts. Place the rear shield into position so that the notch on the shield wraps the lip on the
stove top. Insert and tighten the four 1/4” X 2-1/2" hex bolts provided.
FAN KIT (P/N Z1514)
Includes ZRSBRII rear shield
NOTE:Fan kit should be installed before the stove is placed into position
INSTALLATION: See instructions included with fan kit.
ELECTRICAL CONNECTION:
Your Blaze King fan kit is equipped with a three-prong (grounded) plug to decrease shock hazard.
THIS PLUG SHOULD BE INSERTED DIRECTLY INTO A PROPERLY-GROUNDED, THREE-
HOLE RECEPTACLE. DO NOT CUT OR REMOVE THE GROUNDING PRONG FROM THIS
PLUG. Do not route the power cord in front or under the stove.
OUTSIDE AIR KIT (P/N Z1526)
REQUIRED FOR: MOBILE HOME (any installation)
e outside air inlet hose is a exible tube to bring outside air for combustion into the stove from
outside the residence, through the wall or up through the oor. e exible tube will allow some
adjustment over or around oor joists or plumbing. DO NOT CHANGE THE STRUCTURAL
INTEGRITY OF THE FLOOR. is air hose must be kept open at all times to provide outside air
for combustion.
INSTALLATION
See instructions included with the outside air kit. Tools needed: 1/4" or 3/8" drill motor, saber
saw, saber saw wood & metal blades, 5/16" nut driver or wrench, 7/16" wrench, Small tube of hi-
heat silicone.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 19
BRII/90
INSTALLATION INSTRUCTIONS cont.
DOOR INSTALLATION AND CHANGE-OUT
To install the door upon stove installation or to change it out, follow these steps:
DOOR IS HEAVY, PLEASE HOLD FIRMLY.
INSTALLATION
1. Insert the top of door hinge rod into the top hinge hole on the rebox.
2. Lower door onto bottom hinge hole.
NOTE: Ifyour door hasagold orsilverplating onit ,please follow theinstructions
on the PLATED DOOR & TRIM CARE card found in the manual pack.

OM-BRII90 E V1.03 wo739 July 14, 2015
Page 20 BRII/90
OPERATING INSTRUCTIONS
YOUR FIRST FIRE!
e following pages contain information on the major components and operation of your heater. Please take
time to read about them as it will give you a better understanding of how your stove works. is understanding
will help you to operate your stove properly thus will extend the life of your stove and allow you to get the
highest eciencies from your heater.
SELECTING WOOD
• THIS APPLIANCE IS DESIGNED TO BURN NATURAL WOOD ONLY. DO NOT BURN
TREATED WOOD, COAL, CHARCOAL, COLORED PAPER, CARDBOARD, SOLVENTS OR
GARBAGE.
• HIGHER EFFICIENCIES AND LOWER EMISSIONS WILL GENERALLY RESULT WHEN
BURNING AIR DRIED SEASONED WOODS, AS COMPARED TO WET, GREEN OR
FRESHLY CUT WOODS.
• BURNING WET UNSEASONED WOOD CAN CAUSE EXCESSIVE CREOSOTE
ACCUMULATION. WHEN IGNITED IT CAN CAUSE A CHIMNEY FIRE THAT MAY RESULT
IN A SERIOUS HOUSE FIRE.
Use dry seasoned wood, split and stacked and protected from rain for at least 24 months with a moisture content
of 20% or lower. It takes a great deal of energy to evaporate the moisture contained in green wood and that
energy will not be heating your house. Also, green or wet wood will greatly increase creosote problems. e
only accurate method to determine moisture content in wood is to use a moisture meter.
Never burn salt-water driwood. It is very corrosive and will damage the rebox. Burning salty wood also voids
the warranty.
is controlled combustion rebox has been designed for high eciency and long burn times. e proper time
to add more wood is when the last charge has been reduced to a glowing charcoal bed. ere will be very little
smoke at this stage in the burn cycle.
Both hardwood and sowood burn equally well in this appliance but hardwood, which is more dense, will weigh
more per cord and burn a little slower and longer.
Firewood should be split and stacked in a manner that air can get to all parts of it and covered in early spring to
be ready for burning that fall.
The only accurate way to determine wood moisture is to purchase a moisture meter.
• NEVER START A FIRE UNLESS ALL BRICKS ARE CORRECTLY PLACED INSIDE THE
FIREBOX. CHECK THE INSTALLATION INSTRUCTIONS CAREFULLY.
