Blaze TURBO 6000watt Lithium scooter User manual

BLAZE TURBO 6000watt Lithium scooter
Read Instructions Before Using Your New Electric Scooter

Users’ Manual
2
Version 2.0
INSPECTION BEFORE RIDING
WARNING!
Please make sure to inspect before riding:
1. Make sure the control panel can be turned
on.
2. Make sure the brake levers working properly.
3. Make sure the front of the E-scooter is
stable.
4. Make sure the seat is installed firmly (If any).
5. Make sure the horn working properly.
6. Make sure the light system working properly.
7. Make sure the Single and Dual drive switch is
working properly.
8. Make sure the Eco and Turbo mode switch
working properly.
9. Make sure the folding mechanism working
normally.
10. Inspect the brake pads

Users’ Manual
3
Version 2.0
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
1. Be sure to wear helmet, knee, and elbow pads
before riding.
2. Please ride at low speed at the beginning;
After your skilled use of an E-scooter, you can
speed up gradually.
3. Please do not ride on a rainy day or ride into a
puddle.
4. The E-scooter is for adults only.
5. Check carefully if the brakes are in good
condition.
6. Adjust the handlebar to the appropriate position.
7. Make sure all screws are fastened well.
8. Do not recharge the E-scooter in an
unmanned environment or while sleeping.
9. Only original power adapters are allowed to
recharge E-scooter.
10. Do not do any modifications to E-scooter.
11. Obey your country’s traffic rules.

Users’ Manual
4
Version 2.0
GET TO KNOW EACH PART
ELECTRIC SCOOTER ILLUSTRATION
Note
Some accessories may need to purchase
additionally.

Users’ Manual
5
Version 2.0
CHECK ACCESSORIES AFTER UNPACKING
MAKE SURE YOU HAVE RECEIVED ALL
ACCESSORIES
1. Check if there is a Charger
2. Check if there is a Seat
3. Check if there is manual
4. Check if there is an Alarm Remote Controller

Users’ Manual
6
Version 2.0
FOLDING OPERATION
HANDLEBAR FOLDING OPERATION
Step 1 Find the two folding Step 2 Pull the folding
Sleeves on the handlebar Sleeve and fold down
toward the Direction of
the arrow
Step3, repeat operation as Step 2

Users’ Manual
7
Version 2.0
FOLDING OPERATION
POLE FOLDING
Step 1 Pull down the safety Step 2 Hold the pole by
Lock One hand; Press down the
Red folding Lock by the
other hand; Then fold the
pole down
UNFOLDING OPERATION
Step 1 Push down the folding Step 2 Push back the
Lock, and Push back the Pole Safety Lock
At the same time

Users’ Manual
8
Version 2.0
T-TUBE HEIGHT ADJUSTMENT
T-TUBE HEIGHT ADJUSTMENT
Step 1 Pull the fastening Step 2 Adjust the poleheight
Buckle and loosen it. To your required height.
Step 3 Tighten the fastening
Buckle, and turn it back

Users’ Manual
9
Version 2.0
GET TO KNOW THE HANDLEBAR OF YOUR
E-SCOOTER
Top：from left to right Turning light gear speed Front light
Bottom：from left to right battery motor throttle controller brake
Press the green button will change gears from 1 to 3
MULTIFUNCTIONAL
DISPLAY
LIGHT SWITCH
TURNING LIGHT
SWITCH/ HORN
ECO/TURBO
BUTTON
SINGLE/DUAL
BUTTON

Users’ Manual
10
Version 2.0
ECO & TURBO / SINGLE & DUAL
ECO TURBO / SINGLE DUAL SWITCH
1. The red button ( ) is a Single and dual
switch that is used for shifting Single motor
driving and dual motor driving mode.
2. The yellow button ( )is used for riding athigh
speed or low speed.
NOTE
We strongly recommend you ride in SINGLE AND ECO
mode for the first time. When you can ride skillfully at
low speed, you can try dual motors and at Turbo mode.
Please be noted that the mileage will be shorter at dual
motor and Turbo mode. If you want to ride for a long
distance, we recommend riding the scooter with a
Single motor and in ECO mode.

Users’ Manual
11
Version 2.0
RECHARGING OPERATION
RECHARGING BATTERY
1. Open the cover of the charging port
2. Insert the DC plug of the power adapter
into the charging port
3. Insert the AC plug of the power
adapter intoawall socket.
NOTE
1. Must use the original Power adapter to recharge
your E-scooter.
2. There are 2 charging ports on your electric scooter,
we recommend recharging your E-scooter witha
single charger, which can prolong the battery life
span.
3. Please do not recharge your E-scooter indoors,and
do not recharge without a person monitoring

Users’ Manual
12
Version 2.0
TROUBLE SHOOTINGS
COMMON FAULTS AND SOLUTIONS
Cannot start E-scooter
1: Confirm if the battery is out of electricity
2: Open the foot pedal and check if the battery fuse is
disconnected or burned.
3: Open the foot pedal to check if the connection
between the accelerator main line and the
controller loosened or not.
4: Check the connection between battery and controller.
Cannot Recharge E-scooter
1: Connect the charger to the charging port to see if
the indicator light works or not.
2: Open the foot pedal to check if the battery fuse is
disconnected or burned out.
Cannot accelerate E-scooter
1: Confirm if the brake lever is bound back to its original
position.
2: Open the foot pedal to check if the connection
between the controller and motor loosened or
not.

Users’ Manual
13
Version 2.0
E-SCOOTER MAINTENANCE
E-SCOOTER MAINTENANCE
1. Please charge your e-scooter after your
receipt of it and recharge it after yourriding
every time.
2. Please check battery status regularly and
recharge it in time if you do not ride it for
a long time.
3. Do not ride on rainy days or ride into puddles
4. It’s forbidden to disassemble or modify
E-scooter.
5. When braking performance starts to decline,
please check whether there is brake oil in the
tubing. If not, please add brake oil. If the
brake efficiency is still not in good condition,
and there is an audible sound, please replace
the brake pads.
6. Every 6 months, a small amount of lubricant
should be used to maintain the clutch of the
folding handle. (Please not use WD40 to
lubricate the E-scooter, and not lubricate the
front and rear wheels.)
7. When the tires are visually worn, please
replace them immediately.
8. Check all screws regularly to make sureeach
of them is fastened.

Users’ Manual
14
Version 2.0
WARRANTY GUARANTEE
WARRANTY GUARANTEE
We have a warranty and provide after-sale
services to our customers. If the E-scooter has
any quality issues, please feel free to contact us.
We will offer professional instructions and
solutions to you timely.
We offer 365 days warranty for the following
parts MOTOR, ACCELERATOR, CHARGER,
CONTROLLER, BATTERY, AND SCOOTER BODY
under the condition of normal operation. Please
be noted that we will not offer a warranty
under the following situations:
1. Not proper maintenance according toour
manual.
2. Man-made damages.
3. Damage caused by force majeure.
4. Other deficiencies situations will be judged
by our company or dealer.
CAUTION!
Our warranty is only provided after receipt of
the warranty card or original purchase
certificate or proof provided by our dealers.
Please keep any of them properly.

Users’ Manual
15
Version 2.0
Model NO
BLAZE TURBO 6000watt Lithium scooter
frame
Aluminum and High Tensile Steel Frame
motor
60V 3000W Motor Front and Rear
controller
60V 3000W *2
battery
60V 25AH lithium battery
charger
60V 2A AC110-230V DC60V
charger time
Up to 7 hours
Brake(front/rear)
Hydraulic Oil disc brake
tire
11-inch Pneumatic tires
front light
yes
rear light
yes
running distance
Up to 50 Miles (Varies due to rider weight,
speed, and terrain)
Speed
Up to 55 MPH (Varies due to rider weight and
terrain)
load capacity
500 lbs.
G.W/N. W
110 / 100 lbs.
carton size
130*33*64CM
The climbing power for this scooter is 60
degrees. It can climb any mountain hill with
ease.
