Kumpan electric 54i User manual
Customer Service
+49 (0) 2642 999 800
e-bility GmbH
Dieselstraße 28
D-53424 Remagen
kumpan-electric.com/download
www.kumpan-electric.de
Connect Power
Pack with the Charging
Unit using a charging
cable
Connect the mains plug
to a socket and switch on
the charging unit
Read the charge level on
the display
12 3
54 i
CONTACTCONTACT
This Quick Starter Guide will help you take your first steps with the Kumpan. It
does not replace the User Manual! Please make sure to above all read through
the hazard warnings!
QUICK STARTERQUICK STARTER
Checklist before your first drive
• Did you read through the Quick Starter Guide/
Manual?
• Licence plate installed?
• Battery charged and stowed in the battery
compartment?
• Mirrors mounted and set correctly?
• Checked the tyres for the correct pressure: 2.2 bar
front, 2.6 bar rear?
• Do all signalisation and lighting systems
work properly?
• Checked the brake system for proper function –
confirmed the brake pressure point?
• Helmet and protective clothing on?
• Unused battery slots closed using the covering cap?
1st PREPARING1st PREPARING
continue in the Display
Start release
a - “Enter” button on the control pad or
b - Confirm “OK” on the touch screen
Brake check –
applying both brakes
Switching the driving mode
a – via the display or
b – via the control pad + Enter
– in the menu, select the driving mode
and switch
Fold up the main stand –
ready to go!
Start
Press Start/Stop
Recognising the key
(Key nearby, not
covered)
1
2
3
3
4
4
5a
5b
5
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
ECO
Wh
0
km/h
0
08:22 Uhr · 01.01.2019 MENU
2. START2. START
User Manual
up to 6s
MENU08:22 Uhr ·
01.01.2019
ECO
START
ZUM STARTEN
BESTÄTIGEN
OK
Customer Service
+49 (0) 2642 999 800
e-bility GmbH
Dieselstraße 28
D-53424 Remagen
kumpan-electric.com/download
www.kumpan-electric.de
Connect Power
Pack with the Charging
Unit using a charging
cable
Connect the mains plug
to a socket and switch on
the charging unit
Read the charge level on
the display
12 3
54 i
CONTACTCONTACT
This Quick Starter Guide will help you take your first steps with the Kumpan. It
does not replace the User Manual! Please make sure to above all read through
the hazard warnings!
QUICK STARTERQUICK STARTER
Checklist before your first drive
• Did you read through the Quick Starter Guide/
Manual?
• Licence plate installed?
• Battery charged and stowed in the battery
compartment?
• Mirrors mounted and set correctly?
• Checked the tyres for the correct pressure: 2.2 bar
front, 2.6 bar rear?
• Do all signalisation and lighting systems
work properly?
• Checked the brake system for proper function –
confirmed the brake pressure point?
• Helmet and protective clothing on?
• Unused battery slots closed using the covering cap?
1st PREPARING1st PREPARING
continue in the Display
Start release
a - “Enter” button on the control pad or
b - Confirm “OK” on the touch screen
Brake check –
applying both brakes
Switching the driving mode
a – via the display or
b – via the control pad + Enter
– in the menu, select the driving mode
and switch
Fold up the main stand –
ready to go!
Start
Press Start/Stop
Recognising the key
(Key nearby, not
covered)
1
2
3
3
4
4
5a
5b
5
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
ECO
Wh
0
km/h
0
08:22 Uhr · 01.01.2019 MENU
2. START2. START
User Manual
up to 6s
MENU08:22 Uhr ·
01.01.2019
ECO
START
ZUM STARTEN
BESTÄTIGEN
OK
Customer Service
+49 (0) 2642 999 800
e-bility GmbH
Dieselstraße 28
D-53424 Remagen
kumpan-electric.com/download
www.kumpan-electric.de
Connect Power
Pack with the Charging
Unit using a charging
cable
Connect the mains plug
to a socket and switch on
the charging unit
Read the charge level on
the display
12 3
54 i
CONTACTCONTACT
This Quick Starter Guide will help you take your first steps with the Kumpan. It
does not replace the User Manual! Please make sure to above all read through
the hazard warnings!
QUICK STARTERQUICK STARTER
Checklist before your first drive
• Did you read through the Quick Starter Guide/
Manual?
• Licence plate installed?
• Battery charged and stowed in the battery
compartment?
• Mirrors mounted and set correctly?
• Checked the tyres for the correct pressure: 2.2 bar
front, 2.6 bar rear?
• Do all signalisation and lighting systems
work properly?
• Checked the brake system for proper function –
confirmed the brake pressure point?
• Helmet and protective clothing on?
• Unused battery slots closed using the covering cap?
1st PREPARING1st PREPARING
continue in the Display
Start release
a - “Enter” button on the control pad or
b - Confirm “OK” on the touch screen
Brake check –
applying both brakes
Switching the driving mode
a – via the display or
b – via the control pad + Enter
– in the menu, select the driving mode
and switch
Fold up the main stand –
ready to go!
Start
Press Start/Stop
Recognising the key
(Key nearby, not
covered)
1
2
3
3
4
4
5a
5b
5
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
ECO
Wh
0
km/h
0
08:22 Uhr · 01.01.2019 MENU
2. START2. START
User Manual
up to 6s
MENU08:22 Uhr ·
01.01.2019
ECO
START
ZUM STARTEN
BESTÄTIGEN
OK
Afterwards, the
handlebar lock
automatically engages
when twisting the
handlebar to the left.
Parking
Place the vehicle on solid
ground using the main
stand
4. PARKING & SECURING4. PARKING & SECURING
Switching
off:
1st Press Start/Stop
- Hold until you hear the
locking sound
1
2
Note
Preparing to drive
- Close Power Pack sockets not
in use with the covering cap
- Loading flap at the front of the
scooter closed (does not apply to the 54
inspire model)
3
LAW & LEGAL
The Kumpan 54i models are road vehicles – in other words, they are
exclusively approved for use on public roads. Your Kumpan is a quiet
vehicle. You must therefore be particularly careful about other road
users noticing you.
For safe and carefree driving:
- Drive carefully and considerately
- Observe the applicable road laws
- Use an approved helmet
- Only drive with appropriate insurance cover and
- only with a driver’s licence valid for the vehicle class
The Kumpan models with max. speeds of 25/45 km/h may not be
used to drive on motorways and express ways.
1
2
1
Storage space
in the compartments behind the cladding or
under the seat
in the topcase (accessory) 08:22 Uhr · 01.01.2019 MENU
ECO
open
*Push here
3
2
3
Switch Unit Left
Full beam – on/off
Anti-glare light – permanently
active
Turn signal switch – pull to the left
or the right
Switch off – tap
1
2
1
2
3
3
Switch Unit Right
Emergency-Off switch –
motor stop + warning lights
automatically switch on
Control pad + enter –
operation on the display
Cruise control
4
5
4
5
6
6
Twist the gas
handle to
accelerate
rear < Brake > front
Operation
Display
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
Speed display
warning lights
Battery level/consumption
Driving Mode
7
8
1
2
6 8
7
10
9
3. DRIVING3. DRIVING
Safety instructions
Carefully use the gas handle and brakes, especially while you’re
becoming acquainted with vehicle operation. The quickest way to
stop is by simultaneously applying both brakes.
Driving in wet/slippery conditions – slip
hazard!
accelerate and brake carefully
- with slippery/wet roads
- new tyres
- new braking discs, pads
The vehicle cannot accelerate
if the side stands are folded out
Afterwards, the
handlebar lock
automatically engages
when twisting the
handlebar to the left.
Parking
Place the vehicle on solid
ground using the main
stand
4. PARKING & SECURING4. PARKING & SECURING
Switching
off:
1st Press Start/Stop
- Hold until you hear the
locking sound
1
2
Note
Preparing to drive
- Close Power Pack sockets not
in use with the covering cap
- Loading flap at the front of the
scooter closed (does not apply to the 54
inspire model)
3
LAW & LEGAL
The Kumpan 54i models are road vehicles – in other words, they are
exclusively approved for use on public roads. Your Kumpan is a quiet
vehicle. You must therefore be particularly careful about other road
users noticing you.
For safe and carefree driving:
- Drive carefully and considerately
- Observe the applicable road laws
- Use an approved helmet
- Only drive with appropriate insurance cover and
- only with a driver’s licence valid for the vehicle class
The Kumpan models with max. speeds of 25/45 km/h may not be
used to drive on motorways and express ways.
1
2
1
Storage space
in the compartments behind the cladding or
under the seat
in the topcase (accessory) 08:22 Uhr · 01.01.2019 MENU
ECO
open
*Push here
3
2
3
Switch Unit Left
Full beam – on/off
Anti-glare light – permanently
active
Turn signal switch – pull to the left
or the right
Switch off – tap
1
2
1
2
3
3
Switch Unit Right
Emergency-Off switch –
motor stop + warning lights
automatically switch on
Control pad + enter –
operation on the display
Cruise control
4
5
4
5
6
6
Twist the gas
handle to
accelerate
rear < Brake > front
Operation
Display
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
Speed display
warning lights
Battery level/consumption
Driving Mode
7
8
1
2
6 8
7
10
9
3. DRIVING3. DRIVING
Safety instructions
Carefully use the gas handle and brakes, especially while you’re
becoming acquainted with vehicle operation. The quickest way to
stop is by simultaneously applying both brakes.
Driving in wet/slippery conditions – slip
hazard!
accelerate and brake carefully
- with slippery/wet roads
- new tyres
- new braking discs, pads
The vehicle cannot accelerate
if the side stands are folded out
Afterwards, the
handlebar lock
automatically engages
when twisting the
handlebar to the left.
Parking
Place the vehicle on solid
ground using the main
stand
4. PARKING & SECURING4. PARKING & SECURING
Switching
off:
1st Press Start/Stop
- Hold until you hear the
locking sound
1
2
Note
Preparing to drive
- Close Power Pack sockets not
in use with the covering cap
- Loading flap at the front of the
scooter closed (does not apply to the 54
inspire model)
3
LAW & LEGAL
The Kumpan 54i models are road vehicles – in other words, they are
exclusively approved for use on public roads. Your Kumpan is a quiet
vehicle. You must therefore be particularly careful about other road
users noticing you.
For safe and carefree driving:
- Drive carefully and considerately
- Observe the applicable road laws
- Use an approved helmet
- Only drive with appropriate insurance cover and
- only with a driver’s licence valid for the vehicle class
The Kumpan models with max. speeds of 25/45 km/h may not be
used to drive on motorways and express ways.
1
2
1
Storage space
in the compartments behind the cladding or
under the seat
in the topcase (accessory) 08:22 Uhr · 01.01.2019 MENU
ECO
open
*Push here
3
2
3
Switch Unit Left
Full beam – on/off
Anti-glare light – permanently
active
Turn signal switch – pull to the left
or the right
Switch off – tap
1
2
1
2
3
3
Switch Unit Right
Emergency-Off switch –
motor stop + warning lights
automatically switch on
Control pad + enter –
operation on the display
Cruise control
4
5
4
5
6
6
Twist the gas
handle to
accelerate
rear < Brake > front
Operation
Display
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
Speed display
warning lights
Battery level/consumption
Driving Mode
7
8
1
2
6 8
7
10
9
3. DRIVING3. DRIVING
Safety instructions
Carefully use the gas handle and brakes, especially while you’re
becoming acquainted with vehicle operation. The quickest way to
stop is by simultaneously applying both brakes.
Driving in wet/slippery conditions – slip
hazard!
accelerate and brake carefully
- with slippery/wet roads
- new tyres
- new braking discs, pads
The vehicle cannot accelerate
if the side stands are folded out
Afterwards, the
handlebar lock
automatically engages
when twisting the
handlebar to the left.
Parking
Place the vehicle on solid
ground using the main
stand
4. PARKING & SECURING4. PARKING & SECURING
Switching
off:
1st Press Start/Stop
- Hold until you hear the
locking sound
1
2
Note
Preparing to drive
- Close Power Pack sockets not
in use with the covering cap
- Loading flap at the front of the
scooter closed (does not apply to the 54
inspire model)
3
LAW & LEGAL
The Kumpan 54i models are road vehicles – in other words, they are
exclusively approved for use on public roads. Your Kumpan is a quiet
vehicle. You must therefore be particularly careful about other road
users noticing you.
For safe and carefree driving:
- Drive carefully and considerately
- Observe the applicable road laws
- Use an approved helmet
- Only drive with appropriate insurance cover and
- only with a driver’s licence valid for the vehicle class
The Kumpan models with max. speeds of 25/45 km/h may not be
used to drive on motorways and express ways.
1
2
1
Storage space
in the compartments behind the cladding or
under the seat
in the topcase (accessory) 08:22 Uhr · 01.01.2019 MENU
ECO
open
*Push here
3
2
3
Switch Unit Left
Full beam – on/off
Anti-glare light – permanently
active
Turn signal switch – pull to the left
or the right
Switch off – tap
1
2
1
2
3
3
Switch Unit Right
Emergency-Off switch –
motor stop + warning lights
automatically switch on
Control pad + enter –
operation on the display
Cruise control
4
5
4
5
6
6
Twist the gas
handle to
accelerate
rear < Brake > front
Operation
Display
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
Speed display
warning lights
Battery level/consumption
Driving Mode
7
8
1
2
6 8
7
10
9
3. DRIVING3. DRIVING
Safety instructions
Carefully use the gas handle and brakes, especially while you’re
becoming acquainted with vehicle operation. The quickest way to
stop is by simultaneously applying both brakes.
Driving in wet/slippery conditions – slip
hazard!
accelerate and brake carefully
- with slippery/wet roads
- new tyres
- new braking discs, pads
The vehicle cannot accelerate
if the side stands are folded out
Customer Service
+49 (0) 2642 999 800
e-bility GmbH
Dieselstraße 28
D-53424 Remagen
kumpan-electric.com/download
www.kumpan-electric.de
Connect Power
Pack with the Charging
Unit using a charging
cable
Connect the mains plug
to a socket and switch on
the charging unit
Read the charge level on
the display
12 3
54 i
CONTACTCONTACT
This Quick Starter Guide will help you take your first steps with the Kumpan. It
does not replace the User Manual! Please make sure to above all read through
the hazard warnings!
QUICK STARTERQUICK STARTER
Checklist before your first drive
• Did you read through the Quick Starter Guide/
Manual?
• Licence plate installed?
• Battery charged and stowed in the battery
compartment?
• Mirrors mounted and set correctly?
• Checked the tyres for the correct pressure: 2.2 bar
front, 2.6 bar rear?
• Do all signalisation and lighting systems
work properly?
• Checked the brake system for proper function –
confirmed the brake pressure point?
• Helmet and protective clothing on?
• Unused battery slots closed using the covering cap?
1st PREPARING1st PREPARING
continue in the Display
Start release
a - “Enter” button on the control pad or
b - Confirm “OK” on the touch screen
Brake check –
applying both brakes
Switching the driving mode
a – via the display or
b – via the control pad + Enter
– in the menu, select the driving mode
and switch
Fold up the main stand –
ready to go!
Start
Press Start/Stop
Recognising the key
(Key nearby, not
covered)
1
2
3
3
4
4
5a
5b
5
08:22 Uhr ·
01.01.2019
MENU
ECO
Wh
0
km/h
0
ECO
Wh
0
km/h
0
08:22 Uhr · 01.01.2019 MENU
2. START2. START
User Manual
up to 6s
MENU08:22 Uhr ·
01.01.2019
ECO
START
ZUM STARTEN
BESTÄTIGEN
OK
Other manuals for 54i
2
Table of contents
Other Kumpan electric Scooter manuals
