1. GETTING STARTED
What’s In The Box?
• 1 x Puck CSI™ Xtreme UV LED PAR Fixture
• 1x IEC Power Cord
• This Lovely User Manual
Getting It Out Of The Box
Congratulations,aspiringcrimeghterand/orpsychedelicmusicacionado!Nowthat
you’ve got The Puck CSI™ Xtreme (or hopefully, Xtreme’s!), you should carefully unpack
the box and check the contents to ensure that all parts are present and in good condition.
If anything looks as if it has been damaged in transit, notify the shipper immediately and
keep the packing material for inspection. Again, please save the carton and all packing
materials.Ifaxturemustbereturnedtothefactory,itisimportantthatthexturebe
returned in the original factory box and packing.
Powering Up!
Allxturesmustbepowereddirectlyoffaswitchedcircuitandcannot be run off a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch -Notallxtureshaveavoltageselectswitch,sopleaseverifythatthe
xtureyoureceiveissuitableforyourlocalpowersupply.Seethelabelonthextureor
refertothexture’sspecicationschartformoreinformation.Axture’slistedcurrent
ratingisitsaveragecurrentdrawundernormalconditions.Checkthextureordevice
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, just give us a call or send an email. We’ll be happy to
help, honest.
Blizzard Lighting
N16 W23390 Stoneridge Dr. Suite E
Waukesha, WI 53188 USA
www.blizzardlighting.com
414-395-8365
Email: [email protected]
Disclaimer:Theinformationandspecicationscontainedinthisdocumentaresubject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardlighting.com.
Author: Date: Last Edited: Date:
J. Thomas 6/13/2013 J. Thomas 3/3/2014

Page 4
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
SAFETY INSTRUCTIONS
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
calorrearpanelofthexture.
• This product is intended for indoor use only.
•Topreventriskofreorshock,donotexposexturetorainormoisture.
•Makesuretherearenoammablematerialsclosetotheunitwhileoperating.
• The unit must be installed in a location with adequate ventilation, at least
20in(50cm)fromadjacentsurfaces.Besurethatnoventilationslotsare
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
•ALWAYSsecurextureusingasafetychain.NEVERcarrythexturebyits
cord. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
your unit may require service, please contact Blizzard Lighting at sup-
[email protected].

Page 5
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
2. MEET THE PUCK CSI™XTREME
CONTROL FEATURES
• High output UV via 36x 3w 390-410nm UV LEDs
• Full on UV LED intensity + 4 separate LED pixel patterns
• Variable electronic strobe
• Variable electronic dimmer
• Built-in automated programs via DMX and master/slave
• Built-in sound active programs
ADDITIONAL FEATURES
• Lightweight and compact (It kept its New Years’ resolution!)
• 4-Button LED control panel for easy programming
•Dualbracketforexibilityinmounting
•Poweroutletforxturelinking
DMX Quick Reference (7-Channel Mode)
Channel Channel Value What It Does
1000 <-> 255 Master Dimmer (0% <--> 100%)
2000 <-> 255 Pattern 1 Intensity (0% <--> 100%)
3000 <-> 255 Pattern 2 Intensity (0% <--> 100%)
4000 <-> 255 Pattern 3 Intensity (0% <--> 100%)
5000 <-> 255 Pattern 4 Intensity (0% <--> 100%)
6000 <-> 255 Strobe (slow <--> fast)
7000 <-> 255 Auto Mode (slow <--> fast)
DMX Quick Reference (4-Channel Mode)
Channel Channel Value What It Does
1000 <-> 255 Pattern 1 Intensity (0% <--> 100%)
2000 <-> 255 Pattern 2 Intensity (0% <--> 100%)
3000 <-> 255 Pattern 3 Intensity (0% <--> 100%)
4000 <-> 255 Pattern 4 Intensity (0% <--> 100%)

Page 6
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Figure 1: The Puck CSI™ Pin-Up Picture
Ridiculously Thin!
Dual Mounting Yokes
Figure 2: The Rear Connections
AC Power In/Out
DMX In DMX Out
LED Control Panel Microphone
36x 3-watt UV LEDs

Page 7
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
Withaatheadscrewdriver,wedgethe
fuse holder out of its housing. Remove the
damaged fuse from its holder and replace
with exact same type fuse. Insert the fuse
holder back in its place and reconnect
power.
Connecting A Bunch of Puck CSI™ Xtreme Flat LED PAR Cans
You will need a serial data link to run light shows using a DMX-512
controllerortorunshowsontwoormorexturessettosyncinmas-
ter/slave operating mode. The combined number of channels required
byallthexturesonaserialdatalinkdeterminesthenumberofx-
tures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line.
Also,connectingmorethan32xturesononeserialdatalinkwithout
the use of a DMX optically-isolated splitter may result in deterioration
of the digital DMX signal.
The maximum recommended cable-run distance is 500 meters (1640
ft).Themaximumrecommendednumberofxturesonaserialdata
linkis32xtures.
Data/DMX Cabling
Tolinkxturestogetheryou’llneeddatacables.Youshouldusedata-
grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
Forinstance,Belden©9841meetsthespecicationsforEIARS-485
applications. Standard microphone cables will “probably” be OK, but
note that they cannot transmit DMX data as reliably over long distanc-
es. In any event, the cable should have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms

Page 8
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR
connector on the other end. (Duh!)
CAUTION:Donotallowcontactbetweenthecommonandthex-
ture’s chassis ground. Grounding the common can cause a ground
loop,andyourxturemayperformerratically.Testcableswithan
ohm meter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
They are widely available over the internet and from specialty retailers If you’d like to build your own, the
chart below details a proper cable conversion:
Conductor 3-Pin Female
(Output)
5-Pin Male
(Input)
Ground/Shield Pin 1 Pin 1
DMX Data (-) Pin 2 Pin 2
DMX Data (+) Pin 3 Pin 3
Not Used. No Connection. No Connection.
Not Used. No Connection. No Connection.
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the
DMX cable to the female connector (output)
on the controller.
Step 2: Connect the female connector of the
DMXcabletotherstxture’smaleconnec-
tor (input). Note: It doesn’t matter which
xtureaddressistherstoneconnected.
Werecommendconnectingthexturesin
terms of their proximity to the controller,
ratherthanconnectingthelowestxture
numberrst,andsoon.
Step 3:Connectotherxturesinthechain
from output to input as above. Place a DMX
terminatorontheoutputofthenalxture
to ensure best communication.

Page 9
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3 pin connector side of the
DMX cable to the output (female) 3 pin connector of
therstxture.
2. Connect the end of the cable coming from the
rstxturewhichwillhavea(female)3pinconnec-
tortotheinputconnectorofthenextxturecon-
sisting of a (male) 3 pin connector. Then, proceed
to connect from the output as stated above to the
inputofthefollowingxtureandsoon.
A quick note: Often,
the setup for Master-
Slave and Standalone
operation requires that
therstxtureinthe
chain be initialized for
this purpose via either
settings in the control
panel or DIP-switches.
Secondarily,thextures
that follow may also re-
quire a slave setting.
Check the “Operating Adjustments” section in this manual for com-
pleteinstructionsforthistypeofsetupandconguration.
Mounting & Rigging
ThisxturemaybemountedinanySAFEpositionprovidedthereis
enough room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the
xtureusingasuitable“C”or“O”typeclamp.Theclampshouldbe
ratedtoholdatleast10xthexture’sweighttoensurestructuralsta-
bility. Do not mount to surfaces with unknown strength, and ensure
properly“rated”riggingisusedwhenmountingxutresoverhead.
Adjusttheangleofthexturebylooseningbothknobsandtiltingthe
xture.Afterndingthedesiredposition,retightenbothknobs.
• When selecting installation location, take into consideration lamp
replacement access (if applicable) and routine maintenance.
• Safety cables MUST ALWAYS be used.
•Nevermountinplaceswherethexturewillbeexposedtorain,
high humidity, extreme temperature changes or restricted ventilation.

Page 10
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
USING THIS FIXTURE WITH THE wiCICLE® WIRELESS
DMX SYSTEM
In addition to the unbridled thrill you already re-
ceivedthersttimeyoupluggedinyourxture,
you’llbedelightedtoknowthatThisxturealso
works seamlessly with our wiCICLE®Wireless
DMX system, without additional power.
•ONLYxturesbearingthislogoarecertiedforusewiththewiCICLE®without
external power.
• Unauthorized modication and/or using the wiCICLE®with unap-
proved xtures may cause damage to the wiCICLE® or xture. UNDER
NO CIRCUMSTANCES IS BLIZZARD LIGHTING RESPONSIBLE FOR ANY
DAMAGE FROM SUCH OPERATION.
• Fixtures bearing the above logo MUST only use cable and connectors which
separate chassis/case ground from cable shielding. Cabling with the shield con-
nected to the connector’s case/chassis may cause malfunction and damage to
the wiCICLE®orxture.
• wiCICLE®transmitters have additional power requirements and there-
forecannotbepowereddirectlyfromthexture.Youwillneedtoutilize
the supplied AC/DC adaptor to drive wiCICLE®transmitters in your
system.
WE HAD THIS SPACE, SO WE FIGURED WE’D DRAW
YOU A PICTURE:
Antenna Housing & 1/2-wave
Antenna
Antenna ferrule & articulation
joint
Stainless Steel Housing
Recessed Selector Button
Status LED
3-Pin XLR Connector
(Male on transmitter, Female
on receiver model)

Page 11
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Each wiCICLE®acts as both a transmitter and a receiver, depending on whether
a DMX source is applied to the integral XLR connector. This is an extremely
powerful feature of the system, however, it also requires 1 piece of due dili-
gence, and that is the removal of extraneous DMX signals from your lighting rig
BEFORE proceeding.
SO: BEFORE DOING ANYTHING ELSE, YOU SHOULD DISABLE ANY
BUILT-IN PROGRAMS IN THE FIXTURES YOU WISH TO CONNECT AND/
OR SET THEM AS SLAVES PRIOR TO RETURNING THEM TO DMX MODE
(IF APPLICABLE). Most xtures contain a built-in automatic, sound
active or custom program which is designed to operate with the xture
NOT connected to a DMX chain.
Someoftheseprogramswillautomaticallyrununlessthextureissettoslave
mode.ThesexturestypicallysenseDMXautomaticallyandswitchtoDMX
mode upon receiving DMX signal (our Pucks do that!)
If you plug a wiCICLE®“receiver”intoanautosensingxturesetasa“mas-
ter, “chances are good that the wiCICLE®“receiver” will begin transmitting the
master program. Most times, this is undesirable, and taking the two seconds to
switch these programs off will solve a lot of ails.
Got that done? Good! Then let’s proceed!
1. Plug the wiCICLE®Receiverintothe“DMXIN”connectorofthextureand
verify it is receiving power (the STATUS LED should illuminate.)
2. Connect the AC/DC adaptor to the wiCICLE®Transmitter and verify it is re-
ceiving power (the STATUS LED should illuminate.)
3. Press the RECESSED SELECTOR BUTTON on the Transmitter to select the
operating channel group. (The system will store this setting for future use)
The 7-Color Status LED will change color to indicate the current channel group:
· GROUP 1: RED
· GROUP 2: GREEN
· GROUP 3: YELLOW
· GROUP 4: BLUE
· GROUP 5: VIOLET
· GROUP 6: CYAN
· GROUP 7: WHITE
4. Follow the same procedure on the Receiver to select the channel group.
5. Once both the transmitter and receiver(s) are both set to the same chan-
nel group, connect the transmitter to the DMX controller or the DMX out of a
xtureonyourDMXchain.
6. Once a DMX signal is provided to the transmitter, the status LED will blink
RED slowly until communication is established with the receiver. The status
LEDonthereceiver(s)willashGREEN slowly until communication is estab-
lished.
7. Once the clearest channel is auto-selected, the status LEDs will blink quickly
on both the transmitter and receiver. NOTE: The color of the LED DURING
operation does not indicate channel group, instead it indicates whether the
unit is transmitting or receiving. That’s It!
NOTE: “GROUP” number
also corresponds to the
“GROUP” setting on our
LightCaster™wireless DMX
Transceiver.

Page 12
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and different modes possible with the Puck CSI Xtreme
areaccessedbyusingthecontrolpanelontherearofthexture.
There are 4 control buttons below the LED display which allow you to
navigate through the various control panel menus.
<MENU>
Is used to navigate to the previous higher-level menu item.
<UP>
Scrolls through menu items and numbers in ascending order.
<DOWN>
Scrolls through menu items and numbers in descending order.
<ENTER>
Isusedtoselectandconrm/storethecurrentselection.
The Control Panel LED Display shows the menu items you select from
the menu map on page #13. When a menu function is selected, the
displaywillshowimmediatelytherstavailableoptionfortheselected
menu function. To select a menu item, press <ENTER>.
Press the <MENU> button repeatedly until you reach the desired
menu function. Use the <UP> and <DOWN> buttons to navigate the
menu options. Press the <ENTER> button to select the menu function
currently displayed, or to enable a menu option. To return to the previ-
ous option or menu without changing the value, press the
<MENU> button.

Page 13
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Co 1 Pixel Group 1
Co 2 Pixel Group 2
Co 3 Pixel Group 3
Co 4 Pixel Group 4
Co 5 Pixel Group 5
Co 6 Pixel Group 6
Co 7 Pixel Group 7
Co 8 Pixel Group 8
Co 9 Pixel Group 9
Co10 Pixel Group 10
Co11 Pixel Group 11
Co12 Pixel Group 12
Co13 Pixel Group 13
Co14 Pixel Group 14
Co15 Pixel Group 15
Auto Auto Mode
Speed: SP1-SP8
Control Panel Menu Structure
Addr 001 - 512 To set DMX address: 1-512
Chnd 7CH To choose 7 channel DMX mode
4CH To choose 4 channel DMX mode
SLnd NASt Setasmasterxture
SLAu Setasslavexture
ShNd Soun Sound Active Mode
CoLo <ENTER>
FAdE Fade Mode, Speed: SP1-SP8
NAnu red Pixel Group 1 Intensity (0-255)
GrEE Pixel Group 2 Intensity (0-255)
bLuE Pixel Group 3 Intensity (0-255)
UhIt Pixel Group 4 Intensity (0-255)
test Test Mode / Auto Check
FhrS Displays Total Running Hours

Page 14
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Set the DMX Starting Address
1.TosettheDMXaddressofthexture,usethe<MENU> button to navigate to
Addr, then press <ENTER>.
2. Then use the <UP/DOWN> buttons to choose the starting DMX address
within the range of 000-512.
3. Press the <ENTER>buttontoconrm.
Set the DMX Channel Mode
1.TosettheDMXchannelmodeofthexture,usethe<MENU> button to
navigate to ChNd, then press <ENTER>.
2. Then use the <UP/DOWN> buttons to highlight 7CH or 4CH.
3. Press the <ENTER>buttontoconrm.
Master/Slave Modes
Allows you to link up to 32 units together without a controller.
1. To set the unit to act as either a master or slave, use the <MENU> button to
navigate to SLNd, then press <ENTER>.
2. Use the <UP/DOWN> buttons to highlight NASt (master) or SLAu (slave).
3. Press the <ENTER>buttontoconrm.
*TherecanbeonlyonemasterxtureintheDMXchain.Therstxtureshould
be set as the master, while the others set as slave units. It may be necessary to
useaterminatoratthelastxture.
Sound Active, Pixel Groups, Auto, & Fade Mode:
Display static pixel groups individually or combined in sound active, auto or fade modes.
Sound Active Mode
1. Use the <MENU> button to navigate to ShNd then press <ENTER>.
2. Then use the <UP/DOWN> buttons to display SoUn (thedisplaywillash).
3. Do not press any buttons. You will enter sound active mode in 15 seconds.
Static Pixel Groups
1. Use the <MENU> button to navigate to ShNd then press <ENTER>.
2. Then use the <UP/DOWN> buttons to display CoLo then press <ENTER>.
3. Press the <UP/DOWN> buttons to display Co 1 - Co15.
4. Press the <ENTER> button, then <ENTER> again to save.
Auto Mode
1. Use the <MENU> button to navigate to ShNd then press <ENTER>.
2. Then use the <UP/DOWN> buttons to display CoLo then press <ENTER>.
3. Press the <UP/DOWN> buttons to display Auto.
4. Press the <ENTER> button, then from here use the <UP/DOWN> buttons to
navigate the speed setting from SP1 (slow) to SP8 (fast).
5. Press the <ENTER> button, then <ENTER> again to save.

Page 15
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Fade Mode
1. Use the <MENU> button to navigate to ShNd then press <ENTER>.
2. Then use the <UP/DOWN> buttons to display FAde then press <ENTER>.
3. Press the <UP/DOWN> buttons to navigate the speed setting from SP1
(slow) to SP8 (fast).
4. Press <ENTER>. The selected fade will start in 15 seconds.
Individual Pixel Group Intensity
Allows the user to adjust the intensity level of each grouping of LEDs. These settings are
global, they will effect all modes.
1. Use the <MENU> button to navigate to NAnu, then press <ENTER>.
2. Then use the <UP/DOWN> buttons to choose either red, Gree, bLue, or
Uhlt.
3. Press the <ENTER> button.
4. Use the <UP/DOWN> buttons to select from 0(off) to 255 (100%).
5. Press the <ENTER>buttontoconrm.
Troubleshooting
Symptom Solution
Fixture Auto-Shut
Off
Checkthefaninthexture.Ifitisstoppedormovingslowerthan
normal, the unit may have shut itself off due to high heat. This is to
protectthexturefromoverheating.Clearthefanofobstructions,
or return the unit for service.
Beam is Dim Check optical system and clean excess dust/grime. Also ensure that
the 220V/110V switch is in the correct position, if applicable.
No Light Output Checktoensurextureisoperatingundercorrectmode,IEsound
active/auto/DMX/Etc., if applicable.
Chase Speed Too
Fast/Slow
Checktoensurepropersetupofspeedadjustment.
No Power Check fuse, AC cord and circuit for malfunction.
Blown Fuse Check AC cord and circuit for damage, verify that moving parts are
not restricted and that unit’s ventilation is not obstructed
Slow Movement Verify that 220V/110V switch is in the correct position, if applicable.
Also check that speed channels are set appropriately.
No Response to
Audio
Verifythatthextureisin“SoundActive”mode.
AdjustAudioSensitivity,IfApplicable.
Fixture Not
Responding /
Responding Er-
raticly
Make sure all connectors are seated properly and securely.
Use Only DMX Cables and/or check cables for defects
Install a Terminator.
Resetxture(s).
Intermittent
Lamp
Check lamp for properly installation.
Relamp, lamp may have reached end of life.
Remote Doesn’t
Work
Verify remote control cable is installed properly and securely.
Verify remote is correct type (CA-9 or other as applicable.)
Fixture Moving
On Its Own
Verifypropermodeofoperation.Isthexturein“Auto”mode?
If your problem persists or isn’t listed contact [email protected].

Page 16
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
5. APPENDIX
Keeping Your Puck CSI™Xtreme As Good As New
Thextureyou’vereceivedisarugged,toughpieceofprolightingequipment,andaslong
as you take care of it, it will take care of you. That said, like anything, you’ll need to take
careofitifyouwantittooperateasdesigned.Youshouldabsolutelykeepthexture
clean, especially if you are using it in an environment with a lot of dust, fog, haze, wild
animals, wild teenagers or spilled drinks.
Cleaning the optics routinely with a suitable glass cleaner will greatly improve the quality of
lightoutput.Keepingthefansfreeofdustanddebriswillkeepthexturerunningcooland
prevent damage from overheating.
Intransit,keepthexturesincases.Youwouldn’tthrowaprizedguitar,drumset,orother
piece of expensive gear into a gear trailer without a case, and similarly, you shouldn’t even
thinkaboutdoingitwithyourshinynewlightxtures.
Commonsenseandtakingcareofyourxtureswillbethesinglebiggestthingyoucando
to keep them running at peak performance and let you worry about designing a great light
show, putting on a great concert, or maximizing your client’s satisfaction and “wow factor.”
That’s what it’s all about, after all!
Returns (Gasp!)
We’ve taken a lot of precautions to make sure you never even have to worry about sending
a defective unit back, or sending a unit in for service. But, like any complex piece of equip-
ment designed and built by humans, once in a while, something doesn’t go as planned. If
youndyourselfwithaxturethatisn’tbehavinglikeagoodlittlextureshould,you’ll
need to obtain a Return Authorization (RA).
Don’t worry, this is easy. Just send an email to [email protected], and we’ll is-
sue you an RA. Then, you’ll need to send the unit to us using a trackable, pre-paid freight
method.WesuggestusingUSPSPriorityorUPS.Makesureyoucarefullypackthexture
for transit, and whenever possible, use the original box & packing for shipping.
Whenreturningyourxtureforservice,besuretoincludethefollowing:
1.) Your contact information (Name, Address, Phone Number, Email address).
2.) The RA# issued to you
3.) A brief description of the problem/symptoms.
Wewill,atourdiscretion,repairorreplacethexture.Pleaserememberthatanyshipping
damage which occurs in transit to us is the customer’s responsibility, so pack it well!
Shipping Issues
Damage incurred in shipping is the responsibility of the shipper, and must be re-
ported to the carrier immediately upon receipt of the items. Claims must be made
within seven (7) days of receipt.

Page 17
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
Tech Specs
Weight & Dimensions
Length 8.25 inches (210 mm)
Width 3.875 inches (98.43 mm)
Height 8.5 inches (215.9 mm)
Weight 4.2 lbs (1.3 kg)
Power
Operating Voltage 110-230VAC, 50-60 Hertz
Power Consumption 108W
Light Source
LED 36x 3w 390-410nm UV LEDs
Optical
Beam Angle 25degrees,29degreeeld
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 4 or 7 (User Selectable)
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave, Sound Active
Pimp Name
Sugartastic Puck CSI Dogg
Warranty
2-year limited warranty, does not cover malfunction
caused by damage to LED’s.

Page 18
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
This page intentionally left blank.

Page 19
The Puck CSI Xtreme User Manual Rev. B Copyright (c) 2014 Blizzard Lighting, LLC
This page intentionally left blank.

Enjoy your product!
Our sincerest thanks for your purchase!
--The team @ Blizzard Lighting
