Blodgett CONVECTION STEAMERS KETTLES BRAISING PANS User manual

NEW
Introducing
Blodgett
Steam
Your Complete
Line of Quality
Steam Equipment
CONVECTION STEAMERS • KETTLES • BRAISING PANS

WHY STEAM?
Page 2
CONVECTION STEAMER APPLICATIONS
Meals per Hour Suggested Steamer Size
Less than 200 3, 4 or 5 pan steamer
200-400 6 pan steamer
400-800 10 pan steamer
Blodgett convection steamers
are perfect for vegetables,
rice, pasta, fish, shellfish,
poultry, hard boiled eggs,
ribs and much more
STEAM KETTLE APPLICATIONS
Meals per Day Suggested Total Kettle Capacity*
100-250 20 gallon
251-350 30 gallon
351-500 40 gallon
501-750 60 gallon
751-1,000 80 gallon
1,001-1,250 100 gallon
1,250-5,000 160 gallon
Use Blodgett steam
kettles for soups,
stocks, stews, sauces
and chili * Blodgett offers steam
kettles from 6 - 100
gallons. However, you
may prefer using
multiple kettles to reach
your total capacity.
BRAISING PAN APPLICATIONS
Meals per Day Suggested Braising Pan Capacity
100-250 One 30 gallon pan
251-350 One 30 gallon pan
351-500 One 40 gallon pan
501-750 Two 30 gallon pans
751-1,000 Two 40 gallon pans
Blodgett braising
pans are ideal for stir
fries, scrambled eggs,
chicken fried steak,
sauces, and much,
much more
Steam is one of the most efficient means of heat transfer available to the
foodservice industry, providing an economical solution to any application,
large or small. Blodgett is pleased to introduce a complete line of quality
steam equipment to meet all of your needs.

Page 3
Kettle table with
BTT-12E braising pan
and KTT-10E shown
+
+
+
+
+
All built with the rugged durability and quality
you have come to expect from Blodgett.
Pressureless Convection Steamers
High Efficiency Gas Convection Steamers
Steam Boiler Cabinets
Steam Kettles
Braising Pans
Cooking in Blodgett Steam
Equipment reduces
loss of nutrients, while
increasing flavor
and moisture.
BLODGETT STEAM - BUILT LIKE A BLODGETT

Page 4 Page 5
PRESSURELESS
CONVECTION STEAMERS
Countertop
Electric & Gas
Convection Steamers
Cabinet Base Electric
Convection Steamers Cabinet Base Gas Convection Steamers High Efficiency
Gas Convection Steamer
Blodgett pressureless convection steamers provide efficient, consistent results
with high volume productivity. High velocity dry steam is available with either
steam generators or cabinet boiler bases in a variety of sizes for any application.
STANDARD FEATURES & BENEFITS
+
+
+
+
+
Easy to clean polished 304
stainless steel exterior
316 stainless steel liner in
cooking compartment for
superior rust prevention
Coved corner liner for
easy cleaning
Simple, easy to operate
controls include
on/off/delime switch,
timer dial, and steamer
ready light
Heavy duty commercial
plumbing components
+
+
+
+
EZ open door with
hands free quick
release handle design
Robust, heavy duty
slammable doors with
EXCLUSIVE 5 year door
warranty
Auto steam generator
blowdown reduces
mineral buildup
Unique, easy to
distinguish timer signal
COUNTERTOP, CABINET BASE, STEAM BOILER BASE
+
+
+
Separate cold water condenser
for each steamer compartment
saves on filtered water expense
The high efficiency gas models
feature unique, high output
steam injectors for quicker
recovery and increased
production
Two water inlets, one for steam,
one for condensate

Steam Boiler
Cabinet Base
Convection Steamers
available in gas,
electric & steam coil models
All Convection Steamers
come with our EXCLUSIVE
5 year Door Warranty.
BLODGETT WaterGuard Filtration System
Blodgett’s filtration system is
specifically engineered to improve
the quality of feed water to your
steamer providing equipment
protection as well as food safety in
the most efficient and thorough
food preparation available. The
Blodgett Filtration System uses
multi functional Ceramic MATRIX
and Polycarbon technology that
converts calcium into nano crystals
that will not adhere to any
surfaces. This system also protects
your equipment from the negative
effects of Chlorine and
Chloramines found in most water
supplies.
When used properly with regular
cartridge replacment, the Blodgett
Filtration System will greatly
extend the life of your boiler and
reduce overall maintenance costs.
Each cartridge will filter up to
12,000 gallons of water
(depending on local water
conditions), and replacement is
simple and quick. The monitoring
gauge lets the operator know
when replacement is required, so
there’s no guess work. A
preventative maintenance
program is readily available from
Blodgett’s local network of service
providers.
Page 5
Second year
warranty included
with purchase of
WaterGuard
Filtration System
+
+
Steam boiler cabinets are
available in 24, 36, 42 and 48
Kw electric units and 140,000,
200,000, 250,000 and
300,000 BTU gas models for
steam service to additional
equipment.
Cabinets available in 24” or
36” widths.
STEAM BOILER CABINETS
Blodgett
convection steamers
are available in
a variety of sizes
including
3, 4, 5, 6, 7,
10 and 16 pan.
Available in
two sizes
based on
your needs
BWG-12K
Water Filter

Page 6
STEAM KETTLES
Countertop or floor model, self-contained or direct steam,
Blodgett steam kettles are perfect for any application. With kettles
from 6 to 100 gallons, Blodgett is sure to have a solution for you.
STANDARD FEATURES & BENEFITS
COUNTERTOP, TRI-LEG, PEDESTAL, CABINET BASE
+
+
+
+
Up to 50 PSI for quick
recovery, greater menu
flexibility and increased
production
Highly polished interior
resists food deposits for easy
cleaning
Safe, smooth easy tilt
mechanisms
2” tangent draw off standard
on all stationary model
(optional on tilting models)
+
+
+
+
+
Easy to clean polished 304
stainless steel exterior
316 stainless steel kettle liner
for high acid content
product standard in 6 to 40
gallon models
2/3 jacketed with
hemispheric design for
optimum heat distribution
ASME code constructed
Simple, easy to operate
controls include temperature
dial, and kettle ready light
Electric self-contained kettle
available in
tri-leg or pedestal, tilting or stationary
Gas self-contained kettle
available in
tilting or stationary

Page 7
DIRECT STEAM KETTLES
+
+
+
Direct steam kettles are
available in a variety of sizes
for connection to an outside
steam source
Connects to Blodgett steam
boiler cabinets
Available in 6 to 100 gallon
models
Direct steam kettles
available in countertop,
tri-leg, pedestal base,
cabinet base and
tilting or stationary
Tilting countertop kettles
are available in
electric or direct steam
+
+
+
Tilt lock mechanism for all
countertop models
Countertop models available in 6,
10 and 12 gallon models
Perfect for mounting on a Blodgett
kettle stand or table
COUNTERTOP KETTLES
Full options package available to
customize your kettle including
spring assist covers, 316 stainless
steel liner for 60, 80 & 100 gallon
models, faucets, 3” draw offs and
much, much more.
TILTING OR STATIONARY

Page 8
BRAISING PANS
STANDARD FEATURES & BENEFITS
+
+
+
+
Robust 304 stainless steel
construction for long life
Unique finned heat
distribution on gas units for
even heating
Multiple tilt mechanisms to
choose from, one is sure to
fit your application
Coved corners for easy
cleaning
With four different tilting mechanisms to choose from, Blodgett
offers the most diverse line in the industry. Choose from tabletop
or floor model, manual, gearbox, power or hydraulic tilt.
+
+
+
+
+
Electronic ignition
standard on all gas
models
Pour strainer standard
Simple, easy to use
controls
High temperature
safety cut-off standard
on all models
Heat proof knob on
countertop models
Electric 12 gallon
countertop model
Electric or Gas 16 gallon
round countertop model
(shown with optional stand & faucet)
Optional stands available
with either sliding shelf or
sliding drawer and drain
connection.
The countertop braising
pans also mount to the
Blodgett kettle table for a
truly customized
workspace.

Page 9
MANUAL, GEARBOX, POWER, & HYDRAULIC TILT
Blodgett braising pans offer
four great tilting
mechanisms to
choose from.
EXCLUSIVE
Manual Gearbox tilt mechanism
for gas and electric braising pans
Manual Tilt Mechanism
Power Tilt Mechanism
Heavy Duty Hydraulic
Tilt Mechanism
MANUAL TILT
The Blodgett manual
tilt mechanism features
side trunnion pivots for
easy tilting.
POWER TILT
An electric
motor driven
tilting
mechanism
provides for
easy
automated
tilting.
HYDRAULIC TILT
The Blodgett
heavy duty
hydraulic lift
system is powered
by a ½ HP motor.
The hydraulic tilt
mechanism is
available in cabinet
base only.
EXCLUSIVE MANUAL GEARBOX TILT
This permanently lubricated,
self-contained gearbox tilt mechanism
offers an easy to tilt braising pan with
water resistant control in a smaller
footprint than most manual tilt models.

Page 10
SPECIFICATIONS
Model Pan Capacity Input Footprint (”)
ST-3E 3 7.5 kW 27.5d x 24w x 12.5h
ST-4E 4 10 kW 27.5d x 24w x 18.25h
ST-5E 5 15 kW 27.5d x 24w x 21.62h
ST-5G 5 45,000 BTU 32d x 24w x 40.38h
SC-7E 7 17.5 kW 24d x 33w x 63.75h
SC-10E 10 30 kW 24d x 33w x 73.5h
SC-7G 7 90,000 BTU 33d x 24w x 76.25h
SC-10G 10 90,000 BTU 33d x 24w x 76.13h
SC-5GH* 5 95,000 BTU 33.13d x 24w x 59.13h
SC-7GH* 7 140,000 BTU 33.13d x 24w x 67.00h
SC-10GH* 10 190,000 BTU 33.13d x 24w x 76.88h
SC-16GH* 16 190,000 BTU 33.13d x 36w x 70.38h
SC-6DS 6 direct steam 33d x 24w x 55.5h
SC-10DS 10 direct steam 33d x 24w x 68.5h
SB-6E 6 24 kW 33d x 24w x 55.5h
SB-10E 10 36 kW 33d x 24w x 68.5h
SB-6G 6 140,000 BTU 33d x 24w x 55.5h
SB-10G 10 200,000 BTU 33d x 24w x 68.5h
SB-6SC 6 steam coil 33d x 24w x 55.5h
SB-10SC 10 steam coil 33d x 24w x 55.5h
* High efficiency gas models
COUNTERTOP
CONVECTION STEAMERS
CABINET BASE
BOILER BASE
Model Input Footprint (”)
CB24-24E 24 Kw 33d x 24w x 28h
CB24-36E 36 Kw 33d x 24w x 28h
CB24-42E 42 Kw 33d x 24w x 28h
CB24-48E 48 Kw 33d x 24w x 28h
CB24-140G 140,000 BTU 33d x 24w x 28h
CB24-200G 200,000 BTU 33d x 24w x 28h
CB36-24E 24 Kw 33d x 36w x 28h
CB36-36E 36 Kw 33d x 36w x 28h
CB36-42E 42 Kw 33d x 36w x 28h
CB36-48E 48 Kw 33d x 36w x 28h
CB36-140G 140,000 BTU 33d x 36w x 28h
CB36-200G 200,000 BTU 33d x 36w x 28h
CB36-250G 250,000 BTU 33d x 36w x 28h
CB36-300G 300,000 BTU 33d x 36w x 28h
COUNTERTOP
STEAM BOILER CABINETS
24”CABINET
36” CABINET
BRAISING PANS
Model Gallons Input Footprint (”)
BTT-12E 12 9 kW 25.75d x 29w x 33.25h
BTT-16E 16 7.5 kW 29d x 29.25w x 38.75h
BTT-16G 16 30,000 BTU 29.88d x 29.25w x 40.75h
BLT-30E 30 18 kW 36.5d x 50.5w x 36.5h
BLT-40E 40 27 kW 36.5d x 66.5w x 36.5h
BLT-30G 30 80,000 BTU 40.25d x 49.5w x 37.25h
BLT-40G 40 100,000 BTU 40.25d x 58.5w x 37.25h
BLP-30E 30 12 kW 37d x 36w x 40.5h
BLP-40E 40 15 kW 37d x 48w x 40.5h
BLP-30G 30 80,000 BTU 37d x 36w x 42h
BLP-40G 40 100,000 BTU 37d x 48w x 43.5h
BLG-30E 30 15 kW 37d x 36w x 40.5h
BLG-40E 40 18 kW 37d x 48w x 40.5h
BLG-30G 30 100,000 BTU 37d x 36w x 42h
BLG-40G 40 120,000 BTU 37d x 48w x 43.5h
BCH-30E 30 12 kW 37d x 36w x 40.5h
BCH-40E 40 15 kW 37d x 48w x 40.5h
BCH-30G 30 80,000 BTU 37d x 36w x 42.5h
BCH-40G 40 100,000 BTU 37d x 48w x 44h
COUNTERTOP
MANUALTILT
GEARBOXTILTPOWER TILT
For complete information refer to product spec sheets.
HYDRAULICTILT

STEAM KETTLES
Model Gallons Input Footprint (”)
KTT-6E 6 7.5 kW 15.25d x 22.5w x 33.5h
KTT-10E 10 12 kW 17.25d x 26.25w x 34.88h
KTT-12E 12 12 kW 17.25 x 26.25w x 36.88h
KTG-6E 6 7.5 kW 15.25d x 25.125w x 25h
KTG-10E 10 12 kW 19.125d x 28.875w x 25.3h
KTG-12E 12 12 kW 19.125d x 28.875w x 27.5h
KTT-6DS 6 direct steam 15.1d x 15.75w x 19.5h
KTT-10DS 10 direct steam 19.1d x 15.75w x 18.5h
KTT-12DS 12 direct steam 19.1d x 15.75w x 20.5h
KTT-20E 20 12 kW 24.25d x 31w x 30.62h
KTT-20DS 20 direct steam 24.1d x 36w x 26.5h
KLT-12G 12 43,000 BTU 25.38d x 30w x 32.88
KLT-20E 20 12 kW 34d x 36w x 38h
KLT-30E 30 15 kW 36d x 39w x 38h
KLT-40E 40 18 kW 37.75 x 41w x 38h
KLT-60E 60 18 kW 23.75d x 44.5w x 38h
KLT-80E 80 18 kW 44d x 48w x 42h
KLT-100E 100 24 kW 45.5d x 49.5w x 48.75h
KLT-20G 20 80,000 BTU 40.63d x 41.13w x 40.13h
KLT-40G 40 100,000 BTU 43.63d x 55.25w x 43.25h
KLT-60G 60 120,000 BTU 45.63d x 59w x 43.88h
KLT-20DS 20 direct steam 33.25d x 23.75w x 38h
KLT-30DS 30 direct steam 36d x 27.75w x 38h
KLT-40DS 40 direct steam 38d x 29.75w x 38h
KLT-60DS 60 direct steam 37d x 33.75w x 42h
KLT-80DS 80 direct steam 40d x 36.75w x 45h
KLT-100DS 100 direct steam 23.5d x 40w x 48h
KLS-20E 20 12 kW 33.25d x 23.75w x 38h
KLS-30E 30 15 kW 36d x 27.75w x 38h
KLS-40E 40 18 kW 38d x 29.75w x 38h
KLS-60E 60 18 kW 37d x 33.75w x 42h
KLS-80E 80 18 kW 40d x 36.75w x 45h
KLS-100E 100 24 kW 43.5d x 40w x 48h
KLS-20G 20 100,000 BTU 32d x 31.25w x 40h
KLS-40G 40 100,000 BTU 38.5d x 35.5w x 44h
KLS-60G 60 130,000 BTU 42d x 40w x 49.5h
KLS-80G 80 130,000 BTU 54.25 x 41.625w x 49.25h
KLS-100G 100 130,000 BTU 54.25 x 41.625w x 49.25h
KLS-20DS 20 direct steam 33.25d x 23.75w x 38h
KLS-30DS 30 direct steam 36d x 27.75w x 38h
KLS-40DS 40 direct steam 38d x 29.75w x 38h
KLS-60DS 60 direct steam 37d x 33.75w x 42h
KLS-80DS 80 direct steam 40d x 36.75w x 45h
KLS-210S 100 direct steam 43.5d x 40w x 48h
COUNTERTOP
FLOOR MODEL
Model Gallons Input Footprint (”)
KPS-20E 20 12 kW 33.25d x 23.75w x 38H
KPS-30E 30 15 kW 36d x 27.75w x 38h
KPS-40E 40 18 kW 38d x 29.75w x 38h
KPS-60E 60 18 kW 37d x 33.75w x 42h
KPS-80E 80 18 kW 40d x 36.75w x 45h
KPS-100E 100 24 kW 43.5d x 40w x 48h
KPS-20DS 20 direct steam 18.75d x 22.75w x 37h
KPS-30DS 30 direct steam 31d x 25.88w x 37h
KPS-40DS 40 direct steam 32.75d x 27.88w x 37h
KPS-60DS 60 direct steam 33.25d x 31.38w x 40.5h
KPS-80DS 80 direct steam 37d x 34.75 x 42.5h
KPS-100DS 100 direct steam 37.75d x 37.25w x 44.5h
KPT-20DS 20 direct steam 21d x 34.75w x 37h
KPT-30DS 30 direct steam 24d x 37.75w x 37h
KPT-40DS 40 direct steam 26d x 39.75w x 37h
KPT-60DS 60 direct steam 29.5d x 43w x 40.5h
KPT-80DS 80 direct steam 33d x 46.5w x 42.5h
KCH-30DS 30 direct steam 39d x 36w x 37.25h
KCH-40DS 40 direct steam 40d x 36w x 38.38h
KCH-60DS 60 direct steam 43d x 42w x 41.12h
PEDESTAL STATIONARY
TRI-LEGTILTING
TRI-LEG STATIONARY
PEDESTALTILTING
HYDRAULIC TILT
Page 11

44 Lakeside Avenue Burlington, Vermont 05401 U.S.A. 800-331-5842•
www.blodgett.com
The best equipment
deserves the best
warranty. Before leaving
our factory, each piece of
equipment must pass
meticulous quality control
checks. But our
commitment to
excellence goes even
further. We stand behind
our steam equipment
with a full one year parts
and labor warranty*. In
addition we offer an
additional four year door
warranty as standard on
all convection steamers*.
*U.S. and Canada
FAST, RELIABLE
SUPPORT AND SERVICE
THE BEST WARRANTY
IN THE BUSINESS
When it comes to expert
support and service, you
can count on Blodgett’s
network of distributors for
a quick response. Our
highly trained service
professionals keep your
equipment operating by
providing replacement
parts and equipment
repair. You can rely on
prompt, high quality
service, especially in an
emergency when
dependability counts the
most.
Blodgett means superior service,
before and after the sale.
Convection, Deck, Conveyor, Combi,
Range, Steam...
Blodgett offers a full kitchen lineup
complete with Steam Kettles, Braising
Pans and Convection Steamers.
Blodgett has a solution for any
application.
CONVECTION STEAMERS • KETTLES • BRAISING PANS
