Blueair Cabin P2i User manual

1
Blueair Cabin P2i
Car Air Purifier User Manual
Araç İçi Hava Temizleyici Kullanım Kılavuzu

2

3
Before using your Blueair Cabin P2i car air purifier please refer to the User Manual.
Note:
There may be local variations of this model.
By using this product, you hereby signify that you have read this disclaimer carefully and that you understand and agree
to abide by the terms and conditions herein.
Blueair accepts no liability for damage, injury or any legal responsibility incurred directly or indirectly from the use of
this product. You agree that you will use this product in a proper and safe way which is in accordance with all applicable
laws, regulations, standards and all terms and guideline made by Blueair (including but not limited to those set out under
this User Manual). You agree that you are solely responsible for your own conduct while using this product, and for any
consequences thereof.
Please read this User Manual carefully to become familiar with the features of this product and the instructions for
assembly, set-up, placement and use of this product before operating. Failure to operate this product correctly or in a
safe manner as specified in this User Manual may result in damage to the product, personal property and cause injury.
This product is not intended for use by children without direct adult supervision. Please do not use this product with
incompatible components or alter this product in any way outside of the documents provided by Blueair.
Contents
General ........................................................................................................................................4
Safety instructions.......................................................................................................................5
Blueair Cabin P2i car air purifier.................................................................................................8
Filters ...........................................................................................................................................9
Getting started........................................................................................................................... 10
Functionality.............................................................................................................................. 13
Care and maintenance.............................................................................................................. 18
EN

4
General
Blueair Cabin P2i car air purifier
The car air purifier is designed for use in cars, and
purifies the air while the car is in use.
Blueair´s HEPASilent™ advanced filtration
technology enables the car air purifier to remove
harmful pollutants (i.e. VOCs such as
Formaldehyde), particles and odors.
The car air purifier monitors the particle level in
your car, displays the current air quality on your
smartphone and provides app control.
When Auto mode is active, the fan is automatically
adjusted based on the readings from the built-in
laser particle sensor, thus achieving optimal air
purification.
A control knob (also 12V power) enables the driver
to either change the fan speeds (3 speed options)
or activate the Clean Cycle program. A USB
charging port on the control knob is available for
use by the driver or front seat passenger.
A 4,5 m cable connects the control knob to the
main unit so that it can be installed behind a
backseat headrest.
This product is equipped with an easily accessible
USB charging port so that back seat passengers
can charge another device while the cabin air is
cleaned.

The car air purifier is an electrical appliance. Read these safety instructions
carefully before use and take the necessary precautions to reduce the risk of fire,
electric shock or injury.
The car air purifier warranty applies only if the product is installed, used and
maintained according to these instructions.
Please do not adjust the settings , or look at the display of the car air purifier whilst
driving.
Please do not look at your mobile phone whilst driving. You must comply with all
applicable safe driving laws and behaviors, including those addressing the use of
mobile devices.
General
Safety instructions
DISCLAIMER:
Ensure that the car air purifier is installed according to the instructions in this user
manual. For your safety use only the items supplied in the box.
Whilst operating the device, the driver must be aware of, and take into consideration
the prevailing trac conditions. Blueair declines all responsibility for personal harm or
injury whilst using the product if the installation has not been carried out correctly or if
the product is used incorrectly.
WARNING: Indicates a hazardous situation that, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a hazardous situation that, if not avoided, could result in
minor or moderate injury.
5
Hereby, Blueair AB, declares that the radio equipment type P2i is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: www.blueair.com/customer-support

To avoid a hazard, a supply cable must always be replaced (because of damage,
malfunction or any other reason) by the manufacturer, service agent or similarly
qualified person.
Do not spill any liquids such as water, detergents or flammable solvents on the
device. Do not use the device if any liquids have spilled on it. If there is a spill, wipe
the exterior of the unit with a soft, clean, damp cloth.
Use only the mounting strap included in the box and ensure that the unit is
securely fastened as specified. Blueair disclaims all liability for any harm or accident
caused by improper installation, usage, disassembly and maintenance by any user
or third party.
To avoid injury it is important not to install any unit in front of, or near the safety
airbag which is normally located in the dashboard in front of the front passenger
seat.
WARNINGS:
Note: The mounting strap shall not be removed from the unit.
Note:
The product can also be installed in a boat, truck or RV/motorhome 12V power
outlet. Ensure that the unit is securely fastened.
CAUTIONS:
Only use the power cable provided with your car air purifier to plug directly into an
appropriate 12V power outlet in a car.
The car air purifier is designed for connecting to a 12V power outlet in a car that
automatically turns on or o when the ignition is turned on or o. Therefore we
highly recommend using an ignition-controlled 12V power outlet in the car to avoid
the risk of draining the battery.
6

Do not alter the plug in any way.
Do not use the unit if the power cable or plug is damaged or malfunctions in any
manner.
Keep the power cable away from heated surfaces.
No foreign objects should enter the unit as this may cause an electric shock or
damage.
To prevent damage to the unit do not block the air outlets, air inlets or air ducts.
Install the unit in a position where air can fully circulate around it - do not cover
the unit.
The device contains high precision technology. Dropping or striking the device
may cause damage.
Install the unit in the appropriate position inside the vehicle by using
accompanying accessories and according to the instructions in the user manual.
Do not remove or replace the mounting strap that is delivered with the units.
Intended use
CAUTIONS:
This appliance is not intended for use by persons with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
To avoid electric shock or damage, keep the product out of the reach of children
since it is not a toy.
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
7

Contents of box
Product Overview
Blueair Cabin P2i car air purifier
1. Open and unpack the box
2. Read the User Manual
Please refer to www.blueair.com for more
information.
13
245
IMPORTANT
1. Purifier unit
2. Mounting strap
3. Particle+Carbon filter
4. Control knob with a 4,5m power cable
5. User information
1. Top cover
2. Folded Particle+Carbon
filter
3. Unfolded Particle
+Carbon filter
4. Purifier unit base
5. Top cover release lock
6. USB charging port
7. Main unit base (top view)
8. Filter reset button
9. Control knob
10. USB charging port
11. Power cable
12. Back view
13. Mounting strap
14. Cable plug area
15. Power supply port (12 V)
16. Air inlets
17. Air outlets
IMPORTANT!
Please note that the Particle+Carbon filter is not
mounted inside the unit when purchased. The filter is
a separate item inside the box and MUST be installed
before use.
3
9
10
12
11
13
14
1
17
2
16
15
64
5
FILTER RESET
7
8
8

Filters
IMPORTANT!
Use only genuine Blueair filters to ensure proper function of your unit and to qualify for full
warranty coverage.
IMPORTANT!
Please note that the Particle+Carbon filter is not mounted inside the unit when purchased. The
filter is a separate item inside the box and MUST be installed before use.
Blueair filter subscription program
This convenient service is available in some countries – contact your local Blueair retailer or check the
Blueair website to find out if you can join.
Model number
Serial number
Retailer’s name
Retailer’s address
Date of purchase Telephone number
Filter checklist
To make it easy to find the right filter in the future, please fill in the customer record below and keep
this user manual for reference. The model number and serial number of this product can be found
on the rating label on the bottom of the unit.
One Blueair Particle+Carbon filter is delivered with the car air purifier.This filter removes the following
airborne pollutants from the car:
PM 2.5 DustPollen Pet
Dander Tire wearFormaldehyde Benzene
9

10
Getting started
1. Remove the top cover
1. Place the purifier unit
on a flat surface or car
seat and release the top
cover by pressing the left
and right release locks IN
and UP as shown.
2. Lift o the top cover.
3. Turn top cover
upside down and place
next to the purifier unit
base.
2. Install the filter
1. Remove the plastic
bag from around the
filter and pull the two
sides of the filter apart
to form a square.
2. Mount the unfolded
filter onto the purifier
base unit.
3. Remount the top
cover onto the purifier
base unit
1
IN
UP
Note:
There is no need to press the filter reset button
for initial filter installation.
3. Connect cable to unit
DC 12V
IN
1Before installing the
unit into the car,
connect the power
cable to the power
supply port on the back
of the unit.

11
4. Attach the mounting strap
6. Connect control knob and 12 V power supply
Connect the control
knob with power supply
into the 12 V power
supply port located near
the driver.
7. Cable management
Route the cable under
carpets or other plastic
details between the
control knob and the
unit. To avoid cable
damage when adjusting
car seats, do not route
the cable too close to
the seat tracks. Coil any
cable excess and fasten
with the supplied cable
tie.
Thread the mounting
strap through the unit
as shown. Velcro side
faces unit.
POWERIN
POWEROUT
5a. Choose mounting location
Note: If placed behind a headrest, the strap should
be attached around the supporting rods (or at the
bottom of the headrest), not in the middle of the
headrest.
Placement options
Front/rear headrests, center console
If length adjustments are needed, adjust strap
length on the buckle side (2) of the strap.
5b. Fasten strap to firmly secure unit
Thread the velcro side
(1) through the buckle
and close the strap.
2
1Make sure the full length
of velcro is engaged
when closing the strap.
Caution:
Attach the unit behind a headrest or on
top of the center console.

12
8. Connect the car air purifier to your smartphone
To control the product remotely and view the air quality in real time, connect the product to your
smartphone using Bluetooth.
2. Install the car air
purifier. Refer to section
“4. Place and install the
unit”.
Note:
For complete information about technical requirements on your phone, please refer to the Blueair
app store description. For detailed instructions about Bluetooth pairing, please visit the support
section on blueair.com. Also, step-by-step pairing instructions are shown on the app screen.
4. Turn on the unit -
(a blue LED lights up
on the top cover
indicating the unit is
powered-up).
3. Turn on the car´s
ignition.
1. Download the Blueair
app to your
smartphone from your
relevant app store.
Register an account
and log in.
After connecting successfully you can remotely
control the unit and track air quality in real time.
To stay up-to-date with latest improvements, the
product firmware can be upgraded over the air.
The Blueair app will alert you when a new firmware
update is available for download. After the
firmware update has been accepted in the app,
the control knob will indicate the ongoing update
with a green light. Keep the unit powered up and
connected to Bluetooth and Internet until the
firmware update is completed. The unit will restart
once the firmware update is complete.
5. Follow the on screen
instructions to pair your
product using Bluetooth.
Note:
Do not turn o the unit
during OTA. The unit
automatically restarts
and continues with the
latest fan setting.
9. OTA (Over-the-air updates)

13
The car air purifier unit is controlled by pressing down the control knob to adjust the fan setting.
Functionality
1. General
Notes:
1. In order for the unit to clean the air optimally, please ensure that the car´s recirculation mode is
active and any window or sunroof is closed.
2. When the unit is powered o and then powered-up again, the fan speed is activated at the same
speed as the last used setting.
3. The cleaning time depends on the cabin volume of the cars in question.
2. The control knob - overview
The control knob is
mounted into the 12V
power supply port, e.g.
on the dashboard of the
car.
The other end of the
cable is inserted into
the power supply port
located on the main
unit.
A USB port on the
control knob enables
the driver or front seat
passenger to connect
and charge another
device (e.g.mobile
phone).
DC 12V
IN
1
Low fan speed
Medium fan speed
High fan speed
Clean Cycle mode
Back to low fan speed
etc.
Unit power on/idle
mode
Particle level inside
the car
Filter change alert
Fan speed setting
Notifications (see
section
“Notifications”)
Press the control knob
once and toggle
through the fan speeds
(see section “Adjusting
fan speed”). The
control knob display is
only illuminated when
the fan is active
The control knob can
also display:
2a. Navigation
2b. Information

14
When the unit is turned
on, the start up
sequence begins and
the fan is activated at
the same speed as the
last used setting.
After start up the air
quality is analysed and
displayed on the control
knob after 9 seconds.
After 3 blinks the
control knob displays
the current air quality
(see “Air Quality
Indication”).
3. Turn on
3b.
3a.
To turn the unit on
flick right or left once.
4. Adjusting the fan speed
By flicking the control knob to the right, the fan
speed sequence goes around in a loop from Low
to Medium to High to Auto mode to Low again etc.
Note:
The unit must be
connected to the
power supply port
and powered up (i.e.
the car´s ignition is
on.)
1 2 3 4
LED behaviour for each fan speed:
Low speed (1) = 1 white LED blinks 3 times
Medium speed (2) = 2 white LEDs blink 3 times
High speed (3) = 3 white LEDs blink 3 times
Auto mode (4) = 6 white LEDs blink 3 times

15
Note:
The cleaning time depends on the cabin
volume of the cars in question.
Cabin performance
Car size cleaning time
5–6
minutes
8–11
minutes
SUV
Sedan
Minivan
Hatchback
P2i
3–4
minutes
5–6
minutes
P1 + P1D
5. Air Quality Indication (AQI)
The air quality of
particles (PM2.5) is
indicated by color on
the control knob.
Detailed real time data
is presented in the
Blueair app.
When Auto mode is
active, the fan is
automatically adjusted
based on the readings
from the built-in laser
particle sensor.
6. Auto mode
HIGH
MED
LOW
AUTO MODE
= Sensor particle reading
= Fan speed
Moderate
Action vital
Highly Polluted
Action recommended
Good
Polluted
Excellent
Slightly Polluted

16
x 3 sec Flick the control knob
counterclockwise and
hold for 3 seconds until
the lights are turned o.
8. Notifications
7. Idle mode
3 red LEDs blink in a
triangle formation
should a notification or
error occur (see table
below).
SITUATION RECOMMENDED ACTION
Unit is not working - unit is disconnected from
the control plug.
Check that control knob is correctly installed
and that the cable/connector is not damaged.
Unit is not working - USB charging port overload.
If the USB charging port is powering a device that
draws too much power, the system may shut
down.
Remove external device from USB charging
port.
General hardware failure Contact customer service
Other error not indicated by error code. The
LEDs on the control knob do not light up even
though the unit is functioning.
Contact customer service

17
5. Remount the top
cover onto the main
base unit
9. Changing the filter
A filter change alert is
displayed on the
control knob when a
filter change is due.
1. Lift o the top cover
and mount the new
filter onto the purifier
base unit.
3. Turn on the unit -
(a blue LED lights up
indicating the unit is
powered-up).
2. Turn on the car´s
ignition.
4. Press the filter reset
button.
FILTER RESET
Note:
The recommendation of approximately 6
months/180 days between filter changes is
based on a usage of 360 hrs during that period
(2,5hr * 6 days * 4 weeks * 6 months).

18
Environment protection:
Let’s protect the environment!
Our products and packaging are sustainably designed and made from recyclable materials. Do not
discard the filter or the product with household waste. Bring it to the nearest ocial waste recycling
service.
Help and support
If you have questions about Blueair products, please visit www.blueair.com.
Warranty information
The Blueair Limited Warranty applies only if the unit is installed, used, and maintained according to
the instructions in this manual.
Care and maintenance
We recommend regular cleaning in order to keep your unit in top condition.
When changing filters
1. Wipe the underside of the top cover clean after removal.
2. Vacuum the air outlets using a soft brush and/or other suitable attachment.
3. Vacuum the small air inlets with a soft brush attachment.
General
1. Wipe the exterior of the unit with a soft, clean, damp cloth.
2. Never clean with gasoline, chemical solvents or corrosive material as these agents may
damage the surface.
3. Do not allow foreign objects to enter the ventilation or exhaust openings. This may
cause electric shock or damage the unit.
4. Do not try to repair or adjust any of the electrical or mechanical functions on your
Blueair unit yourself. Contact your local dealer or Blueair for warranty information.

19

20
