BlueSpot 02005 User manual

1/2" TORQUE WRENCH &
3/8" TORQUE WRENCH
User Manual
02005 / 02007

01
Thank you for purchasing a BlueSpot product, you can find further information
on our range at www.bluespot.uk.com. Please ensure that you are using the
product correctly and that all guidance and cautions are followed in accordance
with the instructions. Please retain these instructions for future reference.
General Information
Please make sure that you read these instructions carefully in order to avoid injury when
using the tool. Follow all health and safety rules and regulations. If in doubt and available
please contact a more knowledgeable source.
DO NOT use if damaged.
• If tool is damaged do not use as this may cause damage to property or injury
• As with all vehicle testing and maintenance please use appropriate fixing such as
axel stands or wheel chocks
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear
non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• Always dress appropriately and wear the correct PPE such as goggles and a dust
mask if required
Always store the torque wrench in the lowest torque setting
Refer to vehicle manual and contact manufacturer if unsure.These instructions are
intended as a guide only.
Safe use
Stock code: 02005
Drive: 1/2”
Length: 470mm
Range: 42-210NM
Stock code: 02007
Drive: 3/8”
Length: 370mm
Range: 19-110NM
Introduction and Specication
Stock code: 02005
Drive: 1/2”
Length: 470mm
Range: 40-210NM
Introduction and Specication

g. 1
g. 2
02
Stock code: 02007
Drive: 3/8”
Length: 370mm
Range: 19-110NM
1. Hold the wrench in a comfortable position so
that the scale is visible
2. Loosen the knurled locking screw at the end of
the handle by turning it anti-clockwise
3. Adjust the wrench to the desired setting by
twisting the handle clockwise to the desired
torque level.
Example: 76 Nm.
4. Turn the grip of the wrench until the top edge is
in line with the marked scale on the wrench shaft.
5. The edge of the grip should be even with the 70
Nm graduation. (fig.1)
6. Turn the grip of the wrench so that the 6 on the
scale of the grip is lined up with the marking on
the wrench shaft (fig.2)
7. This wrench is now set to 76NM and can be used.
8. Turn the knurled locking screw at the base of the
handle to lock the wrench
9. Once you begin tightening the fixing you are
working on you will hear and feel the wrench
click once the desired torque is met.
NOTE: Once the fixing is torqued to the desired load do not overload the wrench after the
clicks otherwise this can damage the wrench.
Remember to store the torque wrench at its lowest setting by turning the handle
anti-clockwise this will stop the spring from being overstretched and the wrench becoming
inaccurate.
It is advisable to store the wrench in the case that it comes in along with the instructions
and the calibration certificate should you require them at a later date.
If you are using the wrench for the first time after a long period of inactivity it is advisable
to operate it on a low setting multiple times in order to coat the internal parts with grease.
How to use
Clean the wrench only by using a clean and dry cloth and do not immerse the wrench into
any cleaning liquid as this will damage the function of the tool.
Further Care Instructions

5 0.69 6.78 10 7.38 1.02 1 9.81 7.23
10 1.38 13.56 20 14.75 2.04 2 19.61 14.47
15 2.07 20.34 30 22.13 3.06 3 29.42 21.70
20 2.76 27.12 40 29.50 4.08 4 39.23 28.93
25 3.46 33.90 50 36.88 5.10 5 49.04 36.17
30 4.15 40.68 60 44.26 6.12 6 58.84 43.40
35 4.84 47.46 70 51.63 7.14 7 68.65 47.87
40 5.53 54.24 80 59.01 8.16 8 78.46 50.63
45 6.22 61.02 90 66.38 9.18 9 88.26 65.10
50 6.91 67.80 100 73.80 10.20 10 98.07 72.33
55 7.60 74.58 110 81.14 11.22 11 107.88 79.57
60 8.29 81.36 120 88.51 12.24 12 117.68 86.80
65 8.98 88.14 130 95.89 13.26 13 127.49 94.03
70 9.67 94.92 140 103.26 14.28 14 137.30 101.27
75 10.37 101.70 150 110.64 15.30 15 147.11 108.50
80 11.06 108.48 160 118.02 16.32 16 156.91 115.74
85 11.75 115.26 170 125.39 17.34 17 166.72 122.97
90 12.44 122.04 180 132.77 18.36 18 176.53 130.20
95 13.13 128.82 190 140.14 19.38 19 186.33 137.43
100 13.82 135.60 200 147.52 20.40 20 196.14 144.67
105 14.51 142.38 210 154.90 21.42 21 205.95 151.90
110 15.20 149.16 220 162.27 22.44 22 215.75 159.13
115 15.89 155.94 230 169.65 23.46 23 225.37 166.37
120 16.58 162.72 240 177.02 24.48 24 235.37 173.60
125 17.28 169.50 250 184.40 25.50 25 245.18 180.84
130 17.97 176.28 260 191.78 26.52 26 254.98 188.08
135 18.66 183.06 270 199.15 27.54 27 264.79 195.30
140 19.35 189.84 280 206.53 28.56 28 274.60 202.54
145 20.04 196.62 290 213.91 29.58 29 284.41 209.77
150 20.73 203.40 300 221.29 30.60 30 294.22 217.00
155 21.42 210.18 310 228.67 31.62 31 304.03 224.23
160 22.11 216.96 320 236.05 32.64 32 313.84 231.46
165 22.80 223.74 330 243.43 33.66 33 323.65 238.69
170 23.49 230.52 340 250.81 34.68 34 333.46 245.92
175 24.19 237.70 350 258.30 35.70 35 343.35 253.05
180 24.88 244.08 360 265.68 36.72 36 353.16 260.28
185 25.57 250.86 370 273.06 37.74 37 362.97 267.51
190 26.26 257.64 380 280.44 38.76 38 372.78 274.74
195 26.95 264.42 390 287.82 39.78 39 382.59 281.97
200 27.64 271.20 400 295.20 40.80 40 392.40 289.20
205 28.33 277.98 410 302.58 41.82 41 402.21 296.43
210 29.02 284.76
215 29.71 291.54
220 30.40 289.32
225 31.09 305.10
230 31.78 311.88
235 32.47 318.66
240 33.16 325.44
245 33.85 332.22
250 34.54 339.00
260 35.88 352.56
270 37.26 366.12
280 38.64 379.68
290 40.02 393.24
300 41.40 406.80
Conversion Formulas
1 CMKG=13.887 IN-OZ 1 dNM=14.16 IN-OZ
1 CMKG=0.867 IN-LB 1 Nm=8.8507 IN-LB
1 MKG=7.233 FT-LB 1 Nm=0.73756 FT-LB
1 KPCM=1CMKG 1KPM=1MKG
1CMKG=0.98Nm 1MKG=9.80665 Nm
